Beko ATP 6100 I User manual

Air Purifier
Instruction Manual
01M-8501793200-1821-11
ATP 6100 I

Air purifier/ Instruction Manual 3 / EN
CONTENTS
1 Important Safety and Environmental
Instructions
4-7
1.1 General Safety. . . . . . . . . . . . . . . . . . . . 4
. 5
. 6
. . . . . . . . . . . . . 6
. . . . . . . 6
. . 7
2 How The Air Purifier Works 8
3 Know Your Air Purifier 8
4 Control Panel Introduction 9
5 Operating Instructions 10
5.1 İmportant notes . . . . . . . . . . . . . . . . . 10
6 Controls Introduction 10
7 To Operate Your Air Purifier 11
8 Change The Hepa Filter 12
9 Troubleshooting 12
10 Technical Data 13

Air purifier/ Instruction Manual 5 / EN
sory or mental capabilities, or lack
of experience and knowledge, un-
less they have been given super-
vision or instruction concerning
use of the appliance by a person
responsible for their safety.
•Children should be supervised to
ensure that they do not play with
the appliance. This appliance can
be used by children aged from
8 years and above and persons
with reduced physical, sensory or
mental capabilities or lack of ex-
perience and knowledge if they
have been given supervision or
instruction concerning use of the
appliance in a safe way and un-
derstand the hazards involved.
Children shall not play with the
appliance. Cleaning and user
maintenance shall not be made by
children without supervision.
•This appliance is intended to be
used in household and similar ap-
plications such as:
– Staff kitchen areas in shops, of-
fices and other working environ-
ments;
– Farm houses;
– By clients in hotels, motels and
other residential type environ-
ments;
– Bed and breakfast type environ-
ments.
•Save these instructions
CAUTION: To prevent risk of
electric shock, remove cord plug
fromoutlet before activating the
appliance. To prevent risk of fire,
inspect and clean equipment reg-
ularly as noted in this manual.
•If the supply cord is damaged, it
must be replaced by the manufac-
turer, its service agent or similarly
qualified persons in order to avoid
a hazard.
1.2 Compliance with
the WEEE Directive and
Disposing of the Waste
Product:
This product complies with EU
WEEE Directive
(2012/19/EU). This product bears
a classification symbol for waste
electrical and electronic equipment
(WEEE).
This symbol indicates that
this product
shall not be disposed with
other household wastes at
the end of its service
1

Air purifier/ Instruction Manual 7 / EN
1
Groove
Fastener
1.6 Vacuum Or Wash
The Pre-filter
Occasionally vacuum the exterior of
the fabric pre-filter to remove dust.
Always unplug the unit before re-
moving the fabric pre-filter.
1. Carefully rotate the body anti-
clockwise and remove it from the air
inlet grill.
2. Remove the pre-filter from the
HEPA filter.
3. Wash the pre-filter in the wash-
ing machine.
4. After the pre-filter is cleaned well
and dried, attach the pre-filter onto
the HEPA filter.
5. Carefully put the HEPA filter with
pre-filter into the air inlet grill.
6. Put the body onto the air inlet
grill, then rotate the body clockwise
until the fastener locks into the
groove.

8 / EN Air purifier/ Instruction Manual
2 How The Works
grass pollen, tree pollen, household
3 Know Your
Air inlet grill
Pre-Filter
HEPA Filter
Body
Dust sensor
Timer button
Fan speed button
Air outlet
Air quality indicator

Air purifier/ Instruction Manual 9 / EN
4
Timer
Button
Air
Outlet
Fan Speed
Button
Power
Button

Filter change
indicator
10 / EN Air purifier/ Instruction Manual
5
5.1 İmportant notes
•Carefully unpack your air purifier.
•Select a firm level place where there are no
obstructions to the air inlet grill or air outlet.
•Remove all PE bags from filters before use.
•Do not point air outlet towards wall.
Power button
Touch the Power button, the machine will
start running under the default “AUTO” set-
ting, and the indicator of “AUTO” setting will
illuminate.
Fan speed button
There are 4 speed settings including Low,
Medium, High and AUTO for selection. Touch
the Fan speed button to select your desired
speed setting.
The timer allows you to run your air purifier
at your convenience, for up to 8 hours. With 3
settings including 2hr, 4hr and 8hr.
Dust sensor
This Air Purifier has a built-in smart dust sen-
sor which can detect the air quality of current
environment automatically, and the air qual-
ity can be shown by the air quality indicator
which can illuminate in blue, pink and red
when the air quality is very good, good and
bad accordingly.
6
This appliance has an independent Ionizer
rocker switch equipped at the bottom of body,
feature which, when turned on, releases neg-
ative ions into outgoing filtered air to help the
air purification process.
Ionizer rocker
switch

12 / EN Air purifier/ Instruction Manual
8
Always unplug the unit before changing the
HEPA filter.
1. When the filter change indicator illuminates in
white, it’s time to change the HEPA filter.
2. Turn off the unit and unplug it.
3. Carefully rotate the body anticlockwise and
remove it from the air inlet grill.
4. Remove the HEPA filter out of the air inlet grill.
5. Remove the pre-filter.
6. Replace a new HEPA filter into the air inlet grill.
7. Put the body onto the air inlet grill, then rotate
the body clockwise until the fastener locks into
the groove.
8. Simultaneously hold and Touch the Power
and Timer buttons for 3 seconds to activate the
filter function.
9
Problem
Check to make sure the unit is plugged in.
Check to make sure the unit is on.
Check condition of the filter and replace if necessary.
Check to ensure nothing is blocking the air inlet and
filtered air outlet.
Be sure the plastic bag has been removed from the filter.

Air purifier/ Instruction Manual 13 / EN
10
Model No.
ATP6100I
Power supply
100-240V~, 50-60Hz
Rated power
21.6 W
Beko A&NZ Pty Ltd 55 Blanck Street ,
Ormeau QLD, 4208 AUSTRALIA
Parameter of External Power Supply
Manufacturer
Debom Technology Co.,Ltd.
DBS024A-1201800A
Input Voltage
100-240V~
Input Frequency
50-60Hz
Input Current
0.8A Max
Output Voltage
12.0V DC
Output Current
1.8A
Output Power
21.6W
88,03%
79,98%
0.070W

55 Blanck Street, Ormeau
Q 4208 P O Box 354,
Ormeau Q 4208 p :
5549 3146 f : 5549
3546
ABN : 49 152 055 162
ADVICE FORM
BEKO AIR PURIFIER
24 months warranty, full parts and labour warranty only.
WARRANTY CONDITIONS
The following conditions apply only in relations to the warranty expressly given on this Warranty Advice Form supplied with t he product. This
warranty only applies to appliances purchased and used in Australia or New Zealand and is in addition to (and does n ot exclude, restrict or
modify in any way) other rights and remedies under a law to which the appliances relate, including any non-excludable statutory guarantees in
Australia and New Zealand. It applies to the original purchaser and for appliances used in domestic applications only.
1. This warranty does not apply:
(a) if the identification number attached to the appliance has been altered,rendered illegible or removed;
(b) to light globes;
(c) to paint and vitreous enamel finishes and glass;
(d) to surfaces damaged by use of aerosols or cleaners;
(e) if the appliance has been
(i) subject to misuse, abuse, negligence, accident, fire or floods;
(ii) connected or improper, inadequate or faulty electricity, gas, water or drainage services or intake or exhaust
ducts or flues, or operated using incorrect or contaminated fuels or lubricants;
(iii) installed, maintained or operated otherwise than in accordance with the instructions furnished by Beko including the
improper use of detergents, bleaches, cleaners or other additives;
(iv) damaged by foreign objects in the appliance;
(v) serviced, repaired or altered otherwise than by Beko authorised service agents of Beko, or using other than Beko
approved replacement parts.
2. The purchaser shall be responsible for any expenses involved in making the appliances readily accessible for servicing, the purchaser
shall be responsible for any costs of transporting the appliance or parts thereof to and from the nearest Beko authorised service agent.
3. This warranty is the only expressed warranty given by Beko.
4. Beko reserves the right to determine whether or not the fault is caused by faulty workmanship or material or that any part is defective.
5. Where permitted by law, this warranty shall not apply to loss suffered through or resulting from the non-operation or the ineffective
operation of the appliance or any part of the appliance.
6. The purchaser must produce proof of the date of purchase together with this Warranty Advise Form when making a claim.
7. Subject to your statutory rights as to the merchantable quality of the product or accessory. In the event of a product or acc essory being
replaced during the guarantee, the guarantee on the replacement will expire at the original date, i.e., 24 months from the original
purchase date.
8. Australia: For Appliances and services provided by Beko in Australia, Beko goods come with a guarantee by Beko that cannot be
excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for
any other reasonably foreseeable loss or damage. You are also entitled to have the Appliance repaired or replaced if the Appliance
same meaning as referred toin the Australian Consumer Law.
9. New Zealand: For Appliances and services provided by Beko in New Zealand, the Appliances come with a guarantee by Beko
pursuant to the provisions of the Consumer Guarantees Act, the Sales of Goods Act and the Fair Trading Act. Where the Appliance
was purchased in New Zealand for commercial purposes the Consumer Guarantee Act does not apply.
These Warranty Conditions supersedes and excludes all other representations, conditions and warranties, except those implied
by legislation previously referred to.
For Service or Spare Parts: Aust 1300 282 356 NZ 0800 692 356

Beko A&NZ Pty Ltd
55 Blanck Street , Ormeau QLD, 4208 AUSTRALIA
www.beko.com.au
