Linear Security DUAL 824 Installation manual

SUPERVISED WIRELESS
SECURITY CONTROL PANEL
DUAL 824
USA & Canada [phone] & [phone]
[phone] - Toll Free FAX [phone]
www.linearcorp.com
Installation & Programming Instructions
PRINTER’S INSTRUCTIONS:
INSTR,INSTL,DUAL 824 - LINEAR P/N: 217703 D - INK: BLACK - MATERIAL: 20 LB. MEAD BOND WITH 80 LB. WHITE COATED COVER - SIZE: 8.500” X 11.000” - SCALE: 1-1 - FOLDING: ALBUM FOLD - BINDING: SADDLE-STITCH

CONGRATULATIONS for selecting Linear's DUAL 824
Security System. The Model DUAL 824P Control Panel and
the Model DUAL 824KP Keypad incorporate many advanced
and sophisticated features. The system can be expanded
and customized to fit the installation's specific needs.
The DUAL 824P Control Panel and its accessories are
designed and manufactured by the oldest wireless security
company in North America. You can look ahead to many
years of reliable service with this Control Panel and its
accessories.
Many insurance companies offer discounts on homeowners and
renters policies when a security system is installed. Discount
credits vary with different companies and generally increase in
savings with an increase in the level of protection. Inform the
user to ask their insurance agent about savings available.
The DUAL 824P Control Panel is UL Listed. For a UL smoke
alarm system, there must be at least one smoke detector
programmed into the Control Panel to meet National Fire
Protection Association (NFPA) Rule 72 Chapter 2 and UL
217 requirements. Many insurance companies require these
conditions to be met to qualify for a discount. Only use the
Model DXS-73 smoke detector with this Control Panel for a
UL smoke alarm system.
NOTE: Some cities and municipalities may require an
alarm system permit. Check with the local authorities
before installing this system.
In this manual, the bullets preceding the text help to define
the information. For example:
✦ This symbol indicates a feature.
✴ This symbol is for lit indications or system
sounds.
✎ This symbol is for important notes.
CONTROL PANEL
MODEL DUAL 824P
KEYPAD
MODEL DUAL 824KP
DUAL 824 SYSTEM
UL Listed as a Single Station
Smoke Detector Accessory, also
suitable as a Household Burglar-
Alarm System Control Unit. UL
Category CCN UTGT & NBSX
RING
TIP
R1
T1
DUAL 824 WIRING DIAGRAM
WARNING:
Incoming
Phone Line
Local
Telephones
RED
GREEN
GRAY
BROWN
AUXILIARY FUSE
TYPE 2AG, 1 AMP
ANT
SHIELD
To internal antenna
wires or to Model LA-P
external antenna kit
RED (+)
BLACK (-)
CONNECT TO
12 VDC/4AH
GEL CELL
BATTERY
LOOP
1
COM LOOP
2
LOOP
3
COM LOOP
4
LOOP
5
COM LOOP
6
LOOP
7
COM LOOP
8
H/A
-
H/A
+
RLY
COM
RLY
N/C
RLY
N/O
+12
VDC
KPD
+
KPD
-
KPD
CLK
KPD
DAT
KPD
SPK+
KPD
SPK -
AC AC
HARDWIRED LOOP INPUTS OUTPUTS KEYPAD XFRMR
BATTERY FUSE
TYPE 2AG, 3 AMP
Battery wires
Charging voltage: 13.8 VDC
ANTENNA
BACKUP BATTERY
Normal battery
life should
exceed 3 years
TELEPHONE
Fire protection must follow NFPA Standard No. 72 (National
Fire Protection Association, Batterymarch Park, Quincy, MA
02269). Printed information describing proper installation,
operation, testing, maintenance, evacuation planning, and
repair service is to be provided with this equipment.
TRANSFORMER
16VAC, 1.25A
Connect to
24hr. 120VAC,
60 Hz Outlet
LOOP RESPONSE TIME: 400 mS MAXIMUM RECOMMENDED LOOP LENGTH: 500 FEET
AUTOMATION
OUTPUT
Current limited
switched
+12 VDC, 40 mA
voltage source
See instructions
for output options
ALARM RELAY
Rated 12 volts,
1 amp maximum
EXTERNAL SIREN
12 VDC at 1 Amp
maximum
To any COM terminal
RED BLACK ORANGE WHITE
KEYPAD WIRING
4-conductor 22 AWG wire
Up to 100 feet for all keypads used allowed
DUAL 824KP
HARDWIRED KEYPAD
ONE OR TWO
UNITS ALLOWED
AUXILIARY
POWER
OUTPUT
12 VDC at 1 Amp
maximum
FOR INSTALLATION INSTRUCTIONS,
REFER TO THE MANUAL SUPPLIED
WITH THIS PRODUCT
N.C.
2.2k
E.O.L.
RESISTOR
LOOP 1
N.C.
2.2k
E.O.L.
RESISTOR
LOOP 2
N.O. N.O.
N.C.
2.2k
E.O.L.
RESISTOR
LOOP 3
N.C.
2.2k
E.O.L.
RESISTOR
LOOP 4
N.O. N.O.
N.C.
2.2k
E.O.L.
RESISTOR
LOOP 5
N.C.
2.2k
E.O.L.
RESISTOR
LOOP 6
N.O. N.O.
N.C.
2.2k
E.O.L.
RESISTOR
LOOP 7
N.C.
2.2k
E.O.L.
RESISTOR
LOOP 8
N.O. N.O.
CAUTION: IMPORTANT:
[phone] • FAX [phone]
USA & Canada [phone] & [phone]
Toll Free FAX [phone]
www.linearcorp.com
1) MISCONNECTIONS MAY CAUSE DAMAGE TO
CONTROL PANEL ELECTRONICS
2) DO NOT REVERSE BATTERY LEADS
3) TO PREVENT RISK OF ELECTRICAL SHOCK,
DISCONNECT TELCO JACK BEFORE SERVICING
THIS CONTROL PANEL
4) FOR CONTINUED PROTECTION AGAINST FIRE,
REPLACE ONLY WITH SAME TYPE AND RATING OF
FUSES
1) NO USER SERVICABLE PARTS INSIDE
2) RISK OF FIRE AND ELECTRICAL SHOCK, ROUTE
WIRES AWAY FROM INTERNAL COMPONENTS
3) REMOVE AC POWER BEFORE CONNECTING
TRANSFORMER, BATTERY, OR REPLACING FUSES
1) USE UL LISTED CABLE FOR ALL CONNECTIONS
2) WEEKLY TESTING IS REQUIRED TO ENSURE PROPER
OPERATION OF THIS SYSTEM
3) DO NOT CONNECT AC POWER TO A RECEPTACLE
CONTROLLED BY A SWITCH
4) CONNECTION OF THE FIRE ALARM SIGNAL TO A
FIRE ALARM HEADQUARTERS OR A CENTRAL STATION
SHALL BE PERMITTED ONLY WITH THE APPROVAL OF
THE LOCAL AUTHORITY HAVING JURISDICTION. THE
BURGLAR ALARM SIGNAL SHALL NOT BE CONNECTED
TO A POLICE EMERGENCY NUMBER.
LINEAR LLC
RESIDENTIAL SECURITY RECEIVER
MODEL: DUAL 824
PART # SSC00056
FREQUENCY: 315 MHz
POWER SUPPLY: 16 VAC, 1.25A
This device complies with FCC Part 15 and IC
Canada Rules and Regulations. Operation is
subject to the following two conditions: (1) This
device may not cause harmful interference and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
Complies with Part 68, FCC Rules.
FCC Registration Number: EF4HKG-31823-AL-E
Ringer Equivalence Number: 1.7B
Warranty Expiration Date:
MODEL RSM-2
VOICE RESPONSE
SPEAKER
8 Ohm - 2 Watts
USOC JACKS:
RJ31X, RJ38X
MADE IN CHINA 454
CANADIAN REGULATORY INFORMATION
IC ID 1078-102-556A
Complies with IC RSS 210
En conformité avec IC CNR 210.
INTRODUCTION

1
1. THE DUAL 824 SECURITY SYSTEM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
CONTROL PANEL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
DOOR/WINDOW SENSORS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
WIRELESS KEYPAD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
SMOKE DETECTOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
REMOTE CONTROLS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
GLASS BREAK DETECTOR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
PANIC BUTTONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
BILL TRAP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
PASSIVE INFRARED MOTION DETECTOR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. SECURITY SYSTEM FLOOR PLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
EXAMPLE SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
DESIGN THE INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3. OVERVIEW OF KEYPADS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
HARDWIRED KEYPAD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
WIRELESS KEYPAD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
ABOUT SENSOR STATUS SUPERVISION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4. HARDWIRED KEYPAD FEATURES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
5. CONTROL PANEL FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6. CONTROL PANEL INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
SYSTEM LOCATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
WALL MOUNTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
EXTERNAL ANTENNA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
HARDWIRED KEYPAD INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
HARDWIRED LOOP WIRING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
ARM/DISARM KEY STATION WIRING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
EXTERNAL ALARM SIREN CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
TELEPHONE LINE CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
AUTOMATION OUTPUT CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
VOICE RESPONSE MODULE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
CONTROL PANEL POWER CONNECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
BACKUP BATTERY INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
7. BASIC CONTROL PANEL PROGRAMMING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
CREATE THE MASTER USER CODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
PROGRAM THE HARDWIRED LOOPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
PROGRAM THE WIRELESS SENSORS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
PROGRAMMING DIFFERENT SENSOR TYPES. . . . . . . . . . . . . . . . . . . . . . . . 16
8. BASIC SENSOR INSTALLATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
DXS-10 WIRELESS KEYPAD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
DXS-31 & DXS-32 DOOR/WINDOW SENSORS . . . . . . . . . . . . . . . . . . . . . . . . 19
TEST SENSORS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
9. CUSTOMIZING THE KEYPAD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
LABELING THE SENSOR LOCATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
10. SYSTEM OPERATING MODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
OFF MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
CHIME MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
HOME MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
SECURE EXIT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
HOME INSTANT MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
MANUAL BYPASSING OF SENSORS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
AWAY MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
MANUAL BYPASSING OF SENSORS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
TEST MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
11. SYSTEM TROUBLE INDICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
CONTROL PANEL POWER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
WIRELESS SENSOR LOW BATTERIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
SENSOR RADIO TROUBLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
12. CUSTOMIZING THE SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
ADDING SENSORS TO THE SYSTEM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
REMOVING SENSORS FROM THE SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . 26
MAKING A SENSOR A 24-HOUR DOOR CHIME . . . . . . . . . . . . . . . . . . . . . . . 27
MAKING A SENSOR INTERIOR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
MAKING A SENSOR PERFORM A DIFFERENT FUNCTION . . . . . . . . . . . . . . 28
13. ADVANCED PROGRAMMING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
SETUP MODE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
CHANGING A SENSORS SUPERVISION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
CHANGING A SENSORS RESTORE REQUIREMENTS . . . . . . . . . . . . . . . . . . 30
ENTRY DELAY TIME. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
EXIT DELAY TIME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
BURGLARY SIREN TIME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
EMERGENCY SIREN TIME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
FIRE SIREN TIME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
AUTOMATION OUTPUT TIME . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
REMOTE CONTROL & HARDWIRE ARMING LEVEL . . . . . . . . . . . . . . . . . . . . 31
REMOTE CONTROL & HARDWIRE DISARMING LEVEL . . . . . . . . . . . . . . . . . 31
ENTRY DELAY BEEPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
EXIT DELAY BEEPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
SILENT BURGLARY ALARMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
SILENT EMERGENCY ALARMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
DISABLING QUICK ARMING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
AUTOMATIC RESTORAL OF BYPASSED SENSORS . . . . . . . . . . . . . . . . . . . . 32
AUTOMATIC BYPASSING OF OPEN SENSORS . . . . . . . . . . . . . . . . . . . . . . . . 32
AUTOMATION OUTPUT MODE DURING ALARM . . . . . . . . . . . . . . . . . . . . . . . 33
AUTOMATION ACTIVATION TONE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
REMOTE CONTROL & HARDWIRE ARM/DISARM CHIRP . . . . . . . . . . . . . . . . 33
AUTOMATION OUTPUT ON DURING AND AFTER ALARM . . . . . . . . . . . . . . . 33
AUTOMATION OUTPUT ON DURING ALARM. . . . . . . . . . . . . . . . . . . . . . . . . . 33
AUTOMATION OUTPUT WHILE ARMED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
AUTOMATION OUTPUT DURING EXIT/ENTRY DELAYS . . . . . . . . . . . . . . . . . 34
AUTOMATION OUTPUT POLARITY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
REMOTE ACCESS PASSWORD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
DURESS CODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
MASTER USER CODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
ADDING ADDITIONAL USER CODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
REMOVING ADDITITIONAL USER CODES. . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
CONTROL PANEL MASTER RESET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
14. COMMUNICATOR PROGRAMMING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
SETUP MODE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
GENERAL COMMUNICATOR OPTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
COMMUNICATOR ENABLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
2-WAY AUDIO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
VOICE RESPONSE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
REMOTE LOCKOUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
CALL LIMITER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
DIALING DELAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
DIALING METHOD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
COMMUNICATOR REPORTING OPTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
REPORTING FORMAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
CALL ROUTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
ACCOUNT NUMBER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
PRIMARY TELEPHONE NUMBER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
SECONDARY TELEPHONE NUMBER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
SUPERVISORY OR PAGER TELEPHONE NUMBER . . . . . . . . . . . . . . . . . . . . 40
TELEPHONE NUMBER DELAYS AND SPECIAL CHARACTERS. . . . . . . . . . . 40
REPORT CONTROL PANEL TROUBLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
REPORT FORCE ARMING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
OPENING AND CLOSING REPORTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
POINT ID REPORTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
COMMUNICATOR REPORTING CODES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
GENERAL REPORTING CODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
SYSTEM REPORTING CODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
FORCE ARMING REPORTING CODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
DURESS REPORTING CODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
4 BY 2 FORMAT POINT ID REPORTING CODES . . . . . . . . . . . . . . . . . . . . . . . 44
4 BY 2 FORMAT POINT ID ALARM REPORT CODES. . . . . . . . . . . . . . . . . . . . 44
4 BY 2 FORMAT POINT ID TROUBLE REPORT CODES . . . . . . . . . . . . . . . . . 44
IMPORTANT INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
LINEAR LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
WIRELESS PRODUCT NOTICE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
FCC NOTICE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
FCC TELEPHONE RULES AND REGULATIONS . . . . . . . . . . . . . . . . . . . . . . . . 46
FIRE EVACUATION PLANNING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
INDUSTRY CANADA NOTICES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
TABLE OF CONTENTS

2
CONTROL PANEL
The DUAL 824P Control Panel is the heart of the system.
It monitors all of the system's wireless sensors, hardwired
loops, and controls the alarm sirens and Model DUAL 824KP
hardwired keypads.
The Control Panel constantly monitors the condition of the
system's sensors and hardwired contacts, displaying which
protected doors and windows are open or closed. If an
alarm occurs, the keypads display which sensor(s) caused
it. When a sensor has a low battery, the keypads display
which sensor needs a new battery. Sensors that send hourly
status transmissions keep the Control Panel informed of their
operating condition.
Up to eight different custom user codes can be used to
operate the system. For security, a user code must be
entered to disarm (turn off) the system. The system can be
armed (turned on) by entering a user code, or with the unique
“Quick Arm” feature. The five restricted user codes and the
special page alert user code can only arm and disarm the
system, no programming changes (except changing user
and duress codes) are allowed. The master user code is
allowed to program the Control Panel, and a duress code
can be selected for emergency disarming of the system with
a duress report to the Central Station. The page alert user
code can dial a pager number to inform the pager wearer
when the system is disarmed.
The Control Panel's memory will retain the user codes and
all of the system's programming, even during a total power
loss. An optional backup battery can be installed to power the
system during short power failures.
The built-in digital communicator connects the Control Panel
to a Central Alarm Monitoring Station through the telephone.
With a monitored system, the central station can dispatch
authorities in case of burglary, fire or other emergency. The
central station can also call family, friends, neighbors, or
anyone else designated on a custom call list. System arming
(closing) and disarming (opening) reports by user can also
be sent.
Each sensor can report directly to the Central Station using
the digital communicator's Point ID feature. If a sensor triggers
an alarm or experiences supervisory trouble, a unique report
code can be sent for immediate identification of the event.
The optional Model VB-2 digital voice response module can
be installed in the Control Panel. The VB-2 module provides
three exciting features: 2-way audio monitoring capability at
the Central Station through the communicator, local voice
prompts from the keypad's speaker (with Model RSM-2
speaker/microphone kit installed), and voice prompted
remote system control using in-house or off-site pushbutton
telephones.
The system has 24-hour capabilities that are always ready
to operate, even when the system is disarmed. They can be
triggered by buttons on the hardwired keypads, a wireless
keypad, portable remote controls, carbon monoxide detectors,
and smoke detectors. Pressing the EMERGENCY or FIRE button
for two seconds will cause an immediate siren and call the
central station. IMPORTANT: For personal emergency use
only. Not for use as a UL Listed Medical Alert System.
The Control Panel's Environmental feature is active 24-hours
and can be triggered with sensors connected to devices such
as water flow detectors, over/under temperature sensors, flood
sensors, etc. The Environmental feature activates the chime
annunciator without sounding the siren. The Environmental
feature does not send communicator reports.
An Automation Output in the Control Panel provides an
easy way to connect external devices to the Control Panel.
The output is fully programmable to activate on a variety
of conditions, such as when the system is armed, during
alarms, and during exit/entry delays. The Automation Output
can connect to lighting control modules, relays, noisemakers,
and indicators. The Control Panel's and wireless keypad's
key and any system sensors can control the Automation
Output.
The Control Panel can be programmed locally using its own
keypad or remotely, over the telephone, using Linear's Model
RA-2400 Remote Access software program. The RA-2400
upload/download program is a Windows™application that
runs on a personal computer and communicates with the
Control Panel through a modem, connected directly to the
panel, or through the telephone line.
1. THE DUAL 824 SECURITY SYSTEM
DXS-91 GLASS
BREAK DETECTOR †
DXS-73
SMOKE DETECTOR
DUAL 824P
CONTROL
PANEL
DXS-10
WIRELESS
KEYPAD
DXS-31
DOOR/WINDOW
SENSOR
DXS-54
PIR
DXT-41 & DXT-42
REMOTES
DXT-61A
REMOTE †
DXS-81
BILL TRAP †
DXT-21 & DXT-23
REMOTES †
DUAL 824KP
HARDWIRED
KEYPAD
DXS-32 MINI
DOOR/WINDOW
SENSOR
DXS-62A
REMOTE
† NOTE: These accessories
are not listed by UL.

3
DOOR/WINDOW SENSORS
The DXS-31 and DXS-32 sensors monitor doors and windows. They
send radio signals to the Control Panel. One type of signal is sent
when the door or window is opened, and a different type of signal is
sent when the door or window is closed. If the system is armed, a
sensor can trigger the Control Panel's burglary siren when its door
or window is opened. Both sensors are supervised, send hourly
status reports, and monitor their battery condition.
WIRELESS KEYPAD
The DXS-10 wireless keypad is used to operate the system remotely.
It can be placed in a convenient spot so the user doesn't have to
go to the hardwired keypad to operate the system. The wireless
keypad can also trigger the emergency or fire siren and actuate the
Automation Output. Pressing will cause the hardwired keypad(s)
to sound Beeps corresponding to the current
operating mode. The DXS-10 is supervised,
it sends hourly status reports and monitors
its battery condition. IMPORTANT: For
personal emergency use only. Not for use
as a UL Listed Medical Alert System.
SMOKE DETECTOR
The DXS-73 is a high quality smoke detector with a built-in radio
transmitter. As soon as smoke is detected, the unit will sound its local
noisemaker. Then, 20 seconds after the local noisemaker sounds,
the transmitter sends an alarm signal to the Control Panel.The alarm
signal will be repeated every 20 seconds as long
as smoke is still present. A restoral signal will be
sent when the smoke detection chamber clears.
The DXS-73 is supervised, it sends hourly status
reports, and monitors its battery condition.
☞NOTE: A Model DXS-73 Smoke Detector is required to
create a UL Listed smoke alarm system. See Page 26 for
details on adding a smoke detector sensor to the system.
REMOTE CONTROLS
The DXT-41, DXT-61 single-button and DXT-23, DXT-42 multi-button
remote controls can be used to remotely arm and disarm the system.
The DXT-42’s left button will arm and the right button will disarm
the system. Pressing both buttons simultaneously will trigger the
emergency siren. Alternately the Control Panel can be programmed
to respond to the DXT-42 by arming and disarming with the left
button, and activating the automation output with the right button.
These transmitters can also be programmed to activate various
other Control Panel zones. These transmitters are not supervised.
GLASS BREAK DETECTOR
The DXS-91 is a glass break detector with an audio sound
discriminator and a built-in radio transmitter. The unit “listens” for
the sound of breaking glass. When glass breakage is detected,
the unit sends an alarm signal to the Control Panel. The DXS-91 is
supervised, it sends hourly status reports and monitors its battery
condition.
PANIC BUTTONS
The DXT-21, DXS-21 single-button, and DXT-23, DXS-23 two-button
transmitters can be used as portable “panic buttons”. Pressing the
front or top button on the DXT-21 or DXS-21 at any time will trigger
the emergency siren. Pressing both front buttons simultaneously
on the DXT-23 or DXS-23 at any time will trigger the emergency
siren. These transmitters can be programmed to activate various
other system functions.The DXT-21 and DXT-23 transmitters are not
supervised. The DXS-21 and DXS-23 transmitters are supervised.
The DXS-62A transmitter is typically used as a portable “panic
button”. Pressing the button on a DXS-62A at any time will trigger
the emergency siren.This transmitter can send hourly status signals
and low battery signals if the battery is low.
BILL TRAP
The DXS-81 bill trap can be used with the Control Panel in non-
UL small commercial hold-up installations. The unit is concealed in
a cash drawer under a stack of currency, with a single “bait” bill
secured in its money clip. During a hold-up, the cashier removes
the stack of currency along with the “bait” bill. When a “bait” bill is
removed, the transmitter sends a signal to the Control Panel. Four
additional signals are sent within the first minute
after the “bait” bill is removed. When the “bait” bill
is replaced, a restore signal is sent. The DXS-81
is supervised, it can send hourly status reports
(optional) and monitors its battery condition.
PASSIVE INFRARED MOTION DETECTOR
The DXS-54 is a passive infrared (PIR) motion detector with a built-in
radio transmitter. The PIR detects motion in its detection pattern by
measuring the infrared emission levels of objects that it “sees”. If
the infrared levels change quickly, as when a person moves across
the detection pattern, the PIR will recognize the
change as an intrusion and send an alarm signal
to the Control Panel. An alarm will be triggered if
the system is in the Away Mode. The DXS-54 is
supervised, it sends hourly status reports and
monitors its battery condition.
DXS-31
DXS-32
DXS-10
DXS-73
DXT-41
DXT-61‡
DXT-42
DXS-91‡
DXT-21‡ DXS-21‡ DXT-23‡ DXS-23‡ DXS-62A
DXS-81‡
DXS-54
‡ NOTE: These accessories not listed by UL

4
EXAMPLE SYSTEM
✦ The example shows a typical DUAL 824 system.
✦ Any or all of the accessories shown can be used.
✦ A total of 24 sensors can be used with each
Control Panel. Each wireless sensor, hardwired
loop, and wireless keypad used occupies a
sensor location.
DESIGN THE INSTALLATION
1. Draw a floor plan for the installation.
2. Consider the security needs of the premises.
3. Determine which doors and windows are
vulnerable to intrusion.
4. Figure which interior areas an intruder might go
to if unlawful entrance is gained.
5. Indicate locations for door/window sensors,
interior motion detectors, wireless and hardwired
keypads, glass break detectors and external
siren speakers.
6. Decide on a centralized location for the security
Control Panel.
2. SECURITY SYSTEM FLOOR PLAN
CP
S
GARAGE
MS
S
MD
ES
HK
S
S
MD
MS
S
S
CP - CONTROL PANEL
HK - HARDWIRED KEYPAD
S - DOOR/WINDOW SENSOR
WK - WIRELESS KEYPAD
MD - MOTION DETECTOR
ES - EXTERNAL SIREN
SD - SMOKE DETECTOR
CO - CARBON MONOXIDE DETECTOR
GB - GLASS BREAK SENSOR
MS - HARDWIRED MAGNETIC SWITCH
LIVING
DINING
KITCHEN
ENTRY
BED
BATH DEN
GB
SD
GB
BED
NOTE: IN NEW CONSTRUCTION, NFPA 72 REQUIRES A
SMOKE DETECTOR LOCATED INSIDE EACH BEDROOM
AS WELL AS A SMOKE DETECTOR ON EACH LEVEL.
MS
WK
HK
S
S
S
CO
Example Residential Security System Floor Plan

5
HARDWIRED KEYPAD
✦ One or two hardwired keypads can be used for
controlling the system.
✦ Three system status indicators:
READY, ARMED, & TROUBLE
✦ Three system supervisory indicators:
POWER, BATTERIES, & RADIO
✦ Five system mode indicators:
OFF, CHIME, HOME, AWAY & TEST
✦ 24 system sensor indicators.
✦ Location inside beauty cover for supplied sensor
identification labels.
✦ Press to activate the automation output.
✦ Pressing clears the keypad.
✦ Pressing for two seconds sounds the mode
Beeps from the hardwired keypad(s).
✔ Off Mode: 1 “Gong”.
✔ Chime Mode: 1 “Gong” & 1 “Beep”.
✔ Home Mode: 1 “Gong” & 2 “Beeps”.
✔ Away Mode: 1 “Gong” & 3 “Beeps”.
✔ Test Mode: 1 “Gong” & 4 “Beeps”.
✦ Emergency and fire alarm can be triggered from
the keypad at any time.
✎ UL NOTE: For personal emergency use only. Not
for use as a UL Listed Medical Alert System.
WIRELESS KEYPAD
✦ For controlling the system remotely.
✦ Green operation light.
✦ Internal 9-volt battery is monitored by the Control
Panel.
✦ Keypad's beeper will buzz during transmissions
when the battery is low.
✦ Up to 3 years battery life (depends on frequency
of activation). (UL tested for 1 year minimum.)
✦ Sends hourly status reports to the Control Panel.
✦ Press to activate the automation output.
✦ Pressing clears the keypad.
✦ Pressing for two seconds sounds the mode
Beeps from the hardwired keypad(s).
✔ Off Mode: 1 “Gong”.
✔ Chime Mode: 1 “Gong” & 1 “Beep”.
✔ Home Mode: 1 “Gong” & 2 “Beeps”.
✔ Away Mode: 1 “Gong” & 3 “Beeps”.
✔ Test Mode: 1 “Gong” & 4 “Beeps”.
✦ Emergency and fire alarm can be triggered from
the wireless keypad at any time.
✎ UL NOTE: For personal emergency use only. Not
for use as a UL Listed Medical Alert System.
ABOUT SENSOR STATUS SUPERVISION
All DXS Format sensors transmit hourly status reports. All DXT
Format sensors do not transmit hourly status reports. Both sensor
formats can be used with the system.
When a sensor is programmed into the Control Panel, the system
will set the sensor as non-supervised or supervised. Sensors set
as non-supervised are not expected to send hourly status reports.
Sensors set as supervised are expected to send hourly status
reports. If a status report is not received in 8 hours from a sensor
set as supervised, the RADIO indicator will flash.
When sensors are programmed into the Control Panel, ALL
STATIONARY SENSORS ARE SET AS SUPERVISED, ALL
PORTABLE SENSORS ARE SET AS NON-SUPERVISED.
If stationary DXT Format sensors have been programmed into the
Control Panel, be sure to change their setting to non-supervised
to prevent RADIO indications. This will not prevent low battery
monitoring.
If portable DXS Format sensors have been programmed into the
Control Panel, and the installation requires supervision for specific
portable sensor(s), change the selected portable sensors setting to
supervised.
After programming the sensors, if changes are required, refer to
“Changing a Sensors Supervision” on Page 30 for details on
changing the way a sensor’s supervision is set.
3. OVERVIEW OF KEYPADS
HARDWIRED
KEYPAD
WIRELESS
KEYPAD

6
1 BEAUTY COVER
★ The beauty cover snaps open and shut to hide the keypad’s keys, mode and
supervisory indicators, and the sensor location labeling area.
2 KEYPAD
★ Backlit keys for easy viewing in low light conditions.
★ For entering the user's user code (numerically or alphabetically).
★ Used when programming system options.
★ Press to activate the Automation Output.
★ Press to clear keypad if the wrong key is pressed.
★ Press for two seconds to view sensor battery and supervisory status (see
BATTERIES and RADIO indicator description).
3 24-HOUR BUTTONS
★ Pressing FIRE for two seconds sounds the fire siren and sends a “fire” message
to a central monitoring station through the digital communicator (if the system
is monitored).
★ Pressing EMERGENCY for two seconds sounds the emergency siren and sends
an “emergency” message to a central monitoring station through the digital
communicator (if the system is monitored).
★ Both work even when system is disarmed.
★ IMPORTANT: For personal emergency use only. Not for use as a UL Listed
Medical Alert System.
4 SYSTEM SUPERVISORY INDICATORS
★ Shows the current status of the system.
POWER LIGHT
★ Glows when AC power is on.
★ Blinks when AC power is off and backup battery is installed.
★ Blinks when the backup battery is low, recharging or missing.
★ Off when AC power is off and no backup battery is installed (system disabled).
BATTERIES LIGHT
★ Blinks when one or more sensors have a low battery.
★ Press for two seconds to view sensor status. Sensor status indicator for any
sensor with a low battery will light along with the BATTERIES indicator.
★ Switch to Test Mode after replacing the sensor battery and completely test the
system (see Test Mode). Switching to Test Mode clears the low battery indication.
RADIO LIGHT
★ Blinks when one or more sensors have not reported status during the eight hour
status time period.
★ Press for two seconds to view sensor status. Sensor status indicator for any
sensor that has not reported in will light along with the TROUBLE indicator.
★ Switch to Test Mode after servicing the sensor and completely test the system
(see Test Mode). Switching to Test Mode clears the trouble indication.
5 MODE INDICATORS
★ The indicators next to the mode keys light to show the current system mode.
★ HOME indicator will blink during Secure Exit and Home Instant modes.
★ AWAY indicator will blink during the exit delay in the Away Mode.
6 MICROPHONE (OPTIONAL)
★ Location for the high sensitivity microphone included with the Model RSM-2
speaker/microphone kit.
★ Detects room audio when communicator is reporting to the Central Station
in 2-way audio mode (Model VB-2 digital voice response module and RSM-2
speaker/microphone kit must be installed).
7 SENSOR STATUS INDICATORS
★ Blacked-out sensor status indicators are only visible when lit.
★ Indicate the status of each of the system's wireless sensors and hardwired
loops.
★ Indicators show which doors and windows are open.
★ Indicators flash to display sensors that have caused an alarm.
★ Stick-on labels are provided to identify the custom sensor locations.
8 SYSTEM STATUS INDICATORS
★ Shows the current status of the system.
READY LIGHT
★ Lights when all system sensors are closed.
★ Shows that the system is ready to be armed.
★ The system can be armed without the READY indicator being lit, if sensors are
bypassed either manually or automatically.
ARMED LIGHT
★ Blinks during the exit delay.
★ Lights when the system is fully armed.
TROUBLE LIGHT
★ Lights when the system has detected supervisory trouble.
★ Supervisory trouble can be caused by power, sensor low battery, or sensor radio
supervision conditions.
★ Press for one second then view the system supervisory and status indicators
to determine the origin of the trouble.
9 MODE BUTTONS
★ Used to operate the system.
OFF
★ Off Mode disarms the system.
★ Switching to Off Mode stops the alarm siren.
✓ Multiple Beeps sound and sensor status indicators flash if an alarm has
occurred.
☞ Multiple Beeps mean caution. AN INTRUDER MAY STILL BE PRESENT.
CHIME
★ Chime Mode disarms the system.
★ Switching to Chime Mode stops the alarm siren.
✓ Multiple Beeps sound and sensor status indicators flash if an alarm has
occurred.
☞ Multiple Beeps mean caution. AN INTRUDER MAY STILL BE PRESENT.
★ Chime Mode is for monitoring doors and windows.
✓ Use this mode as an “automatic door chime” when at home.
✓ Opening any protected door or window causes the keypad(s) to “ding-dong”.
HOME
★ Home Mode arms the perimeter sensors, but not the interior sensors.
✓ Use this mode when anyone is staying behind.
✓ Interior motion detectors and interior door sensors are not armed.
✓ Home secure mode makes all delayed perimeter sensors instant.
✓ Secure exit mode starts an exit delay while remaining in Home Mode.
✓ Re-entering during the exit delay restarts the exit delay (one time only).
AWAY
★ Away Mode arms the entire system.
✓ Use this mode when leaving home.
✓ Door sensors set for delayed will have a time delay that allows the user to
leave and enter the premises without sounding the alarm.
✓ Re-entering during the exit delay restarts the exit delay (one time only).
✓ Entry Delay Beeps warn the user to disarm the system before the siren
starts.
TEST
★ Test Mode is for testing the system sensors.
✓ All sensor status lights blink when the Test Mode is entered.
✓ Each sensor status light will stop blinking when its sensor is tested.
★ Hold the TEST button down to test all of the keypad's indicator lights.
10 SOUNDER
★ Makes unique sounds for burglary, fire and emergencies.
★ Alarm sirens stop automatically after five minutes.
★ Sounds advisory tones to confirm keystrokes from the keypad.
★ Sounds mode selection tones.
★ Sounds alarm memory tones.
★ Beeps when Automation Output is activated.
★ The Control Panel has terminals available for an external siren.
11 SPEAKER (OPTIONAL)
★ Location for the speaker included with the Model RSM-2 speaker/microphone
kit.
★ Sounds voice operating prompts and audio from the Central Station (Model
VB-2 digital voice response module and Model RSM-2 required).
4. HARDWIRED KEYPAD FEATURES
4
3
5
9
6
7
8
10
1
2
11

7
1 BATTERY FUSE
★ Type 2AG, 3-amp fuse for the backup battery.
★ If the keypad's POWER light is flashing and the optional backup battery is
installed and charged, check this fuse.
✎ WARNING: For continued protection against the risk of fire, replace only
with the same type and rating of fuse.
2 CONDUIT KNOCKOUTS
★ Four cabinet knockouts are provided for wiring using conduit.
★ The 3/4" knockouts fit standard 3/4" conduit fittings.
3 WIRING ACCESS SLOT
★ Provides access for wiring through a hole in the mounting wall.
★ Route cables for power, telephone, external speaker, etc. through this slot.
4 MAIN TERMINAL BLOCK
★ Terminals for hardwired loop inputs.
★ Terminals for Automation Output to connect to an automation controller.
★ Terminals for external relay output for “dry” contacts (Form C, normally open/
normally closed, 1 amp @ 24 volts maximum).
★ Terminals for fused auxiliary 12 volt output and common ground.
★ Terminals for connection to one or two Model DUAL 824KP keypads.
★ Terminals for connection to the plug-in AC transformer.
5 AUXILIARY FUSE
★ Type 2AG, 1-amp fuse.
★ Protects the auxiliary power output and siren driver circuit.
★ Fuse will blow when load exceeds 1 amp total.
✎ WARNING: For continued protection against the risk of fire, replace only
with the same type and rating of fuse.
6 TELEPHONE TERMINAL BLOCK
★ Provides telephone connections for the digital communicator.
★ Provides telephone connection for voice prompted telephone remote control
(optional VB-2 digital voice response module required).
★ Provides seized ring and tip connections for local telephone instruments.
Communicator will disconnect local telephones while on-line.
7 WALL-MOUNT KEYHOLE SLOTS
★ Four slots used when mounting Control Panel to the wall.
★ Used as a template for the Control Panel when it is mounted to the wall.
8 DIGITAL VOICE RESPONSE MODULE (OPTIONAL)
★ The Model VB-2 gives the Control Panel's digital communicator listen-only,
manual 2-way and full duplex 2-way audio capability with the Central Station.
★ The module allows remote command of the system using a standard pushbutton
telephone, on or off site.
★ The module provides optional voice prompts from the keypad(s) (Model RSM-2
speaker/microphone kit required for each keypad).
9 ANTENNA KNOCKOUT
★ A cabinet knockout is provided for mounting an external antenna connector.
★ For an external antenna, use Linear's Model LA-P antenna kit.
★ The antenna kit can also be used to connect the Control Panel to co-ax for a
remote antenna.
10 ANNUNCIATOR VOLUME CONTROL
★ Varies the volume of the advisory tones that come from the keypad(s) speaker
when the Model RSM-2 speaker/microphone kit is installed in the keypad.
★ Does not affect keypad's sirens (they are always full volume).
11 RADIO TEST POINTS
★ Used to monitor the Control Panel's radio receiver during troubleshooting.
★ Provides connection for an audio amplifier to listen to the receiver's output.
★ Helpful to determine sources of radio interference.
12 ANTENNA TERMINALS
★ Antenna and shield (ground) terminals for receiving signals from the system's
sensors.
★ Pre-wired to the Control Panel's internal wire dipole antenna.
★ Alternately connects to the Model LA-P local whip and remote antenna kit.
13 OPTIONAL BACKUP BATTERY
★ Space for 12-volt, 4 amp/hour backup battery. (Highly recommended.)
★ Backup battery is automatically charged and monitored by the Control Panel.
★ Backup battery can power the Control Panel for up to 6 hours.
★ UL NOTE: Normal estimated battery life should be 3 to 4 years.
14 REMOVABLE CABINET COVER
★ The cabinet cover can be removed for easy system wiring and setup.
★ Two screws secure cabinet cover when closed.
★ An optional cabinet lock can be installed for additional security.
5. CONTROL PANEL FEATURES
1
4
5
6
78
3
9
10
11
12
14
13
2

8
SYSTEM LOCATION
✎ NOTE: Wireless sensor signals must be able to
reach the Control Panel.
✔ Try to centrally locate the Control Panel.
✔ Keep Control Panel away from large metal
appliances.
✔ Maximum recommended sensor range is 400
feet (system tested at 1000 feet).
✎ NOTE: If you don't use the wireless keypad, a
hardwired keypad should be easily accessible to
the usual entrance.
✔ When the Control Panel is set in the Away
Mode, the user has 30 seconds to switch to
Off Mode before the burglary siren sounds.
✎ NOTE: Make sure a hardwired keypad is in a place
where the alarm can be heard during the night hours.
✔ Optional remote external sirens (up to 150
feet from the Control Panel) can be used to
make alarms louder and remote the sound
location.
1. Locate the Control Panel near a 115 VAC outlet
that's not controlled by a light switch.
2. Locate the Control Panel near a telephone outlet
(if using the digital communicator).
WALL MOUNTING
1. Use the Control Panel's case bottom as a
template and mark the locations for the four
mounting screws.
2. Mark the wiring access slot if the wiring is being
routed from behind the cabinet.
3. Use a hole saw to cut out the location for the
wiring access slot (if used) or punch out selected
cabinet wiring knockouts for conduit wiring.
4. Use four screws and appropriate screw anchors
to mount the unit to the wall.
EXTERNAL ANTENNA
✦ Linear's Model LA-P antenna kit can be used
with the DUAL 824P Control Panel to replace the
standard internal antenna.
✦ The antenna can be mounted on the cabinet,
or the kit can be used to connect to co-ax for a
remote antenna.
1. Remove the two standard white antenna wires
attached to the ANT and SHIELD terminals.
2. Punch out the antenna knockout.
3. Mount the antenna connector in the antenna
knockout.
4. Route the antenna co-ax down to the Control
Panel's antenna connector.
5. Connect the antenna's co-ax center conductor to
the ANT terminal.
6. Connect the antenna's co-ax shield to the SHIELD
terminal.
7. Route the two antenna ground wires as shown.
6. CONTROL PANEL INSTALLATION
USE THE CASE BOTTOM
AS A TEMPLATE TO MARK
THE FOUR KEYHOLE
MOUNTING HOLES
FOR RECESSED WIRING,
MARK WIRING SLOT, THEN
CUT OUT HOLE WITH
DRYWALL SAW
FOR CONDIUT WIRING,
PUNCH OUT REQUIRED
KNOCKOUTS AND INSTALL
3/4" CONDUIT HUBS IN
HOLES
PUNCH OUT ANTENNA
KNOCKOUT AND
INSTALL LA-P ANTENNA
CONNECTOR INTO HOLE
1
2
CONNECT CO-AX
SHIELD TO SHIELD
TERMINAL AND CO-AX
CENTER CONDUCTOR
TO ANT TERMINAL
3
INSTALL THE WHIP
ANTENNA AND ROUTE
THE TWO GROUND
WIRES AS SHOWN

9
HARDWIRED KEYPAD INSTALLATION
✦ One or two Model DUAL 824KP keypads can be
used with the DUAL 824P Control Panel (one
keypad is included in the DUAL 824 system
package).
✦ The keypad is supplied with a short wiring
harness and connector.
1. Use a flat blade screwdriver to open the keypad
case. Identify the keypad internal components.
2. Set the keypad select jumper to KEYPAD 1 if this
is the first, or only, keypad installed. Set the
jumper to KEYPAD 2 if this is the second keypad
installed.
3. For a silent keypad, set the SOUNDER jumper to
OFF.
4. Select an indoor location with easy wiring access
to the Control Panel and use the keypad's
mounting plate as a template to mark the
mounting holes for the keypad.
5. Route 4-conductor 22 AWG (or larger) wire from
the Control Panel to the keypad(s). Up to 100
feet of wire total can be used with this system.
If installing two keypads, each keypad can be
“home-run” or “daisy-chained”.
✎ Note: If a Model VB-2 voice response module is
going to be used with the system, in addition
to the keypad’s four wires, route 2-conductor
shielded cable and 2-conductor 22 AWG wire from
the Control Panel to the keypad(s) for the keypad’s
microphone and speaker. When using two keypads
and two microphones, each shielded microphone
cable must be home run to the VB-2 terminal block.
6. If using the VB-2 voice response module, refer
to the instructions supplied with the Model
RSM-2 speaker/microphone kit for details on
installing and wiring the keypad’s speaker and/or
microphone.
7. Connect the 4-conductor wire to the Control
Panel's keypad terminals, noting wire colors.
8. Noting wire colors, connect the keypad's wiring
harness to the wire from the Control Panel.
9. Plug the keypad wiring harness into the keypad
connector and snap the keypad case closed.
DEFAULT JUMPER POSITIONS
ALTERNATE JUMPER POSITIONS
TWIST SCREWDRIVER
IN SLOTS TO OPEN
THE KEYPAD CASE
RSM-2 KIT
SPEAKER
LOCATION
KEYPAD
CONNECTOR SOUNDER
JUMPER
(ON OR OFF)
KEYPAD
SELECT
JUMPER
(KPD1 OR KPD2)
RSM-2 KIT
MICROPHONE
LOCATION
SOUNDER JUMPER
SET TO "ON"
KEYPAD SELECT
JUMPER SET
TO "KEYPAD 1"
SOUNDER JUMPER
CAN BE SET TO "OFF" SET KEYPAD SELECT
JUMPER TO "KEYPAD 2"
IF THIS IS THE 2ND KEYPAD
COMPONENT
LOCATIONS
NOTE: MAXIMUM RECOMMENDED
WIRE RUN IS 100 FEET COMBINED
TOTAL FOR ALL KEYPADS
MOUNT KEYPAD INDOORS
AT A CONVENIENT HEIGHT
AND LOCATION FOR THE USERS
USE THE MOUNTING PLATE
AS A TEMPLATE TO MARK
SCREW LOCATIONS
USE SCREWS AND ANCHORS
OR APPROPRIATE FASTENERS
TO AFFIX MOUNTING PLATE
THE MOUNTING PLATE IS ALSO
DESIGNED TO BE ATTACHED
TO A SINGLE-GANG OUTLET BOX
DUAL 824P
CONTROL PANEL
TO
DUAL 824KP
KEYPAD
IF THE RSM-2 SPEAKER/MICROPHONE KIT IS
GOING TO BE USED, RUN AN ADDITIONAL PAIR
FOR THE SPEAKER AND A SHIELDED PAIR
FOR THE MICROPHONE
ROUTE WIRING
CONNECTOR THROUGH
MOUNTING PLATE HOLE
KPD DAT
KPD CLK
KPD
KPD
WHITE
ORANGE
BLACK
RED
ROUTE 4-CONDUCTOR 22 AWG WIRE OR LARGER
FROM CONTROL PANEL TO KEYPAD
WIRING
HARNESS
CONNECTOR
INSERT CONNECTOR INTO THE KEYED
SOCKET ON THE KEYPAD UNTIL IT
SNAPS TOGETHER
ALIGN TOP OF CASE FIRST,
THEN SNAP BOTTOM TOGETHER

10
HARDWIRED LOOP WIRING
✦ The DUAL 824 supports up to eight normally
open/closed hardwired loops each with 2.2K
end-of-line resistor supervision.
✦ Each hardwired loop that is wired and
programmed uses one sensor location.
✦ Each hardwired loop can be programmed to any
sensor number.
✦ Each hardwired loop can be programmed as any
sensor type, including arm/disarm toggle.
✦ Four COM terminals are shared as loop returns
for the eight loops.
✦ Each hardwired loop has a 400 millisecond
response time.
✎ NOTE: For UL installations, use UL Listed cable for
all hardwired loop wiring.
1. Route wiring from the Control Panel to each
hardwired switch contact, sensor, or device.
Route the wires through the wiring slot or
through a knockout for conduit wiring.
✎ NOTE: Maximum recommended hardwired loop
length is 500 feet (250' out, and 250' back) for each
loop. Maximum loop resistance (excluding the EOL
resistor) is 100 ohms.
2. Connect the loop wires to LOOP # and COM
terminals. For powered devices connect power
wires to +12 VDC and any COM terminal.
3. On the sensor end, connect each normally
closed sensor in series with the loop wires.
Connect each normally open sensor in parallel
with the loop wires. See wiring figure.
4. After the last sensor on the loop, connect a 2.2K
end-of-line resistor across the loop.
✎ NOTE: Before the hardwired loops will function,
they will need to be programmed. This will be
covered in the Basic Control Panel Programming
section of this manual.
ARM/DISARM KEY STATION WIRING
✦ Any of the hardwired loops can be used with a
momentary keyswitch to arm and disarm the
system.
1. Connect the loop as shown to the keyswitch and
end-of-line resistor.
2. Connect an LED indicator from the switch plate
to the H/A- and H/A+ terminals.
3. When programming the system, set the loop
sensor function to “Type 9, Arm/Disarm Toggle”
and set the Automation output to “Active while
Armed”.
RUN LOOP WIRING
BETWEEN THE CONTROL
PANEL AND THE REMOTE
HARDWIRED SENSORS
RUN 4-CONDUCTOR WIRE
TO POWERED DEVICES
RUN 2-CONDUCTOR WIRE
TO DEVICES NOT POWERED
FROM THE CONTROL PANEL
4-CONDUCTOR
FOR HARDWIRED
INFRAREDS
2-CONDUCTOR
FOR MAGNETIC
CONTACTS
LOOP
1
COM LOOP
2
LOOP
3
COM LOOP
4
LOOP
8
H/A
-
H/A
+
RLY
COM
RLY
N/C
RLY
N/O
COM
2.2K END-OF-LINE
RESISTOR FOR
EACH LOOP USED
NORMALLY CLOSED
SWITCHES (CONTACTS)
NORMALLY OPEN
SWITCHES (CONTACTS)
USE +12 VDC AND
ANY COM TERMINAL
TO POWER EXTERNAL
DEVICES (1 AMP MAX.)
MAIN TERMINAL BLOCK
+12
VDC
CONNECT EACH HARDWIRED
INPUT TO A LOOP AND COM
TERMINAL
FOR POWERED DEVICES, WIRE
POWER LEADS TO +12 VDC
AND ANY COMMON TERMINAL
(OBSERVE POLARITY)
LOOP
1
COM LOOP
2
LOOP
3
COM LOOP
4
LOOP
8
H/A
-
H/A
+
RLY
COM
RLY
N/C
RLY
N/O
COM
NORMALLY CLOSED,
SPRING RETURN, KEYSWITCH
470 OHM
KEYSTATION
2.2K OHM
LED
PROGRAM AUTOMATION
OUTPUT FOR "ACTIVE
WHILE ARMED"
LED WILL LIGHT
WHEN SYSTEM
IS ARMED
PROGRAM LOOP FOR
ARM/DISARM TOGGLE
(SENSOR TYPE 9)
MAIN TERMINAL BLOCK

11
EXTERNAL ALARM SIREN CONNECTION
✦ An external siren alerts occupants and neighbors
with a loud siren during alarm.
✦ Use a 12 volt, 1 amp maximum rated weather-
resistant horn speaker with a built-in siren driver.
Do not use a plain speaker without a siren driver.
✎ NOTE: Connection of an electromechanical bell or
motor bell is not recommended because of the radio
interference generated when the bell is running.
✎ UL NOTE: Only one external siren is allowed in UL
installations.
1. Mount the external siren.
2. Route the wires from the external siren to the
Control Panel.
3. Route the siren wires up through the wiring access
slot or through a knockout when using conduit.
4. Connect a jumper wire from the +12 VDC terminal
to the RLY COM terminal.
5. Connect the positive siren wire to the RELAY
N/O terminal.
6. Connect the negative siren wire to one of the
COM terminals.
✎ NOTE: The relay contacts are isolated. Use the
RLY N/O & RLY COM terminals alone to switch an
externally powered load.
TELEPHONE LINE CONNECTION
✦ Connect the Control Panel to the telephone
line if the system is monitored, requires 2-way
audio, telephone remote command, or for remote
programming with RA-2400 software.
✦ Telephone RING & TIP terminals are for
connection to the incoming telephone line.
✦ Seized telephone ring & tip (R1 & T1) are for
connection to local telephone sets. When the
communicator activates, all the local telephone
sets will be disconnected to prevent an off-hook
telephone on the premises from blocking the
communicator call.
1. Install a USOC RJ31-X or RJ38-X jack to the
telephone system near the Control Panel.
2. Route an appropriate modular telephone line
cord from the jack to the Control Panel.
3. Route the line cord through the Control Panel's
wiring access slot or through a knockout for
conduit wiring.
4. Connect the incoming telephone line wires to the
Control Panel's telephone terminal block TIP and
RING terminals.
5. Connect the local telephone set wires to the Control
Panel's telephone terminal block T1 and R1 terminals.
✦ When directly connecting (without a telephone line)
to the DUAL 824 with the RA-2400 remote access
software (Version 1.3 or later), disconnect the
incoming telephone line and connect the modem
to the panel's TIP and RING terminals (with the
modem's red & green phone line wires). Press the
EMERGENCY key while in Test Mode to cause the
panel to connect to the modem.
LOOP
8
H/A
-
H/A
+
RLY
COM
RLY
N/C
RLY
N/O
COM
EXTERNAL SIREN
12 VDC 1 AMP
MAXIMUM
EXTERNAL
ALARM RELAY
12 VDC, 1 AMP
MAXIMUM
INSTALL WIRE
JUMPER TO PROVIDE
POWER TO RELAY
CONTACTS
+12
VDC
MAIN TERMINAL BLOCK
CONNECT EXTERNAL
SIREN TO ALARM RELAY
TERMINALS
INSTALL A JUMPER
WIRE BETWEEN THE
+12 VDC AND RLY COM
TERMINALS
SEIZED
RING (R1)
SEIZED
TIP (T1)
LINE
RING (R)
LINE
TIP (T)
GRAY
RED
T
R
T1
R1
 ! " # $ % &
TO LOCAL
TELEPHONE
SETS
TO TELEPHONE
NETWORK
8-POSITION
USOC RJ31-X
(OR RJ38-X)
JACK
6 4 4  6 
SHORTING BAR
SHORT REMOVED
ON PLUG
INSERTION
8-PIN
MODULAR
PHONE CORD
DUAL 824P
TELEPHONE
TERMINAL
BLOCK
GREEN
BROWN
BLUE, ORANGE
BLACK, AND
YELLOW NOT
USED
TELEPHONE TERMINAL BLOCK
CONNECT INCOMMING AND
OUTGOING TELEPHONE LINES
TO THE TELEPHONE TERMINAL BLOCK
TELEPHONE
TERMINAL
BLOCK
EXTERNAL
ALARM
SIREN

12
AUTOMATION OUTPUT CONNECTION
✦ The Control Panel provides a Automation Output
to control lights, devices and appliances.
✦ Automation Output can connect to most popular
home automation devices and other simple
electronic devices (see figure).
✦ Press to turn the Automation Output on,
press again to turn it off.
Programmable Options
✦ There are many programmable options for the
Automation Output.
✦ The Automation Output can be programmed for
a variety of useful functions, such as: flashing
during alarm, flashing after an alarm, on while
armed, or, on during exit/entry delays.
✦ See the “Advanced Programming” section of this
manual for details on changing the function of the
Automation Output.
VOICE RESPONSE MODULE
✦ The DUAL 824P circuit board has a plug-in
location for a Model VB-2 voice response module.
✦ The VB-2 module allows remote command
of the system locally and remotely through a
pushbutton telephone.
✎ NOTE: The following two features require a Model
RSM-2 speaker/microphone kit installed in the
keypad.
✦ The VB-2 module can sound voice prompts
through a speaker installed in the keypad.
✦ The VB-2 module supports listen-only audio,
two-way manual audio, and full duplex two-way
audio communication with the Central Station
through a microphone installed in the keypad.
✎ NOTE: Refer to the VB-2 instructions for details on
operating the voice response module.
Voice Response Module Installation
1. Identify the audio module components, noting the
terminal block positions.
2. Connect shielded microphone wire to the
VB-2 MICROPHONE COMMON (for shield) and
MICROPHONE #1 (for center conductor) terminals.
Connect the other end of the wire’s shield to
the BLACK, and center conductor to the RED
microphone wires in the keypad.
3. If using two keypads for audio monitoring, repeat
Step 2 for the second keypad, except connect
the center conductor to the VB-2 MICROPHONE #2
terminal.
4. WITHOUT POWER APPLIED TO THE
CONTROL PANEL, plug the voice response
module into the sockets on the Control Panel's
circuit board. Be sure the arrows on the module
board are pointing up.
5. Connect 2-conductor wire from the Control
Panel’s KPD SPK+ and KPD SPK- terminals to the
two speaker wires in the keypad.
LOOP
8
H/A
-
H/A
+
RLY
COM
MAIN TERMINAL BLOCK
ANY SENSOR CAN
BE PROGRAMMED
TO TOGGLE
THE AUTOMATION
OUTPUT
PRESS THE
KEY ON ANY
SYSTEM KEYPAD
TO TOGGLE THE
AUTOMATION
OUTPUT
A
THE POSITIVE H/A TERMINAL PROVIDES
+12 VOLTS DC AND IS CURRENT LIMITED
AT 40 MILLIAMPS MAXIMUM
THE NEGATIVE H/A TERMINAL WILL
SWITCH TO GROUND WHEN
AUTOMATION OUTPUT IS ACTIVATED
X-10
BURGLAR ALARM
INTERFACE
(CAN CONTROL
HOUSE LIGHTS
THROUGH X-10
SYSTEM)
X-10
LINEAR RB-90
RELAY MODULE
YOUR
LOAD
POWER
SOURCE
LIGHT
EMITTING
DIODE
(L.E.D.)
EXAMPLE AUTOMATION OUTPUT HOOK-UPS
H/A +
H/A -
H/A +
H/A -
H/A +
H/A -
470 OHM
MICROPHONE
TERMINALS MICROPHONE #1 (+)
MICROPHONE COMMON (-)
MICROPHONE #2 (+)
MICROPHONE
DIGITAL VOICE
VOLUME CONTROL
MODULE-TO-CONTROL
PANEL CONNECTOR
MODULE-TO-CONTROL
PANEL CONNECTOR
VB-2 VOICE RESPONSE MODULE
CAREFULLY PLUG VOICE MODULE
INTO THE TWO CIRCUIT BOARD SOCKETS BE SURE ALL
PINS ARE ALIGNED
BOARD ARROWS
POINT UP
BE SURE CONTROL PANEL POWER IS DISCONNECTED!

13
CONTROL PANEL POWER CONNECTION
✦ The Control Panel is powered by a low voltage
plug-in transformer.
✦ Use up to 25 feet of 20 AWG or larger
2-conductor wire to connect the transformer to
the Control Panel.
1. Route the power wires from the plug-in
transformer to the Control Panel.
2. Connect the wires to the transformer terminals
(do not plug the transformer in until the
wiring is complete).
3. Route the power wires through the Control
Panel's wiring access slot or through a knockout
for conduit wiring.
4. Connect the power wires from the transformer to
the Control Panel's main terminal block AC & AC
terminals.
5. Plug transformer into an unswitched AC outlet.
6. Secure transformer with screw to prevent
unplugging.
BACKUP BATTERY INSTALLATION
✦ A 12-volt backup battery may be installed and is
highly recommended.
✦ The backup battery will power the system for up
to 6 hours during AC power loss.
✦ The backup battery is automatically charged by
the Control Panel when AC power is present.
✦ A low backup battery will cause the keypad's
POWER indicator to flash as it is being charged.
1. Position the battery as shown.
2. Connect the black battery lead to the negative
battery terminal.
3. Connect the red battery lead to the positive
battery terminal.
✎ WARNING: DO NOT REVERSE THE BATTERY
LEADS! THE BATTERY FUSE WILL BLOW.
KPD
CLK
KPD
DAT
KPD
SPK +
KPD
SPK- AC AC
KPD
-
MAIN TERMINAL BLOCK
XFRMRKEYPAD
PLUG-IN TRANSFORMER
16 VAC, 28 VA
BE SURE TO SELECT AN
UN-SWITCHED AC OUTLET
FOR THE TRANSFORMER
CONNECT
TRANSFORMER WIRES
TO THE AC TERMINALS
ON THE MAIN TERMINAL
BLOCK
TRANSFORMER
115 VAC
OUTLET
PLUG TRANSFORMER
INTO 115 VAC OUTLET
THAT IS NOT CONTROLED
BY A LIGHT SWITCH
SCREW
AFTER ALL WIRING IS COMPLETE,
CONNECT THE BACKUP BATTERY
BE SURE RED WIRE ATTACHES
TO POSITIVE (+) TERMINAL, AND
BLACK WIRE ATTACHES TO
NEGATIVE (-) TERMINAL

14
✦ In a new installation, when power is first
applied the system's master user code is
“1234”.
CREATE THE MASTER USER CODE
✎ NOTE: Local programming must be entered on
the system's hardwired keypad, not on a wireless
keypad.
1. Press (clears keypad if any other keys have
been pressed).
2. Place the system in Test Mode (enter 1234 and
press TEST.
✴ A “gong” and four “beeps” will sound.
3. Enter the Setup Mode from Test Mode, enter
1234 then press TEST again.
✴ A “gong” and five “beeps” will sound. The system is now
in Test Mode.
4. Enter 99 then press HOME.
5. Enter any combination of 1-5 digits for the master
user code, then press AWAY.
✎ NOTE: For maximum security, a three to five digit
code is recommended.
6. Press and hold the OFF key for 3 seconds to exit
program mode.
7. Test the new master user code by entering it then
pressing TEST.
8. Log the master user code in the box below.
✎ NOTE: The master user code can be used to enter
Setup Mode. The restricted user codes cannot. To
create restricted user codes, see the “Advanced
Programming” section of this manual.
7. BASIC CONTROL PANEL PROGRAMMING
MASTER USER CODE:
START IN SETUP MODE
PROGRAMMING
STEP #99
ENTERS STEP
NUMBER
NEW
MASTER
USER
CODE
STORES
NEW CODE
DONE
SETTING A
NEW MASTER
USER CODE
HOLD FOR
3 SECONDS
TO EXIT
SETUP
START IN OFF MODE
CLEARS
KEYPAD
DEFAULT
MASTER
USER
CODE
1 GONG &
4 BEEPS
(TEST MODE)
DEFAULT
MASTER
USER
CODE
1 GONG &
5 BEEPS
(SETUP MODE)
ENTERING
SETUP
MODE

15
PROGRAM THE HARDWIRED LOOPS
✦ Each hardwired loop used must be programmed
into the Control Panel's memory.
✦ Each hardwired loop programmed uses one of
the twenty four available sensor locations.
1. Start with the system in Test Mode (enter the
master user code and press TEST).
2. Enter the Setup Mode from Test Mode, enter the
master user code then press TEST again.
✴ A “Gong” and five “Beeps” will sound. The system is now
in Setup Mode.
✴ The sensor status indicators will light for any sensors
already programmed into the Control Panel.
3. Enter programming Step #301-308 (301=loop 1,
302=loop 2, etc.) for the hardwired loop desired.
4. Press HOME to select step.
5. Enter an unused sensor number from 01-24 for
the loop (you must enter two digits, example:
5 = 05).
6. Press AWAY to store.
✴ A single “Bing” tone will sound and the sensor status
indicator for that sensor will stay lit. A double “Buzz” will
sound if that sensor location is already in use.
7. Repeat Steps 3-6 to enable all of the hardwired
loops used.
✎ NOTE: The default sensor function for the
hardwired loops is Perimeter (Type 5). Any sensor
function can be selected for each hardwired loop,
refer to the “Customizing the System” section of
this manual.
PROGRAM THE WIRELESS SENSORS
✦ Each wireless sensor used must be programmed
into the system’s memory. See the next two pages for
details on activating different models of transmitters.
✦ Each wireless sensor programmed uses one of
the twenty four available sensor locations.
1. Start with the system in Test Mode (enter any
user code and press TEST).
2. Enter the Setup Mode from Test Mode, enter the
master user code then press TEST again.
✴ A “Gong” and five “Beeps” will sound. The system is now
in Setup Mode.
✴ The sensor status indicators will light for any sensors
programmed into the Control Panel.
3. Enter an unused sensor number from 01-24 (you
must enter two digits, example: 5 = 05).
✴ The sensor indicator light will flash for the sensor number
selected.
4. Activate the sensor by sending a test or alarm
signal (be sure the sensor's battery is connected
or that its battery protection strip is removed).
✴ A single “Bing” tone will sound and the sensor status
indicator for that sensor will stay lit. A “Buzz” will sound if
that sensor location is already in use.
5. Repeat Steps 3 & 4 for each additional sensor, or
exit Setup Mode by pressing the OFF button for
three seconds.
START IN TEST
MASTER
USER
CODE
1 GONG & 5 BEEPS
(SETUP MODE)
STEP #301-308
FOR LOOP #1-8
ENTERS STEP
NUMBER
STORES LOOP
SENSOR NUMBER
1 BING
SENSOR
NUMBER (01-24)
FOR LOOP
DONE
START IN TEST
MASTER
USER
CODE
1 GONG & 5 BEEPS
(SETUP MODE)
NEW SENSOR
NUMBER
1 BING AND
SENSOR
INDICATOR
LIGHTS
REPEAT OR EXIT
ACTIVATE
SENSOR
SENSOR
INDICATOR
FLASHES

16
PROGRAMMING DIFFERENT SENSOR TYPES
✦ Follow the instructions on the previous page to
select a sensor number to program the sensor
into.
✎ NOTE: A sensor can be programmed into more
than one location. Be sure to choose an UNUSED
sensor number. If a sensor gets entered into more
than one location, delete the duplicates using the
remove sensor function.
✦ To add DXS-10 wireless keypads, press and hold
the keypad's key until programmed into the
Control Panel.
✦ For DXS-31 and DXS-32 door/window sensors,
move the magnet away from the side of the
sensor.
✎ IMPORTANT NOTE: The DXS-31 & DXS-32 door/
window sensors are pre-set at the factory for
delayed burglary response. If the sensor is going
to be used on a non-entry portal (window, sliding
glass door, etc.) a jumper can be changed in the
sensor to select instant response. The jumper
should be changed before programming the
sensor so the Control Panel will assign the sensor
to the proper sensor function. See the “Basic
Sensor Installation” section of this manual or the
sensor’s instructions for details on changing the
jumper.
✦ For DXS-81, DXS-91, DXS-54, DXS-73,
& accessory sensors, simply send a test
transmission (refer to the sensor's instructions for
details on sending a test transmission).
DXS-10
DXS-32
DXS-81

17
PROGRAMMING DIFFERENT SENSOR TYPES (CONT.)
✦ For DXT-61, DXT-21, DXS-21, DXT-41, &
DXS-62A single-button remotes, simply press the
unit's button.
✎ NOTE: After the Control Panel recognizes the
transmitter, single-button remotes must be
re-programmed as “panic buttons” or home
automation controllers. Refer to Page 28 in the
“Customizing the System” section of this manual.
✦ For DXT-23, DXS-23, & DXT-42 multi-button
remotes: Learn the transmitter by pressing the
left button. The remote will arm the Control Panel
with the left button and disarm with the right
button. Labels are provided with the DXT-42 for
identifying the buttons.
✎ NOTE: After the Control Panel “learns” the
transmitter, multi-button remotes can easily be
re-programmed to have the left button arm/disarm
the Control Panel and the right button activate/
deactivate the Home Automation output. Refer
to the “Advanced Programming” section of this
manual.
For All Models:
✴ A single “Bing” tone will sound and the sensor status
indicator will stay lit when the sensor is programmed into
the Control Panel.
✴ A “Buzz” tone will sound if there is already another
sensor programmed to that sensor number.
✦ Exit Setup Mode by pressing the key then
press OFF for three seconds. Reminder: The
system will automatically exit the Setup Mode
and return to Off Mode after three minutes of
keypad inactivity.
✎ NOTE: To remove sensors from the Control Panel's
memory, see Page 26 in the “Customizing the
System” section of this manual.
DXT-21
SEND SIGNAL WITH LEFT BUTTON
LEFT = ARM/DISARM
RIGHT = DISARM
BOTH = EMERGENCY
DXT-42

18
✦ Each accessory sensor is packaged with its
own set of installation instructions specific to the
model of sensor.
✦ Refer to the sensor's instructions for details
on installing, operating, and testing of the
sensor.
✦ Following are basic instructions for installing
two popular DUAL 824 accessories: The Model
DXS-10 Wireless Remote Keypad and the Model
DXS-31 & DXS-32 Door/Window Transmitters.
DXS-10 WIRELESS KEYPAD
✦ The DXS-10 is used to remotely operate the
system.
✦ The keypad can be simply set on a table or
mounted to a flat surface.
TABLE-TOP USE
✦ Four anti-mar pads are provided as a scratch
deterrent for the keypad.
✎ NOTE: Do not use the adhesive pads if the keypad
is going to be wall mounted.
1. Peel off the adhesive tape backing on the pads
and stick them to the back of the keypad.
✦ The wireless keypad can be used as a portable
keypad. Because of the hourly supervisory
transmissions, if the unit is taken out of range
from the Control Panel for more than eight hours,
the hardwired keypad will indicate “radio trouble”
for the wireless keypad. The keypad's sensor
number can be programmed for “non-supervised”
if required. See the “Advanced Programming”
section of this manual.
WALL MOUNT USE
✦ The wireless keypad can be wall mounted.
1. Open the keypad by inserting a small screwdriver
in one of the top slots in the keypad case. Gently
twist the screwdriver until the case pops open.
2. Attach the rear case to the wall using the two
screws provided.
✎ NOTE: For best signal transmission, the keypad
should be mounted at least three feet above
ground level.
3. Hook the top edge of the keypad case together
and snap the keypad onto the rear case.
✎ WARNING: The wireless keypad is designed for
indoor use only.
8. BASIC SENSOR INSTALLATION
CONNECT BATTERY
TO BATTERY CLIP
FROM TOP OF CASE TWIST
SCREWDRIVER BETWEEN
CASE HALVES UNTIL IT
POPS OPEN
USE THE FOUR SCRATCH
DETERRENT PADS PROVIDED
FOR TABLE-TOP USE
ATTACH REAR CASE TO WALL
WITH THE TWO SCREWS PROVIDED
MOUNT AT A CONVENIENT
LOCATION NEAR PRIMARY
ENTRY/EXIT DOOR
