Lightware VINX-110-HDMI-DEC User manual

VINX-120-HDMI-ENC
VINX-110-HDMI-DEC
User’s Manual
Video Over IP Multimedia Extender


VINX-1x0-HDMI Extenders – User's Manual 2
Important Safety Instructions
Class II apparatus construction.
The equipment should be operated only from the power source
indicated on the product.
To disconnect the equipment safely from power, remove the power
cord from the rear of the equipment, or from the power source. The
MAINS plug is used as the disconnect device, the disconnect device
shall remain readily operable.
There are no user-serviceable parts inside of the unit. Removal of the
cover will expose dangerous voltages. To avoid personal injury, do not
remove the cover. Do not operate the unit without the cover installed.
The appliance must be safely connected to multimedia systems.
Follow instructions described in this manual.
Ventilation
For the correct ventilation and to avoid overheating ensure enough
free space around the appliance. Do not cover the appliance, let the
ventilation holes free and never block or bypass the ventilators (if any).
WARNING
To prevent injury, the apparatus is recommended to securely attach to

The apparatus shall not be exposed to dripping or splashing and that


be placed on the apparatus.
Waste Electrical & Electronic Equipment
WEEE
This marking shown on the product or its literature,
indicates that it should not be disposed with other
household wastes at the end of its working life. To
prevent possible harm to the environment or human
health from uncontrolled waste disposal, please
separate this from other types of wastes and recycle it
responsibly to promote the sustainable reuse of material
resources. Household users should contact either the
retailer where they purchased this product, or their local government
            
environmentally safe recycling. Business users should contact their
supplier and check the terms and conditions of the purchase contract.
This product should not be mixed with other commercial wastes for
disposal.
Common Safety Symbols
Symbol Description
Direct current
Alternating current
Double insulation
Caution: for indoor use only
Caution: possibility of eletric shock
Caution






VINX-1x0-HDMI Extenders – User's Manual 3
Symbol Legend
The following symbols and markings are used in the document:
WARNING! Safety-related information which is highly
recommended to read and keep in every case!
ATTENTION! Useful information to perform a successful procedure;
it is recommended to read.
INFO: A notice which may contain additional information. Procedure
can be successful without reading it.
DEFINITION: The short description of a feature or a function.
TIPS AND TRICKS: Ideas which you may have not known yet but can
be useful.
Navigation Buttons
Go back to the previous page. If you clicked on a link previously,
you can go back to the source page by pressing the button.
Navigate to the Table of Contents.
Step back one page.
Step forward to the next page.




Document Information
Allpresentedfunctionsrefertotheindicatedproducts.Thedescriptions
have been made during testing these functions in accordance with the

Item Version
Core version 1.1.0b1
Web version 1.1.0b1
Firmware package version 1.1.0b7
Document revision: 1.3
Release date: 08-06-2018
Editor: Laszlo Zsedenyi






VINX-1x0-HDMI Extenders – User's Manual 4
1. INTRODUCTION...................................................................................6
 ...................................................................................6
 ................................................................................6
 ...................................................................6
..................................................................7
 ......................................................................7
2. INSTALLATION.....................................................................................8
.........................................................................8
2.1.1. VESA100 Mounting Adapter for Extenders...................................... 8
2.1.2. Rack Shelf Mounting ......................................................................... 8
2.1.3. UD-kit Mounting................................................................................. 8
..........................................................................9
2.2.1. Preparing the Network ...................................................................... 9
2.2.2. LAN Connection (Multicast Mode)................................................... 9
2.2.3. Further Steps ..................................................................................... 9
3. PRODUCT OVERVIEW ......................................................................10
 ............................................10
 ............................................10
..............................................................11
 ........................................................................11
...................................................................................11
 ...................................................................11
 ...........................................................................12
3.7.1. One-to-one Video Transmission (Unicast Mode) .......................... 12
3.7.2. One-to-All Video Transmission (Multicast Mode) ......................... 12
3.7.3. Layout Examples ............................................................................. 13
..............................................................................14
.........................................................................14
4. SOFTWARE CONTROL - USING THE BUILT-IN WEBSITE .............15
......................................................15
.........................................................................15
4.2.1. General Settings .............................................................................. 15
4.2.2. Video Status and Settings (Encoder) ............................................. 16
4.2.3. Video Status and Settings (Decoder)............................................. 17
4.2.4. Network Settings ............................................................................. 17
4.2.5. Frame Detector ................................................................................ 18
....................................................................................18
4.3.1. The EDID Memory Structure ........................................................... 18
4.3.2. EDID Operations............................................................................... 19
......................................................................20
4.4.1. Common Settings (Encoder and Decoder).................................... 20
4.4.2. Decoder-related Settings ................................................................ 21
4.4.3. LW3 Terminal ................................................................................... 22
.........................................................................23
4.5.1. Creating a Video Wall ...................................................................... 23
4.5.2. Identify the Decoders ...................................................................... 24
4.5.3. Gap and Bezel Settings ................................................................... 24
4.5.4. Modifying a Video Wall ................................................................... 24
4.5.5. Deleting a Video Wall ...................................................................... 24
5. PROGRAMMERS' REFERENCE .......................................................25
......................................................................................25
...........................................................................25
5.2.1. The LW3 Tree Structure................................................................... 25
5.2.2. The LW3 Command Structure......................................................... 25
5.2.3. Legend for the Control Commands................................................ 25
5.2.4. General Rules................................................................................... 25
5.2.5. Command Types.............................................................................. 26
5.2.6. Prefix Summary ............................................................................... 26
5.2.7. Error Messages................................................................................ 26
5.2.8. Escaping........................................................................................... 26
5.2.9. Subscription..................................................................................... 26
5.2.10. Signature........................................................................................ 27
5.2.11. Notifications about the Changes of the Properties .................... 27
.......................................................................27
5.3.1. Querying the Product Name ........................................................... 27
5.3.2. Setting the Device Label.................................................................. 27
5.3.3. Querying the Serial Number............................................................ 27
5.3.4. Querying the Firmware Version ...................................................... 28
5.3.5. Querying the Core Version .............................................................. 28
5.3.6. Resetting the Device........................................................................ 28
5.3.7. Restoring the Factory Default Settings .......................................... 28
 ..............................................................28
5.4.1. Querying the IP Address.................................................................. 28
5.4.2. Querying the DHCP State................................................................ 28
5.4.3. Setting the DHCP State ................................................................... 28
5.4.4. Setting a Static IP Address ............................................................. 29
5.4.5. Querying the Subnet Mask.............................................................. 29
5.4.6. Setting a Static Subnet Mask ......................................................... 29
5.4.7. Querying the Gateway Address ...................................................... 29
5.4.8. Setting a Static Gateway Address.................................................. 29
 .......................................................29
5.5.1. Querying the Input Video Signal Presence..................................... 29
5.5.2. Querying the Resolution of the Input Video Signal........................ 29
5.5.3. Querying the Video Quality Mode................................................... 30
5.5.4. Setting the Video Quality Mode ...................................................... 30
5.5.5. Querying the HDCP State................................................................ 30
5.5.6. Setting the HDCP State ................................................................... 30
 .......................................................31
5.6.1. Querying the Resolution of the Output Video Signal..................... 31
5.6.2. Querying the Scaling Mode of the Output Video Signal................ 31
5.6.3. Setting the Scaling Mode of the Output Video Signal................... 31
5.6.4. Setting the Resolution of the Output Video Signal........................ 31
5.6.5. Querying the Signal Type of the Output Video Signal ................... 31
5.6.6. Setting the Signal Type of the Output Video Signal....................... 32
5.6.7. Querying the State of the USB Connection .................................... 32
5.6.8. Establishing the USB Connection................................................... 32
...................................................................32
5.7.1. Setting the Port Availability............................................................. 32
5.7.2. Setting the RS-232 Port Mode ........................................................ 32
5.7.3. Setting the Baud Rate of the Port................................................... 33
5.7.4. Setting the Data Bits........................................................................ 33
5.7.5. Setting the Stop Bits........................................................................ 33
5.7.6. Setting the Parity ............................................................................. 33
..........................................33
.......................... 33
............................. 33
5.8.3. Querying the Video Stream ID Setting Method.............................. 34
5.8.4. Querying the DIP Switch State........................................................ 34
5.8.5. Querying the Video Stream ID......................................................... 34
5.8.6. Ignoring the DIP Switch................................................................... 34
5.8.7. Setting the Video Stream ID............................................................ 34
....................................................................35
5.9.1. Setting the Name of the Video Wall ............................................... 35
5.9.2. Assigning a Decoder to a Video Wall ............................................. 35
 ...........................................36
.....................................................37
5.11.1. Querying the Emulated EDID......................................................... 37
5.11.2. Setting the Emulated EDID on the Input Port............................... 37
5.11.3. Copying an EDID............................................................................ 37
5.11.4. Querying the Preferred Resolution of an EDID............................. 37
5.11.5. Deleting an EDID from the User Memory..................................... 38
..............................................39
Table of Contents






VINX-1x0-HDMI Extenders – User's Manual 5
6. FIRMWARE UPGRADE......................................................................41
...................................................................41
 ............................41
 .......................41
6.3.1. Firmware Upgrading Steps ............................................................. 41
 ...................................................42
6.4.1. Installation ....................................................................................... 42
6.4.2. Before Starting the Upgrade ........................................................... 42
6.4.3. Firmware Upgrading Steps ............................................................. 43
7. TROUBLESHOOTING........................................................................44
8. TECHNOLOGIES................................................................................45
........................................................................45
8.1.1. Understanding the EDID.................................................................. 45
8.1.2. Advanced EDID Management......................................................... 45
 ...............................................................................46
......................................................................46
8.3.1. Protected and Unprotected Content .............................................. 46
8.3.2. Disable Unnecessary Encryption.................................................... 46
9. APPENDIX ..........................................................................................47
 .............................................................................47
 .................................................................48
 .....................................................49
........................................................................50
...........................................................50
.......................................................................50
 ...................................................51
...................................................................53






1. Introduction VINX-1x0-HDMI Extenders – User's Manual 6
1
Introduction
Thank you for choosing Lightware’s VINX Video Network Extender devices. In

important features in the below listed sections:
Ý
Ý
Ý
Ý
Ý
1Supplied with the Encoder
2Supplied with the Decoder
1.3. Optional Accessories
VESA-100 compatible
mounting adaptor
Infrared
transmitter unit
Under desk
mounting kit
Infrared
receiver unit
1.1. Description
VINX-120-HDMI-ENC and VINX-110-HDMI-DEC are LAN-based
    
a local source to a remote sink. The Encoder and Decoder devices
connect either via a direct CATx cable connection or through a Gigabit
Ethernet Switch in between. The maximum delivery distance can reach
up to 100 m with minimal latency and employing a quality, proprietary
wavelet transform based image compression.
The maximum supported resolution is 3840 x 2160 @ 30Hz with
7.1 audio. The devices support both static and dynamic (DHCP) IP
address settings. Pre-programmed factory EDID presets and user
EDIDs are stored in the Encoder.
Devices feature embedded web for control.
DIP switches serve quick manual setting for device pairing over
the network, a quick and easy installation method. Gap and bezel
compensation can be adjusted for video walls. Scaling is available on
the receiver side and videos can be freely cropped.
Model Denomination
1.2. Box Contents
HDMI cable
(male to male)
USB cable
(mini-B to B-type) 1
Serial cable
(DE-9 female to RJ12) 1
Serial cable
(DE-9 male to RJ12) 2
VINX-120-HDMI-ENC
1x input Type of the A/V interface
Product Series 2x outputs Type of the extender

device
5V DC power adaptor
and interchangeable
plugs
Safety & warranty info,
Quick Start Guide
Safety and
Warranty
Info
Quick
Start
Guide






1. Introduction VINX-1x0-HDMI Extenders – User's Manual 7
1.4. Features of the Device
1.5. Typical Application
PC1
Video (4K@30Hz)
VINX-120-HDMI-
ENC
VINX-110-HDMI-DEC
16-port L3 Switch
Control Laptop
1-output decoder with HDMI connector
HDMI1.4
Infra port
Bidirectional RS-23 2
USBHIDextension
CONNEC T button (fo r furth er details p lease see the U ser's manual )
Short pres s:A cquir e USB conn ectioni nmulticast mode
Long p ress: R eset to fac tory defau lts
VideoStream I D
0:Recei ve stre am with V ideoStream I D set viaso ftware
1-15: Rece ive stre amw ith fix edVideo St reamID set bythesw itch
FrontLE Ds
POWER
OFF:Nopow er
Blin king: Booting
Cont inuous:Po wer connected
VIDEO
OFF: Nocon nection with ENCODER
Blinking:Con nectedt o ENCODER, n o video ou tput
Continuous: Conn ectedto ENCODER, vi deo outp ut
USB
OFF:No USB co nnect ion
Continuous:USB c onnection a quired
VINX-110-HDMI-DEC
HDMIOUTPUT
CONNECT
POWER
VIDEO
USB
1GbELAN
(AVINPUT)
CHANNELID
ON DIP
LINK ACT.
1 2 3 4
8-4-2-1
DECODER
1-output decoder with HDMI connector
HDMI 1.4
Infra port
Bidirectional RS -232
USBHID extension
NECT butto n (forfurther de tails p lease seeth eUser's ma nual)
Short press: A cquire U SBconnection in multicast mode
Long p ress:Rese t to fact ory def aults
Video S tream ID
0: Rece ive stream w ithVi deo Strea m ID set vi a softw are
1-15:Receiv es tream w ith fixedV ideo Str eamID set b ythe switc h
Front LEDs
POWER
OFF:Nop ower
Blin king: Boot ing
Cont inuous: Po wer conne cted
VIDEO
OFF:Noconnectionwit h ENCODE R
Blink ing: Con nectedto ENCO DER, no v ideoout put
Continuous:Connect ed to ENC ODER,video output
USB
OFF:NoU SBconnec tion
Continuous: US Bc onnect iona quired
VINX-110-HDMI-DEC
HDMIOUTPUT
CONNECT
POWER
VIDEO
USB
1GbELAN
(AVINPUT)
CHANNELID
ON DIP
LINK ACT.
1 2 3 4
8-4-2-1
DECODER
1-outputdecoder with HDMI connector
HDMI1.4
Infraport
Bidirectional RS- 232
USB HIDextension
CONNE CT button(for fu rther details pleasese e the Use r's man ual)
Short p ress: Acquire U SB conne ctioninm ulticast mode
Long p ress:Reset to fa ctory d efaul ts
VideoStream I D
0:Receivest reamw ith Video St ream ID s et via sof tware
1-15:Recei ve strea m with fixedVideo St reamID set b y the swi tch
Front LE Ds
POWER
OFF:Nopower
Blinking:B ooting
Continuous : Powerconnected
VIDEO
OFF:No conn ectionwith ENCODER
Blin king:Conne ctedto EN CODER , no vide o output
Continuous:Connect edto ENCODER, video o utput
USB
OFF:N o USB connecti on
Conti nuous : USBconnecti on aquired
VINX-110-HDMI-DEC
HDMIOUTPUT
CONNECT
POWER
VIDEO
USB
1GbELAN
(AVINPUT)
CHANNELID
ON DIP
LINK ACT.
1 2 3 4
8-4-2-1
DECODER
1-output decoderwith HDMI connector
HDMI1.4
Infraport
Bidirectional RS- 232
USB HIDextension
CONNEC T button(f or furth erde tails please see the U ser's man ual)
Short pr ess:Acquir e USB con necti oninmulticast m ode
Longpress: Reset to f actorydefaults
VideoStrea m ID
0:Recei ve streamwith Video Stream I D set vias oftware
1-15:Recei ve stream w ith fixed Vid eoStreamIDset by t heswit ch
Front LE Ds
POWER
OFF:Nopower
Blinking:Booti ng
Conti nuous:P ower connected
VIDEO
OFF:N oc onnect ionwithENCODER
Blinki ng: Con nectedto E NCODER, n o video ou tput
Continuous: Conn ected to EN CODER,video output
USB
OFF:NoUSB c onnection
Continuous:USB c onnec tion aqui red
VINX-110-HDMI-DEC
HDMIOUTPUT
CONNECT
POWER
VIDEO
USB
1GbELAN
(AVINPUT)
CHANNELID
ON DIP
LINK ACT.
1 2 3 4
8-4-2-1
DECODER
1-output decoderwith HDMI connector
HDMI 1.4
Infra port
Bidirectional RS-232
USBHID extens ion
CONNE CT button (f or furt her detail s pleas e see the U ser's manual)
Short press:Acquire USB connectio ni n multicast mo de
Longp ress: Reset to f actory defaults
VideoStrea m ID
0: Rec eive stre am with Video S tream I D set via sof tware
1-15:Receiv estream w ith fixed V ideo Str eam ID set b ythe switch
Front LEDs
POWER
OFF: No power
Blin king:Booting
Cont inuous:Po wer connected
VIDEO
OFF:No conn ectionw ithENCODER
Blin king:Conn ectedtoE NCODER, no video ou tput
Continuous: Con nected to EN CODER,vi deo output
USB
OFF:No US B connection
Continuous:USB c onnect ionaquir ed
VINX-110-HDMI-DEC
HDMIOUTPUT
CONNECT
POWER
VIDEO
USB
1GbELAN
(AVINPUT)
ON DIP
LINK ACT.
1 2 3 4
8-4-2-1
DECODER
1-output decoder with HDMI connector
HDMI 1.4
Infraport
Bidirection al RS-232
USB HID extension
CONNEC Tb utton(f orfurther details p leasese ethe User' s manual)
Short press: Acquire U SB conn ectio n in multic ast mode
Longpr ess:Reset to fac torydefau lts
VideoStreamI D
0: Receive st ream wit h Video S treamID s et viasoft ware
1-15: Rece ive stre am with f ixedVide o Strea m ID set by t heswitch
Front LE Ds
POWER
OFF:Nopower
Blin king: Booti ng
Cont inuous: P owerconnected
VIDEO
OFF:No connection wi th ENCODE R
Blin king:Connecte d to ENCODER, no v ideo output
Continuous : Connec ted to EN CODER ,video out put
USB
OFF:No USB con nection
Continuou s:USBc onnec tion aquired
VINX-110-HDMI-DEC
HDMIOUTPUT
CONNECT
POWER
VIDEO
USB
1GbELAN
(AVINPUT)
NNELID
ON DIP
LINK ACT.
1 2 3 4
8-4-2-1
DECODER
CATx
HDMI
Analog audio
1-output decoder with HDMI connector
HDMI 1.4
Infra port
Bidirectional RS-23 2
USBHID extension
CONNEC T button (for f urther d etailsp leasesee th e User' s manual)
Shortpress: A cquire U SB connec tionin multicast m ode
Long p ress: Reset t o facto ry defa ults
Video St ream ID
0: Receive stream w ith Vide oStream ID se t viasof tware
1-15: R eceive strea m with fix edVideo St ream ID set byt he switch
Front L EDs
POWER
OFF:No power
Blin king:Booti ng
Continuou s: Powe r conne cted
VIDEO
OFF:Noconnection wi th ENCODE R
Blin king:Connect edto ENCO DER, no v ideo outpu t
Continuous: Connectedt o ENCODER, v ideooutput
USB
OFF:No USB con nection
Continuous:USBc onnectiona quired
VINX-110-HDMI-DEC
HDMIOUTPUT
CONNECT
POWER
VIDEO
USB
1GbELAN
(AVINPUT)
CHANNELID
ON DIP
LINK ACT.
1 2 3 4
8-4-2-1
DECODER
1-output decoder with HDMI connector
HDMI 1.4
Infraport
Bidirectional RS-232
USB HIDextension
CONNECTbut ton(for furtherdetails p leaseseeth e User'smanu al)
Short pre ss: Ac quire USB conne ctionin multicast mode
Long pre ss: Res et to factory defau lts
VideoStreamI D
0: Rece ivestream w ith Vide o StreamID set v ia softwar e
1-15:Recei ve stream with fixedVide oStr eam ID se t bythe swit ch
Front LEDs
POWER
OFF:No p ower
Blinking: Bo oting
Continuous:Power connected
VIDEO
OFF:No connectio n with EN CODER
Blinking:Connected t oENCOD ER, no vi deo output
Continuous: Connecte d to ENCO DER, vi deo outpu t
USB
OFF:NoUSB conn ection
Continuous: USB co nnecti on aquir ed
VINX-110-HDMI-DEC
HDMIOUTPUT
CONNECT
POWER
VIDEO
USB
1GbELAN
(AVINPUT)
ON DIP
LINK ACT.
1 2 3 4
8-4-2-1
DECODER
1-output decoder with HDMIconnector
HDMI 1.4
Infraport
Bidirectional RS-23 2
USBHIDextension
CONNE CT button(f or furtherdetai ls plea se seethe User's manua l)
Short press:Acquir eU SB connection i nmulticastmode
Long pr ess: Res et to fac tory de fault s
Video Stre am ID
0: Rec eivestream withVi deoStrea m ID set via soft ware
1-15: Rece ive str eamwith fixed Video Stream I D set by theswitc h
Front L EDs
POWER
OFF: No p ower
Blin king:Bootin g
Conti nuous: Pow er connect ed
VIDEO
OFF: No c onnectio n with ENCODE R
Blinking:C onnect ed to ENC ODER, no video output
Conti nuous:Con nected to EN CODER, vid eoo utput
USB
OFF:No USB con nection
Continuous:USB con nection a quired
VINX-110-HDMI-DEC
HDMIOUTPUT
CONNECT
POWER
VIDEO
USB
1GbELAN
(AVINPUT)
ON DIP
LINK ACT.
1 2 3 4
8-4-2-1
DECODER
HDMI
(localout)
MODE
VIDEO
USB
1GbELAN
(AVINPUT)
VIDEO
STREAMID
ON DIP
LINK ACT.
1 2 3 4
8-4-2-1
ENCODER
DA2HDMI-4K-
Plus-A
Audio Amplifer
with Speakers
A
r
A
Display Wall
Local Display
1.35/3.5mm
2-output encoder with HDMI connector
HDMI 1.4
Infra port
Bidirectional RS-232
USBHID extension
MODE button (forf urtherde tailsp lease s ee the User'smanual )
Short pres s: Toggle between b est video qu ality and adaptiv e data rate
Long press : Reset to f actory defaults
VideoStre am ID
0: Tran smitstream w ith Vid eoStrea m ID setvi asoftware
1-15:Transmit str eam wit h fixed Vid eoStreamI D setb ythe swit ch
FrontLEDs
POWER
OFF:No po wer
Blinki ng:Booting
Conti nuous:Po wer connect ed
VIDEO
OFF:No conn ection with DE CODER
Blinking: C onnected toD ECODER, no vi deo out put
Continuous: Connectedto DECODER, video signal detected o n HDMI inpu t
POWER and VI DEO
Blink ing: Video Stre am ID con flict i n thenetwork
VINX-120-HDMI-ENC
VIDEO
STREAMID
VIDEO
STREAMID
VIDEO
STREAMID
Video Wall Application
The VINX devices can be arranged to a Video wall up
to 8x8 Display devices. The displayed video can be the
same on each display, one image enlarged to all the
sinks, or the mixture of these.
Supporting 4K Resolution
Up to HDMI 2.0 4K 2160p@60Hz 4:2:0 video input
or 3840 x 2160 @ 30Hz resolution over a 1 Gigabit
network with very low latency.
Advanced EDID Management
The user can emulate any EDID on the inputs
independently, read out and store any attached
monitor's EDID in the User memory locations, upload

ENC
DEC
Local HDMI Output
A display device can be connected to the Encoder for
local signal checking. The port carries the same video
as the transmitted signal.
Frame Detector and Signal Analysis
The exact video and audio signal format can be
determined such as timing, frequencies, scan mode,
HDCP encryption, color range, color space and audio
sample rate.
Scaling the Output Image
Scaling is available at the Decoder side and videos can
be freely cropped.
Image Adjustment
         
Decoder side.
Built-in Website
Easy access from a web browser to control and

USB Extension
KVM extension for USB HID (Human Interface Devices,
e.g. keyboard, mouse, presenter) and Mass Storage
devices (Flash drive, Hard drive).
RS-232 Serial Data Transmission
Transparent serial data transmission is available
between the endpoints: Encoder and Decoder devices.






2. Installation VINX-1x0-HDMI Extenders – User's Manual 8
2
Installation
The chapter is about the installation of the device and connecting to other
appliances, presenting also the mounting options and further assembly steps.
Ý
Ý
2.1. Mounting Options
INFO: In order to get the necessary mounting accessory please
contact [email protected].
2.1.1. VESA100 Mounting Adapter for Extenders
Mounting under the Desk
Two pieces of the adapter is needed for this kind of mounting. Fasten
the adapters to the bottom of the extender and the desk as shown in

Mounting to a Display Device
Two mounting holes can be found on the bottom of the extender
          
  
compatible device (e.g. rear panel of an HDTV).
POWER
VIDEO
USB
CONNECT
HDMI OUTPUT
ACT.LINK
1GbELAN
(AVINPUT)
8-4-2-1
VIDEO
STREAM ID
1 2 3 4
ON DIP
VINX Device
(bottom view)
VESA100
Mounting adapter
100 mm
67.5 mm
HDTV
(rear view)
2.1.2. Rack Shelf Mounting
The 1U high rack shelf provides mounting holes for fastening four
VINX devices and put them into a standard rack cabinet (width of the
Rack shelf is 448 mm – without the ears). Fix the device to the Rack

2.1.3. UD-kit Mounting


POWER
VIDEO
MODE
HDMI
(LOCAL OUT)
ACT.LINK
1GbELAN
(AV OUT)
8-4-2-1
VIDEO
STREAM ID
1 2 3 4
ON DIP
POWER
VIDEO
MODE
HDMI
(LOCAL OUT)
ACT.LINK
1GbELAN
(AV OUT)
8-4-2-1
VIDEO
STREAM ID
1 2 3 4
ON DIP
POWER
VIDEO
MODE
HDMI
(LOCAL OUT)
ACT.LINK
1GbELAN
(AV OUT)
8-4-2-1
VIDEO
STREAM ID
1 2 3 4
ON DIP






2. Installation VINX-1x0-HDMI Extenders – User's Manual 9
2.2. Connecting Steps
2.2.1. 
For the correct installation build a Local Area Network with a
Layer 3 (L3) type switch (highly recommended). However, Unicast
mode requires only Layer 2 (L2) switch. In both cases the switch must
support the Multicast routing.
ATTENTION! VINX Encoder and Decoder send certain system
commands over multicast packages. If the multicast routing is
disabled on the network, the signal transmission may fail.
Layer 2 vs. Layer 3 Switch
The VINX Encoders and Decoders use multicast routing. The managed
switch in the network shall offer the following capabilities:
▪IGMPv2
▪IGMP snooping
▪IGMP fast leave
▪IGMP Querier
▪
▪
These features are supported by the Layer 3 type switches. Please
see more technical information about the network requirements in the
Application Note (LW-AN-001) section.
2.2.2. 
CATx
Connect a CATx cable between the VINX devices and the
L3 Switch.
HDMI
Connect an HDMI source device (e.g. a computer) to the
HDMI input port of the Encoder. Optionally connect a Local
Display to the Output port of the Encoder.
Connect HDMI display devices to the HDMI output port of
the Decoder devices.
RS-232
Optionally for RS-232 serial transmission: connect the
desired devices (e.g. a Touch Control, Relay Box) to the
RS-232 ports by the supplied serial cables.
USB
Optionally for USB extension: connect USB devices to
the USB ports of the Decoders. Connect the desired host
device (e.g. Computer) to the Encoder via the USB mini-B
type port. Please pay attention to the indicated port types
(USB 1.1 and USB 2.0 support)
Power
Connect the power cord of the supplied adaptor to the DC

CATx
Connect a computer to the L3 Switch; thus, you can
connect to any VINX extender and arrange the necessary
settings easily.
HDMI
HDMI
RS-232
USB
HDMI
HDMI HDMI
HDMI
Local Display
Computer
Encoder
Decoder
Decoder
Laptop
Decoder
Decoder RS-232
Relay Box
Keyboard
Touch Panel
USB Mass
Storage Drive
Video
Wall
L3 Network Switch
POWER
VIDEO
MODE
HDMI
(LOCAL OUT)
ACT.LINK
1GbELAN
(AV OUT)
8-4-2-1
VIDEO
STREAM ID
ON DIP
1 2 3 4
POWER
VIDEO
USB
CONNECT
HDMI OUTPUT
ACT.
LINK
1GbELAN
(AVINPUT)
8-4-2-1
VIDEO
STREAM ID
ON DIP
1 2 3 4
POWER
VIDEO
USB
CONNECT
HDMI OUTPUT
ACT.
LINK
1GbELAN
(AVINPUT)
8-4-2-1
VIDEO
STREAM ID
ON DIP
1 2 3 4
POWER
VIDEO
USB
CONNECT
HDMI OUTPUT
ACT.
LINK
1GbELAN
(AVINPUT)
8-4-2-1
VIDEO
STREAM ID
ON DIP
1 2 3 4
POWER
VIDEO
USB
CONNECT
HDMI OUTPUT
ACT.
LINK
1GbELAN
(AVINPUT)
8-4-2-1
VIDEO
STREAM ID
ON DIP
1 2 3 4
RS-232
USB
CATx
CATx
2.2.3. Further Steps
Step 1. Connect a computer to the network to arrange the necessary
settings easily (see the Establishing the Connection section).
Step 2. Group the devices by the DIP switch or via the built-in website
(see the Video Status and Settings (Encoder) section).
Step 3. Select the desired Decoder for USB transmission (see the USB
Settings (Multicast Mode) section).
ATTENTION! Usually, an Ethernet switch needs more time to be
ready after powered on, than the VINX extenders. If the VINX devices
and the Ethernet switch are powered on at the same time, the VINX
devices may not get IP address and they cannot be accessed over
Ethernet. The solution is to power off the VINX devices and power
on again.






3. Product Overview VINX-1x0-HDMI Extenders – User's Manual 10
3
Product Overview

output ports and connectors
Ý
Ý
Ý
Ý
Ý
Ý
Ý
Ý
Ý
3.1. VINX Encoder Front and Rear View
WARNING! Always use the supplied 5V power adaptor. Warranty
void if damage occurs due to use of a different power source.
1 3 4 52
96 7 q8
1Status LEDs See the Front Panel LEDs section.
2Mode
Button
Short press (less, than 3 sec): switching
between Video and Graphics modes.
Long press (more, than 3 sec): reset to
factory default settings.
3HDMI


as the AV Output Port.
4 Linking Encoder and Decoder devices; for
more information see the DIP Switch section.
5AV Output


Decoder device or Network switch.
6DC 5V Input 5V DC input for local power supply.
7 RJ12 connector for transparent serial
communication (point-to-point or point-to-
multi point).
8 Mini B-type connector for USB pass-through
(IP KVM) application.
9HDMI Input

Video port for DVI or HDMI signal.
qIR Output

IR signal output connector (for 3.5 mm Jack,
3-pole, TRS plug).
3.2. VINX Decoder Front and Rear View
1 2 3 4 5
86 7 9
1Status LEDs See the Front Panel LEDs section.
2Connect
Button
Short press (less, than 3 sec): acquire USB
connection (only in Multicast mode)
Long press (more, than 3 sec): reset to
factory default settings.
3HDMI

HDMI output to a sink device.
4 Linking Encoder and Decoder devices; for
more information see the DIP Switch section.
5AV Input


the Encoder device or Network switch.
6DC 5V Input 5V DC input for local power supply.
7 RJ12 connector for transparent serial
communication (point-to-point or point-to-
multi point).
8 USB 1.1 and 2.0 compatible A-type ports
for transmitting USB HID devices in Unicast
mode. USB 1.1 port can be used for changing
the video stream by a keyboard, see the
Keyboard Shortcuts section.
9 IR signal input connector (for 3.5 mm Jack,
3-pole, TRS plug).






3. Product Overview VINX-1x0-HDMI Extenders – User's Manual 11
3.3. Electrical Connections
1 GbE LAN
The devices provide standard RJ45 connectors for
  . Always use
high quality Ethernet cable for connecting Encoders and
Decoders.


T 568 B standards:

The devices are assembled with standard 19-pole
HDMI connectors for inputs and outputs. Special
HDMI cables can be fastened to the housing by the
nut.

The devices contain a standard RJ12 connector which is
used for RS-232 serial connection. The port can be used to
connect serial devices by using the supplied serial cables.
Please see the RS-232 Interface section for more details.

The USB ports allow USB extension. The Encoder is
assembled with USB mini-B type port (connecting a
computer), and the Decoder device contains two USB
1.1 and two USB 2.0 compatible A-type port. For more
information about the USB extension see the USB Interface section.
  Wire Color  Wire Color
1 
2green orange
3 
4blue blue
5 
6orange green
7 
8brown brown
3.4. 

▪OFF: the device is not powered.
▪BLINKING: booting is in progress.
▪ON: the device is powered on.
VIDEO LED
▪OFF: there is no network connection.
▪BLINKING: the device is connected to a network but there is no
video stream in progress.
▪ON: the device is connected to a network and video stream is in
progress.

▪OFF: there is no USB transmission between the Encoder and the
Decoder.
▪ON: the USB transmission is active between the Encoder and
the Decoder.

▪BLINKING together: there is a Video Stream ID clash in the network,
e.g. another Encoder is set to the same Video Stream ID.
3.5. 
The DIP switch can be used to set the Video Stream ID manually (HW
setting). The interpretation of the DIP switch values can be found in
the DIP Switch States section; please see the examples below:
POWER
VIDEO
USB
3.6. VINX Device Concept

an Encoder to many Decoder devices. The number of the Encoder and
Decoder devices is 'limited' to 100 within a system. The video wall can
be expanded at a later time, e.g. building a wall with 12 Decoders and
add further 12 Decoders later. Another feature is the transmission of
RS-232, USB and Infrared signals.

A Decoder is connected to an Encoder device.

Many Decoder devices are connected to the same Encoder.
The USB transmission is available only at one Encoder-Decoder
connection at the same time. The desired device can be activated by
the front panel button or via the built-in website.
Audio /
Video
Signal Unicast mode Multicast mode
RS-232
IR
Encoder Decoder
USB
E E
E
E
E
E
D
D
D
D
D
D
D
D
E
D
D
D
E
D
D
D
E
D
D
D
 Video Stream ID 
DipSwitch value
Set by Value
8-4-2-1
VIDEO
STREAM ID
1 2 3 4
ON DIP SW setting see the
built-in web 0x0
8-4-2-1
VIDEO
STREAM ID
1 2 3 4
ON DIP HW setting 1 0x1
8-4-2-1
VIDEO
STREAM ID
1 2 3 4
ON DIP HW setting 8 0x8






3. Product Overview VINX-1x0-HDMI Extenders – User's Manual 12
3.7. Video Interface
The following sections describe the modes of the video transmissions.
When the necessary network settings are arranged, the followings
have to be set:
Video Stream ID Setting
DEFINITION: The Video Stream ID is a four-digit number sequence
         
received by a Decoder.
The Video Stream ID creates the connection between an Encoder and
a Decoder. Set the Video stream ID to the same value in the desired
VINX devices:
▪Use the DIP switch and set a value other than '0000', or
▪Set the DIP switch built-in web
page, see the Video Status and Settings (Encoder) section, or
▪Set the DIP switch         
necessary LW3 command to the device, see the Setting up a
Video Wall (Example) section.
INFO: The DIP switch state can be ignored by an LW3 command,
see the Ignoring the DIP Switch section.

DEFINITION: The Unicast mode means an Encoder and a Decoder
are connected directly.
DEFINITION: The Multicast mode means Encoder(s) and Decoders
are connected via a switch in a Local Area Network (LAN).
Set the desired working mode of the extenders by:
▪Selecting the mode via the built-in web page, see the Advanced
Settings section, or
▪Sending the necessary LW3 command to the device, see the
 section.
3.7.1. 
The Encoder and the Decoder devices are arranged in a LAN by
connecting them to an L2 or L3 switch. Setting the extenders to Unicast
mode it is possible to extend the video signal by an Encoder to a
dedicated Decoder.
INFO: The Encoder and the Decoder can be connected directly and

but there is no way to communicate with other VINX devices.
Encoder Decoder
Encoder Decoder
Encoder Decoder
Encoder Decoder
L2/L3 Switch
Displayed images of the Sinks connected to the Decoders
3.7.2. 
The Encoder and Decoder devices are arranged in a LAN by connecting
them to an L3 switch. Setting the extenders to Multicast mode a certain
video can be extended from an Encoder to multiple Decoders.
Video Wall Montage
Tiled Video Wall
Encoder Decoder
Encoder Decoder
Encoder Decoder
Encoder Decoder
L3 Switch






3. Product Overview VINX-1x0-HDMI Extenders – User's Manual 13
3.7.3. Layout Examples
Multicast Mode with Video Wall
The Layout
Features
▪
are installed (bottom row).
▪Any of the video signals can be displayed on the wall and on a
single display device.
▪The other video signal can be seen on the other display device.
▪The video signal on the wall can be changed by using software
tools (built-in web or LW3 protocol commands).
Legend
L3 Switch
E
WWWW
DDDDDD
E
EEncoder
Decoder
The Decoder is assigned to a Video wall
D
W
Two Video Walls and Local Monitors with One Encoder
The Layout
Features
▪         
displays are installed (e.g. the video walls and the local displays
are located in different rooms).
▪One video signal is displayed on the two video walls and on two
local monitors.
E
L3 Switch
W W W W W W W W
DDDDDDDDDD
Small View and Large View Combined in Multicast Mode
The Layout
Features
▪
are installed (bottom row).
▪Any of the video signals can be displayed on the wall and on a
single display device.
▪The other video signals can be seen on the single display
devices (bottom row).
▪The video signal on the wall can be changed by using software
tools (built-in web or LW3 protocol commands).
L3 Switch
E
WWWWWWWWWWWW
DDDDDDDDDDDDDDDD
EEEE






3. Product Overview VINX-1x0-HDMI Extenders – User's Manual 14
3.8. USB Interface
USB 1.1 and USB 2.0 data transmission works between an Encoder and a
certain Decoder device. Connect the host device (e.g. a computer) to the
Encoder and the USB devices to the Decoder. Supported USB devices:
▪USB HID devices: keyboard, mouse, presenter.
▪Mass storage devices: 
The transmission works in Unicast and Multicast mode as well, but
in latter case the desired Decoder has to be selected by any of the
following ways:
▪Pressing the Mode button on the front panel for less, than 3
seconds (the connected display device will show Starting USB,
the other Sinks will show Stopping USB),
▪Pressing the Acquire USB connection button in the Advanced tab
on the built-in web page (see the USB Settings (Multicast Mode)
section), or
▪Sending an LW3 command to the desired Decoder.
The USB devices connected to the other Decoders will be still powered
but the data transmission is suspended.
ATTENTION! USB 1.1 ports can be used for the stream changing,
see the Keyboard Shortcuts section.
ATTENTION! The active Decoder works like an extended USB hub
connected to a computer. Please pay attention for the storage
device to remove safely before unplugging it or interrupting during
a disc operation.
INFO: The USB transmission is automatically enabled between the
Encoder and the Decoder in Unicast mode.
USB Transmission between an Encoder and a Decoder
Encoder DecoderComputer
Decoder
Decoder
Decoder
L3 Switch




Keyboard
Presenter
Flash drive
Mouse
3.9. RS-232 Interface
Serial data transmission works between an Encoder and all the
connected Decoders which have the same Video Stream ID. This
   
Multicast). To connect serial devices please use the cables supplied
with the extenders.
ATTENTION! The serial data is transmitted only if video is
transmitted between the affected devices.

DEFINITION: The Pass-through mode means fully transparent
bidirectional data transmission from an RS-232 port of a VINX
Extender to an RS-232 port of a VINX Decoder – and Vice versa.
All data received from the serial ports of the Decoders is transmitted
to the serial port of the Encoder and vice versa: the data received from
the serial port of the Encoder is transmitted to the serial ports of all
connected Decoders.
RS-232 Data Transmission (Pass-through mode)
Please note that transmitting data between two Decoders is not
          
Control to the Projector is not possible.
ATTENTION! The data transmission works only if the serial port
parameters are set to the same values in all devices: serial data

Encoder DecoderComputer
Decoder
Decoder
Decoder
L3 Switch


Touch control
Projector
Command Injection Mode
DEFINITION: The Command Injection mode
bidirectional converter.The mode allows data transmissionbetween


from a computer) and a serial device is connected to the RS-232 port
of a VINX device they can communicate with each other.
RS-232 Data Transmission (Command Injection mode)
The mode can be enabled as described in the Setting the RS-232 Port
Mode section.
Encoder Decoder
Computer
Decoder
Decoder
L3 Switch


Touch control
Projector






4. Software Control - Using the Built-in Website VINX-1x0-HDMI Extenders – User's Manual 15
4
Software Control - Using the Built-in Website
The VINX extenders allow setting all the parameters via a user-friendly
           
          
settings. The features of this built-in web are described in these sections.
Ý
Ý
Ý
Ý
Ý
TIPS AND TRICKS: To get the best visibility of the screenshots in
this chapter adjust the zoom setting of your PDF Reader software

4.1. Establishing the Connection
ATTENTION! The supported web browsers are Google Chrome and
Mozilla Firefox.
INFO: The default setting of the IP address is dynamic (DHCP).
Step 1. 
the steps described in the Connecting Steps section.
Step 2. Connect a suitable control device (e.g. computer, mobile
device) to the same network.
Step 3. Open the web browser and type the IP address of the desired
VINX device in the address line. If the IP address is not known
use the MAC address (written on the housing of the device):
a) Connecting to an Encoder: 

Connecting to a Decoder: 

b) The factory default IP address is Dynamic (DHCP). Check
the list of the connected devices (DHCP client list) in the
DHCP server and note the IP address (or the MAC address
and connect to the device as written in paragraph 'a').
INFO: When you successfully connected to an Encoder, all the other
counterpart devices will be listed in the Main settings tab (General
section).
4.2. The Main Window
4.2.1. General Settings
Grouping the VINX Extenders
Video Stream ID
    

▪When the DIP switch is in 0000 position the SW setting will be
valid or else the HW setting (DIP switch) will be valid.
▪When the DIP switch is set back to 0000 the SW setting will
inherit the ID (the previous DIP switch value).
▪SW setting and HW setting can be combined within the group
but in this case the DIP switch value will determine the common
Video Stream ID.
INFO: The DIP switch state can be ignored by an LW3 command,
see the Ignoring the DIP Switch section.
Decoder Assignment
The list contains the VINX devices which are available within the same
subnet. Mark the desired devices to set the same ID.
The Main Window of the Built-in Website
(Displayed on a Mobile Device)
Device Label
Unique name (up to 32 ASCII characters) can be set which will be
visible when the given device is listed in the built-in web page of other
VINX devices. Furthermore, the name is listed when browsing the
client list of a DHCP server.
ATTENTION! It might happen that two or more Encoders installed in
the same system with the same Video Stream ID. That would result
display problems (e.g. more mouse cursors are displayed when
desktop images are shown). Check the Video Stream ID settings of
the Encoders.
The current
working mode
The Video
stream ID is
set by the DIP
switch
The given
Decoder
belongs to a
video wall
Displaying the
Main Menu
(if there is not
enough space)
Connecting to
another device
(opened in new
tab)
UNICAST
DIP SWITCH






4. Software Control - Using the Built-in Website VINX-1x0-HDMI Extenders – User's Manual 16
4.2.2. 
The properties of the incoming and outgoing video signals are
displayed with the followings:
▪The emulated EDID can be selected (see the EDID Operations
section).
▪
▪Selecting the video quality (see below).
▪Displaying the Frame Detector in a new window, see the Frame
Detector section.
ATTENTION! If the HDCP setting is changed a window will pop up
        
when clicking Yes.
ATTENTION! The EDID information cannot be read by the source
attached to the HDMI input of an Encoder if HDCP is disabled on the
input. That may stop the video transmission in the case of certain
source devices.

When the network bandwidth is not enough to transmit the video
signal the following modes are available in the Encoder:
▪Video mode (Lower image quality @ Less bandwidth): The image
quality is adjusted to the available bandwidth. If the bandwidth
is decreased the image quality will be lower, but the video
streaming is continuous.
▪Graphics mode (Best image quality @ High bandwidth): The image
quality is kept at a high level. If the bandwidth is decreased the
image quality does not change, but frame drop may appear.
The setting has an affect when the available bandwidth is less than
required.
Video Bandwidth Settings
affects
only the video signal transmission. The following values are available:

The Auto setting is the default value which means: the available

ATTENTION! If the Bandwidth setting is changed a window will pop

when clicking Yes.
The Main Window of an Encoder
(Displayed on a Computer)






4. Software Control - Using the Built-in Website VINX-1x0-HDMI Extenders – User's Manual 17
4.2.3. 
The content of the window is almost the same as in the case of the
Encoder. The addition is the Scaler settings which is also available on
the Advanced Settings page.
DEFINITION: Scaling a video signal means changing the image

the appearance of the image.
Scaler settings
The outgoing video signal can be set in each Decoders separately.
Output Scaling
▪Pass-through: the resolution, the refresh rate, and the type of the
outgoing and incoming signals are the same.
▪Auto detect from EDID: the resolution of the outgoing video is
scaled to meet with the preferred timing coming from the EDID
of the connected display device.
▪Custom: a wide range of the scaling resolutions are available
from 640x480 till 4096x2160.
Output Standard
When the Output scaling is set to Custom, the outgoing signal can be
set to DVI or HDMI.

The following options are available:
▪No rotation,
▪Flip vertically,
▪Flip horizontally,
▪Rotate 90 degrees,
▪Rotate 180 degrees,
▪Rotate 270 degree.
4.2.4. Network Settings
The factory default IP address of the extender is set to get it from
the DHCP server in the network. The drop-down list and the further
parameters allow changing the network settings to the desired value.
ATTENTION! When the desired Network parameters are set, press
the Apply changes button; the device will reboot.
ATTENTION! Please use the port number 6107 for connecting to
the device directly from a third-party application (e.g. a terminal
software or other controller application).
The Main Window of a Decoder (Displayed on a Computer)






4. Software Control - Using the Built-in Website VINX-1x0-HDMI Extenders – User's Manual 18
4.2.5. Frame Detector
The ports can show detailed information about the signal like blanking intervals and active video resolution.
This feature is a good troubleshooter if compatibility problems occur during system installation. Lightware’s
Frame Detector function works like a signal analyzer and makes possible to determine the exact video
format that is present on the port, thus helps to identify many problems. E.g. actual timing parameters may
differ from the expected and this may cause some displays to drop the picture.
Frame Detector measures detailed timings on the video signals just like a built-in oscilloscope, but it is
much more easy to use. Actual display area shows the active video size (light grey). Dark grey area of the
full frame is the blanking interval which can contain the info frames and embedded audio data for HDMI
signals. Shown values are measured actually on the signal and not retrieved only from the HDMI info frames.
Frame Detector (Opened in a New Tab)
4.3. EDID Menu
DEFINITION: The Extended Display Identication Data (EDID) is the passport of the display devices. It contains
information about the capabilities of the display, such as supported resolutions and audio formats, refresh
rates, the type and the manufacturer of the display device, etc.
See more information in the EDID Management section.
Advanced EDID Management is available in the Encoder. Navigate to the EDID menu. There are two panels:
the left contains the Source EDIDs, the right panel contains the Destination places where the EDIDs can be
emulated or copied.
4.3.1. The EDID Memory Structure
The EDID memory consists of four parts:
▪Factory EDID list shows the pre-programmed EDIDs (F1-F132).
▪Decoder EDID list shows the EDIDs of the display devices connected to the assigned Decoders. The
Decoders store the last display devices’ EDID on the HDMI output, so there is an EDID shown even if
there is no display device attached to the output port at that moment.
▪User memory locations

▪Emulated EDID shows the currently emulated EDID for the HDMI input port of the Encoder. The source
column displays the memory location that the current EDID was routed from.






4. Software Control - Using the Built-in Website VINX-1x0-HDMI Extenders – User's Manual 19
4.3.2. EDID Operations
Changing the Emulated EDID
Step 1. Choose the desired EDID list on the source panel and select an EDID.
Step 2. Select the Emulated tab on the Destination panel.
Step 3. Select the desired port on the right panel.
Step 4. Press the Transfer button to change the emulated EDID.
Learning an EDID
The process is the same as changing the emulated EDID; the only
difference is the Destination panel: select the User tab. Thus, one or
more EDIDs can be copied into the user memory.
Exporting an EDID

Step 1. Select the desired EDID from the Source panel.
Step 2. Press the Export
Importing an EDID

Step 1. Select the User tab on the Source panel and select a memory slot.
Step 2. Press the Import button below the Source panel.
Step 3.           Open
          
selected User memory.
ATTENTION! The new EDID overwrites the selected memory place.

The EDID(s) from the User memory can be deleted as follows:
Step 1. Select the User tab on the Destination panel.
Step 2. Select the desired memory slot(s); one or more can be selected
(Select All and Select None buttons can be used).
Step 3. Press the Clear selected button to delete the EDID(s). The EDID Menu of the Built-in Website
Control Buttons


Executing EDID emulation or copying
(Transfer button)
Clearing the selected EDID from the User
memory
Selecting all memory places in the right
panel
Selecting none of the memory places in the
right panel






4. Software Control - Using the Built-in Website VINX-1x0-HDMI Extenders – User's Manual 20
4.4. Advanced Settings
4.4.1. 
The submenu contains two tabs: Multicast and Unicast. The currently
valid mode is highlighted with yellow. Press the desired button to
choose the mode and access the settings.
ATTENTION! When the mode is changed the device must be

Network Settings
For the details please see the Network Settings section.
Upgrade Firmware
For the details please see the Firmware Upgrade section.

See the LW3 Terminal section (next page).
RS-232 Settings
The RS-232 serial data transmission is fully transparent between the
Encoder and the connected Decoder devices. All data received on
the serial port of the Decoders is transmitted to the serial port of the
Encoder and vice versa: the data received on the serial port of the
Encoder is transmitted to the serial port of all connected Decoders.
ATTENTION! The data transmission works only if the serial port
parameters were set to the same values in all the devices: serial

See more information in the RS-232 Interface section.

The Encoder displays the name of the currently connected Decoder.
The Decoder displays if the USB connection is established; press the
button to acquire the connection if needed.
The Advanced Settings Menu of an Encoder in Multicast Mode




