Lightolier QVS1GPFOS2FT User manual

Mounting Methods / Features Dimensions
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
Lightolier a Genlyte Thomas Company www.lightolier.com
Technical Information: [phone] • Fax [phone]
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division)
A0902 Section 5 / Folio L20-25
Features
• Efficiency 47.2%.
• Swing down microperforated lamp shield for easy relamping and
maintenance.
• Alter soft white film on inside of mesh conceals lamp image
providing balance between reflected and direct light.
• Fully recessed luminaire and lamp compartment.
• 95% Reflective Alter soft white paint finish.
• Specular interior reflector. (solid lamp shield only)
• One piece body for easy installation.
• Exclusive socket locks lamp into place.
• Easy access to ballast through lamp compartment.
• Fits standard T-Grid ceilings.
ALTER SOFT LIGHTS QVS1GPFOS2FT
Page 1 of 2 1'x4' RECESSED DIRECT/INDIRECT FLUORESCENT
2 LAMP, TT5 BI-TUBE, 5’’ DEEP
MICROPERFORATED MESH LAMP SHIELD, STATIC
Microperforated mesh
lamp shields
Also available with solid opaque swing-
down lamp shield
T type luminaire
e.g. QVS1TPFOS232120SO
Suited to standard exposed
T-grid ceilings
Suited to standard exposed
Slot T-grid ceilings
Construction specially
designed for exposed slot
T-grid to preserve the cove effect
Ceiling compatibility for G type luminaire e.g. QVS1GPFOS232120SO

ALTER SOFT LIGHTS QVS1GPFOS2FT
Page 2 of 2 1'x4' RECESSED DIRECT/INDIRECT FLUORESCENT
2 LAMP, TT5 BI-TUBE, 5’’ DEEP
MICROPERFORATED MESH LAMP SHIELD, STATIC
Lightolier a Genlyte Thomas Company www.lightolier.com
Technical Information: [phone] • Fax [phone]
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division)
A0902 Section 5 / Folio L20-25
Job Information Type:
Specifications
MATERIALS: One piece chassis constructed from die formed 20 gauge cold rolled
steel. Reflectors - 95% reflectance baked white acrylic matte paint finish.
Specular interior reflector (only with solid shield). Soft white acrylic film on inside
of lamp shield conceals lamp image.
FINISH: Chassis exterior - phosphate undercoating, baked white acrylic matte
high reflectance paint finish.
ELECTRICAL: Rapid start HPF, thermally protected class “P” ballast (Bi-tube type).
If K.Os are within 3” of ballast use wire suitable for at least 90C.
LABELS: Listed by
Photometry
Ordering Information
Explanation of Catalog Number. Example: QVS1GPFOS2FT120SB
QUALITY
VISUAL
STATIC
Recessed direct
indirect soft light
optical system FIXTURE
WIDTH:
1’
CEILING TYPE:
Standard exposed
T-grid ceilings
LAMP SHIELD:
PF = Microperforated
SD = Solid
OS = Open slot (no acrylic)
LAMP
QUANTITY
LAMP/FIXTURE
LENGTH:
(NOMINAL 48”)
FT = TT5
Bi-Tube
VOLTAGE:
120V
277V
347V
QVS 1 G OS 2FT
BALLAST:
BE = 50W Electronic TT5 RS
BR = 40W Electronic TT5 RS
BX = 40W Magnetic TT5 RS
PB = 40W TT5 PowerSpec Dimming*
PC = 50/55W TT5 PowerSpec Dimming*
SB = 40W Generic Electronic TT5
*Not available in 347V.
OPTIONS:
R = Radio Interference Filter
O = Emergency Lighting System
(for Canada)
N = Emergency Lighting System
(for U.S.)
