Lightolier LINEAR ADAPTER Instructions for use

r>
READAND UNDERSTANDTHESEINSTRUCTIONSBEFOREINSTALLINGFIXTURE INSTRUCTION SHEET NO,
‘his fixture is intendedfor installationin accordancewith the NationalElectricalCode and local
emulations.To assure full compliance with local codes and regulations, check with your local electrical
nspector before installation. To prevent electrical shock, turnoff electricity at fuse box before proceeding. IS:8276
Retain these instructions for maintenance reference. 0892 Page 1of 2
INSTRUCTIONS FOR ATTACHING LINEAR” ADAPTER TO LYTESPAN@ TRACK
FOR USE WITH LYTESPAN BASIC OR ADVENT TRACK SYSTEM ONLY
INSTRUCTIONSFORAllACHING LINEAR” TO SINGLECIRCUITTRACK SYSTEMS
1. Insertinto LYlESPAN TRACK (see Fig. 1). LOCKINGLEVERmustbe onthe samesideof track as BEAD.
2. RotateFITTING90° clockwiseuntilLOCKINGLEVERsnapsandlocksin place (see Fig. 2and 3).
3. To remove: depress LOCKING LEVER, then rotate FITTING 90° counterclockwise.
YTESPANTRACK
FITTING
FIG. 1FIG. 2FIG. 3
INSTRUCTIONSFORCONVERTINGFITTINGTO OPERATEON2BRASSCON
CIRCUITTRACK SYSTEMS
See Fig.4. BRASSCONTACTcan be raisedor lowered.Brokenline indicates LOCKING
position for 1circuit or lower circuit of 2circuit track system. LEVER
To convert attachment FllTING for upper circuit of 2circuit track, raise BRASS
CONTACT to high position by lifting CONTACT as high as stop permits and
CONTACT clicks into place.
SEE BACK FOR LAMPING
1- I<>1-1 TC> 14 E[2” ER’#E?lH’K~TR;;

INSTRUCTION SHEET NO.
1S:8276
0892 Page20f2
OPERATION
1. AIMING ADJUSTMENTS
Simply rotate LYTESPOT to the desired position as indicated in Fig. 1.
FIG. 1
1. LAMPING
To prevent electrical shock, turn off power to track. Pull louver straight out with both hands. To remove lamp, swing lamp from the end until
it snaps out of holding clip, then pull sideways until it detaches from the lamp socket (see Fig. 2), Install new lamp. Replam louver by lining
up locking tabs to the inside edge of fixture’s opening, then push louver until it snaps in position. See list below for selection of appropriate lamp.
PROD. #
(12”) 8276- Twin Tube 18W
(14) 8277- Twin Tube 27W
FIG. 2
LOCKING
TABS
