1. PRODUCT DESCRIPTION
Linear’s Xtended Range FM receivers and transmitters are designed for use in various
wireless remote control applications. The Model XR-D serial data output receiver is used for
specialty O.E.M. data acquisition and processing systems. When the Model XR-D receiver
detects a signal from its companion transmitter(s), it will output 9600 baud ASCII serial data
through its RS-232 style interface in “real-time” (no buffering) as the transmitted data is
received.
The XR-D receiver’s serial data output contains all of the information that can be sent from
any type of Linear’s Xtended Range transmitters. In a typical installation, the receiver’s output
terminals would be connected to a computer through a user supplied custom made cable.
The computer would run user supplied software written to suit the needs of the application.
It could display and log the transmitted unit number, channel number, bank number, alarm
state, battery condition, status reports, and transmitter type. Alternately, the XR-D could be
connected directly to a line printer for specialty or diagnostic purposes.
Power for the XR-D receiver can come from an external regulated 12 VDC power supply
(Linear Model T-124DC) or from a 12-volt battery. A diode protects the unit from reverse
power polarity. The XR-D draws about 30 mA current.
Two antennas (sold separately) are available for the XR-D. The Model ANT-1A is an 8-inch
“rubber duck” antenna for short range applications (less than 1 mile). The ANT-1A requires
a CON-180A (straight) connector to mate the antenna to the transmitter. For a right angle
antenna, use the CON-180A plus the CON-90A.The Model ANT-2 is a 3-foot whip antenna
for use in long range or difficult installations where more range from the XR-D is required. A
common 9-foot 1/4 wave CB whip antenna can also be used with the XR-D for maximum
range.
The receiver is housed in a rugged weather-resistant metal enclosure with a sturdy SO-239
antenna connector and a water-tight wiring strain relief bushing. Two indicators are visible through
a window on the case. The green power indicator lights when the receiver has power. During
reception, the red RF indicator lights. A two-position single-packet option jumper allows selection
of one round of only new data for each transmission or all data sent for each transmission. Two
internal test points are provided for signal strength and audio monitoring.
Data Specification:
Baud Rate: 9600
Stop Bits: 1
Parity: None
2. OPEN RECEIVER
3. COMPONENT LOCATIONS 4. INSTALLATION TIPS 5. MOUNT RECEIVER CASE
If using the ANT-1A antenna: For best range mount the XT/XR unit to a metal plate with a
minimum size of 12" x 12". The ANT-1A antenna should extend above the mounting plate
and be free of obstructions. If the ANT-1A antenna cannot be mounted in the open, consider
using an extension coaxial cable with PL-259 connectors to move the antenna’s location.
The XT/XR series of radios operate in the 27 MHz Citizens Band (CB) and may use any CB
antennas or CB antenna accessories. Antennas, PL-259 extension cables and other adapters
are available at Radio Shack® or other electronics stores.
18-FOOT CABLE
UNIVERSAL
MOUNTING BRACKET
3-FOOT
ANT-2
ANTENNA
8-INCH
ANT-1A
ANTENNA
STRAIGHT-THRU
CONNECTOR
(CON-180A)
RIGHT ANGLE
CONNECTOR
(CON-90A)
USE ANT-1A ANTENNA FOR
SHORT RANGE APPLICATIONS
(LESS THAN 1 MILE)
USE ANT-2 ANTENNA FOR MAXIMUM
RANGE OR DIFFICULT APPLICATIONS
LINE-OF-SIGHT
BETWEEN THE
TRANSMITTER AND
RECEIVER ANTENNAS
WILL PROVIDE THE
BEST RANGE
ANTENNAS ARE MOUNTED
VERTICALLY, ON HIGH POINTS
OF BUILDINGS TRANSMITTING THROUGH
STRUCTURES, METAL AND
GEOGRAPHIC OBSTACLES WILL
REDUCE RADIO RANGE
BAD INSTALLATIONGOOD INSTALLATION
AT LEAST 9 FEET
ABOVE GROUND IS
RECOMMENDED
MOUNT ANTENNA AS HIGH AS POSSIBLE
WHEN MOUNTING ON
THE SIDE OF A
STRUCTURE, USE A
MINIMUM OF A 3-FOOT
SPACER TO DISTANCE
THE ANTENNA FROM
THE STRUCTURE
GOOD ANTENNAS NEED GOOD GROUNDS
IDEALLY, A GROUND
PLANE WITH A RADIUS
OF NINE FEET MINIMUM
IS DESIRED
9 FEET
METAL ROOF
ANTENNA LOCATION IS
OF PRIMARY CONCERN
OK
FAIR
POOR
3'
REMOVE FOUR
CASE SCREWS AND
SLIDE OUT CIRCUIT
BOARD
CASE SCREWS
END CAP STAYS
ATTACHED TO
THE CIRCUIT
BOARD
BOARD FITS IN
3RD SLOT UP
REFERENCE
CARD FITS IN
1ST SLOT
ANTENNA
CONNECTOR
(HIDDEN)
TEST
BUTTON
GROUND
TEST POINTS
SIGNAL
LEVEL
AUDIO
OUTPUT
POWER & DATA OUTPUT
TERMINAL BLOCK
POWER
INDICATOR
(GREEN)
RF SIGNAL
INDICATOR
(RED)
SINGLE-PACKET OPTION JUMPER
(USE AS SHOWN FOR NEW DATA ONLY PACKET
PER TRANSMISSION, PLACE ON
OTHER PINS FOR ALL PACKETS
FOR EACH TRANSMISSION)
MOUNT UNIT WITH
TWO BOTTOM SCREWS
(DON'T INSTALL TOP
SCREWS UNTIL WIRING
IS COMPLETE)
UNIT SHOULD BE
MOUNTED IN SHELTERED
LOCATION WITH ACCESS
TO ANTENNA CO-AX AND
POWER/SIGNAL WIRES
WARNING: THIS
PRODUCT SHOULD NOT
BE USED IN LIFE
SAFETY APPLICATIONS.
FCC Rules allow
unlicensed high-power
transmissions at or near
the operating frequency
of this product which
may interfere with, or
even disable, normal
operation of this radio
device.

INSTR, INSTL, XR-D LINEAR P/N: 215170 B MATERIAL: 20 LB. MEAD BOND SIZE: 8.500" X 11.000" SCALE: 1-1 INK: BLACK SIDE 2 OF 2 (BACK)
6. CONSTRUCT CABLE & CONNECT POWER 7. ASCII DATA OUTPUT DETAILS 8. MOUNT ANTENNA AND ROUTE CABLE
9. TEST SYSTEM 10. COMPLETE INSTALLATION LINEAR LIMITED WARRANTY
This Linear product is warranted against defects in material and workmanship
for twelve (12) months. The Warranty Expiration Date is labeled on the product.
This warranty extends only to wholesale customers who buy direct from Linear or
through Linear’s normal distribution channels. Linear does not warrant this product
to consumers. Consumers should inquire from their selling dealer as to the nature of
the dealer’s warranty, if any. There are no obligations or liabilities on the part of
Linear LLC for consequential damages arising out of or in connection with use
or performance of this product or other indirect damages with respect to loss of
property, revenue, or profit, or cost of removal, installation, or reinstallation. All
implied warranties, including implied warranties for merchantability and implied
warranties for fitness, are valid only until Warranty Expiration Date as labeled on the
product. This Linear LLC Warranty is in lieu of all other warranties express or
implied.
All products returned for warranty service require a Return Product Authorization
Number (RPA#). Contact Linear Technical Services at 1-800-421-1587 for an RPA#
and other important details.
IMPORTANT !!!
Linear radio controls provide a reliable communications link and fill an important need
in portable wireless signaling. However, there are some limitations which must be
observed.
1WARNING: THIS PRODUCT IS NOT TO BE USED IN LIFE SAFETY APPLICATIONS. FCC Rules allow
unlicensed high-power transmissions at or near the operating frequency of this product which may
interfere with, or even disable, normal operation of this radio device.
1For U.S. installations only: The radios are required to comply with FCC Rules and Regulations as Part 95
Radio Control devices. As such, they have limited transmitter power and therefore limited range.
1A receiver cannot respond to more than one transmitted signal at a time and may be blocked by radio signals
that occur on or near their operating frequencies, regardless of code settings.
1Changes or modifications to the device may void FCC compliance and user’s authority to operate equipment.
1Infrequently used radio links should be tested regularly to protect against undetected interference or fault.
1A general knowledge of radio and its vagaries should be gained prior to acting as a wholesale distributor or
dealer, and these facts should be communicated to the ultimate users.
Copyright © 2004 Linear LLC 215170 B
ANT-1A
ANTENNA
USE ANT-1A ANTENNA
FOR SHORT RANGE (LESS
THAN 1 MILE)
APPLICATIONS CON-180A
STRAIGHT
CONNECTOR
CON-180A + CON-90A
ANGLE CONNECTOR
MOUNT ANTENNAS AS HIGH AS POSSIBLE
(A METAL MOUNTING POLE IS RECOMMENDED)
AN 18-FOOT RG-58 CABLE IS SUPPLIED WITH THE
ANT-2 KIT. UP TO 50 FEET OF RG-58 CAN BE USED.
USE RG-8 FOR UP TO 100-FOOT CABLE RUNS.
TO UNIT
USE 3-FOOT LONG ANT-2 ANTENNA FOR LONGER
RANGE APPLICATIONS OR DIFFICULT
INSTALLATIONS
GROUND
+12 VDC DATA TERMINAL READY (DTR)
TRANSMIT DATA (TD)
SIGNAL GROUND (SIG GND)
GROUND
+ 12 VDC
TD
DTR
SIG GND
XR-D TO FEMALE DB-9 FOR COMPUTER CABLE
GROUND
+ 12 VDC
TD
DTR
SIG GND
XR-D TO FEMALE DB-25 FOR COMPUTER CABLE
GROUND
+ 12 VDC
TD
DTR
SIG GND
XR-D TO MALE DB-25 FOR PRINTER CABLE
GROUND
+ 12 VDC
TD
DTR
SIG GND
WARNING
THIS UNIT REQUIRES 12 VDC AT 1/2 AMP.
THE NO-LOAD VOLTAGE OF THE SUPPLY
MUST NOT EXCEED 17.5 VDC OR DAMAGE
TO THE UNIT WILL OCCUR!
ROUTE WIRES THROUGH
CASE STRAIN RELIEF
BUSHING BEFORE
CONNECTING TO TERMINALS
PIN 5 (SIG GND)
PIN 6 (DSR)
PIN 2 (RD)
PIN 7 (SIG GND)
PIN 6 (DSR)
PIN 3 (RD)
PIN 7 (SIG GND)
PIN 6 (DSR)
PIN 3 (RD)
FEMALE
DB-9
FEMALE
DB-25
MALE
DB-25
TRANSMITTER
RECEIVER
INSTALL AND SETUP THE TRANSMITTER AS
DESCRIBED IN ITS INSTALLATION INSTRUCTIONS
APPLY POWER AND TRIGGER THE
TRANSMITTER'S INPUT
THE TRANSMIT INDICATOR
SHOULD LIGHT WHEN THE
TRANSMITTER IS TRIGGERED
SEND MORE TEST TRANSMISSIONS, THE
RECEIVER'S SIGNAL INDICATOR SHOULD
LIGHT AS THE SIGNALS ARE RECEIVED (IF
LIT WITH NO SIGNALS, IT IS INTERFERENCE)
WARNING
NEVER CONNECT THE TRANSMITTER AND
RECEIVER ANTENNA CONNECTORS
DIRECTLY TO EACH OTHER. MAJOR
DAMAGE TO BOTH UNITS WILL OCCUR!
VERIFY THAT COMPUTER OR PRINTER
IS SETUP PROPERLY AND ACQUIRING
THE DATA FROM THE RECEIVER
(PRESSING THE RECEIVER'S TEST
BUTTON WILL ALSO SEND DATA)
1
2
3
SLIDE RECEIVER
BOARD INTO CASE IN
THE 3RD SLOT UP
BAUD RATE: 9600
STOP BITS: 1
PARITY: NONE
SECURE END PLATE BY
INSTALLING THE FOUR
CASE SCREWS
TIGHTEN WIRING STRAIN
RELIEF BUSHING TO
SECURE AND WEATHER
PROOF WIRING
INSTALL THE TWO REMAINING
MOUNTING SCREWS
TEST SYSTEM AGAIN AFTER
COMPLETING INSTALLATION
P SSSSSS CCCC BTARVXE
XR-D SERIAL DATA OUTPUT STRING KEY
DATA OUTPUT PRODUCED WHEN PRESSING XR-D TEST BUTTON
A 65432 0001 21A0HX
P= PACKET TYPE CHARACTER (A OR B). XT TRANSMITTERS SEND FOUR ROUNDS
OF DATA EACH ACTIVATION. PACKET TYPE "A" IS FIRST ROUND, PACKET TYPE "B"
IS FOR THE NEXT THREE ROUNDS.
S= FIVE-DIGIT DECIMAL NUMBER (00000 - 65535) THAT IS EQUAL TO THE BINARY
CODE SET ON THE TRANSMITTER'S SYSTEM CODE SWITCHES "A" & "B" . SYSTEM
CODE SWITCH "B", POSITION 8 IS THE LEAST SIGNIFICANT BINARY DIGIT, SWITCH
"A" POSITION 1 IS THE MOST SIGNIFICANT BINARY DIGIT.
C= FOUR BINARY DIGITS (0 OR 1) INDICATING TRANSMITTER CHANNEL
ACTIVATED. 0=NO ALARM, 1=ALARM. ORDERED CH4, CH3, CH2, CH1.
B= ONE-DIGIT DECIMAL NUMBER (0 - 3) EQUAL TO THE BANK NUMBER (1-4) SET IN
THE TRANSMITTER.
T= ONE-DIGIT DECIMAL NUMBER (0 - 2) DEFINING TRANSMITTER TYPE
(0 = XT-1, 1 = XT-4, 2 = XT-2H OR XT-4H IN MULTI-CHANNEL MODE).
A= ALARM/RESTORE CHARACTER (A OR R). RELEVANT FOR SINGLE-CHANNEL
TRANSMITTERS ONLY.
R= ONE-DIGIT BINARY DIGIT (0 OR 1) INDICATING THE STATE OF THE
TRANSMITTER'S AUTO-RESTORE SWITCH (0 = OFF, 1 = ON).
V= TRANSMITTER VOLTAGE CHARACTER (H OR L). NORMAL CONDITION = "H". IF
TRANSMITTER VOLTAGE IS BELOW 10.5 VDC CHARACTER = "L".
X= SPARE CHARACTER, NOT IMPLEMENTED AT THIS TIME.
E= END-OF-DATA. A CARRIAGE RETURN AND A LINE FEED ARE SENT.
