Lighting Systems LSB-10
1BHFPG -ZUFTQSFBEÜ-4#1BSBCPMJD-PVWFS-JHIU51FS'PPU/PNJOBM4FDUJPO
#
Features
1. Housing: Extruded aluminum. Die-cast end cap mechanically attached with
no exposed fasteners or hardware.
2. Lamping: Two T5, 28 or 54 watt (as specified) fluorescent lamps per 4-foot
nominal section. Provided by others.
3. Reflector: Precision die-formed semi-specular aluminum.
4. Louver: Parabolic louver, low-iridescent semi-specular anodized aluminum,
41° shielding lengthwise, blades are 1-1/3” (3.39cm) high and 2” (5.08cm) O.C.
Louver frame is extruded aluminumand finished to match housing.
Electrical
Ballast is <10% THD, .98 ballast factor, pre-heat start. 18 gauge wire. Color-
coded quick connectors allow ease of connection for joiner modules. Power feed
is 18 gauge white SJT. For special circuiting consult factory. Factory installed
ballast disconnect allows the ballast to be disconnected fromand reconnected to
incoming power under load without turning the entire circuit off.
Dimming: 120/277 VAC 1% dimming level, 4 wire feed required.
Emergency Battery Pack: 28 watt: 520 lumens @ 90 minutes, 54 watt: 700
lumens @ 90 minutes, 4 wire feed required.
Mountings
Finish
Powder coated baked white or aluminumfinish. Customcolors available, consult
factory.
Options and Accessories
Emergency Circuiting; special circuiting; X, T & L joiner blocks - consult factory.
Labels
UL, cUL and I.B.E.W.
Ordering Instructions
Individual Fixtures:
1. Order number of MODULES required.
2. Order one POWER FEED END SET per MODULE.
Continuous Rows:
1. Determine run length.
2. Order the appropriate number of MODULES for the complete run.
3. Order one POWER FEED END SET per run.
4. Order one CABLE ASSEMBLY per MODULE minus one per run.
5. For runs that exceed amperage limits, order the appropriate
number of CABLE/CORD ASSEMBLIES.
Cable suspension (not shown) - 4-1/2" (11.43cm) diameter canopy finished white
enamel, 1/16" (0.16cm) diameter stainless steel aircraft cable adjustable up to 36"
(91.44cm). Dual-screw draw-tight connector to create hairline seambetween joiner
modules.
Complete ordering instructions below.
Ordering Information
Family Lamps Voltage Finish
2= 2-Lamp T5 C= Parabolic Louver AL = Aluminum
WH = White
LSB 2 C
Length Shielding Ballast
1 = 120 volt
2 = 277 volt
28 = 28W T5
54 = 54W T5
5E = 54W T5 Emergency Pack
2E = 28W T5 Emergency Pack
5D = 54W T5 Dimming
4= 4-Foot
8= 8-Foot
Half Scale
8 1/2" (216 mm)
1 3/4" (37.5 mm)
12
3 1/4" (82.6 mm)
4
2 5/8" (66.7 mm)
3

Job Information Type:
"JSQPSU3PBE'BMM3JWFS."tt'BY
We reserve the right to change details of design, materials and finish.
XXXMJHIUPMJFSDPN½1IJMJQT(SPVQt #
Lighting Systems LSB-10
1BHFPG -ZUFTQSFBEÜ-4#1BSBCPMJD-PVWFS-JHIU51FS'PPU/PNJOBM4FDUJPO
Performance
CANDLEPOWER CURVE CANDLEPOWER
ZONE 0 22 45 67 90
DEG.
CANDELAS
180 749 749 749 749 749
175 748 746 752 752 755
165 717 729 755 781 784
155 661 695 757 837 861
145 574 641 762 897 940
135 457 563 744 947 1002
125 356 500 758 1011 1022
115 226 428 710 869 918
105 113 339 556 621 629
95 28 119 80 79 62
90 0 0 0 0 0
85 1 1 5 3 3
75 2 7 8 10 10
65 3 8 14 47 53
55 63 89 222 382 415
45 329 257 344 462 529
35 493 406 323 365 386
25 610 566 469 386 375
15 688 676 650 610 594
5 731 730 732 725 725
0 735 735 735 735 735
REPORT NO: LRL 300-1H
CAT NO: LSB24C28
LAMPS: 2 F28T5
LUMENS: 2900
EFFICIENCY: 83.3%
COEFFICIENTS OF UTILIZATION
% EFFECTIVE CEILING CAVITY
REFLECTANCE
80 70 50
WALL REFLECTANCE
70 50 30 70 50 30 50 30 10
0858585757575585858
1787472696764525049
2716662645956474442
3665953585348423936
4605246544742373431
5554741494237343027
6514236463833312724
7473731423429272321
8433428393125252118
9403125362823221916
10 37 28 22 34 25 21 21 17 14
20% FLOOR CAVITY REFLECTANCE
DISTRIBUTION
Zone Lumens % Lamp % Luminaire
0-90 1248 21.5 25.8
90-180 3587 61.8 74.2
0-180 4834 83.3 100.0
Calculations are for 28 watt T5 lamps, for 54 watt T5 lamps multiply by 1.7
Fixture Lengths & Mounting Locations
48"
(121.92cm)
4' 5-1/8"
(134.94cm)
96" (243.84cm)
8' 5-1/8" (256.86cm)
96" (243.84cm)
96" (243.84cm)
96" (243.84cm)
96" (243.84cm) 96" (243.84cm)
96" (243.84cm) 96" (243.84cm) 96" (243.84cm)
48"
(121.92cm)
48"
(121.92cm)
12' 5-1/8" (378.78cm)
16' 5-1/8" (500.70cm)
20' 5-1/8" (622.62cm)
24' 5-1/8" (744.54cm)
4-Foot 8-Foot
12-Foot
16-Foot
20-Foot
24-Foot
Mounting Accessories
Power Feed End Set
Straight Cord: LSBEC36WH (white)
LSBEC36AL (aluminum)
4 Wire Cord*: LSBEC36WHX4 (white)
LSBEC36ALX4 (aluminum)
Cable Assembly
Single Cable: LSBC36
Ceiling Grid Kit
CGK
Includes both Standard 1” (2.54cm)
Tee Bar Clip & Slot Tee Clip
*Use for dimming, switching, and emergency battery packs.
Cable/Cord Assembly
Single Cable & Cord: LSBCC36
Single Cable & 4 Wire Cord*: LSBCC36X4
4-Foot
Module
8-Foot
Module
Cable/
Assembly
Power Feed
End Set
4-Foot Run 11
8-Foot Run 11
12-Foot Run 11 1 1
16-Foot Run 21 1
20-Foot Run 12 2 1
24-Foot Run 32 1
