Linear LDC0800 Operating instructions

LDCO800
QUICK PROGRAMMING GUIDE
2 GREEN FLASHES = SET UP LIMIT
PRESS UP (+) OR DOWN (-)
TO JOG THE DOOR TO THE
CORRECT POSITION
PRESS LEARN & UP
FOR 3 SECONDS
PRESS LEARN TO STORE LIMIT
LEARN
DOWN -
UP +
SETTING THE OPEN LIMIT
NOTE: LIMITS ARE PRESET FOR 7-FOOT DOORS
2 GREEN FLASHES = OPEN LIMIT STORED
LEARN
DOWN -
UP +
LEARN
DOWN -
UP +
SETTING THE CLOSE LIMIT
2 RED FLASHES = SET DOWN LIMIT
PRESS UP (+) OR DOWN (-)
TO JOG THE DOOR TO THE
CORRECT POSITION
PRESS LEARN & DOWN
FOR 3 SECONDS
PRESS LEARN TO STORE LIMIT
LEARN
DOWN -
UP +
2 RED FLASHES = CLOSE LIMIT STORED
LEARN
DOWN -
UP +
LEARN
DOWN -
UP +
ADDING A TRANSMITTER OR KEYPAD CODE
RED LED WILL LIGHT FOR 15
SECONDS - READY TO LEARN
PUSH TRANSMITTER BUTTON OR
ENTER KEYPAD CODE
PRESS & RELEASE
LEARN BUTTON
LEARN
DOWN -
UP +
1 FLASH = TRANSMITTER BUTTON OR
KEYPAD CODE LEARNED
RED LED WILL LIGHT FOR 15
SECONDS - READY TO ERASE
PUSH TRANSMITTER BUTTON OR
ENTER KEYPAD CODE
PRESS & RELEASE
LEARN BUTTON
LEARN
DOWN -
UP +
4 FLASHES = TRANSMITTER BUTTON
OR KEYPAD CODE ERASED
ERASING A TRANSMITTER OR KEYPAD CODE
ERASING ALL TRANSMITTERS & KEYPADS
PRESS LEARN BUTTON
FOR 10 SECONDS
LEARN
DOWN -
UP +
3 FLASHES = ALL TRANSMITTERS &
KEYPADS ERASED
10
SEC.
SETTING THE DOOR FORCE
RUN THE OPERATOR FOUR
COMPLETE UP & DOWN CYCLES
THE OPERATOR AUTOMATICALLY
SETS THE CORRECT DOOR FORCE
FOR OPTIONAL OPEN AND CLOSE FORCE
MODIFICATIONS, SEE INSTRUCTIONS
Copyright © 2010 Linear LLC 231165 A
USA & Canada [phone] & [phone]
[phone] - Toll Free FAX [phone]
www.linearcorp.com
