Lindy VGA to DVI Scaler 32563 User manual

© LINDY ELECTRONICS LIMITED & LINDY-ELEKTRONIK GMBH - FIRST EDITION (Dec 2007)
VGA to DVI Scaler
Manual English
LINDY No. 32563
www.lindy.com

Manual English
Introduction
Thank you for purchasing the LINDY VGA to DVI Scaler. The VGA to DVI Scaler takes your analogue VGA or
Component Video signal and scales it to DVI, in either analogue or digital format. Perfect for use with LCD, Plasma
and Projector displays the VGA to DVI scaler will automatically detect the input type, and allow you to choose your
preferred output resolution using an OSD (on screen display).
Package Contents
•LINDY VGA to DVI Scaler
•3 RCA to VGA Adapter Cable
•DVI Cable
•VGA Cable
•Power Adapter
•This User Manual
Installation
Input
The VGA to DVI Scaler can accept both VGA and Component Video inputs.
When using a VGA input; use the supplied VGA cable to connect your VGA source to the PC/HD Input connector
on the back of the VGA to DVI scaler. When using a Component Video input; use the supplied VGA to 3 RCA cable
to connect your Component Video source to the PC/HDTV Input connector of the VGA to DVI scaler. The VGA to
DVI scaler will automatically detect the mode and resolution of the PC/HDTV input.
Supported Input Resolutions
Output
The VGA to DVI scaler can output a variety of PC and High Definition resolutions, in both analogue and digital
format.
To use the digital output; connect the supplied DVI cable from the DVI Output connector to your display/monitor,
then press the menu button. From the on screen menu, choose Output Setup then select DVI-D.
To use the analogue output; connect a DVI to VGA cable (LINDY part no. 41206 – not supplied) from the DVI
Output connector to your display/monitor, then press the menu button. From the on screen menu, choose Output
Setup then select DVI-A.
Operation
Front Panel Rear Panel

Manual English
Pressing the MENU button will bring up the OSD (on screen display) menu controls on the screen as follows:
•Input set up
•Output Setup
•Picture Adjust
•HV Adjust
•OSD Adjust
•System Information
•Auto Adjust
•Exit
Use the + and –keys to move the arrow cursor to your desired selection, then press MENU to confirm your
selection and enter into sub menu.
Input Setup
When entering the Input Setup menu you will see the following:
Use the + and –keys to highlight the parameter your want to adjust and then press MENU to make your selection.
Once a parameter has been selected use the + and –keys to increase or decrease the setting value.
Adjusting the Clock setting allows you to set the optimal clock frequency where the picture is stable and unskewed.
Pressing the +button allows you to narrow the width of the picture towards the left of the screen.
Pressing the -button allows you to extend the width of the picture towards the right of the screen.
Adjusting the Phase setting using the + and –keys will change the amount of noise which is seen on the display.
The VGA to DVI Scaler will automatically detect and display the input signal format as either YPbPr or RGB, this
can be manually adjusted by pressing the + or –button, followed by MENU to confirm your selection.
Output Setup
When entering the Output Setup menu you will have the option to choose between DVI-A (analogue) and DVI-D
(Digital). Select the required output by pressing the + or –button, followed by MENU to confirm your selection.
Analogue Output Modes
Digital Output Modes

Manual English
Picture Adjust
When entering the Picture Adjust menu you will see the following:
Use the +and –keys to highlight the setting you want to adjust and then press MENU. You can now adjust the
setting using the +and –keys accordingly. Press MENU again to save your changes and return to the Picture
Adjust menu.
The table below shows the range for each setting along with the factory default values.
HV Adjust
When entering the HV Adjust menu you will see the following:
Use the +and –keys to highlight the setting you want to adjust and then press MENU. You can now adjust the
setting using the +and –keys accordingly. Press MENU again to save your changes and return to the Picture
Adjust menu.
OSD Adjust
When you enter this menu you can adjust the position of the OSD box using the +and –keys.
System Information
When you enter this menu you will see the current input and output resolutions, along with their refresh rates.
Auto Adjust
Selecting this menu will automatically adjust all settings back to their factory preset values.
Technical Support and Service
For commercial or general product support, contact LINDY.
For technical help contact LINDY via our website www.lindy.com
