Linja Calgary User manual

Assembly instructions
For the models:
Calgary / TGS3C
Helsinki / T3C
Oravi / TF3C
LinJa GmbH & Co. KG
Unterdürrbacherstr. 222
97080 Würzburg
Tel: [phone]
Email: [email protected]

Table of contents
Foreword....................................................................................................................................................3
Important Instructions...............................................................................................................................3
Safety Instructions .....................................................................................................................................4
Usage tips...................................................................................................................................................4
Transport....................................................................................................................................................4
Packaging ...................................................................................................................................................4
Installation informations............................................................................................................................5
Assembly....................................................................................................................................................5
Step 1 –Bottom plate............................................................................................................................5
Step 2 –Back walls.................................................................................................................................5
Step 3 –Benches....................................................................................................................................6
Step 4 –Front.........................................................................................................................................6
Step 5 –Roof..........................................................................................................................................6
Step 6: Sauna stove................................................................................................................................6
Manual Controller......................................................................................................................................7
DO-T .......................................................................................................................................................9
Installation .........................................................................................................................................9
Function .............................................................................................................................................9
Connecting the cables tot he control box................................................................................................11
Connecting the Sauna-Controller / Display .............................................................................................12
Connecting the temperature sensor........................................................................................................13
Connecting the sauna stove.....................................................................................................................13

Foreword
Dear Customer,
We are pleased that you have chosen one of our products.
Before unpacking the sauna, check the packaging for any damage!
Before assembly, all parts must also be checked for damage and completeness.
Before assembling and using this product, please read all the instructions and strictly follow the
procedure.
This sauna was designed in terms of design and functionality for private use.
We are not liable for improper use of our products.
Our products are subject to constant development.
Therefore, there may be changes in the design and use of other components.
Do you have questions regarding the product?
Please contact us at: [email protected]. Our team will be happy to help you.
Important Instructions
Damage found when unpacking must be reported to us immediately with photos.
Please send these to: [email protected]
Two people (or three, depending on the size of the cabin) should set up the sauna, taking these
assembly instructions into account.
The power connection for the sauna must be carried out by a certified electrician.
He must also ensure sufficient grounding to avoid accidents and malfunctions. Please have an
electrician check the operation of the GFCI (if fitted)..
When it comes to the statics of the floor, it must be ensured that it can withstand the total weight of
the sauna and the people intended for it.
Please note:
The product is designed exclusively for private use.
Please read the assembly instructions carefully first!
If you still have questions about the construction, we will be happy to help you.
Complaints arising from incorrect assembly or use are excluded from the warranty!
Note: The photos are for your reference only and may contain some variations.

Safety Instructions
•Never attach a door lock to the sauna!
•Never touch the oven and lamps with your hands when they are switched on!
•Make sure the sauna is adequately ventilated!
•Do not use the sauna if you have open wounds or burns!
•Do not use the sauna if you are pregnant!
•Consult a doctor before use if you suffer from any of the following problems:
oyou are elderly or ill
ohyperthermalgesia
oobesity
odiabetes
ohigh blood pressure
oHeart & circulatory problems
Usage tips
•recommended temperature: 60 –75°C
•The temperature displayed on the controller may differ from the temperature on the
thermometer.
•Drink enough water
•Shower before use
Do not go to the sauna immediately after eating or strenuous activities (e.g. sport).
Transport
Make sure the boxes are not exposed to moisture.
Packaging
The sauna is delivered in 6 boxes.

Installation informations
•Do not connect any other devices to the socket to which you connect the sauna.
•The sauna should be placed on a level surface.
•The sauna must be installed in a dry and covered room.
•Protect the sauna from splashing water.
•Do not store flammable material or chemical substances near the sauna.
Assembly
You need at least 2 adults to assemble the sauna.
Please read the operating and assembly instructions completely and carefully to the end before you
start assembly. If you have any difficulties or questions during assembly, please contact us.
Step 1 –Bottom plate
When choosing the location of the sauna, do not forget that:
•the power connection must be easily accessible
•The subfloor must be level and the room must be dry
Lay the floor panel on the floor with the “FRONT” decal facing the desired direction.
Step 2 –Back walls
First attach the two rear panels.
Make sure they are flush with the bottom panel.

Step 3 –Benches
Next, install the bench seats.
You will notice that the sauna has rails already installed into which the bench slides smoothly.
When this is done, the seats still need to be mounted.
Step 4 –Front
Next install the front panels.
Make sure these are flush with the floor and side panels.
Step 5 –Roof
The last thing you need to do is put on the roof panel. When all the corners are in their intended
place, you can gently press the roof panel down.
Make sure that the cables are not pinched between the walls.
Step 6: Sauna stove
Please pull the cable of the sauna heater from the inside to the outside through the small hole in the
side wall. We advise having the connection carried out by a specialist.

Manual Controller
This button turns the sauna on or off. After switching on, the display shows the temperature in
the sauna.
Turns the light in the sauna on or off.
Temperature / duration setting: Pressing this button takes you to the setting of the desired
temperature. The temperature display starts flashing and can be adjusted using the arrow buttons.
By pressing the button again you switch to the setting for the duration of the sauna session. The time
display starts flashing and can be set.
Press the button again to exit settings. Alternatively, the last step happens automatically after 15
seconds.
If the temperature in the sauna is higher than the set temperature, the LED lights up red and the
heater switches off. If the temperature drops to 2°C below the set temperature, the oven switches on
again and the LED lights up orange.

DO-T
Installation
Function
ON / OFF:
Starts or stops the steam generator. After switching on, the "Work" lamp lights up and the
temperature display shows the temperature. Pressing it again switches the steam generator off again.
LIGHT:
Turns the lights on or off in the steam room. When the lights are on, the LIGHT indicator lamp will be
lit.
TEMP:
Opens the temperature setting. The temperature can be set between 35°C and 55°C by pressing the
arrow keys.
TIME
TEMP
ON/
OFF
LIGHT
1700
mm
Power
Control
Sensor
Work
indicator
up and down key
Lighting
indicator
Temperature
display
TIME
TEMP
ON/
OFF
LIGHT

TIME:
Opens the duration setting. The duration can be set between 1 and 60 minutes using the arrow keys.
If the temperature in the cabin is higher than the set temperature, steam production is stopped.
If the temperature falls below 2°C less than the set temperature, the steam generator is switched on
again.
Sauna 3-18KW 400V 3 ~
Relay box Control Sensor
TAB
KW
4.5
6
Amp mm AWG
2
400V 3~
6.8 412
9412
Sauna
heaters
5XTAB *
Sauna heaters
3 4.5 2.5 13
862086234.5
Sauna heaters
L3L2
L1NN
1NW
VUN
*
3XTAB
Sauna
heaters
6164061645
8102681030
230-240V ~200-208V ~
AWGmm22 AmpAWGmmAmp
9
6
KW
TAB
Sensor
Control
Relay box
Sauna 4.5-9KW 200-240V ~
200-240V ~
L3
Sensor
654321 7 8
1 2 3 4 5 6
L1 L2
N
*Use 90 C copper wire
*
3XTAB
Relay box Relay box
Circuit board Control
6X0.2mm2
NL2
L1 L3
380V 3~
N U V W N 1 N N L1 L2 L3 654321 871 2 3 4 5 6
Sensor
400V 3~
KW Amp 2AWGmm
1241610.5
106
23
116
15
12
18 27 6 9
18
12
6
13.6
9
2
6X0.2mm
Control
Relay box
Circuit board
Relay box
5XTAB *
Use 90 C copper wire
*

Connecting the cables tot he control box
After setting up your sauna cabin, the cables from the control display, temperature sensor and sauna
heater must be connected to the silver control box on the roof of the sauna.
This should only be carried out by a specialist!
The necessary cables are on the side of the cables where the control box is located, taped to a side
panel.

Connecting the Sauna-Controller / Display
Open the control box on the roof by unscrewing it.
.
The white wire must be connected to the green circuit board.
Pull the cable through the hole on the far left.
Attach the connectors to the circuit board as follows:
Left to right: Black, Brown, Red, Yellow, Green

Connecting the temperature sensor
Pull the temperature sensor cable through the ventilation opening in the ceiling and attach it to the
ceiling with the bracket.
Connecting the sauna stove
The sauna stove must also be connected to the control box on the roof.
3-core cables are used for 3kw, 4.5kw or 6kw ovens.
Pull the wire through the right hand opening in the control box and connect both the ground and all
wires as shown in the picture:
This is connected as follows:
Yellow to the ground symbol, blue to N, and brown to U. V and W remain blank with 3-wire cables.
