FXLD312R3I LED LIGHTING FIXTURE
Version0.2 OWNERSMANUAL 03/30/2012
www.lightronics.com
Lightronics Inc. 509 Central Drive Virginia Beach, Va 234354 757 486 3588
FEATURES AND SPECIFICATIONS
LEDS: 12 @ 3W (Tricolor RGB 3 in 1)
Beam Angle: 25 º
Control System: DMX-512
DMX Channels: 3, 4, or 16
DMX Connectors: 3 pin XLR
Power: 100 - 250 VAC, 50/60 Hz
Max Power Consumption: 50 Watts
Body color: Black
Size: 17.8"W x 12.3"D x 9.5"H
Weight: 13 lbs
DESCRIPTION
The FXLD312R3I is a RGB LED lighting fixture. It
is suitable for stage, disco, night club, and other artistic
applications. It has several stand alone control modes
and can operate via a DMX-512 external signal.
A double yoke enables the unit to be operated in
several positions.
INSTALLATION
LOCATION
The FXLD312R3I is rated IP20. The unit is intended
for
INDOOR USE ONLY.
Locate the unit in a well ventilated area away from
moisture and heat. Do not allow the vent or fan intake
holes to be blocked. Holes are provided on the yokes
to install a lighting bar pipe clamp. A safety cable
should also be used.
POWER CONNECTIONS
The FXLD312R3I has dual (male and female) IEC
type power connectors. The recessed male connector is
for a line cable connection to a 120 VAC, 15 Amp,
60Hz, grounded service. This line cord is provided.
The female IEC connector is to chain the power to
another unit if multiple units are used together. An
IEC power cable for this purpose is also provided.
DMX CONNECTIONS
A system using DMX control should be connected as a
chain of devices. In other words the control signal
cable should proceed from the controller to the first
receiving device and then to others in a continuous
"daisy chain" fashion.
The fixture has a DMX IN and a DMX OUT connector
to be used to connect the chain. The control cable
should NOT be split into a multiple run star
arrangement with a cable running from the controller
directly to each receiving device pack.
DMX CONNECTOR PIN ASSIGNMENTS
There are two XLR connector types which can be used
for DMX control. Some units use 3 pin connectors.
Others use 5 pin connectors. The FXLD312R3I
receives a DMX signal on the 3 pin MALE connector
on the back of the unit. The 3 pin FEMALE connector
is used to connect the next DMX device on the control
chain. If your console uses a 5 pin connector you can
make an adapter cable to accommodate this. The table
below shows the pin assignments for both the 3 pin and
5 pin connectors.
DMX TERMINATION
A DMX chain should be terminated at the last
receiving device on the chain. This is done by
installing a commonly available 1/4 Watt, 120 Ohm
PIN # SIGNAL NAME
1 DMX COMMON
2 DMX DATA -
3 DMX DATA +
4 NOT USED
5 NOT USED
CHASSIS REAR VIEW
FUSE
POWER
IN
OUT
DMX
INPUT OUTPUT

Page 2 of 6
FXLD312R3I LED LIGHTING FIXTURE
Version0.2 OWNERSMANUAL 03/30/2012
www.lightronics.com
Lightronics Inc. 509 Central Drive Virginia Beach, Va 234354 757 486 3588
resistor across the DATA - and DATA + wires at the
last device. If you have only a few fixtures very close
together and a very short run to the controller then you
may be able to operate without the terminator.
OPERATION
A control panel on the rear of the unit is used to set the
operating options. It consists of an LED display and
four buttons
(MENU, UP, DOWN, and ENTER)
Push
MENU to access the operating options. Then use
UP and DOWN to scroll through the available choices.
When you reach the option you want to set or change -
push
ENTER .Now you can view the current setting
for the option and or change it. Push
ENTER to save
your changes and activate the option. See the
MENU
NAVIGATION
diagram for additional details.
DISPLAY INVERSION
You can flip the display so that it reads upside down if
you install the unit in an unusual orientation. Use the
P - menu to set it. P 1 is normal and P 2 is upside
down.
DMX OPERATION
Use the A - - - menu to set the starting address of the
unit. You can set the starting address of the unit with
the UP and DOWN buttons.
For DMX operation the FXLD312R3I fixture can be
configured as a 3 channel, 4 channel, or 16 channel
unit. This is controlled by the Mode Selection menu.
See the
MENU NAVIGATION diagram in this manual.
DMX channel functions for the three modes are given
in the table
DMX CHANNEL ALLOCATIONS.
STAND ALONE OPERATION
There are 6 stand alone operation options: Flash All,
Fade Colors, Run Program, Sequence Colors, Sound
Sequence, and Sound Flash.
FLASH ALL
The Flash All mode flashes (strobes) all colors
resulting in a white light strobe effect.. Use the FL - -
menu to set the flash speed and activate the option. The
range is from 00 to 15. 00 is fastest.
FADE COLORS
The Fade Colors mode cycles smoothly through a
sequence of colors. Use the FA - - menu to set the
speed and activate the option. The range is from 00 to
15. 00 is fastest.
RUN PROGRAM
The unit can operate using 16 preset programs. The
first 6 presets are solid colors. The remaining presets
are a variety of changing patterns. Use the Pr - - menu
to select and activate a preset program. The range is
from 00 to 15.
SEQUENCE COLORS
The Sequence Colors mode switches through a
sequence of colors. Use the SP - - menu to set the
sequence speed and activate the option. The range is
from 00 to 15. 00 is fastest.
SOUND SEQUENCE
Use the SonA menu to invoke the Sound Color
option. The unit will sequence through a series of
colors in sync with music base notes.
SOUND FLASH
Use the SonF menu to invoke the Sound Flash option.
The unit will flash through a series of colors in sync
with music base notes.
MENU UP DOWN ENTER
CONTROL PANEL

Page 3 of 6
FXLD312R3I LED LIGHTING FIXTURE
Version0.2 OWNERSMANUAL 03/30/2012
www.lightronics.com
Lightronics Inc. 509 Central Drive Virginia Beach, Va 234354 757 486 3588
MAINTENANCE AND REPAIR
TROUBLESHOOTING
Check that you have power applied to the unit.
Check the fuse.
Check the DMX control cable.
Check the address settings of the unit and the
controller.
REPAIR
The only FXLD312R3I user serviceable part is
externally accessible 5mm x 20mm fuse.
DISCONNECT THE UNIT FROM POWER BEFORE
CHECKING OR REPLACING THE FUSE
Replace the fuse ONLY with 2.0 Amp, 250VAC, fast
blow fuse.
Internal service on the unit by other than Lightronics
authorized agents will void the warranty. If service is
required, contact the dealer from whom you purchased
the item, or contact the Lightronics, Service
Department, 509 Central Drive, Virginia Beach, VA
23454. Tel: [phone].
PHOTOMETRIC DATA
Distance Illuminance Beam Diam.
(ft) (Lux) (ft)
-------------- ------------------ -------------------
10 728 6w X 4h
20 183 10w X 8h
30 86 20w X 12h
CAUTION DO NOT OPEN UNIT
RISK OF ELECTRIC SHOCK
RISK OF FIRE

Page 4 of 6
FXLD312R3I LED LIGHTING FIXTURE
Version0.2 OWNERSMANUAL 03/30/2012
www.lightronics.com
Lightronics Inc. 509 Central Drive Virginia Beach, Va 234354 757 486 3588
DMX Channel Mode 1 (16 Channel) Mode 2 (4 Channel) Mode 3 (3 Channel)
1 0 - 50 Ch 2-16 Enabled
51 - 248 Various Effects
249 - 255 Ch 2-16 Enabled Master Level (All Lamps) Red Level (All Lamps)
2 Red Level (All Lamps) Red Level (All Lamps) Green Level (All Lamps)
3 Green Level (All Lamps) Green Level (All Lamps) Blue Level (All Lamps)
4 Blue Level (All Lamps) Blue Level (All Lamps) Not Used
5 Red Level (Lamp #1) Not Used Not Used
6 Green Level (Lamp #1) Not Used Not Used
7 Blue Level (Lamp #1) Not Used Not Used
8 Red Level (Lamp #2) Not Used Not Used
9 Green Level (Lamp #2) Not Used Not Used
10 Blue Level (Lamp #2) Not Used Not Used
11 Red Level (Lamp #3) Not Used Not Used
12 Green Level (Lamp #3) Not Used Not Used
13 Blue Level (Lamp #3) Not Used Not Used
14 Red Level(Lamp #4) Not Used Not Used
15 Green Level (Lamp #4) Not Used Not Used
16 Blue Level (Lamp #4) Not Used Not Used
NOTE: LAMP #1 is the right hand lamp if you are facing the front of the unit.
DMX CHANNEL ALLOCATIONS

Page 5 of 6
FXLD312R3I LED LIGHTING FIXTURE
Version0.2 OWNERSMANUAL 03/30/2012
www.lightronics.com
Lightronics Inc. 509 Central Drive Virginia Beach, Va 234354 757 486 3588
MENU NAVIGATION

This product is warranted for a period of TWO YEARS from the date of purchase against defects in
materials and workmanship.
This warranty is subject to the following restrictions and conditions:
A) If service is required, you may be asked to provide proof of purchase from an authorized
Lightronics dealer.
B) This warranty is valid only for the original purchaser of the unit.
C) This warranty does not apply to damage resulting from abuse, misuse, accidents, shipping,
and repairs or modifications by anyone other than an authorized Lightronics service
representative.
D) This warranty is void if the serial number is removed, altered or defaced.
E) This warranty does not cover loss or damage, direct or indirect arising from the use or
inability to use this product.
F) Lightronics reserves the right to make any changes, modifications, or updates as deemed
appropriate by Lightronics to products returned for service. Such changes may be made
without prior notification to the user and without incurring any responsibility or liability for
modifications or changes to equipment previously supplied. Lightronics is not responsible
for supplying new equipment in accordance with any earlier specifications.
G)This warranty is the only warranty either expressed, implied, or statutory, upon which the
equipment is purchased. No representatives, dealers or any of their agents are authorized
to make any warranties, guarantees, or representations other than expressly stated herein.
H) This warranty does not cover the cost of shipping products to or from Lightronics for
service.
I) Lightronics Inc. reserves the right to make changes as deemed necessary to this warranty
without prior notification.
