F100 MediaAir Cleaner 68-0239EF—05 1
What to Expect From Your Honeywell
Media Air Cleaner .....................................................2
When Installing this Product..........................................2
How it Works.............................................................2
Application Considerations.......................................3
Models...........................................................................3
Air Conditioning .............................................................3
Humidiers ....................................................................3
UV Lights.......................................................................3
Transitions .....................................................................4
Turning Vanes ...............................................................4
Sheetmetal ....................................................................4
Offsets ...........................................................................4
Important Installation Requirements ........................5
Personal Safety .............................................................5
Before Mounting ............................................................5
If Replacing an Old Air Cleaner.....................................5
Choosing a Mounting Position ..................................6
Mounting the F100 Media Air Cleaner ......................9
Checkout.................................................................10
Maintenance...........................................................10
Specications.........................................................10
FC100A Efciency .......................................................10
Filter Media..................................................................10
Capacity And Pressure Drop ....................................... 11
Temperature Rating.....................................................11
Mounting...................................................................... 11
Dimensions.................................................................. 11
Approvals ....................................................................11
Upgrade Path .............................................................. 11
Replacement Media .................................................... 11
Replacement Filter Table............................................. 11

GETTING
STARTED
Congratulations for selecting the Honeywell Media Air Cleaner for your home comfort system! The F100 Media
Air Cleaner captures and removes a signicant amount of the air-borne particles from the air circulated through
the high-efciency pleated media lter. The Media Air Cleaner easily mounts in any position within the return air
duct of any gas, oil, and electric forced warm air furnaces and to compressor cooling up to 5 tons. Additionally, it
requires no electrical connections or maintainence beyond periodic media lter replacement.
When Installing this Product...
1. Read these instructions carefully. Failure to follow them could damage the product or cause a hazardous
condition.
2. Check the rating given in the instructions and on the product to make sure the product is suitable for your
application.
3. Installer must be a trained, experienced service technician.
4. After installation is complete, check out product operation as provided in these instructions.
How it Works
The lter in your F100 Media Air Cleaner is made up of a web of bers. As air passes through the Media Air
Cleaner, particulates such as dust, pollen, dander, mold, and bacteria collide with the bers in the lter and
become trapped. Meanwhile, the clean air is allowed to continue through your heating and cooling system and
into your home. The particle removal efciency of the F100 Media Air Cleaner can be found in the Specication
section of this manual.
What to Expect From Your Honeywell Media Air Cleaner
F100 MediaAir Cleaner 68-0239EF—05
2

GETTING
STARTED
Application Considerations
The Honeywell F100 Media Air Cleaner is designed to work with gas, oil, and electric forced warm air furnaces
and with compressor cooling. It can also be used with heat pumps if the lter is changed regularly to prevent
excessive pressure drop. The F100 Media Air Cleaner is not recommended for applications where pressure drop
may be critical.
Models
F100F Media Air Cleaner includes cabinet, access door and pleated media lter. F100B Media Air Cleaner
includes cabinet and access door.
Air Conditioning
Mount the media air cleaner upstream of the evaporator coil in a cooling system. The lter will help to keep the
coil clean and reduce maintenance.
Humidiers
The media air cleaner is compatible with humidiers. Avoid applications where water mist will reach the media.
If an atomizing humidier is used, the lter media will require replacement more often because of minerals in the
water.
UV Lights
Germicidal UV lights can cause degradation of the media lter. The UV light should be located out of line of sight
or a minimum of 3 feet from the lter. Otherwise the lter may need to be replaced more frequently.
F100 MediaAir Cleaner 68-0239EF—05 3

GETTING
STARTED
Transitions
For most efcient air cleaning, spread airow evenly
across the face of the media. If the duct is a different
size than the media air lter cabinet, gradual transitions
are required. Follow these guidelines when fabricating:
• Use gradual transitions to reduce air turbulence and
increase efciency.
• Use no more than 20 degrees (about 4 in. per
running ft. (100 mm per 300 linear mm)) of
expansion on each side of a transition tting.
Turning Vanes
If the media air cleaner is installed next to an elbow
or angle tting, add turning vanes inside the angle to
distribute airow more evenly across the face of the
media. See middle gure.
Sheetmetal
The media air cleaner is adaptable to all new or
existing forced air heating and cooling systems used
in residential applications. Transitions or turning vanes
may be required in some applications for effective
media air cleaner operation.
Offsets
If the duct connection to the furnace in a side
installation allows less than 7 in. (178 mm) for mounting
media air cleaner cabinet, attach an offset to the elbow.
See bottom gure at right.
TURNING
VANES
M5651
M948B
LESS
THAN
7 in.
(178 mm)
OFFSET
AT LEAST
7 in.
(178 mm)
1
1 REQUIRED TURNING VANES HELP DISTRIBUTE AIRFLOW EVENLY.
20 DEGREE EXPANSION PER SIDE PER
FITTING (4 IN. PER RUNNING FOOT
[100 MM PER 300 LINEAR MM])
RETURN AIR
DUCT
TRANSITION FITTING
ELECTRONIC AIR CLEANER CABINET M947B
DUCT SIZE CHANGED GRADUALLY TO PREVENT TURBULENCE.
F100 MediaAir Cleaner 68-0239EF—05
4

GETTING
STARTED
Important Installation Requirements
Personal Safety
• Wear safety glasses while installing the unit.
• Do not cut into any air conditioning or electrical line.
• Follow professional safety standards and all local codes for plumbing, electrical, and mechanical
considerations.
Before Mounting
• Using the gure on the cover and the lists on the inside cover, make sure that you have all the components for
your Honeywell Media Air Cleaner and the tools to install it.
• Ensure airow direction through the Honeywell Media Air Cleaner matches the arrows on the lter cartridge.
The arrows should point in the direction of the airow.
• Choose a location that is readily accessible for checking and replacing the lter. Allow at least 26 in. (660 mm)
clearance in front of the unit for removal of the cartridge.
• Install the media air lter where the temperature will not exceed the ratings in the Specications.
• Do not mount in the supply air duct.
NOTE: Generally, the best location is in the return air duct next to the blower compartment so the media air
cleaner can help to keep the blower motor and evaporator coils clean.
If Replacing an Old Air Cleaner
If the Honeywell Media Air Cleaner is not identical in size and shape to the existing air cleaner, before performing
a retrot installation, you might need to add duct transitions to ensure a smooth air ow.
For optimum system performance, replace the lter every six months (before heating season and before cooling
season). Adjust the schedule to your needs, but replace the lter at least once per year.
Failure to comply with these requirements will result in voided warranty, improper installation, and
service callbacks.
F100 MediaAir Cleaner 68-0239EF—05 5

MOUNTING
The Media Air Cleaner mounts in any position within the return air duct, usually next to the furnace blower
compartment, but the arrow on the cartridge must point in the same direction as the airow. See Figs. 3-10 for
proper location of the media air cleaner for a variety of furnace installations.
NOTE: The media air cleaner cabinet is sturdy enough to easily support the weight of the furnace and evaporator
coil.
M939B
M940B
Choosing a Mounting Position
Before beginning Mounting:
I have chosen an installation location that meets the requirements on pages 3 through 5.
Fig. 1. Highboy furnace with side installation. Media air
lter is mounted vertically where return enters side inlet
of furnace.
Fig 2. Highboy furnace, with installation beneath
furnace. Media air cleaner is mounted horizontally
where return enters from below.
F100 MediaAir Cleaner 68-0239EF—05
6

MOUNTING
M941A M942B
Fig. 3.Highboy furnace, with closet installation. Media air
cleaner is mounted vertically on furnace between
furnace and louvered return air opening in closet door.
Fig. 4. Lowboy furnace, with media air cleaner
mounted horizontally in return plenum just above
furnace and opposite heating plenum.
F100 MediaAir Cleaner 68-0239EF—05 7

MOUNTING
M943B
M944B
Fig. 5. Counterow furnace, with media air cleaner
mounted horizontally in return duct or plenum just above
furnace.
Fig. 6. Central fan installation, with media air cleaner
mounted horizontally in central return duct.
M945B
M946B
Fig. 7. Horizontal furnace, with media air lter mounted
vertically in return duct near furnace.
Fig. 8. Two or more media air cleaners used in a high
capacity system.
F100 MediaAir Cleaner 68-0239EF—05
8

MOUNTING
The following procedure describes a typical side installation on an existing highboy furnace (Fig. 1). Alternate
procedures are noted as appropriate. Other changes in installation procedures may be necessary to complete
your installation.
NOTE: Before starting the installation, remove and discard the existing furnace lter (if used). Thoroughly clean
the blower compartment. If possible, power vacuum the ductwork to remove accumulated dust in an
occupied home or remove construction dirt in a new home. The media air cleaner cannot remove dirt that
has settled in the blower compartment and distribution ducts.
STEP ONE: Review the Installation Plan
Temporarily place the cabinet on the oor, oriented as it will be when installed. Insert and remove the cartridge to
make sure the plan allows adequate clearance for easy removal and replacement of the cartridge.
STEP TWO: Fasten the Cabinet to the Furnace
a. Align the cabinet with the return air opening.
b. Place blocks under the cabinet, as necessary, to make sure the unit sits securely.
c. Create an opening in the furnace to match the cabinet opening.
d. Attach the cabinet securely to the furnace. Attach the unit directly or t a starting collar in the furnace opening.
Either drill holes and fasten with sheetmetal screws or rivets, or use slip joints. If you are drilling holes, use a
locking pliers to help hold the unit in place during drilling.
STEP THREE: Install Turning Vanes
Install turning vanes to help distribute air equally over the full surface of the upstream side of the media. Install
them whenever an abrupt 90 degree elbow is installed directly against the media air cleaner cabinet.
STEP FOUR: Fasten Cabinet to Ductwork
Fasten side of cabinet to the ductwork using sheet-metal screws, rivets, or slip joints, as appropriate.
STEP FIVE: Connect Ductwork
a. Connect the vertical duct section to the elbow. If the vertical drop of the duct is less than 7 in. (178 mm) from
the side of the furnace, shorten the horizontal trunk or attach an offset tting to the elbow.
b. When ductwork is properly aligned, connect the vertical duct to the horizontal trunk.
STEP SIX: Seal Joints
Seal all joints in the return air system between the media air lter and the furnace to prevent dust from entering
the clean airstream.
STEP SEVEN: Install Filter Cartridge
Slide the lter cartridge into the cabinet, making sure the arrow on the cartridge points in the direction of air ow.
Replace access door. Insert the tab on the bottom of the door into the slot in the cabinet. Swing the door closed
and press it into place.
Mounting the F100 Media Air Cleaner
F100 MediaAir Cleaner 68-0239EF—05 9

MOUNTING
Visually check the installation and make sure that:
• Airflow is in the direction of the arrow on the media air filter cartridge.
• Turning vanes and transitions, if used, are properly installed.
• Joints in sheetmetal between media air filter and furnace are sealed.
• All sheetmetal connections are complete.
• Original furnace filter has been removed and blower compartment is cleaned.
When you have veried that checkout has been completed:
• Replace any access doors removed during the Installation or Checkout.
• Run the furnace or cooling system through one complete cycle to make sure the system operates as desired.
The media lter must be replaced when pressure drop across the media lter reaches 0.5 in. w.c. (0.1 kPa), or at
least annually. If the media air cleaner is installed downstream from an atomizing humidier or if the installation
includes both heating and cooling, more frequent replacement may be necessary. Clogged media must be
replaced promptly to avoid restricting airow and reducing efciency of the heating/cooling system. Record the
replacement date in the space provided on the replacement media lter.
Checkout
Maintenance
Specications
The specications in this publication do not include normal manufacturing tolerances; therefore, an individual unit may not exactly
match the listed specications. This product is tested and calibrated under closely controlled conditions, and some minor differences in
performance can be expected if those conditions are changed.
FC100A Efciency
Efciency Ratings: Based on American Society of Heating, Refrigerating and Air-Conditioning Engineers
Standard 52.2-1999. Efciency ranges are dened for small particles, E1 = 0.3 to 1.0 micron; medium particles
E2 = 1.0 to 3.0 microns; and large particles, E3 = 3.0 to 10.0 microns.
Initial Efciency: E1 = 32% at 492 FPM
E2 = 72% at 492 FPM
E3 = 96% at 492 FPM
Minimum Efciency Reporting Valve (MERV): 10 at 492 fpm.
Filter Media
Pleated for greater media capacity.
F100 MediaAir Cleaner 68-0239EF—05
10

SPECIFICATIONS
Capacity And Pressure Drop
Initial Pressure Drop: 0.23 in. wc at 492 fpm.
Temperature Rating
-40° to +140°F (-40° to +60°C)
Mounting
Mounts in any position in the return air duct, usually
next to the furnace blower compartment. Cabinet is
sturdy enough to support weight of a residential furnace
and evaporator coil.
Approvals
Underwriters Laboratories, Inc.: Listed to UL 900,
Class 2.
Upgrade Path
The F100 uses the same cabinet as the F300
Electronic Air Cleaner. Upgrade may require installing
the cell key, electronic cells, protective screens and
installation and wiring of the power box, depending on
model. (Note that 25 x 20 in. and 25 x 22 in models
cannot be upgraded to an electronic air cleaner.)
Replacement Media
For optimum system performance, replace the lter
every six months (before heating season and before
cooling season). Adjust the schedule to you needs, but
replace the lter at least annually.
Replacement Filter Table
Filter Size (in.) Part Number
20 x 12-1/2 x 4-3/8 FC100A1052
16 x 24-7/8 x 4-3/8 FC100A1029
16 x 19-3/4 x 4-3/8 FC100A1003
20 x 24-7/8 x 4-3/8 FC100A1037
20 x 19-3/4 x 4-3/8 FC100A1011
0500 1000 1500 2500
0.000
0.100
0.200
0.300
0.400
0.500 16 X 20
16 X 25
20 X 20
20 X 25
FILTER SIZE
PRESSURE
DROP
(IN. WC)
AIRFLOW (CFM)
M32820
WHEN FIRST INSTALLED. PRESSURE DROP INCREASES AS FILTER
BECOMES LOADED. REPLACE FILTER WHEN PRESSURE DROP
REACHES 0.5 IN. WC. (0.1 kPa).
1
1
2000
M14710E
F100 SIZE
IN.
16 X 25
16 X 20
20 X 25
20 X 20
25 X 20
25 X 22
MM
406 X 635
406 X 508
508 X 635
508 X 508
635 X 508
635 X 559
DIM. A
14 7/16
14 7/16
18 7/16
18 7/16
23 5/16
23 5/16
367
367
468
468
592
592
DIM. B
16 3/16
16 3/16
20 3/16
20 3/16
25 1/8
25 1/8
411
411
513
513
638
638
23 1/4
18 1/4
23 1/4
18 1/4
18 3/8
20 1/4
DIM. C
591
457
591
457
467
514
DIM. D
25 1/2
20 1/2
25 1/2
20 1/2
20 5/8
22 1/2
648
521
648
521
524
572
DIM. C (SEE TABLE)
DIM. D (SEE TABLE)
DIM. B
(SEE TABLE)
DIM. A
(SEE TABLE)
1-1/8 (29)
7/8
(22) 5/8
(16)
6-3/4
(171)
7/8
(22)
IN. MM IN. MM IN. MM IN. MM
Dimensions
F100 MediaAir Cleaner 68-0239EF—05 11

Automation and Control Solutions
Honeywell International Inc.
1985 Douglas Drive North
Golden Valley, MN 55422
http://yourhome.honeywell.com
® U.S. Registered Trademark.
© 2011 Honeywell International Inc.
68-0239EF—05 M.S. 07-11
Printed in U.S.A.

POUR
COMMENCER MONTAGE CARACTÉRISTIQUES
TECHNIQUES
INCLUS DANS LA BOÎTE
68-0239EF-05
Épurateur d’air à fibres F100
• 
PROFESSIONAL INSTALLATION GUIDE.
• GUIDE D’INSTALLATION PROFESSIONNELLE.
Outils requis pour installer l’épurateur d’air amélioré
Tournevis normal
Tournevis cruciforme
Cisailles à tôle
Perceuse
Produit d’étanchéité de gaine
Filtres à air de rechange
Dimension du ltre (po) Référence de pièce
12,5 x 20 FC100A1052
16 x 25 FC100A1029
16 x 20 FC100A1003
20 x 25 FC100A1037
20 x 20 FC100A1011

POUR
COMMENCER MONTAGE CARACTÉRISTIQUES
TECHNIQUES
Épurateurd’airàbresF100
BESOIN D’AIDE? Pour obtenir de l’aide sur ce produit, prière de visiter le site
http://yourhome.honeywell.com
ou d’appeler le service d’assistance à la clientèle de Honeywell au 1-800-468-1502.
Lire et conserver ces instructions.
® Marque de commerce déposée américaine. Brevets en instance. Copyright © 2011 Honeywell International Inc. Tous droits réservés.
?
Épurateur d’air à bres F100 68-0239EF—05 1
Àproposdel’épurateurd’airàbres
F100 de Honeywell...................................................2
Lors de l’installation du produit......................................2
Fonctionnement........................................................2
Considérations relatives à l’application....................3
Modèles.........................................................................3
Climatisation..................................................................3
Humidicateurs..............................................................3
Lampes UV....................................................................3
Transitions .....................................................................4
Aubes directrices...........................................................4
Tôle ...............................................................................4
Déviations......................................................................4
Exigences d’installation importantes........................5
Sécurité personnelle......................................................5
Avant le montage ..........................................................5
Pour le remplacement d’un ancien épurateur d’air........5
Sélection de la position de montage ........................6
Montagedel’épurateurd’airàbresF100..............9
Vérication .............................................................10
Entretien .................................................................10
Caractéristiques techniques...................................10
Efcacité du FC100A...................................................10
Filtre à bres................................................................10
Capacité et chute de pression..................................... 11
Température nominale................................................. 11
Montage ......................................................................11
Dimensions.................................................................. 11
Homologations ............................................................11
Remplacement du ltre ...............................................11
Tableau des ltres de rechange .................................. 11

POUR
COMMENCER
Félicitations pour votre choix de l’épurateur d’air à bres Honeywell pour votre système de confort d’intérieur!
L’épurateur d’air à bres F100 capture et retire une quantité considérable de particules contenues dans l’air
circulant par le ltre à bres à plis haute efcacité. L’épurateur d’air à bres se monte facilement dans toutes les
positions dans la gaine d’air de retour de tout appareil de chauffage à gaz, mazout, électrique et air pulsé et les
systèmes de refroidissement par compresseur jusqu’à 5 tonnes. En outre, il ne nécessite aucun branchement
électrique ni entretien excepté le remplacement périodique du ltre à bres.
Lors de l’installation du produit...
1. Lire attentivement ces instructions. Le non-respect des instructions peut endommager le produit ou provoquer
une situation dangereuse.
2. Vérier les caractéristiques nominales indiquées dans les instructions et sur le produit pour s’assurer que le
produit correspond bien à l’application prévue.
3. L’installateur doit être un technicien expérimenté ayant reçu la formation adéquate.
4. Une fois l’installation terminée, vérier que le produit fonctionne comme indiqué dans ces instructions.
Fonctionnement
Le ltre de l’épurateur d’air à bres F100 est constitué d’un réseau de bres. Lorsque l’air passe par l’épurateur
d’air à bres, les particules comme la poussière, le pollen, les squames animales, les moisissures et les bactéries
entrent en collision avec les bres du ltre et sont piégées. L’air propre ltré est acheminé dans le système de
chauffage et de refroidissement et aère la maison. L’efcacité du nettoyage des particules de l’épurateur d’air à
bres F100 est spéciée dans la section Caractéristiques techniques de ce manuel.
Àproposdel’épurateurd’airàbresdeHoneywell
Épurateur d’air à bres F100 68-0239EF—05
2

POUR
COMMENCER
Considérations relatives à l’application
L’épurateur d’air à bres F100 de Honeywell est conçu pour fonctionner avec les appareils de chauffage à gaz,
mazout, électrique et air pulsé et les systèmes de refroidissement par compresseur. Il peut aussi être utilisé
avec des thermopompes uniquement si le ltre est remplacé régulièrement pour éviter les chutes de pression
excessives. L’épurateur d’air à bres F100 n’est pas recommandé dans les applications pour lesquelles une chute
de pression peut avoir de graves conséquences.
Modèles
L’épurateur d’air à bres F100F inclut une armoire, une porte d’accès et un ltre à bres à plis. L’épurateur d’air à
bres F100B inclut une armoire et une porte d’accès.
Climatisation
Monter l’épurateur d’air à bres en amont du serpentin d’évaporation du système de refroidissement. Le ltre
permet de maintenir la propreté du serpentin et de réduire la maintenance.
Humidicateurs
L’épurateur d’air à bres est compatible avec les humidicateurs. Éviter les applications dans lesquelles de
la brume d’eau peut atteindre le ltre. Si un humidicateur à pulvérisation est utilisé, le ltre à bres doit être
remplacé plus souvent en raison des minéraux contenus dans l’eau.
Lampes UV
Les lampes UV germicides peuvent endommager le ltre à bres. Elles doivent être situées hors de l’axe directe
ou à un minimum de 3 pieds du ltre. Dans le cas contraire, le ltre doit être remplacé plus fréquemment.
Épurateur d’air à bres F100 68-0239EF—05 3

POUR
COMMENCER
Transitions
Pour un nettoyage de l’air optimal, le débit d’air doit
passer uniformément sur la face du ltre. Si la taille
de la gaine est différente de l’armoire du ltre à bres,
des transitions graduelles sont requises. Suivre ces
instructions lors de la fabrication :
• Utiliser des transitions graduelles pour réduire les
turbulences de l’air et augmenter l’efcacité.
• Utiliser des expansions de 20° maximum (environ
100 mm tous les 300 mm linéaires [4 po par pied de
longueur]) de chaque côté du raccord de transition.
Aubes directrices
Si l’épurateur d’air à bres est installé près d’un coude
ou d’un raccord à angle, ajouter des aubes directrices
dans le coude pour distributeur le débit de façon plus
uniforme sur la face du ltre. Voir la Fig. 12.
Tôle
L’épurateur d’air à bres peut être adapté à tous les
systèmes de chauffage et de refroidissement à air
pulsé neufs ou existants utilisés dans les applications
résidentielles. Des transitions ou des aubes directrices
peuvent être requises dans certaines applications pour
une épuration de l’air plus efcace.
Déviations
Si la connexion de la gaine à l’appareil de chauffage
dans une installation latérale alloue un espace inférieur
à 178 mm (7 po) pour le montage de l’armoire de
l’épurateur d’air à bres, attacher une déviation au
coude.
AUBES
DIRECTRICES
MF5651
MF948
MOINS
DE
178 mm
(7 po)
DÉVIATION
AU MOINS
178 mm (7 po)
1
1 AUBES DIRECTRICES REQUISES POUR UNE DISTRIBUTION
UNIFORME DU DÉBIT D'AIR.
EXPANSION DE 20° PAR CÔTÉ PAR RACCORD
(100 MM TOUS LES 300 MM LINÉAIRES
[4 PO PAR PIED DE LONGUEUR])
GAINE D’AIR DE RETOUR
RACCORD DE TRANSITION
ARMOIRE DE L’ÉPURATEUR D’AIR À FIBRES MF947
DIMENSION DE GAINE MODIFI
É
E GRADUELLEMENT POUR
ÉVITER LES TURBULENCES.
Épurateur d’air à bres F100 68-0239EF—05
4
