LIGMAN NEON Series Manual

For Installation of NEON ARC Continuous LED Solution IP67 (24VDC)
24VDC
M ITNO1230001067-VB/16/12/19/REV.0
IP67
ALWAYS UNCOIL BEFORE USE
Actual product characteristics may vary. Ligman Lighting reserves the right to improve, modify or update the product designs without prior notice.
Please note drawings are an installation guide only. Each LED tape application may have variable factors. Cable size may need to be specified to limit the voltage drop throughout the circuit.
17
16
VERTICAL BENDING
MINIMUM
BEND RADIUS
150mm
COLOUR NEON SERIES
WARM WHITE
3000K +/- 175K NEON 1
NATURAL WHITE
4000K +/- 275K NEON 1
2500 - 5000K
TUNEABLE WHITE NEON 2
RGB NEON 3
RGBW NEON 4
RGB DYNAMIC NEON 18
ELECTRICAL & OPTICAL DATA VARIANCE +/- 10%
SOLD BY THE METRE
IES FILES AVAILABLE
NEON ARC │ELECTRICAL AND PHYSICAL INSTALLTION GUIDE
VARIANT CODE
ITNO1230001067-VB
ITNO1240001067-VB
ITNO12TUW01067-VB
ITNO12RGB00567-VB
ITNO15RGBW0567-VB
ITNO16RGB00567-HB

LIGHT SURFACELIGHT SURFACE
DO NOT TWIST THE LIGHT OR BEND
AGAINST THE LIGHT SURFACE
- Avoid bending LED Neon within the first unit (units are
clearly marked with dashed lines on the sides of the product)
- LED Neon can be bent upto the defined
“minimum bend radius” (150mm for Neon Arc)
150mm
BENDING PARAMETERS
M ITNO1230001067-VB/16/12/19/REV.0
NEON ARC CAN BE CURVED
AS SHOWN BELOW

– LED Neon must always be used in conjunction with a
– Check the polarity of the connector before inserting the front
connector and switching on the mains power.
– To minimise voltage drop and ensure consistent light output,
position the power supply near to the power feed end of the
LED Neon, and keep the line as short as possible
– Ensure your maximum run per power feed adheres to the
– Ensure to add 20% buffer when selecting a power supply
– Before making any cuts, installation, maintenance, or
connection, be sure the mains power is disconnected.
– If essential; cut and connect LED Neon correctly. Any
incorrect operation can cause damage.
– All connector joints must be connected correctly to
achieve connector IP rating.
WIRING DIAGRAMS
RGBW
RGB
POWER SUPPLY RGB CONTROL
green wire: “G” terminal (-)
blue wire: “B” terminal (-)
yellow wire: +
red wire: “R” terminal (-)
24V DC
TUNEABLE WHITE
POWER SUPPLY 2-CHANNEL
CONTROL
black wire: Cool White connection (-)
red wire: +
yellow wire: Warm White connection (-)
24V DC
WHITE
POWER SUPPLY RGBW CONTROL
green wire: “G” terminal (-)
blue wire: “B” terminal (-)
white wire: “W” terminal (-)
yellow wire: +
red wire: “R” terminal (-)
24V DC
DYNAMIC RGB ‘CHASING’
POWER SUPPLY DIMMER
optional black wire: -
red wire: +
24V DC
DMX OPTION AVAILABLE
black wire: “GND”, Cathode (-) terminal
red wire: “VCC”, Anode (+) terminal
yellow wire: “Signal” terminal
POWER SUPPLY INDEPENDENT
SPI CONTROL
24V DC
M ITNO1230001067-VB/16/12/19/REV.0

PROFILE INSTALLATION REQUIREMENTS
– Ensure the supply cord is not subject to mechanical stress
–
–
– Avoid placing mechanical stress on the front connector cable
– Do not curl or bend the front connector cable with excessive force
–
–
PULL
M ITNO1230001067-VB/16/12/19/REV.0

SNAP CONNECTIONS - IP67
TOP END FEED END CAP FLEXIBLE
CONNECTOR
WHITE
TUNEABLE ---
RGB ---
RGB CHASING ---
RGBW ---
NEON ARC | CONNECTIONS
300mm
SNAP TOP END FEED CONNECTOR SNAP END CAP SNAP FLEXIBLE CONNECTOR
SUITABLE FOR OUTDOOR APPLICATIONS
MUST BE FITTED CORRECTLY FOR IP67 RATING
FEED CONNECTORS SUPPLIED AS 1M CABLE
STANDARD, CHECK WITH BRIGHT LIGHT FOR
ALTERNATE LENGTHS
M ITNO1230001067-VB/16/12/19/REV.0

SIDE FEED BOTTOM
FEED
TOP END
FEED
MIDDLE FEED END CAP FLEXIBLE
CONNECTOR
T FEED
WHITE
TUNEABLE
RGB
RGB CHASING -
RGBW -
SLIMLINE INJECTION MOULDING CONNECTIONS - IP67
SIDE FEED
END CAP FLEXIBLE CONNECTOR
BOTTOM FEED
T-FEED
TOP END FEED MIDDLE FEED
300mm – 1000mm
150mm – 500mm 150mm – 500mm
300mm – 3000mm
NEON ARC | CONNECTIONS
REQUIRES FITTING AT FACTORY. LEAD
TIMES APPLY
SUITABLE FOR OUTDOOR APPLICATIONS
FEED CONNECTORS SUPPLIED AS 1M
CABLE STANDARD, CHECK WITH BRIGHT
LIGHT FOR ALTERNATE LENGTHS
M ITNO1230001067-VB/16/12/19/REV.0

CAPPED DUAL INJECTION MOULDING - IP68
SIDE FEED BOTTOM FEED TOP END FEED END CAP FLEXIBLE
CONNECTOR
WHITE
TUNEABLE
RGB
RGB CHASING
RGBW
SIDE FEED
TOP END FEED
FLEXIBLE CONNECTOR
BOTTOM FEED
END CAP
21mm
2m m2m m
15mm
20mm 50mm
20m m
10mm
2m m
2m m
20mm
30mm
12 mm
4m m
2m m
2m m
2m m
42mm
27mm
22mm 20mm
3m2 m
51mm
4m m
23mm
20mm
42mm
27mm
15mm
mm34
mm32
mm02
m2 m
m2 m m2 m
4m m
NEON ARC | CONNECTIONS
REQUIRES FITTING AT FACTORY. LEAD TIMES APPLY
SUITABLE FOR OUTDOOR APPLICATIONS
FEED CONNECTORS SUPPLIED AS 1M CABLE
STANDARD, CHECK WITH BRIGHT LIGHT FOR
ALTERNATE LENGTHS
300mm
M ITNO1230001067-VB/16/12/19/REV.0

ACCESSORY L1 L2 HOLE
DIMENSIONS
HOLE
NUMBER
SELF-LOCKING ALUMINIUM PROFILE 2m 100mm 200mm Ø3.5mm 10
SELF-LOCKING ALUMINIUM V2 MOUNTING CLIP 35mm 5mm 25mm Ø3.5mm 2
PLASTIC PROFILE 2m 100mm 200mm Ø3.5mm 10
PLASTIC PROFILE 1m 100mm 200mm Ø3.5mm 5
NEON ARC | MOUNTING ACCESSORIES
SELF-LOCKING ALUMINIUM
V2 MOUNTING CLIP
SELF-LOCKING ALUMINIUM
PROFILE
PLASTIC PROFILE 2M
19
21
L1 L2
20.7
22.3
20.5
20
M ITNO1230001067-VB/16/12/19/REV.0
