ProSpec®120V/277V Track Lighting 37239
Page 1 of 2 PowerWash™ T5 3 Foot Track Mounted 39 Watt High Output Fluorescent
Features
1. Ballast & Reflector Housing: Aluminum with die-cast endcaps.
2. Ballast: 39w electronic.
3. Flood Reflector: Aluminum, with highly reflective and
semispecular finish for a smooth wash of light.
4. Louver: Aluminum, for glare control, with captive locking springs for easy
installation and removal.
5. Vertical Pivot: Die cast rotation housing with positive rotation stop
provides 0° (NADIR) –130° vertical rotation in both directions.
6. Sockets: 600v rated mini bi pin sockets with 90° rotor lock to engage
contacts and retain with a positive detent.
7. Socket Bracket: Adjustable steel, mounting bracket slides out for easy
lamping.
8. Attachment Fitting: Molded polycarbonate; pin rotates fitting into track to
engage luminaire.
9. Track Adapter Arm: Die-cast aluminum with integral polarity keyguard..
Electrical
Class P T5HO Universal Voltage Electronic Ballast
Input Voltage: 120V/277V Sound Rated: A
Power Factor: >98% Minimum Start Temp: 0°F
Input Power: 85W/83W (2 lamps) Do Not Use on Dimming Circuit
Max Input Current: 0.76A @ 120V/0.32A @ 277V
Finish
All painted finishes are baked enamel.
Labels
UL, cUL
Ordering Information
Catalog No. Finishes Track Mountings Lamp
37239WH
37239EBK
Matte White
Matte Black
ProSpec® 120V/277V track systems only.
Not compatible with MonoPoint.
2 x 39W T5 High Output (Fluorescent)
3 25/32 in
[96 mm]
4 13/16 in
[123 mm]
37 23/32 in
[958 mm]
35 19/32 in
[904 mm]
1 5/8 in
[41 mm]
1 3/32 in
[27 mm]
1
82
3
4
5
67
9
Advent®is a registered trademark of Lightolier.

Job Information Type:
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
www.lightolier.com © 2009 Philips Group • B0709
ProSpec®120V/277V Track Lighting 37239
Page 2 of 2 PowerWash™ T5 3 Foot Track Mounted 39 Watt High Output Fluorescent
0’ 1’ 2’ 3’ 4’ 5’
0’ 1’ 2’ 3’ 4’ 5’
Lighting Data 2-39W T5 High Output
1’ 157 132 76 36 17 9
2’ 123 106 65 32 14 6
3’ 78 69 47 27 13 6
4’ 51 46 34 22 13 7
5’ 30 27 21 15 9 6
6’ 19 18 15 11 8 5
7’ 12 12 10 8 6 4
8’ 8 8 7 5 4 3
9’ 6 6 5 4 3 3
196 166 196
153 136 153
107 100 107
83 80 83
50 49 50
40 39 40
27 27 27
19 19 19
16 16 16
170 77 170
129 65 129
84 54 84
63 50 63
35 30 36
29 26 29
19 18 19
13 13 13
11 11 11
Footcandles on Wall
Track 3 Feet From Wall Single Unit Multiple Units
4’ 6’
3’
Distance From Ceiling
45˚
EXAMPLE: With track located 4’ from wall and multiple
units spaced 6’ on center and aimed 45˚ from horizontal,
the illumination on wall 4’ from ceiling will be 57 f.c.
beneath units and 48 f.c. between units.
1’ 87 75 48 24 10 3
2’ 86 76 53 31 16 7
3’ 65 58 43 27 15 8
4’ 47 43 33 23 15 9
5’ 34 32 26 19 13 9
6’ 23 21 18 14 10 7
7’ 16 15 13 10 8 6
8’ 11 11 9 8 6 5
9’ 8 8 7 6 5 4
105 97 105
117 111 117
96 93 96
79 77 79
66 64 66
47 46 47
35 35 35
29 29 29
22 22 22
92 69 92
100 82 100
80 70 80
65 60 65
54 51 54
38 37 38
29 28 29
24 24 24
18 18 18
87 48 87
92 60 92
71 53 71
57 48 57
47 42 47
33 30 33
25 23 25
21 20 21
16 15 16
Track 4 Feet From Wall Single Unit Multiple Units
4’ 5’ 6’
4’
Distance From Ceiling
45˚
Footcandles are average and rounded off and data for multiple units are based on a minimum of five units.
Beam Center
Beam Center
178 114 178
136 95 136
91 74 91
70 62 70
41 38 41
33 32 33
22 21 22
15 15 15
13 13 13
5’
0’ 1’ 2’ 3’ 4’ 5’
1’ 61 55 41 27 16 10
2’ 62 56 43 29 18 11
3’ 55 51 40 28 18 12
4’ 40 38 30 22 15 10
5’ 31 29 24 18 13 9
6’ 24 22 19 15 12 8
7’ 18 17 15 12 10 7
8’ 13 12 11 9 7 6
9’ 10 9 8 7 6 5
99 96 99
104 102 104
101 99 101
77 76 77
63 62 63
53 53 53
43 43 43
32 32 32
27 27 27
83 74 83
87 80 87
84 79 84
63 60 63
51 49 51
44 42 44
36 35 36
26 26 26
22 22 22
74 58 74
77 63 77
75 64 75
54 49 54
44 41 44
37 35 37
31 29 31
22 22 22
19 19 19
Track 5 Feet From Wall Single Unit Multiple Units
4’ 5’ 6’
5’
Distance From Ceiling
45˚
Beam Center
One Lamp, with louver,
aimed 45˚ down.
Two Lamps, without louver,
aimed 45˚ up.
Two Lamps, with louver,
aimed 45˚ down.
one lamp aimed
45degrees down
0˚ 30˚
90˚
60˚
180˚ 150˚
120˚
90˚
0˚ 30˚
90˚
60˚
Lamp Information:
2 X 39W T5 High Output
Mini Bi-Pin Fluorescent (9376)
1 x 39W T5 High Output
Mini Bi Pin Fluorescent (9377)
Footcandles on wall:
