Lightolier Lytecaster 1076 User manual

1076
Lytecaster, 5" Aperture, Basic Baffle Reflector Trim
Page 1 of 2
Catalog number:
Notes: Type:
1076/1002P1 Series
Standard Incandescent
1076/1003R
0™
Non-IC Remodeler
1076/1004IC/N
0™
Convertible IC/Non-IC
6 ¾"
7 ½"
6 ⅛"
4 ¾"
6 ¾"
Complete Fixture consists of Reflector Trim & Frame-In Kit. Select each separately. See Individual Frame-In Kit specification sheets for more information.
Reflector Trim LED Frame-In Kit Fluorescent Frame-In Kit
1076
Matte Black
1076WH
Gloss White
Frame-In Kit Installation Type Lamping Height Frame-In Kit Installation Type Lamping Height
1001LED
1001LEDEM
1001LEDREM
L56LED
Non-IC
Non-IC EM
Non-IC Remodeler
Non-IC Retrofit
LED
LED
LED
LED
6 3/4""
6 3/4"
6 3/4"
6 3/4"
1001F13U Series UniFrame™Non-IC (1) Triple 13W
(GX24q-1)
5 7/8"
Incandescent Frame-In Kit 1001F18U Series UniFrame™Non-IC (1) Triple 18W
(GX24q-2) 5 7/8"
Frame-In Kit Installation Type Lamping Height 1004F13 Series IC (1) Quad/Triple
13W (GX24q-2)
7 1/2"
1000P1
1002P1
Non-IC 60W A19
75W PAR30*
75W BR30
6 3/4" 1004F18** Series IC (1) Quad/Triple
18W (GX24q-2)
7 1/2"
1003R Non-IC
Remodeler
60W A19
75W PAR30*
85W BR30
6 3/4" 1004F26** Series IC (1) Quad/Triple
26W (GX24q-2)
7 1/2"
1000IC
1000AICM
IC
IC AirSeal®
40W A19
65W BR30
75W PAR30
7 5/16"
7 5/16"
1001F13ICU/N Performance IC (1) Triple 13W
(GX24q-1)
7 1/4"
1004ICX/N IC AirSeal®40W A19
75W PAR30*
65W BR30
7 1/4" 1001F18ICU/N Performance IC (1) Triple 18W
(GX24q-2)
7 1/4"
1004IC/N
1004ICR
IC
IC Remodeler
50W PAR30
60W BR30
7 1/2"
7 1/2"
*(Use Socket Extender with Short Neck)
**Lightolier recommends the use of triple tube lamps
1004IC/N
1004ICR
Non-IC
Non-IC Remodeler
65W BR30
75W PAR30
40W A19
7 1/2"
7 1/2"
1004SIC/N
1004SICR
IC
IC Remodeler
50W PAR30*
60W BR30
5 1/2"
5 1/2"
1004SIC/N
1004SICR
Non-IC
Non-IC Remodeler
75W PAR30*
75W BR30
5 1/2"
5 1/2"

1076
Lytecaster, 5" Aperture, Basic Baffle Reflector Trim
Page 2 of 2
Philips Lightolier
e: [email protected]
t: [phone]
w: www.lightolier.com
1076 October 15, 2012
Specifications are subject to change without notice.
© Koninklijke Philips Electronics N.V., 2010.All rights reserved.
Features
1. Reflector: Hydroformed aluminum, .040” thick (18 ga.): non-yellowing,
scratch resistant Perma White finish, 88% reflectance; white trim flange.
2. Step Baffle: Molded high heat plastic with stepped conical surface for low
brightness, matte black or gloss white finish.
3. Frame-In Kit: (1002P1 standard frame shown). Other frames listed above
and shown on the right. See Frame-In Kit specification sheets for more details.
Options & Accessories
Medium-Base PAR30 Socket Extender:
1968 - For use w/short neck PAR30 lamps in P1 and Lytening housings.
Labels
UL (Suitable for Damp Locations), I.B.E.W.
Use quick calculator chart to determine the spacing of 75 Watt PAR30
FL units (Black) for a desired level of illumination. Conversion Factors:
75WPAR30 FL,White, F.C. x 1.1.
Conversion Factor: 75W PAR30 FL;White, C.U. x 1.1 65W BR30
FL; Black, C.U. x .75;White, C.U. x 1.0.
To convert lighting data for a lower wattage incandescent lamp of the same
type, multiply the footcandle (or candlepower) values by the ratio of the
lumens of the two lamps.The coefficients of utilization remain the same.
