Lightware TPS-PI-1P1 User manual

www.lightware.eu Document revision: v1.0
For technical support contact [email protected]
TPS-PI-1P1
Quick Start Guide
Introduction
TPS-PI-1P1 is an IEEE 802.3at compatible high end remote Power Injector (PI) unit providing
power to a remote Powered Device (PD) e.g. TPS transmitter or receiver. The TPS-PI-1P1
placed in the TPS transmission chain, anywhere between the transmitter and the receiver
unit via the CATx* cable is able to power a TPS device. The incoming data stays untouched,
but a 48V DC remote power is added to the signal by this PI.
* CAT7 AWG 23 SFTP cable is always recommended.
Info: Remote powering of the 95 series HDMI-TPS and DVI-HDCP-TPS devices is not available
by the TPS-PI-1P1 power injector.
Info: Comparing to the details of the powered device’s extension distance chart the usage of
the TPS-PI-1P1 may cause approximately 20% distance decrease depending on the
powering mode (local or remote) and cable quality.
Typical application
PI is used for only remote powering
PI supplies both devices with power
This unit provides a uni-directional remote power only, but thanks to the 12V DC local output
option the other device (e.g. HDMI-TPS-RX95) can be powered with the TPS-PI-1P1 if they
are placed close to each other. Powering of the injector itself is provided by its own included
power adaptor.
Front and rear view
Installation
1. Turn off (disconnect) all units, even the video, audio or data devices. Make sure there are no
powered units during the installation.
2. Connect the TPS device to be remote powered (e.g. UMX-TPS-TX140) to the TPS+PoE
connector (2) of the TPS-PI-1P1 Power Injector with a CATx cable.
3. Connect the TPS device to be local powered (e.g. HDMI-TPS-RX95) to the TPS connector 3)
of the TPS-PI-1P1 Power Injector with a CATx cable.
4. Connect the desired video, audio and data devices (e.g. Blu-ray players, amplifiers, Ethernet
switch, RS-232 controller, IR transmitter) to the TPS units. Please read the manuals of all
devices to get help during the installation process.
5. Turn on the devices according to the following sequence:
5a. The Power Injector with connecting the 48V DC adaptor to the 48 DC IN connector.
The remote device e.g. UMX-TPS-TX140 gets power immediately.
5b.The local powered device
▪with connecting its adaptor or
▪with connecting the supplied patch cable* to the 12V DC OUT (5) of the Power Injector.
5c. Turn on the other devices with methods which are mentioned in theirs user’s manuals.
* CAB-12V-U16U (Part No: 13730013)
Info: The maximum distance of the TPS units will not expand by using TPS-PI-1P1.
Warning! Always use the supplied power adaptors. Warranty void if damage occurs due to use
of a different power source.
Status LEDs
1
12V DC OUT
5
48V DC IN
4
TPS port (not powered)
3
TPS port (powered)
2
5
3
2
4

www.lightware.eu Document revision: v1.0
For technical support contact [email protected]
TPS-PI-1P1
Quick Start Guide
Status LEDs
TPS-PI-1P1 has four front panel LED indicators for monitoring of the operation and
troubleshooting.
POWER OVERLOAD: [Red]
▪ON: The delivered power of the wall adaptor exceeds 75% of the maximum value.
▪OFF: The delivered power of the wall adaptor is less than 75% of the maximum value.
Info: TPS-PI-1P1 does not apply current limitation but only indicates the overload.
12V DC OUT ACTIVE: [Green]
▪ON: The 12V DC out is able to power a local device
▪OFF: The 12V DC out is out of order.
Info: The 12V DC out cannot be disabled in normal operation. If it is not working please
contact Lightware technical support team.
REMOTE POWER OUT ACTIVE: [Green]
▪ON: The remote unit is a valid PoE device and gets the power via the TPS line.
▪OFF: There is no PoE compliant device at the remote side or the identification process
was unsuccessful. The Power Injector does not send power over the CATx cable in this
case.
48V DC IN PRESENT: [Green]
▪ON: The 48V DC input is connected, and the voltage level is proper, higher than 40V DC.
▪OFF: The 48V DC input is not connected. If it is connected, the voltage level is not
enough for the proper operation (it is lower than 40V DC).
Info: The appropriate operation of the unit is not guaranteed with 40V DC or lower input
voltage. In this case if the identification and the classification were successful, the
TPS-PI-1P1 switches the inadequate voltage to the TPS line, but the remote powering
can be failed. Always use the supplied power adaptors of the devices.
Supplied accessories
▪12V patch cable for the local power option (CAB-12V-U16U Part No: 13730013)
▪48V DC power adaptor
Compatible product
▪UMX-TPS-TX120
▪UMX-TPS-TX130
▪UMX-TPS-TX140
▪WP-UMX-TPS-TX120-US
▪WP-UMX-TPS-TX130-US
▪SW4-TPS-TX240
The power scheme
Warning! The sum of the power of the two outputs must be under 30W.
Locking DC plug
DC cables from Lightware contain locking DC connector that establishes robust and safe
power connection. After plugging it in, turn the plug clockwise as you can see on the
following figure.
Info: Do not forget to turn the plug counterclockwise before trying to disconnect the cable.
Cooling
The enclosure of the TPS-PI-1P1 has vent holes on the left
and the right side, as well. These holes provide the cooling by
convention.
Warning! Do not block the vent holes otherwise the unit can be overheated.
