Lightware UBEX-PRO20-HDMI-F110 User manual
UBEX-PRO20-HDMI-F100
UBEX-PRO20-HDMI-F110
UBEX-PRO20-HDMI-R100 2xMM-2xDUO
UBEX-PRO20-HDMI-R100 2xMM-QUAD
UBEX-PRO20-HDMI-R100 2xSM-2xDUO
UBEX-PRO20-HDMI-R100 2xSM-QUAD
UBEX-PRO20-HDMI-R100 2xSM-BiDi-DUO
AV Over IP Multimedia Extender
UBEX series – Extender Application Mode – User's Manual 2
This equipment must be used with a mains power system with a
protective earth connection. The third (earth) pin is a safety feature,
do not bypass or disable it. The equipment should be operated only
from the power source indicated on the product.
To disconnect the equipment safely from power, remove the power
cord from the rear of the equipment, or from the power source. The
MAINS plug is used as the disconnect device, the disconnect device
shall remain readily operable.
There are no user-serviceable parts inside of the unit. Removal of the
cover will expose dangerous voltages. To avoid personal injury, do not
remove the cover. Do not operate the unit without the cover installed.
The appliance must be safely connected to multimedia systems.
Follow instructions described in this manual.
For the correct ventilation and to avoid overheating ensure enough
free space around the appliance. Do not cover the appliance, let the
ventilation holes free and never block or bypass the ventilators (if any).
To prevent injury, the apparatus is recommended to securely attach to
The apparatus shall not be exposed to dripping or splashing and that
be placed on the apparatus.
CAUTION AVIS
RISK OF ELECTRIC SHOCK
DO NOT OPEN
RISQUE DE CHOC ELECTRIQUE
NE PAS OUVRIR
WEEE
This marking shown on the product or its literature,
indicates that it should not be disposed with other
household wastes at the end of its working life. To
prevent possible harm to the environment or human
health from uncontrolled waste disposal, please
separate this from other types of wastes and recycle it
responsibly to promote the sustainable reuse of material
resources. Household users should contact either the
retailer where they purchased this product, or their local government
environmentally safe recycling. Business users should contact their
supplier and check the terms and conditions of the purchase contract.
This product should not be mixed with other commercial wastes for
disposal.
CLASS 1
LASER PRODUCT
Alternating current
Protective conductor terminal
Caution, possibility of electric shock
Caution
Laser radiation
UBEX series – Extender Application Mode – User's Manual 3
The following symbols and markings are used in the document:
Useful information to perform a successful procedure;
it is recommended to read.
INFO:A notice which may contain additional information. Procedure
can be successful without reading it.
DEFINITION:The short description of a feature or a function.
TIPS AND TRICKS:Ideas which you may have not known yet but
can be useful.
Go back to the previous page. If you clicked on a link previously,
you can go back to the source page by clicking the button.
Navigate to the Table of Contents.
Step back one page.
Step forward to the next page.
Allpresentedfunctionsrefertotheindicatedproducts.Thedescriptions
have been made during testing these functions in accordance with the
Item
Lightware Device Controller (LDC) software 1.34.0b2
Lightware Device Updater V2 (LDU2) software 2.0.0b22
Firmware package
UBEX-PRO20-HDMI-F100 1.4.1
UBEX-PRO20-HDMI-F110 1.4.1
UBEX-PRO20-HDMI-R100 series 1.4.1
Hardware
UBEX-PRO20-HDMI-F100 1.2
UBEX-PRO20-HDMI-F110 1.3
UBEX-PRO20-HDMI-R100 series 1.3
Document revision:
Release date: 04-12-2019
Editor: Tamas Forgacs
Lightware Visual Engineering supports green technologies and
eco-friend mentality. Thus, this document is made for digital usage
primarily. If you need to print out few pages for any reason, follow the
recommended printing settings:
▪Page size: A4
▪Output size: Fit to page or Match page size
▪Orientation: Landscape
TIPS AND TRICKS:Thanks to the size of the original page, a border
around the content (grey on the second picture below) makes
possible to organize the pages better. After punching the printed
pages, they can be placed easily into a ring folder.
123
UBEX series – Extender Application Mode – User's Manual 4
The side and bottom color of the pages indicates the related application
mode of the device.
This document is about the Extender application mode only. The user's
manual of the UBEX Matrix mode can be downloaded from the
following link:
Sample page for Extender mode
Sample page for Matrix mode
The UBEX F-series endpoint devices can be ordered with various
colored front panel but the transmitter is always red, the receiver is
always yellow, and the transceiver is always white in this manual for the
sake of simplicity.
Transmitter (TX) Receiver (RX) Transceiver (TRX)
For the available colors of the front panel please contact
This user's manual contains keywords with hashtag (#) to help you to
The format of the keywords is the following:
#<keyword>
The usage of the keywords: use the Search
of your PDF reader application, type the #(hashtag) character and the
wished keyword.
The #new
#dhcp
This keyword is placed at the DHCP (dynamic IP address) setting in
the front panel operation, the Lightware Device Controller (LDC) and
the LW3 programmer's reference section.
See the list of all hashtag keywords of the document in the Hashtag
Keyword List section, and it is highlighted with claret in the table of
contents of the document.
An assorted link collection can be found at the end of this user's
manual. The Quick Link Collection
your current activity. The collection is grouped by topic category and
within that is in alphabetical order.
The section of the quick link collection is highlighted with claret in the
table of contents of the document.
Sample page of the Quick Link Collection
UBEX series – Extender Application Mode – User's Manual 5
