LightON AL-LZ100-NM User manual

AL-LZ100-NM
LON ZigBee Gateway
<Main Function>
LON Communication
ZigBee Communication
<AL-LZ100-NM>

Features
AL-LZ100-NM - Reliable and rapid control by LON communication.
- Wireless control by ZigBee communication.
The way of
Communication
* LON communication
- 78Kbps / 2 wire / Non-polarity
- Two-way communication / Event Driven
- Free Topology
* ZigBee communication
- 2.4GHz / 2Mbps
- Point to Point Repeating Function
Operating Temperature -10 °C ~ 50 °C
Operating Voltage DC 24V
2

Description
LightON®AL-LZ100-NM is the device which
convert between the devices using ZigBee
communication and the devices using LON
communication.
Through it, you can build the radio wire
integration solution.
AL-LZ100-NM
Function
Antenna Radio wave Transmit and Receive
(2.4GHz/Helical Antenna)
Status LED Indicate the current state by LED color and blinking
3
Status
LED
Antenna

Description of the Connection
1 Input power
Connection
Connect the DC Power line to the Ground and DC24V
Connection Point.
2 LON Connection
Connect the LON communication lines to the LON N and
LON P Point.
- In case the number of the products connecting
it is few, it can be input power by LON
communication line without external power
(Option)
4
Ground
DC 24V
N/C
LON N
LON P

Cautions
A Warning on Self-Repairs
This product should only be handled by an approved electrician with training about our
products. For your safety, please do not try to disassemble and repair this product yourself.
Prohibition of Putting Foreign Materials
This product should only be handled by an approved electrician with training about our
products. For your safety, please do not try to disassemble and repair this product yourself.
Be careful not to enter the foreign materials. If any foreign materials is input, cut off the
power and remove it immediately.
Shock Damage
When installing this product please make sure that the main power is turned off. Please
do not knock against this product with sharp or heavy objects. This may cause an electric
shock or fire hazard.
Technical Support
Product of ABI SYSTEMS Co,. Ltd.
LON ZigBee Gateway
Model Name: LightON® AL-LZ100-NM
Input Power: DC 24V / 1A
Head Office
#308 ACE Techno Tower 8, 11, Digital-ro 33-gil, Guro-gu, Seoul, 08380, Republic of KOREA
Phone : [phone]
Fax: [phone]
Email: [e-mail]
Web: www.lighton.co.kr / www.abisys.co.kr
※ Information in this document, including URL, and other internet Web site references, is subject
to change without notice.
130408 Ver. 1.0 ABIsystems

FCC Information to User
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
con-nected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution
Modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
FCC Compliance Information : This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation
IMPORTANT NOTE:
FCC RF Radiation Exposure Statement:
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment.
The antennas used for this transmitter must be installed to provide a separation distance of at
least 25 cm from all persons and must not be co-located or operating in conjunction with any
other antenna or transmitter.

1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this equipment near water.
6) Do not using near any heat sources such as radiators, heat resisters, stove, or other
equipment that produce heat.
European CE notice to users and product statements
This product is CE marked according to the provisions of the R&TTE
Directive(99/5/EC). Hereby, ABIsystems Co.,Ltd. declares that this
product is in compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC.
For further information, please contact http:// www.abisys.co.kr
ABIsystems Co.,Ltd.
308 (ACE Techno Tower 8), 11, Digital-ro 33-gil, Guro-gu, Seoul, Korea
Tel: [phone]
Fax: [phone]
URL: www.abisys.co.kr

CONTACT INFORMATION
Manufacturer Address : 308 (ACE Techno Tower 8), 11, Digital-ro 33-gil, Guro-gu, Seoul, Korea To locate in-
country ABIsystems Co.,Ltd., distributors of the ZigBee Gateway please refer to the ABIsystems Co.,Ltd.
Website http://www.abisys.co.kr
These distributor(s) represent local contacts for this product.
CORPORATE HEADQUARTERS:
ABIsystems Co.,Ltd.
308 (ACE Techno Tower 8), 11, Digital-ro 33-gil, Guro-gu, Seoul, Korea
Tel: [phone]
Fax: [phone]
Web: http://www.abisys.co.kr
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is Subject to the following two condition: (1) this device may not cause interference
,and (2) this device must accept any interference, including interference that may cause undesired
operation of the device.

EUROPEAN UNION “DECLARATION OF CONFORMITY”
DECLARATION OF CONFORMITY
ABIsystems Co.,Ltd.
308 (ACE Techno Tower 8), 11, Digital-ro 33-gil, Guro-gu, Seoul, Korea
declare under our sole responsibility that the product(s)
ZigBee Gateway – AL-LZ100-NM
to which this declaration relate(s) is in conformance with the following standards:
EN 301 489-1 V1.9.2:2011
EN 301 489-17 V2.2.1:2012
EN 60950-1:2006/A2:2013
EN 300 328 V1.8.1:2012
following the provisions of the 1999/5/EC Directives.
