Lindgaard Pedersen E-Cruise User manual

Page 1 / 4
Installation instructions for
Toyota Avensis model 2015 -
Signals on CAN: Brake - RPM - VSS
-Cruise
-Cruise
e
If the vehicle is equipped with automatic transmission:
The E-Cruise must be programmed.
See trouble shooting guide - "Test 6 - Setup to Automatic gear",
or order Partno. 1609500 and download "Cruise Toolbox" for Android from Google Play.
1605259 Rev. 1.1

Some good advice.
· Always disconnect the negativ cable from the battery, before installing.
· Always use the enclosed installation instruction for installing the E-Cruise.
· The rev. number on the unitlabel and the installation guide must be the same.
· Be aware that eg. radio code might has to be typed in.
· Find a location to install the unit and control switch.
· If any wire(s) left, then cut off and insulate.
· Only use multimeter to measure.
· Always drive the car for a complete test, before assemble the car.
· Flying lead(s) must be soldered.
· All wire connections are viewed from wire side.
To make the installationen easier, the complete installation instruction should
be read through, before the installation is started.
This installation instruction, contains information, how to install the E-Cruise,
which is not a Do-It-Yourself job.
Modern cars are equipped with electronic, which can be costly damaged by
inappropriate treatment.
Lindgaard · Pedersen A/S can not be held responsible, for any error caused
by wrong installation.
Check that all the parts are included in the kit.
1 pcs. Unit.
1 pcs. 14-p connector.
1 pcs. 2-p connector for OBD.
5 pcs. Cableties.
1 pcs. Installation guide.
1 pcs. Owners manual.
Before installation.
Page 2 / 4
E-Cruise Toyota Avensis model 2015 -
1605259 Rev. 1.1

Black connector behind combinatio meter
(Viewed from wire side)
Green
(CAN hi)
White
(CAN lo)
Black
Red
Black connector on accelerator pedal
Page 3 / 4
E-Cruise Toyota Avensis model 2015 -
1605259 Rev. 1.1

Red
Page 4 / 4
Connector below wiper switch
(Viewed from wire side)
Blue
(Ignition)
1A fuse
E-Cruise Toyota Avensis model 2015 -
1605259 Rev. 1.1
