SP-135T WIRE FEEDER/WELDER
SP-135T is a lightweight, compact 120V
wire feeder/welder and breezes through
MIG welds on a wide range of materials
including mild steel, stainless steel and
aluminum. Handles flux-cored welds on
mild steel with ease. Practically every-
thing you need to MIG weld mild steel is
right in the box. Unit includes: • 4-Step
Tap voltage control • Magnum® 100L
welding gun and 10ft. (3m) cable
assembly, with gas nozzle, .023” - .035”
(0.6–0.9mm) cable liner and .023/.025”
(0.6mm) contact tip • 10ft. work cable & work clamp • 6 ft input power cord
with NEMA Type 5-15P plug • Guide tubes and reversible drive roll for
.023-.035" solid MIG wire and .035" Innershield® flux-cored wire • Factory
installed gas solenoid valve • Adjustable gas regulator and hose for Argon
and Argon-blend gases • 2 lb. spool of .025" SuperArc L-56 mild steel MIG
wire • 6 spare .023/.025" contact tips • Welding handshield with #10 filter
plate and clear glass cover plate.
SP-135T....................P/N 12-00779 ..........$499.95
SP-135T One-Pak Package - includes SP-135T welder an dK2275-1 Utility
cart. Assembly required...............................P/N 12-00780 ..........$568.00
Deluxe adjustable gas regulator & hose kit ....P/N 12-00781 ..........$112.95
Welding Cart (80 cu. ft. bottle cap.) ..............P/N 12-00777 ............$81.50
Utility Cart (150 cu. ft. bottle cap.) ................P/N 12-00773 ..........$170.95
SP-135 PLUS WIRE FEEDER/WELDER
This user-friendly wire feeder/welder is
ready to help you make short work of many
around-the-home jobs, hobby projects,
autobody repairs or farm chores! SP-135
Plus handles MIG welds on a wide range
of materials including mild steel, stainless
steel & aluminum. Flux-cored welds on
mild steel are a breeze. Achieve outstand-
ing perormance on thin sheet metal to
medium plate by fine-tuning the arc using
the continuous output voltage and
wirefeed speed controls. Also boasts industry leading output and arc per-
formance in the 115V machine class. To top it off, we’ve made it easy to
get started – virtually everything you need to MIG weld mild steel is includ-
ed in one convenient package! Just add shielding gas (sold separately).
SP-135 Plus ................................................P/N 12-00445 ..........$572.00
SP-135T One-Pak Package - includes SP-135 Plus welder & K2275-1 Utility
cart. Assembly required...............................P/N 12-00782 ..........$666.00
Deluxe adjustable gas regulator & hose kit ....P/N 12-00781 ..........$112.95
Welding Cart (80 cu. ft. bottle cap.) ..............P/N 12-00777 ............$81.50
Utility Cart (150 cu. ft. bottle cap.) ................P/N 12-00773 ..........$170.95
AC-225C STICK WELDER
This stick welding power source has
continuous output control and produces
a very smooth welding arc at any
amperage. The AC-225C can be used
for many welding applications such as
maintenance repairs, fabrication, modi-
fying equipment, and creating or
rebuilding tools, fixtures, or worn parts.
Features: • Easy Installation • Input power cable and plug included
Easy to Operate • Electrode holder and cable, work clamp and cable,
sample electrodes, welding helmet and welder's guidebook all includ-
ed • Easy to use controls •Convenient size to allow easy storage and
handling • 3 year warranty including parts and labor • Output: 170
amps, 25 volts, 20% duty cycle • Amp Range: 40-225 • Size: 15.2”h
X 14”w X 13.5”d • Weight: 86 lbs. • CSA approved • UL listed •
Powder Paint Finish for increased durabilty.
P/N 12-00772 ........$272.95
Utility Cart ..............................P/N 12-00773 ........$170.95
AC/DC 225/125 STICK WELDER
AC/DC 225/125 is the deluxe version of the
AC-225. The same design but enhanced
with the smoother, more stable DC welding
arc. This model gives you the flexibility to
use the AC arc for welding heavy plates or
the DC for thinner materials giving you a low
current, stable arc. The AC/DC 225/125 is
perfect for use in the home, on the farm,
shop, or for professional use.
Features: • Easy installation including input
power cable and plug • Electrode holder and
cable, work clamp and cable, sample electrodes, and welder's guide-
book all included • Easy to operate • Easy to use front mounted polar-
ity switch and full amperage selector switch for accurate procedure
setting. • 3 year warranty including parts and labor • Output: AC: 225
amps, 25 volts, 20% duty cycle • DC: 125 amps, 25 volts, 20% duty
cycle • Amperage range: AC 40-225, DC 30-125 • Size: 24”h X
17.3”w X 12”d • Wt: 129 lbs. P/N 12-00774 ........$467.95
Wheel Kit ................................P/N 12-00775 ..........$10.60
LINCOLN WELDERS
LINCOLN POWER MIG 140T & MIG 140C
Select the economical Power
MIG® 140T (K2470-1)with sim-
ple tapped voltage control for
basic MIG and flux-cored weld-
ing. Choose the Power MIG®
140C (K2471-1)with continu-
ous voltage control for more
critical projects where precise
adjustment is required. Either
way, Diamond Core
Technology™ and the rugged
drive system aid arc performance for MIG welding on thin gauge
steel, stainless and aluminum. Or, use gas-less flux-cored welding
for deep penetration on thicker steel, even outdoors! With a wide 30-
140 amp welding output range it is the highest output in 120 volt
input power welder class. MIG weld 24 gauge up to 10 gauge (.135")
sheet metal in a single pass. Unit Includes: • Magnum 100L weld-
ing gun (K530-6) • Six spare contact tips • Gas and gasless nozzles
• Work cable and work clamp • Adjustable gas regulator and hose
(for argon & Ar-blend gases) •.025 and .035 smooth drive rolls •.030-
.045 knurled drive roll •.025-.035 wire guide • 2 lb. spool .025" Super
Arc® L-56 wire • 1 lb. spool .035" Innershield® NR-211-MP self-
shielded flux-cored wire • 8" spool spindle adapter • How to Use
DVD.
Lincoln Power MIG 140T K2470-1................12-01624 ......$604.95
Lincoln Power MIG 140C K2471-1 ..............12-01623 ......$658.95
LINCOLN POWER MIG 180T & MIG 180C
The Power MIG® 180 will help
you get the job done! It’s a
portable wire welder designed
for use with industrial 230 volt
input power, so you can weld
on thicker material — up to
3/16" with MIG welding and
1/2" with gas-less flux-cored
welding. Select simple tapped
voltage control on the Power
MIG® 180T for basic welding
jobs or continuous voltage control on the Power MIG® 180C for
more critical projects where precise adjustment is required
Unit Includes:• Magnum 100L welding gun (K530-6). • Six spare
contact tips. • Gas and gasless nozzles. • Work cable and work
clamp. • Adjustable gas regulator and hose (for argon & Ar-blend
gases). •.025 and .035 smooth drive rolls. •.030-.045 knurled drive
roll. •.025-.035 and .045 wire guides. • 2 lb. spool .025" Super Arc®
L-56 wire. • 1 lb. spool .035" Innershield® NR-211-MP self-shielded
flux-cored wire. • 8" spool spindle adapter. • How to Use DVD
Lincoln Power MIG 180C K2473-1 ..............12-01625 ......$807.00
Lincoln Power MIG 180T K2472-1................12-01626 ......$738.95
