DEMO MANUAL DC2367A
DESCRIPTION
LTM4632EV
Ultrathin µModule Regulator for DDR-QDR4
Memory VDDQ, VTT and VREF
Demonstration circuit DC2367A features the LT M
®
4632EV
µModule
®
regulator, a tiny low-profile high-performance
high efficiency dual step-down regulator for DDR power.
LTM4632 has an operating input voltage range of 3.6V
to 15V. The output voltage of channel 1 (VDDQ) is resis-
tor programmable from 0.6V to 2.5V and is capable of
delivering up to 3A of output current. The output voltage
of channel 2 (VTT) is set to regulate ½of the voltage on
the VDDQIN pin which can provided by either the channel
1 output or an external reference voltage. It can source or
sink up to 3A of output current. A 10mA buffered output
of VDDQIN/2 is also provided for supplying VREF voltage
for DDR memory. DC2367A also provides the option for
paralleling channels 1 and 2 together for up to 6A capable
VTT rail. LTM4632 is a complete DC/DC DDR dual point L, LT, LTC, LTM, Linear Technology, the Linear logo, µModule and Burst Mode are registered
trademarks of Linear Technology Corporation. All other trademarks are the property of their
respective owners.
of load regulator in a low-profile thermally enhanced
6.25mm × 6.25mm × 1.82mm LGA package requiring
only a few input and output capacitors. Output voltage
tracking is available through the TRACK/SS pin for supply
rail sequencing. External clock synchronization is avail-
able through the SYNC/MODE pin. For high efficiency at
low load currents the MODE pin jumper (JP4) selects the
Burst Mode
®
option for operation in less noise sensitive
applications. The LTM4632 data sheet must be read in
conjunction with this demo manual for working on or
modifying demo circuit 2367A.
Design files for this circuit board are available at
http://www.linear.com/demo/DC2367A
BOARD PHOTO
Downloaded from Arrow.com.

2
dc2367af
DEMO MANUAL DC2367A
QUICK START PROCEDURE
Demonstration circuit DC2367A is an easy way to evaluate
the performance of the LTM4632. Please refer to Figure 1
for test setup connections and follow the procedure below.
1. With power off, place the jumpers in the following
positions for a typical application for 2.5VOUT1 and
1.25VOUT2 rails:
JP1 JP2 JP3 JP4 JP6
RUN1 RUN2 TRACK/SS MODE VDDQ SEL
ON ON SS CCM 2.5V
2. Before powering up the input supply and loads, preset
the input voltage supply to be between 3.6V to 15V.
Preset the load current for each output rail to 0A.
3. With power off, connect the loads, input voltage supply
and meters as shown in Figure 1.
4. Turn on the input power supply. The output voltage me-
ters for each output rail should display the programmed
output voltage ±1.5%.
5. Once the proper output voltages are established, ad-
just the load current on each rail within the 0A to 3A
range and observe each output rail’s load regulation,
efficiency, and other parameters.
6. To observe increased light load efficiency place the
mode pin jumper (JP4) in the BURST MODE position.
PERFORMANCE SUMMARY
Specifications are at TA= 25°C
PARAMETER CONDITIONS MIN TYP MAX UNITS
Input Voltage Range 3.6 15 V
Output Voltage VOUT1 (VDDQ) Resistor Programmable, Jumper Selectable 1.5 (±1.5%)
1.8 (±1.5%)
2.5 (±1.5%)
V
V
V
Maximum Continuous Output Current IOUT1 Derating Is Necessary for Certain Operating
Conditions. See Data Sheet for Details
3 A
Output Voltage VOUT2 (VTT) VOUT1 = 1.5V
VOUT1 = 1.8V
VOUT1 = 2.5V
0.75
0.9
1.25
V
V
V
Maximum Continuous Output Current IOUT2 Derating Is Necessary for Certain Operating
Conditions. See Data Sheet for Details
±3 A
Default Operating Frequency 1 MHz
Efficiency VIN = 12V, VOUT1 = 2.5V, IOUT = 3A, fSW = 1MHz
VIN = 12V, VOUT2 = 1.25V, IOUT = 3A, fSW = 1MHz
83.9
(See Figure 2)
72.3
(See Figure 3)
%
%
Downloaded from Arrow.com.Downloaded from Arrow.com.

3
dc2367af
DEMO MANUAL DC2367A
VIN
VARIALE RESISTOR
(OPTIONAL) FOR
SINK CURRENT TEST
+
–
+
–
+
–
LOAD
0A TO 3A
+
–
+–
+
–
LOAD
0A TO 3A
+
–
+
–
+
–
+–
QUICK START PROCEDURE
Figure 1. Test Setup
Figure 2. VDDQ 12VIN Efficiency Figure 3. VTT 12VIN Efficiency
OUTPUT CURRENT (A)
0
EFFICIENCY (%)
90
80
70
85
75
65
60 2.01.0
dc2367a F02
3.0
1.50.5 2.5
RUN2 = OFF
VDDQ = 2.5V
VDDQ = 1.8V
VDDQ = 1.5V
OUTPUT CURRENT (A)
0
EFFICIENCY (%)
80
70
75
65
50
55
60
2.01.0
dc2367a F03
3.0
1.50.5 2.5
RUN1 = OFF
VDDQIN, SUPPLIED
EXTERNALLY
VTT = 1.25V
VTT = 0.9V
VTT = 0.75V
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

4
dc2367af
DEMO MANUAL DC2367A
QUICK START PROCEDURE
V
IN = 12V
V
OUT1 = 2.5V
COUT1
= 100µF ×2, 10µF ×1
VOUT1 = 50mV/DIV
IOUT1_STEP = 2A/DIV
dc2367a F04
V
IN = 12V
V
OUT2 = 1.25V
COUT2
= 100µF ×3, 10µF ×1
VOUT2 = 50mV/DIV
IOUT1_STEP = 2A/DIV
dc2367a F05
Figure 4. VDDQ Load Transient Response (0A to 1.5A Load Step)
Figure 5. VTT Load Transient Response (0A to 1.5A Load Step)
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

5
dc2367af
DEMO MANUAL DC2367A
QUICK START PROCEDURE
V
IN = 12V
V
OUT1 = 2.5V
I
OUT1 = 3A
V
OUT2 = 1.25V
I
OUT2 = 3A
f
SW = 1MHz
TA
= 25°C, NO FORCED AIRFLOW
dc2367a F06
Figure 6. 12VIN Full Load Thermal Capture
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

6
dc2367af
DEMO MANUAL DC2367A
PARTS LIST
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
Required Circuit Components
1 2 CIN1, CIN2 CAP., 4.7µF, X5R, 16V, 10%, 0603 TDK - C1608X5R1C475K080AC
2 2 COUT7, COUT9 CAP., 10µF, X5R, 6.3V, 10%, 0805 MURATA, GRM219R60J106KE19D
3 5 COUT1, COUT2, COUT3, COUT4, COUT6 CAP., 100µF, X5R, 6.3V, 20%, 1206 MURATA, GRM31CR60J107ME39L
4 1 R4 RES., 19.1k, 1/10W, 1%, 0603 VISHAY, CRCW060319K1FKEA
5 1 U1 I.C., LTM4632EV, LGA 25-6.25X6.25 LINEAR TECH., LTM4632EV#PBF
Additional Demo Board Circuit Components
1 0 CIN4, COUT5, COUT8 CAP., OPTION, 1206 OPT
2 1 CIN5 CAP., 47µF, X5R, 16V, 20%, 1206 TDK, C3216X5R1C476M160AB
3 1 CIN3 CAP., 2.2µF, X7R, 25V, 10%, 0805 TAIYO YUDEN, TMK212B7225KGHT
4 1 CIN6 CAP., POSCAP, 22µF, X5R, 25V, 20%, 7343 PANASONIC, 25TQC22MV
5 4 CVCC1, C4, C18, CVCC CAP., 1µF, X5R, 10V, 10%, 0603 MURATA, GRM188R61A105KA61D
6 0 CDDQIN CAP., OPTION, 0805 OPT
7 1 CTR1 CAP., 4700pF, X7R, 50V, 10%, 0603 KEMET, C0603C472K5RACTU
8 1 CTTR CAP., 0.01µF, X7R, 50V, 10%, 0603 KEMET, C0603C103K5RACTU
9 1 CFFW1 CAP., 10pF, C0G, 50V, 5%, 0603 MURATA, GRM1885C1H100JA01D
10 0 CC1, CC2, CTTR1 CAP., OPTION, 0603 OPT
11 0 RFB1, RTR2, R7, R26, RD1, RDDQIN RES, OPTION, 0603 OPT
12 1 R5 RES., 30.1k, 1/10W, 1%, 0603 VISHAY, CRCW060330K1FKEA
13 1 R6 RES., 40.2k, 1/10W, 1%, 0603 VISHAY, CRCW060340K2FKEA
14 1 R3 RES., 10k, 1/10W, 1%, 0603 VISHAY, CRCW060310K0FKEA
15 2 RPG1, RPG2 RES., 100k, 1/10W, 1%, 0603 VISHAY, CRCW0603100KFKEA
16 1 R8 RES., 1k, 1/10W, 1%, 0603 VISHAY, CRCW06031K00FKEA
17 2 R1, R2 RES., 1M, 1/10W, 1%, 0603 VISHAY, CRCW06031M00FKEA
18 2 RTR1, RVDDQ RES., 0Ω, 1/10W, 0603 VISHAY, CRCW06030000Z0EA
19 1 RS1 RES., 0.05Ω, 1/4W, 1%, 1206 VISHAY, WSL1206R0500FEA
20 0 R29 RES, OPTION, 2512 OPT
21 1 Q1 XSTR., MOSFET, N-CH, 40V, 14A, TO-252 VISHAY, SUD50N04-8M8P-4GE3
Hardware: For Demo Board Only
1 14 E1-E14 TESTPOINT, TURRET, 0.094" MTG. HOLE MILL-MAX, 2501-2-00-80-00-00-07-0
2 3 JP1, JP2, JP3 CONN., HEADER, 1X3, 2mm SULLINS, NRPN031PAEN-RC
3 1 JP4 CONN., HEADER, 2X3, 2mm SULLINS, NRPN032PAEN-RC
4 1 JP6 CONN., HEADER, 2X4, 2mm SULLINS, NRPN042PAEN-RC
5 5 XJP1, XJP2, XJP3, XJP4, XJP6 SHUNT, 2mm SAMTEC 2SN-BK-G
6 2 J1, J2 CONN, BNC, 5PINS CONNEX, 112404
7 4 STAND OFF STAND OFF, NYLON, SNAP-ON, 0.375" KEYSTONE_8832
