Lindy 70408 User manual

© LINDY ELECTRONICS LIMITED & LINDY-ELEKTRONIK GMBH - FIRST EDITION (Jan 2009)
Manual English
LINDY No. 70406, 70407, 70408 & 70409
www.lindy.com

User Manual
70408 - Digital to Analogue Audio Convertor
Introduction
Thank you for purchasing the LINDY Digital to analogue audio convertor. This convertor allows
you to input digital audio through a coaxial or optical port and output analogue audio through
left and right phono ports. A switch on the side of the unit determines which digital input is
active
Specifications
•Input ports: 1 x TOSLink (Optical Fibre) & 1 x Coaxial
•Output ports: 2 x Phono (Left & Right)
•Integrated digital interpolator filter and Digital to Analogue Converter (DAC)
•Supports uncompressed digital stereo audio input
•Power Supply: 5VDC 0.5A
•Dimensions: (WxDxH) 46 x 46 x 23.5mm
•Weight: 30g
•Housing: Plastic
•Colour: White
Operation
Side View
1. Optical/Coaxial switch: The switch determines which input is active
2. Power: Plug 5VDC PSU (included) into the unit and connect to a wall outlet
Front Panel Rear Panel
1. Optical/Coaxial input: Connect your Optical/Coaxial audio equipment
2. L/R output: Connect to your analogue audio device input port

User Manual
70409 - Analogue to Digital Audio Convertor
Introduction
Thank you for purchasing the LINDY analogue to digital audio convertor. This convertor allows
you to input analogue audio through left and right phono ports and output digital audio through
Coaxial/optical ports. A switch on the side of the unit determines which digital input is active.
The output digital audio signal is a 2-channel uncompressed LPCM (Linear Pulse Code
Modulation) with a sampling rate at 48 KHz. Both Optical Fibre and Coaxial cables can be
connected at the same time and can run up to 5 meters while still provide reliable and lossless
audio signal transmission.
Specifications
•Input ports: 2 x Phono (Left & Right)
•Output ports: 1 x TOSLink (Optical Fibre) & 1 x Coaxial
•Supports uncompressed 2-channel LPCM (Linear Pulse Code Modulation) digital audio
signal output
•Supports output sampling rate at 48 KHz
•Power Supply: 5VDC 0.5A
•Dimensions: (WxDxH) 46 x 46 x 23.5mm
•Weight: 30g
•Housing: Plastic
•Colour: White
Operation
Side View
1. Power: Plug 5VDC PSU (included) into the unit and connect to a wall outlet
Front Panel Rear Panel
1. Phono input: Connect your phono audio equipment
2. Coaxial/optical output: Connect to your digital audio device input port

User Manual
70406 – 2 Port Optical Audio Switch
Introduction
Thank you for purchasing the LINDY 2 port audio switch. This audio switch allows you to have
two digital optical fibre inputs and one digital optical fibre output. Each connected fibre cable
can run up to 5m while still providing a reliable and lossless audio transmission.
Specifications
•Input ports: 2 x TOSLink (Optical Fibre)
•Output port: 1 x TOSLink (Optical Fibre)
•Supports S/PDIF standard of digital audio transmission
•Supports uncompressed 2-channel LPCM (Linear Pulse Code Modulation) digital audio
signal output
•Supports compressed 2-channel and multi-channel Dolby and DTS audio signal
•Power Supply: 5VDC 0.5A
•Dimensions: (WxDxH) 46 x 46 x 23.5mm
•Weight: 22g
•Housing: Plastic
•Colour: White
Operation
Side View
1. Selection: Use this mini switch to select from 2 input ports A or B
2. Power: Plug 5VDC PSU (included) into the unit and connect to a wall outlet
Front Panel Rear Panel
1. Optical input: Connect your optical audio equipment such as DVD player or amp
2. Optical output: Connect to your digital audio device input port
