Lightolier Calculite 782 User manual

Ceiling Cutout: 5 1/16” Dia.
Reflector Trims Frame-In Kit Lamp
782CLW Specular Clear finish with white flange. 7082 T4 250W
782CLP Specular Clear finish with polished flange. Tungsten Halogen Frosted
782CL Specular Clear finish with molded trim ring (flangeless). (Mini-can based)
782 Add suffix for other finishes (see options).
Molded
Trim Ring
Flush Trim
(Molded trim ring removed)
White or
Polished Flange
Top View
1
3
4
5
6
78
2
9
1" max.
Ceiling Thickness
3"
4 1/2" Dia.
4 1/8" Dia.
5 3/4" Dia.
1 1/8" min.
1 7/8" max.
(Ceiling Runner)
11 1/2"
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lightolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division) • A0902
Features
1. Socket Cup: Heat dissipating die-cast aluminum with mini-can base porce-
lain socket, nickel plated screw shell No. 18 SF1 leads effectively act to cool
and properly stabilize lamp temperature. Adjustable socket feature allows
same fixture to be operated as wide or narrow distribution downlight.
2. Mounting Brackets: Adjust vertically from inside of fixture. Durable 16 ga.
steel construction. Use with standard 3/4" or 1 1/2" lathing channels (by
others), or Lightolier accessory mounting bars.
3. Retaining Springs: Precision tooled springs secure aperture mounting
frame for quick tool-less installation.
4. Reflector: Specular clear Alzak®upper reflector, retained by spring latches
for inspection and maintenance, top relampable, (fixture requires accessible
ceiling).
5. Junction Box: 14 ga. steel, 4" x 3 1/2" x 2" box
6. Thermal Protector: Meets NEC and UL requirements. Insulation must be
kept 3” away from fixture sides and wiring compartments. Must not be
placed above fixture in a manner which will entrap heat.
7. Aperture Cone: 16 ga. Specular Alzak®aluminum, 45° visual cutoff of lamp
and lamp image. Available with white or polished flange, or with removable
white molded trim ring (field paintable).
8. Multi-Groove Baffle: One piece seamless aluminum. Sharply detailed con-
centric rings with "sawtooth" profile, optical black finish.
9. Mounting Collar: Die-formed steel painted in baked black enamel.
Other Reflector Finish Options
Comfort Clear Diffuse CCD Specular Black BK
Specular Gold GD Multi-Groove Baffle MG
Flange Options
White W
Polished Flange P
Flangeless Leave Blank (molded trim ring)
Options & Accessories
18" Mounting Bars 1950 (set of 2)
27" Mounting Bars 1951 (set of 2)
T-Bar Anchor Clips 1956 (set of 4, for 1950 & 1951 bars)
Wood Joist Mtg. Bars 7994 (set of 2)
Sloped Ceiling Adapters See SCA specification sheet
Step Down Transformer 7997 (see separate specification sheet)
Chicago Air Plenum LC (add suffix to Frame-in Kit)
Electrical
UL Listed for maximum of 8 No. 12, 75°C through branch circuit conductors, or
60°C supply conductors for end of run.
Labels
UL Listed for damp locations, I.B.E.W.
Install fixtures with minimum spacing of: 4’-0” between centers of adjacent fix-
ture; and 6” between top of fixture and overhead building member; and 2’-0”
between fixture center and building side wall.
Alzak®is a registered trademark of ALCOA.
Calculite®Incandescent Open Downlight 782/7082
Page 1 of 2 4 1/2” Aperture T4 (T.H.) Ellipsoidal Reflector
12"
13 1/2"
4 1/8"
13 1/16"

Calculite®Incandescent Open Downlight 782/7082
Page 2 of 2 4 1/2”Aperture T4 (T.H.) Ellipsoidal Reflector
Lightolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 •[phone] •Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division) •A0902
Job Information Type:
Use quick calculator chart to determine spacing of luminaires for desired level of illumination.
80% Ceiling; 50% Walls; 20% Floor
Room Surface Reflectances:
250 Watt T-4 tungsten Halogen
4800 Lumens Per Lamp
RCR = 10 (Rm. Width - Mtg. Ht. above work plane)
RCR = 5 (Rm. Width - 2 x Mtg. Ht. above work plane)
RCR = 1 (Rm. Width - 10 x Mtg. Ht. above work plane)
CENTER TO CENTER DISTANCE OF FIXTURES IN FEET
AREA PER FIXTURE IN SQUARE FEET
INITIAL FOOTCANDLES
2119 20181716141311 1510 129874 5 6
50 100 150 200 250 300 350 400
10
20
30
40
50
60
70
80
90
100
Use quick calculator chart to determine spacing of luminaires for desired level of illumination.
80% Ceiling; 50% Walls; 20% Floor
Room Surface Reflectances:
250 Watt T-4 tungsten Halogen
4800 Lumens Per Lamp
RCR = 10 (Rm. Width - Mtg. Ht. above work plane)
RCR = 5 (Rm. Width - 2 x Mtg. Ht. above work plane)
RCR = 1 (Rm. Width - 10 x Mtg. Ht. above work plane)
CENTER TO CENTER DISTANCE OF FIXTURES IN FEET
AREA PER FIXTURE IN SQUARE FEET
INITIAL FOOTCANDLES
2119 20181716141311 1510 129874 5 6
50 100 150 200 250 300 350 400
10
20
30
40
50
60
70
80
90
100
1000
2000
90
60
30
3000
4000
COEFFICIENTS OF UTILIZATION
% EFFECTIVE CEILING CAVITY REFLECTANCE
80 70 50 30 10 0
ROOM CAVITY RATIO
20% FLOOR CAVITY REFLECTANCE
50 30 10 50 30 10 50 30 10 50 30 10 50 30 10 0
.89 .87 .86 .87 .86 .85 .84 .83 .82 .81 .80 .79 .79 .78 .77 .76
.84 .81 .78 .82 .80 .78 .80 .78 .76 .77 .76 .74 .75 .74 .73 .72
.79 .76 .73 .78 .75 .72 .76 .73 .71 .74 .72 .70 .72 .71 .69 .68
.75 .71 .68 .74 .70 .68 .72 .69 .67 .71 .68 .66 .69 .67 .65 .64
.71 .67 .64 .70 .66 .63 .69 .65 .63 .67 .64 .62 .66 .64 .62 .61
.67 .63 .60 .67 .63 .60 .66 .62 .60 .65 .62 .59 .64 .61 .59 .58
.64 .60 .57 .64 .60 .57 .63 .59 .57 .62 .59 .56 .61 .58 .56 .55
.61 .57 .54 .60 .56 .54 .60 .56 .54 .59 .56 .53 .58 .55 .53 .52
.58 .53 .51 .57 .53 .50 .56 .53 .50 .56 .52 .50 .55 .52 .50 .49
.54 .50 .47 .54 .50 .47 .53 .50 .47 .53 .49 .47 .52 .49 .47 .46
1
2
3
4
5
6
7
8
9
10
% WALL REFLECTANCE
COEFFICIENTS OF UTILIZATION
% EFFECTIVE CEILING CAVITY REFLECTANCE
80 70 50 30 10 0
ROOM CAVITY RATIO
20% FLOOR CAVITY REFLECTANCE
50 30 10 50 30 10 50 30 10 50 30 10 50 30 10 0
.89 .87 .86 .88 .86 .84 .84 .83 .82 .81 .80 79 .79 .78 .77 .75
.83 .80 .77 .82 .79 .76 .79 .77 .75 .77 .75 .73 .74 .73 .71 .70
.77 .73 .70 .76 .72 .69 .74 .71 .68 .72 .69 .67 .70 .68 .66 .65
.72 .67 .64 .71 .67 .63 .69 .65 .63 .67 .64 .62 .66 .63 .61 .60
.67 .62 .58 .66 .61 .58 .64 .60 .57 .63 .60 .57 .62 .59 .56 .51
.62 .57 .54 .62 .57 .54 .60 .56 .53 .59 .56 .543 .58 .55 .52 .51
.58 .53 .49 .58 .53 .49 .56 .52 .49 .55 .52 .49 .55 .51 .49 .47
.54 .49 .45 .53 .48 .45 .52 .48 .45 .51 .47 .45 .51 .47 .44 .43
.49 .44 .41 .49 .44 .41 .48 .44 .40 .47 .43 .40 .47 .43 .40 .39
.46 .40 .37 .45 .40 .37 .44 .40 .37 .44 .40 .37 .43 .39 .37 .35
1
2
3
4
5
6
7
8
9
10
% WALL REFLECTANCE
2500
5000
90
60
30
7500
10000
SOCKET IN LOW POSITION (PRE-SET) SOCKET IN HIGH POSITION (RE-SET IN FIELD)
I.T.L, INC. REPORT NO. 12425
DATE: 1-14-70
I.T.L, INC. REPORT NO. 12323
DATE: 12-8-69
SPACING RATIO = 1.4 SPACING RATIO = 0.4
DEG CP ZONAL FLUX
0 2482
2 1/2 2453 58
7 1/2 2159 154
12 1/2 2152 255
17 1/2 2639 436
22 1/2 3299 692
27 1/2 2855 723
32 1/2 2539 748
37 1/2 1915 639
42 1/2 230 85
47 1/2 57 23
55 47 42
65 9 11
75 6 6
85 2 2
ZONE LUMENS % LAMP % FIX
0-30 2318 48.3 59.8
0-40 3705 77.2 95.6
0-60 3855 80.3 99.5
0-90 3874 80.7 100
Candlepower Summary
DEG CP ZONAL FLUX
0 10520
1 10480 400
3 9160 105
5 7710 147
7 6810 183
9 6100 210
11 5360 224
13 4950 245
15 4660 265
17 4249 273
19 3710 265
25 2310 1070
35 1106 695
45 66 51
55 21 19
65 12 12
75 6 6
85 3 2
Candlepower Summary
ZONE LUMENS % LAMP % FIX
0-30 3027 62.9 79.2
0-40 3722 77.3 97.4
0-60 3792 78.8 99.2
0-90 3812 79.3 100
