Revi installation guide

REVI INSTALLATION GUIDE | 2 amqsolutions.com
Pedestal
Components.............................3
Castors.................................4
Expandable Bag Drops ....................5
Magnetic Seat Cushion ....................6
Undermount
Components.............................7
Assembly ...............................8
Shelf ..................................10
Laptop Divider ..........................11
Bag Hook ..............................14
File Pocket .............................16
CONTENTS

REVI INSTALLATION GUIDE | 3 amqsolutions.com
Main Housing Castor
x2
Expandable Bag
Drop Castors
x2
Slide
x2
M4*5
x8
M5*6
x16
Expandable Bag Drop
(1 set)
Castor with Brake
x2
PEDESTAL COMPONENTS
OPTIONAL COMPONENTS
EXPANDABLE BAG DROP
Magnetic Seat Cushion
MAGNETIC SEAT CUSHION

REVI INSTALLATION GUIDE | 4 amqsolutions.com
Step 1
Gently place the pedestal upside down, making
sure to rest it on a soft surface. Screw on the
castors using an adjustable wrench.
Note: Assemble the castors with brakes at the
front of the pedestal, and assemble the castors
without brakes at the rear of pedestal.
Tighten screws.
Step 2
Turn your pedestal right side up and your Revi is complete.
INSTALLING CASTORS
Front

REVI INSTALLATION GUIDE | 5 amqsolutions.com
EXPANDABLE BAG DROP
M4*5(x8) M5*6(x8)
M5*6(x8)
Step 1
Extend slides and use M4*5 screw to mount
them on the expandable bag drops.
Step 3
Screw the castors to the castor mounting
plate on each bag drop.
Step 2
Attach the expandable bag drops onto the Undermount
as shown on the diagram below. Secure with screws.
Note: Do not yet fully tighten screws.
Step 4
Gently rest the pedestal on its back on a soft
surface. This will help level the expandable bag
drop panels with the main housing.
Step 5
Fully tighten the screws.
5
4

REVI INSTALLATION GUIDE | 6 amqsolutions.com
MAGNETIC SEAT CUSHION
Step 1
Place magnetic seat cushion on assembled Revi.
Magnets will hold in place.

REVI INSTALLATION GUIDE | 7 amqsolutions.com
Undermount Body TP1/W 5*16
x6
Bag Hook
x1
Laptop Divider + Short Shelf
x1
File Pocket
x1
Shelf
x1
UNDERMOUNT COMPONENTS
OPTIONAL COMPONENTS

REVI INSTALLATION GUIDE | 8 amqsolutions.com
ASSEMBLING REVI UNDERMOUNT TO DESK
Step 1
Turn desk and Revi Undermount upside down to prepare for assembly.
Align Revi Undermount with front edge of worksurface, avoiding any under
worksurface obstacles.
Note: The minimum required distance
from the cantilever on AMQ products
is the followiing:
• ACTIV C-leg: align with cantilever
• ACTIV T-leg: 2” from cantilever
• KINEX 30”D: align with cantilever
• KINEX 24”D: 1.6” from cantilever
Step 2
Use the 6 screws (TP1/W5*16) to mount
the Revi Undermount onto worksurface.
Note: To assemble Revi Undermount
on a desk, the minimum worksurface
thickness required is 0.75”.

REVI INSTALLATION GUIDE | 9 amqsolutions.com
ASSEMBLING REVI UNDERMOUNT ON DESK
Step 3
Turn the desk upright and your installation is complete.

REVI INSTALLATION GUIDE | 10 amqsolutions.com
SHELF
Step 1
Open the door, rotate the shelf and place it inside the Undermount.
Step 2
Adjust the shelf and insert the tabs on the shelf
into the slots on Undermount.
Step 3
Press the shelf firmly to confirm
it is attached securely.
BACK

REVI INSTALLATION GUIDE | 11 amqsolutions.com
LAPTOP DIVIDER (RIGHT SIDE)
Step 1
Open the door, rotate the laptop divider and place it inside the Undermount body,
making sure the L-shaped edge faces the door hinge.
Step 2
Rotate the laptop divider so it’s perpendicular to the bottom of the Undermount and the
magnets on the L-shaped edge adhere to the bottom. Move the laptop divider to the right
until it touches the right side bracket at the top.
1
2

REVI INSTALLATION GUIDE | 12 amqsolutions.com
LAPTOP DIVIDER (RIGHT SIDE), CONTINUED
Step 3
Open the door, rotate the short shelf and place it inside the Undermount. Rotate the short shelf until it
is parallel to bottom. Adjust the short shelf, and insert the tabs on the sides into the slots on left side of
Undermount and laptop divider. Press the short shelf to confirm it is firmly in place.
BACK
Step 4
The laptop divider and short shelf are now installed inside the Undermount.

REVI INSTALLATION GUIDE | 13 amqsolutions.com
LAPTOP DIVIDER (LEFT SIDE)
Step 1
Refer to laptop divider (right side) for detailed installation instructions, pages 11-12.
! Note: When assembling the laptop divider and short shelf, it can only be installed as shown in figure
1, not in figure 2. If installed like figure 2, the remaining opening on the door side of the laptop divider
will be non-functional.
LAPTOP DIVIDER
NOTE: Laptop divider and short shelf can be installed either on the left or on the right on Revi Undermount
without door.
12

REVI INSTALLATION GUIDE | 14 amqsolutions.com
BAG HOOK
The bag hook may be installed on the left
or right side of the Undermount, as shown.
Installation on either side is the same.
Step 1
Rotate the bag book to 70° of the Undermount body and insert it into slot as shown below.
The bag hook may be installed on the left or right side.
Step 2
Slide in the side hook (A) and rotate until it hangs flush along the Undermount body (B).
A B

REVI INSTALLATION GUIDE | 15 amqsolutions.com
FILE POCKET
File pocket may be installed on the left and /or right side of Undermount body and/or on the laptop divider
over the short shelf. The same instructions apply to any installation position.
Step 1
Rotate file pocket so the hook on top goes through the slot as shown.

REVI INSTALLATION GUIDE | 16 amqsolutions.com
FILE POCKET
Step 2
Rotate the file pocket further until it hangs onto the Undermount.
Step 3
Make sure the hook on file pocket fits snugly, positioned flush on the Undermount.

Please contact [email protected] if you are
missing any parts, have difficulty with assembly,
or have any product related questions.
