Linea Plus Sedative Series User manual

Atención:
Este purificador puede ser usado por niños a partir de 8 años y personas con
capacidades físicas, sensoriales o mentales reducidas o faltas de experiencia y
conocimiento, si se les han dado instrucciones sobre el uso del purificador de manera
segura, entienden los peligros derivados de su uso y están bajo supervisión. Los niños
no deben jugar con el purificador. Los trabajos de limpieza y mantenimiento no deben
ser realizados por niños sin supervisión
Si el cable de alimentación estuviese dañado, deberá ser sustituido por el fabricante o un
servicio técnico autorizado para evitar cualquier peligro / daño.
PD-36WB
Gracias por elegir este producto.
Por favor, lea atentamente el manual de instrucciones
antes de usarlo y consérvelo para futuras consultas.
Existen funciones opcionales, por favor verifique con el vendedor si su máquina tiene estas funciones.

Purificador de aire
inteligente
ÍNDICE
PRECAUCIONES
ADVERTENCIA
1-3
2
INSTRUCCIONES DE FUNCIONAMIENTO
Encendido
Crea un ambiente sano para evitar virus PRECAUCIÓN
RENDIMIENTO Y
CARACTERÍSTICAS
TÉCNICAS
Bloqueo infantil
Selección de velocidades
Modo noche
Temporizador
Antibacterias
Recude la cantidad de virus y su propagación
Rendimiento
Características técnicas
COMPONENTES
Exterior
Interior
Unidades operativas
4
4Selección de funciones 11
Aviso para cambio de filtro 12
MANTENIMIENTO Y LIMPIEZA 13
TABLA DE SOLUCIONES 14
●La luz UV elimina las bacterias de manera eficiente e inhibe
la activación de los virus.
PRECAUCIONES ANTES DEL FUNCIONAMIENTO
Cómo tocar el panel de control 7
Extracción de filtros 7
Instalación de filtros 8
Cable de alimetación 8
Colocación 8
PARÁMETROS TÉCNICOS
Parámetros de la unidad
Parámetros de los filtros
Parámetros de la lámpara UV

CAUTIONS
In order to prevent harm or damage happened to users or others, be sure to comply with the requirement as below: WARNING
ATTENTION
Warning/Attention Please supervise your
children and avoid
them from touching
or using machine.
Do not connect or
disconnect the power
with wet hand
It may cause electrical
shocking.
No disassembly,repair and
reconstruction.
It may cause fire or damage.
Please send it to the retailer
for repair.
Donot use the over run socket or
wiringconnector.Dousetherated
voltage.
It may cause fire
Doplug the power into the socket
completely.
Itmay cause fire because of heating or
electrical shocking.
Do not use the damaged plug orloose
socket
Warning It reminds that misusing or mishandling may cause death.
Attention It reminds that misusing or mishandling may cause hurt.
AVOID WET
NO DISASSEMBLE
FORBID
FORBID FORCE
Avoid any water on
the surface of the
unit.
It may cause short
circuit or electrical
shocking.
Theappliancemustbe
disconnected from the
supply mains before
cleaning orother
maintenance
Otherwise the unit may
start working in a sudden
which may cause
electrical shocking or
hurt.
Do not insertanymetal
objects into the unit.
It may cause hurt or electric
shocking
Do not repair it when the cord
orplug is damaged.
It may cause short circuit, electric
shocking or fire.
Please send it to the retailer for
repair.
If there is dust on the plug, it
mayweaken theinsulation,
evencausefire
Take out the plug and clean it with
dry cloth.
Please remove the plug from the
socket if not using for a long period.
Kindly attention: If the power wire is broken,to prevent danger happend,
please send it to agent,after-sales service or technical person for repair.
AVOID WET DISCONNECT POWER FORBID FORBID Do clean the plug termly
Kindly attention:
If the power wire is broken,to prevent danger happend,
Intelligent air purifier User manual 2

ATTENTION PRODUCT PERFORMANCE AND TECHNICAL FEATURES
ATTENTION
Do not power the unit on when using
insecticide in the room
Otherwise the insecticide may be stored in
the unit and will blow out during the normal
working time.It is harmful to the health.
Please ventilate completely after having
used the insecticide before turn on the unit.
Do not use in the room with
lampblack such askitchen.
It may cause hurt because the
machine is not a ventilator
Do not blow in any combustible
or fired cigarette into the unit.
It may cause fire
Do not use in the watery or high
temperatureroomsuch asthe
bathroometc.
Otherwise itmay causecreepage,
electric shocking orfire.
Product performance
●Filtro antimicrobiano: Elimina el moho, alergénos y bacterias.
●HEPA: fabricado con una nueva generación de materiales, elimina eficazmente partículas dañinas
●Carbón activado: una fabricación de alta tecnología en la biosíntesis de cascara de nuez en carbón y un área mayor, cran una mayor
capacidad de adsorción de partículas y humo.
●Foto catalizador: creado con dióxido de titanio tiene como función dañar a las bacterias e inhibir la actividad de los virus.
●Anión: La gran cantidad de iones negativos generados, purifica y desinfecta el aire eliminando bacterias, hongos, alérgenos, virus y malos
olores.
FORBID
Keep away fromalcohol,organic
impregnant or insecticide
It may cause cracking,short circuit, electric
shocking, hurt or fire
Pleaseventilatetimelywhen
used with fire in the room
Otherwise it may cause poisoning
of Co1 as the machine is not a
ventilator
Please hold the plug instead of
the cord when unplug the power.
Otherwise it may cause short circuit,
breaking of the cord,electric shocking
or fire.
Pleaseremovetheplugfromthe
socket if any conditions as below:
●If all switches do not work
●If the power cord or plug hot
singularly
●If any peculiar smell, exceptional
noise or vibration
●Any other abnormality or failure
Technical features
●Panel digital.
●Pantalla LED
●Alarma automatic para el cambio de los filtros
●Diseño ERP c on s um o en r ep os o ≤0.5W.
●Motor de ahorro de energía, más silencioso y ecológico.
If the power cord is damaged, please send it to the retailer or service center or technician for repairing. Do not change or repair it by yourself.

COMPONENTES COMPONENT INTRODUCTION
Exterior Operating parts
●Diagram of operating button
Panel de control Trasera
Entrada de aire I II III 2H 4H 8H Ions
Frontal
Frontal
Frontal
Lateral izquierdo
Lateral derecho
Interior
Encendio/apagado Velocidad Temporizador Funciones
Cubierta izquierda Cuerpo Carbón activado+foto catalizador Antimicrobiano+HEPA Cubierta derecha
5 Intelligent air purifier User manual 6

CAUTIONS BEFORE OPERATING
How to touch the control panel?
● Please touch the button with whole finger
Installation of the filters
●Take off right side cover.
CAUTIONS BEFORE OPERATING
●Take out Antimicrobial+HEPA,activated carbon+photo catalyst filter,and tear off its PE bag,please install filters sequentially.
Wrong
Correct
Disassembling filter cover
●Disassembly diagram ● Installation
diagram
Take off right side cover Install activated carbon+photo catalyst filter
Power supply
●AC voltage
Install Antimicrobial+HEPA
Power plug
Please don't connect this machine with wrong voltage of power supply, inserting the plug firmly into the power socket.
Lift up the unit with one hand and open the side cover with another
hand by holding up from the bottom of the cover.
1.Please insert the top part of side cover into the slot.
2.Press down the bottom part of side cover,then it's installed well. Placement
●Please keep the machine air inlet and outlet 30cm or more away from the wall and home furniture
●Do not use the machine in front of heat source outlet.
7 Intelligent air purifier User manual 8

OPERATING INSTRUCTION OPERATING INSTRUCTION
Power setting
●Pressing the power icon, the device start to work. Fan speed setting
●Pressing SPEED icon to select Low、Med、High speed, The diagram as following:
I II III 2H 4H 8H Ions I II III 2H 4H 8H Ions
Children lock setting
●pressing power icon and hold on for 5 seconds, after a sound like"D", then enter children lock mode. Sleep mode
Pleae note,the other button doesn't work under children lock mode.
Hold on power icon for 5 seconds again to quit children lock mode and other operation recovery.
●Pressing SPEED icon and hold on for 5S, after a sound like "D", the sleep mold will be turn on, machine will under
I speed and all the lights will turn off. Press any button to quit sleep mode.
I II III 2H 4H 8H Ions I II III 2H 4H 8H Ions
9 Intelligent air purifier User manual 10

OPERATING INSTRUCTION OPERATING INSTRUCTION
Timer setting
●Pressing TIMER button to select 2H、4H、8H and no timing mode, The diagram as following:
Filter replacement reminder
1.When speed indictor flashing, it means the filter's life comes to end, please replace new filter.
2.When speed indictor still flashing after a new filter replaced, press time setting button and hold on for 5 seconds,
I II III 2H 4H 8H Ions after a sound like "D",speed indictor will stop flashing and the machine start to record the filter using time.
I II III 2H 4H 8H Ions
Function setting
●Pressing the function icon on the product operating panel, the anion can be turn off or turn on again.
The diagram as following:
I II III 2H 4H 8H Ions
11 Intelligent air purifier User manual 12

MAINTENANCE AND CLEANING INSTRUCTION FAQ
Maintenance and cleaning instruction ●If the machine can't work properly,please kindly check as below before you send it out for repair.
If the problem is still existed after above inspections, please disconnect the power and send it for repair.
13 Intelligent air purifier User manual 14
Benzene Acohol
Maintenance and cleaning instruction
Please remove plug from the socket before
cleaning and maintenance .
D e co nta mi na ti on
Alkalescence
Scour
Abnormal occurrence
Checking methods
Solution
Do not work
●Please check if the plug is disconnected from the socket.
Power plug should be plugged properly
●Please check if the filter cover is installed completely
Recoverthefiltercovercorrectly
Odor can not be removed.
●Is there a very strong odor in the using environment?
(Notes:air should be purified continuously)
Suggesting to ventilate,then start up the
machine.
●Does the using life time for activated carbon filter
come to the end?
Please replace new filters.
High noise
●Is the PE bag for filter removed?
Please take out filters and tear off PE bag.
●Does the using life time for HEPA come to the end?
Please replace new HEPA .
●Cleaning the body for this device by damp cloth, then wipe it dry.
●If machine is too dirty, neutral detergent can be used for cleaning,
but please dilute the detergent before use.
po w er
●Do not clean the unit with the solvent listed on the right which may cause distortion or discolour.

TECHNICAL PARAMETERS TECHNICAL PARAMETERS
Parameters of the unit Filter parameters
15 Intelligent air purifier User manual 16
Description
Size
Life time
Antimicrobial+HEPA
209 x 102x 40(mm)
About 6 months
Activated carbon
and photo catalyst
203 x 97 x 15(mm)
About 6 months
Model No.:
B-757M
Voltage Supply:
220V-240V,50Hz
Air flow volume(m3/h):
≥70m
3
/h
Noise level dB(A):
≤40dB(A)
Length of power cord:
≥1. 4M
Product size:
329×170×300(mm)
Net weight:
3.2KG
Power rating (W):
26W
Applicable area:
12m2(129ft2)

Attention:
This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a safe
B-757M
Intelligent air purifier
way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision. Sedative Series ·desktop
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a hazard.
Thank you for use this product which protected by intellectual property.
Please read this instruction manual carefully before
use and keep it for future use.
If the parameter, specification and other information maybe changed, we will not notice specially, please refer to the actual machine.
The “optional” are optional functions, please kindly check with the retailer if your machine with these functions.

Intelligent air purifier
Sedative Series ·desktop
DIRECTORY INDEX
CAUTIONS
WARNING
1-3
2
OPERATING INSTRUCTION 9-12
Power setting 9
M
Ma ak ke e a an n e ec co ot ty yp pi ic c h ho om me e
t
to o a av vo oi id d v vi ir ru us se es s
ATTENTION
PRODUCT PERFORMANCE
3 Children lock setting 9
Fan speed setting 10
Sleep mode 10
AND TECHNICAL FEATURES 4Timer setting 11
Environment self cicatrization
produces "air vitamin"
●It can generate 5,000,000 "air vitamin" every second which can improve the home environment.
Anti bacteria
Restrain the breeding and activity of viruses
Product performance
Technical features
COMPONENT INTRODUCTION
Diagram of the outlook
Diagram of unit
Operating parts
4
4
5-6
5
5
6
Function setting 11
Filter replacement reminder 12
MAINTENANCE AND
CLEANING INSTRUCTION 13
Maintenance and cleaning instruction 13
FAQ 14
●UV light can efficiently kill bacteria and inhibit its activation CAUTIONS BEFORE OPERATING 7-8
Healthyair
Healthy air is the basis of health and life
●A child needs 400KG of air everyday, equal to 100 times of an adult needs water per day.
So it is very important to the health to improve the air environment of live.
How to touch the control panel? 7
Disassembling filter cover 7
Installation of the filters 8
Power supply 8
Placement 8
TECHNICAL PARAMETERS 15-16
Parameters of the unit 15
Filter parameters 16
UV parameters 16

CAUTIONS
In order to prevent harm or damage happened to users or others, be sure to comply with the requirement as below: WARNING
ATTENTION
Warning/Attention Please supervise your
children and avoid
them from touching
or using machine.
Do not connect or
disconnect the power
with wet hand
It may cause electrical
shocking.
No disassembly,repair and
reconstruction.
It may cause fire or damage.
Please send it to the retailer
for repair.
Do not use the over run socket or
wiringconnector.Dousetherated
voltage.
It may cause fire
Doplug the power into the socket
completely.
It may cause fire because ofheating or
electrical shocking.
Donot use the damaged plug orloose
socket
Warning It reminds that misusing or mishandling may cause death.
Attention It reminds that misusing or mishandling may cause hurt.
AVOIDWET
NO DISASSEMBLE
FORBID
FORBID FORCE
Avoid any water on
the surface of the
unit.
It may cause short
circuit or electrical
shocking.
Theappliancemustbe
disconnected from the
supply mains before
cleaning or other
maintenance
Otherwise the unit may
start working in a sudden
which may cause
electrical shocking or
hurt.
Do not insert any metal
objects into the unit.
It may cause hurt or electric
shocking
Do not repair it when the cord
orplug is damaged.
It may cause short circuit, electric
shocking or fire.
Please send it to the retailer for
repair.
If there is dust on the plug, it
mayweakentheinsulation,
even causefire
Take out the plug and clean it with
dry cloth.
Please remove the plug from the
socket if not using for a long period.
Kindly attention: If the power wire is broken,to prevent danger happend,
please send it to agent,after-sales service or technical person for repair.
AVOID WET DISCONNECT POWER FORBID FORBID Do clean the plug termly
Kindly attention:If the power wire is broken,to prevent danger happend,
Intelligent air purifier User manual 2

ATTENTION PRODUCT PERFORMANCE AND TECHNICAL FEATURES
ATTENTION
Do not power the unit on when using
insecticide in the room
Otherwise the insecticide may be stored in
the unit and will blow out during the normal
working time.It is harmful to the health.
Please ventilate completely after having
used the insecticide before turn on the unit.
Do not use in the room with
lampblack such as kitchen.
It may cause hurt because the
machine is not a ventilator
Do not blow in any combustible
or fired cigarette into the unit.
It may cause fire
Do not use in the watery or high
temperature room such asthe
bathroometc.
Otherwiseitmay cause creepage,
electric shocking orfire.
Product performance
● Antimicrobial Filter: Eliminates mold,allergens and bacterial.
●HEPA: Using a new generation of composite materials,can effectively remove of particle.
●Activated carbon filter: Biosynthesis of walnut shell, the adsorption area is bigger,it can effectively
remove smoke and formaldehyde.
●Photo catalyst: Using titanium dioxide (TiO2) material,its oxidation function can damage the filter captured
the cell membrane of bacteria,inhibit virus activity.
● Anion: Negative ion ispraised asAir Vitamin.People live inthe high negative ionic environment,can promote human new
andoldsuperseded,improveimmunity.
FORBID
Keepaway from alcohol,organic
impregnant or insecticide
It may cause cracking,short circuit, electric
shocking, hurt or fire
Pleaseventilatetimelywhen
used with fire in the room
Otherwise it may cause poisoning
of Co1 as the machine is not a
ventilator
Please hold the plug instead of
the cord when unplug the power.
Otherwise it may cause short circuit,
breaking of the cord,electric shocking
or fire.
Pleaseremovetheplugfromthe
socket if any conditions as below:
●If all switches do not work
●If the power cord or plug hot
singularly
●If anypeculiar smell, exceptional
noise or vibration
●Any other abnormality or failure
Technical features
●Touch control panel: Easy to operate.
●LED light display: Easy to show.
●Automatic alarm:Filters replacement light setting.
● ERP design,standby power≤0.5W.
●Energy saving motor,more quiet and more green.
If the power cord is damaged, please send it to the retailer or service center or technician for repairing. Do not change or repair it by yourself.
3 Intelligent air purifier User manual 4

COMPONENT INTRODUCTION COMPONENT INTRODUCTION
Diagram of the outlook Operating parts
●Diagram of operating button
Touch control panel
Back cover
Air in I II III
2H 4H 8H
Ions
Front cover
Front cover
Side cover
Front view Left view Right view
Diagram of unit
Power Speed Timer Function
Left cover Body Activated carbon+photo catalyst Antimicrobial+HEPA Right filter cover
5 Intelligent air purifier User manual 6

CAUTIONS BEFORE OPERATING
How to touch the control panel?
● Please touch the button with whole finger
Installation of the filters
●Take off right side cover.
CAUTIONS BEFORE OPERATING
●Take out Antimicrobial+HEPA,activated carbon+photo catalyst filter,and tear off its PE bag,please install filters sequentially.
Wrong
Correct
Disassembling filter cover
● Disassembly diagram ● Installation
diagram
Take off right side cover Install activated carbon+photo catalyst filter
Power supply
●AC voltage
Install Antimicrobial+HEPA
Power plug
Please don't connect this machine with wrong voltage of power supply, inserting the plug firmly into the power socket.
Lift up the unit with one hand and open the side cover with another
hand by holding up from the bottom of the cover.
1.Please insert the top part of side cover into the slot.
2.Press down the bottom part of side cover,then it's installed
well.
Placement
●Please keep the machine air inlet and outlet 30cm or more away from the wall and home furniture
●Do not use the machine in front of heat source outlet.
7 Intelligent air purifier User manual 8

OPERATING INSTRUCTION OPERATING INSTRUCTION
Power setting
●Pressing the power icon, the device start to work. Fan speed setting
●Pressing SPEED icon to select Low、Med、High speed, The diagram as following:
I II III 2H 4H 8H Ions I II III 2H 4H 8H Ions
Children lock setting
●pressing power icon and hold on for 5 seconds, after a sound like"D", then enter children lock mode. Sleep mode
Pleae note,the other button doesn't work under children lock mode.
Hold on power icon for 5 seconds again to quit children lock mode and other operation recovery. ●Pressing SPEED icon and hold on for 5S, after a sound like "D", the sleep mold will be turn on, machine will under
I speed and all the lights will turn off. Press any button to quit sleep mode.
I II III
2H 4H 8H Ions I II III 2H 4H 8H Ions
9 Intelligent air purifier User manual 10

OPERATING INSTRUCTION OPERATING INSTRUCTION
Timer setting
●Pressing TIMER button to select 2H、4H、8H and no timing mode, The diagram as following:
Filter replacement reminder
1.When speed indictor flashing, it means the filter's life comes to end, please replace new filter.
2.When speed indictor still flashing after a new filter replaced, press time setting button and hold on for 5 seconds,
I II III 2H 4H 8H Ions after a sound like "D",speed indictor will stop flashing and the machine start to record the filter using time.
I II III 2H 4H 8H Ions
Function setting
●Pressing the function icon on the product operating panel, the anion can be turn off or turn on again.
The diagram as following:
I II III
2H 4H 8H Ions
11 Intelligent air purifier User manual 12

MAINTENANCE AND CLEANING INSTRUCTION FAQ
Maintenance and cleaning instruction ●If the machine can't work properly,please kindly check as below before you send it out for repair.
If the problem is still existed after above inspections, please disconnect the power and send it for repair.
13 Intelligent air purifier User manual 14
Benzene Acohol
Maintenance and cleaning instruction
Please remove plug from the socket before
cleaning and maintenance .
Decontamination
Alkalescence
Scour
Abnormal occurrence
Checking methods
Solution
Do not work
●Please check if the plug is disconnected from the socket.
Power plug should be plugged properly
●Please check if the filter cover is installed completely
Recoverthe filtercover correctly
Odor can not be removed.
●Is there a very strong odor in the using environment?
(Notes:air should be purified continuously)
Suggesting to ventilate,then start up the
machine.
●Does the using life time for activated carbon filter
come to the end?
Please replace new filters.
High noise
●Is the PE bag for filter removed?
Please take out filters and tear off PE bag.
●Does the using life time for HEPA come to the end?
Please replace new HEPA .
●Cleaning the body for this device by damp cloth, then wipe it dry.
●If machine is too dirty, neutral detergent can be used for cleaning,
but please dilute the detergent before use.
power
●Do not clean the unit with the solvent listed on the right which may cause distortion or discolour.

TECHNICAL PARAMETERS TECHNICAL PARAMETERS
Parameters of the unit Filter parameters
15 Intelligent air purifier User manual 16
Description
Size
Life time
Antimicrobial+HEPA
209 x 102x 40(mm)
About 6 months
Activated carbon
and photo catalyst
203 x 97 x 15(mm)
About 6 months
Model No.:
B-757M
Voltage Supply:
220V-240V,50Hz
Air flow volume(m3/h):
≥70m
3
/h
Noise level dB(A):
≤40dB(A)
Length of power cord:
≥1. 4M
Product size:
329×170×300(mm)
Net weight:
3.2KG
Power rating (W):
26W
Applicable area:
12m2(129ft2)
