Lightronics FXLD1036C4O User manual

Page 1 of 6
FXLD1036C4O LED FIXTURE
Version0.1 OWNERSMANUAL 04/05/2012
www.lightronics.com
Lightronics Inc. 509 Central Drive Virginia Beach, Va 234354 757 486 3588
FEATURES AND SPECIFICATIONS
LEDS: 36 Ten Watt LEDs (RGBW)
Beam angle: 45 º
Control system: DMX-512 + Stand Alone
DMX channels: 3, 4, 5, or 8
DMX connectors: 3 pin
Voltage: 100 - 250 VAC, 50/60Hz
Max power consumption: 400 Watts
IP Rating: IP 65
Body Size: 12 7/8"D x 10 7/8"W x 13 7/8"H
Body material: Die Cast Aluminum
Body color: Black
Weight: 28.7 lbs
DESCRIPTION
The FXLD1036C4O is a RGBW LED lighting fixture.
It is suitable for stage, disco, night club, and other
artistic applications. It has several stand alone control
modes, a master/slave mode, and can operate via a
DMX-512 external signal.
A double yoke enables the fixture to be operated in
several positions.
INSTALLATION
LOCATION
The FXLD1036C4O is rated IP65 and can be used
outdoors. The maximum operating temp. is 104 deg F.
Locate the unit in a well ventilated area. The unit can
be run in any position.
Keep the unit at least 18"
from any flammable materials.
Holes are provided on the yokes to install a lighting bar
pipe clamp. Use a safety cable if hanging the fixture.
POWER CONNECTIONS
The FXLD1036C4O has a power input cable and a
power adapter cable for connection to a 120 VAC, 15
Amp, 60Hz, grounded electrical service.
The unit also has a power output cable. This cable can
be used to supply power to another nearby
FXLD1036C4O. You can power a MAXIMUM of 4
fixtures this way.
The power cable ground terminals must be used.
DANGER
RISK OF ELECTRIC SHOCK
RISK OF FIRE

Page 2 of 6
FXLD1036C4O LED FIXTURE
Version0.1 OWNERSMANUAL 04/05/2012
www.lightronics.com
Lightronics Inc. 509 Central Drive Virginia Beach, Va 234354 757 486 3588
DMX CONNECTIONS
The FXLD1036C4O has permanent DMX in and DMX
out cables. Two DMX adapter cables are also supplied
to enable the use of 3 pin XLR connections.
A system using DMX control should be connected as a
chain of devices. In other words the control signal
cable should proceed from the controller to the first
receiving device and then to others in a continuous
"daisy chain" fashion. The control cable should NOT
be split into a multiple run star arrangement with a
cable running from the controller directly to each
receiving device.
DMX CONNECTOR PIN ASSIGNMENTS
There are normally two different connectors used for
DMX control. They are both XLR type connectors.
Some units use 3 pin connectors. Others use 5 pin
connectors. The FXLD1036C4O receives a DMX
signal on the 3 pin MALE connector on one side of the
unit. The 3 pin FEMALE connector is used to connect
the next DMX device on the control chain. If your
console uses a 5 pin connector you can make up an
adapter cable to convert. The table below shows the
pin assignments for BOTH the 3 pin and 5 pin
connectors.
The permantly attached DMX in and DMX out cables
are not XLR connectors but follow the same pin
assignments as 3 pin XLRs.
DMX TERMINATION
A DMX chain should be terminated at the last
receiving device on the chain. This is done by
installing a commonly available 1/4 Watt, 120 Ohm
resistor across the DATA - and DATA + wires at the
last device. If you have only a few fixtures very close
together and a very short run to the controller then you
may be able to operate without the terminator.
OPERATION
A control panel on one side of the unit is used to set the
operating options. It consists of an LED display and
four buttons
(MENU, UP, DOWN, and ENTER)
Push MENU to access the operating options. Then use
UP and DOWN to scroll through the available choices.
When you reach the option you want to set or change -
push
ENTER .Now you can view the current setting
for the option and/or change it. Push
ENTER to save
your changes and activate the option. See the
"MENU
NAVIGATION"
diagram for additional details.
There are 13 operating options: DMX address, Mode,
White Level, Blue Level, Green Level, Red Level,
Flash Sequence, Fade Sequence, Auto Sequence, Run
Program, Program Speed, DMX Mode, and Slave
Mode.
When the unit is powered on it begins operation in the
state it was in when the power was last turned off.
DMX ADDRESS SELECTION
Use the Addr menu to set the starting address of the
unit. You can set the starting address of the unit with
the UP and DOWN buttons.
DMX MODE SELECTION
The FXLD1036C4O can operate using an External
DMX signal in four different configurations (3
Channel, 4 Channel, 5 Channel, and 8 Channel)
Use the Chnd menu to select a DMX Mode.
Detailed channel operation in each of the four modes is
given in the table
"DMX VALUES AND FUNCTIONS" .
IN # SIGNAL NAME
1 DMX COMMON
2 DMX DATA -
3 DMX DATA +
4 NOT USED
5 NOT USED
MENU UP DOWN ENTER
CONTROL PANEL

Page 3 of 6
FXLD1036C4O LED FIXTURE
Version0.1 OWNERSMANUAL 04/05/2012
www.lightronics.com
Lightronics Inc. 509 Central Drive Virginia Beach, Va 234354 757 486 3588
NODE SELECTION
The node function is not currently supported.
MANUAL OPERATION
For manual operation the white, blue, green, and red
LED intensity levels may be independently controlled.
Use the UL - -, bL - -, gL - -, and rL - -, menus
to set the levels. The range is from 00 (OFF) to 15
(Full On).
FLASH OPERATION
Flash mode is a continuous strobe of all LEDs. Use
the FLAS menuto control the speed. The range is 00 -
15. 00 is fastest.
FADE OPERATION
Fade mode is a fading sequence of 8 colors. Use the
FADE menu to control the speed. The range is 00 -
15. 00 is fastest.
COLOR TEST
The COLOR TEST mode switches continuously
through a sequence of 14 colors. Use the CE - - menu
to control the speed. The range is 00 - 15. 00 is fastest.
PROGRAM RUN
The unit can operate using 28 preset programs.
Presets 1 through 13 are solid colors. The remaining
presets are a variety of changing colors and patterns.
Use the Pr - - menu to select and activate a preset
program. The range is from 00 to 28.
PROGRAM SPEED
The speed of some of the PROGRAM RUN selections
can be altered. Use the SP - - menu to set the speed.
The range is 00 - 15. 00 is fastest.
MASTER/SLAVE OPERATION
The FXLD1036C4O can operate in a Master/Slave
mode where one of the units can synchronize other
units of the same model.
Connect the units together using the DMX IN and
DMX OUT connectors. Set the unit to be the Master
in one of the modes above. Use the SLAV menu to set
a unit as a slave.
PHOTOMETRIC CHARACTERISTICS
Illuminance Beam
Distance (Lux) Diameter.
10 ft 5840 8'
20 ft 1680 13'
30 ft 760 18'
MAINTENANCE AND REPAIR
DISCONNECT ALL POWER AND CONTROL
CABLES BEFORE HANDLING THE UNIT
TROUBLESHOOTING
Check that you have power applied to the unit.
Check the DMX control cable.
Check the address settings of the unit and controller.
CLEANING
Do not use harsh chemicals or solvents when cleaning
the fixture. A mild detergent can be used sparingly if
needed. Ensure that the unit is completely dry before
re-use.
REPAIR
The FXLD1036C4O does not contain any parts which
can be serviced by the user.
Internal service on the unit by other than Lightronics
authorized agents will void the warranty.
If service is required, contact the dealer from whom
you purchased the item, or contact the Lightronics,
Service Department, 509 Central Drive, Virginia
Beach, VA 23454. Tel: [phone].
CAUTION DO NOT OPEN UNIT
DANGER
RISK OF ELECTRIC SHOCK
RISK OF FIRE

Page 4 of 6
FXLD1036C4O LED FIXTURE
Version0.1 OWNERSMANUAL 04/05/2012
www.lightronics.com
Lightronics Inc. 509 Central Drive Virginia Beach, Va 234354 757 486 3588
MENU NAVIGATION

Page 5 of 6
FXLD1036C4O LED FIXTURE
Version0.1 OWNERSMANUAL 04/05/2012
www.lightronics.com
Lightronics Inc. 509 Central Drive Virginia Beach, Va 234354 757 486 3588
3 CHANNEL CONFIGURATION
DMX
CHANNEL DMX VALUE FUNCTION
1 0 - 255 Color Mixing (adjusts hue)
2 0 - 255 White Mixing (adjusts color saturation)
3 0 - 255 Master Intensity
4 CHANNEL CONFIGURATION
DMX
CHANNEL DMX VALUE FUNCTION
1 0 - 255 Red Intensity
2 0 - 255 Green Intensity
3 0 - 255 Blue Intensity
4 0 - 255 White Intensity
5 CHANNEL CONFIGURATION
DMX
CHANNEL DMX VALUE FUNCTION
1 0 - 255 Master Intensity
2 0 - 255 Red Intensity
3 0 - 255 Green Intensity
4 0 - 255 Blue Intensity
5 0 - 255 White Intensity
8 CHANNEL CONFIGURATION
DMX
CHANNEL DMX VALUE FUNCTION
1 0 - 255 Master Dimmer
2 0 - 255 Red Level
3 0 - 255 Green Level
4 0 - 255 Blue Level
5 0 - 255 White Level
6 0 - 255 Strobes Currently Set Levels of Ch1 - Ch5
0 - 127 A Variety of Patterns Using Currently Set Levels of Ch1 - Ch5
7 128 - 255 A Variety of Color Patterns
8 0 - 255 Speed Adjust for Channel 7 Functions
DMX VALUES AND FUNCTIONS
