Linja Salo User manual

assembly Instructions
Fort he models:
•Salo / EA3C
LinJa GmbH & Co. KG
Unterdürrbacherstr. 222
97080 Würzburg
Tel: [phone]
Email: [email protected]

Table of contents
Foreword.................................................................................................................................................... 3
Important Instructions............................................................................................................................... 3
Scope of delivery........................................................................................................................................ 4
Safety Instructions ..................................................................................................................................... 5
Usage tips................................................................................................................................................... 5
Transport.................................................................................................................................................... 5
Assembly .................................................................................................................................................... 6
Step 1: Bottom plate.............................................................................................................................. 6
Step 2: Right back wall........................................................................................................................... 6
Step 3: Left back wall ............................................................................................................................. 6
Step 4: Left side glass............................................................................................................................. 6
Step 5: Roof............................................................................................................................................ 6
Step 6: Right Side Glas ........................................................................................................................... 6
Step 7: Front Glass ................................................................................................................................. 6
Step 8: Door ........................................................................................................................................... 7
Step 9: Side paneling of the sauna bench.............................................................................................. 7
Step 10: Upper sauna bench.................................................................................................................. 7
Step 11: Seating upper sauna bench ..................................................................................................... 7
Step 12: Lower sauna bench.................................................................................................................. 7
Step 13: Seating lower sauna bench...................................................................................................... 7
Step 14: Sauna stove and safety grille................................................................................................... 7
Step 15: Lamps and Accessories ............................................................................................................ 8
Sauna stones .......................................................................................................................................... 8
Manual Controller...................................................................................................................................... 9
DO-T ..................................................................................................................................................... 11
Installation ....................................................................................................................................... 11
Function ........................................................................................................................................... 11
Connecting the cables tot he control box................................................................................................ 13
Connecting the Sauna-Controller / Display ............................................................................................. 14
Connecting the temperature sensor........................................................................................................ 15
Connecting the sauna stove..................................................................................................................... 15

Foreword
Dear Customer,
We are pleased that you have chosen one of our products.
Before unpacking the sauna, check the packaging for any damage!
Before assembly, all parts must also be checked for damage and completeness.
Before assembling and using this product, please read all the instructions and strictly follow the
procedure.
This sauna was designed in terms of design and functionality for private use.
We are not liable for improper use of our products.
Our products are subject to constant development.
Therefore, there may be changes in the design and use of other components.
Do you have questions regarding the product?
Please contact us at: [email protected]. Our team will be happy to help you.
Important Instructions
Damage found when unpacking must be reported to us immediately with photos.
Please send these to: reklamatio[email protected]
Two people (or three, depending on the size of the cabin) should set up the sauna, taking these
assembly instructions into account.
The power connection for the sauna must be carried out by a certified electrician.
He must also ensure sufficient grounding to avoid accidents and malfunctions. Please have an
electrician check the operation of the GFCI (if fitted)..
When it comes to the statics of the floor, it must be ensured that it can withstand the total weight of
the sauna and the people intended for it.
Please note:
The product is designed exclusively for private use.
Please read the assembly instructions carefully first!
If you still have questions about the construction, we will be happy to help you.
Complaints arising from incorrect assembly or use are excluded from the warranty!
Note: The photos are for your reference only and may contain some variations.

Scope of delivery
The following components are included in this product:
Count
Element
1
Bottom plate
1
Right back wall
1
Left back wall
1
Roof
2
Side glass
1
Front glass
1
Glass dor
1
Door handle
1
Upper seat cover
1
Lower seat cover
1
Upper sauna bench
1
Lower sauna bench
1
Side paneling of the sauna bench
1
Sauna stove
1
Wooden safety grille for sauna stove
2
Lamp
2
Wood paneling for sauna lamp
1
Thermometer & Hygrometer
1
Hourglass
2
Bucket & Laddle
1
Sauna stones

Safety Instructions
•Never attach a door lock to the sauna!
•Never touch the oven and lamps with your hands when they are switched on!
•Make sure the sauna is adequately ventilated!
•Do not use the sauna if you have open wounds or burns!
•Do not use the sauna if you are pregnant!
•Consult a doctor before use if you suffer from any of the following problems:
oyou are elderly or ill
ohyperthermalgesia
oobesity
odiabetes
ohigh blood pressure
oHeart & circulatory problems
Usage tips
•recommended temperature: 60 – 75°C
•The temperature displayed on the controller may differ from the temperature on the
thermometer.
•Drink enough water
•Shower before use
•Do not go to the sauna immediately after eating or strenuous activities (e.g. sport).
Transport
Make sure the boxes are not exposed to moisture.

Assembly
Step 1: Bottom plate
First, make sure the ground is level.
Lay the bottom panel on the floor with the “FRONT” mark facing forward.
Step 2: Right back wall
Place the right rear panel on the base plate at the corresponding mark.
Step 3: Left back wall
Place the left rear panel on the base plate at the corresponding mark and connect it to the right rear
panel.
The two rear panels are attached using the click fasteners.
Step 4: Left side glass
Place the left side window in the recess in the front left of the sauna floor panel.
Step 5: Roof
Lay the roof down on the rear walls to fit.
One person has to hold the roof while another person screws on the side windows.
Now screw the already placed left side window including the plastic washer. Then attach the silver top
cap over the screw.
Step 6: Right Side Glas
Place the right side window in the recess in the front right of the sauna floor panel.
Now screw on the right side window including the plastic washer. Then attach the silver top cap over
the screw.
Step 7: Front Glass
Place the front window on the right side of the front in the recess there.
Also insert the plastic seal between the front and side windows.

Step 8: Door
Place the door and fasten it in the designated places.
Step 9: Side paneling of the sauna bench
Assemble the side panel of the side bench in the intended position on the left side of the sauna.
Step 10: Upper sauna bench
Fasten the upper sauna bench to the designated place in the base plate.
Step 11: Seating upper sauna bench
Then mount the bench for the upper sauna bench between the upper sauna bench and the left rear
wall.
To do this, place the bench seat flush on the upper sauna bench.
Step 12: Lower sauna bench
Fasten the lower sauna bench at the designated place in the base plate.
Step 13: Seating lower sauna bench
Lay the seat of the lower sauna bench flush on it and fasten it.
Step 14: Sauna stove and safety grille
Place the sauna heater in the marked position and mount the wooden safety grille around the heater.
Then connect the oven to the electricity.
Since the connection involves high current, we recommend having the connection carried out by a
specialist!

Step 15: Lamps and Accessories
Mount the lamps in the corners of the cabin and attach the wood panelling.
Pull the cables through the hole in the ceiling and connect them to the appropriate 3-wire mating
connectors.
Then assemble the thermometer and the hourglass.
Sauna stones
We recommend using sauna stones with a diameter of approx. 3-8cm.
When stacking, make sure that it is loose and the larger stones are at the bottom.
Before use, you should wash the stones with water.
Also replace the sauna stones regularly to ensure optimal functionality of the sauna stove.

Manual Controller
This button turns the sauna on or off. After switching on, the display shows the temperature in
the sauna.
If the temperature in the sauna is higher than the set temperature, the LED lights up red and the
heater switches off. If the temperature drops to 2°C below the set temperature, the oven switches on
again and the LED lights up orange.

DO-T
Installation
Function
ON / OFF:
Starts or stops the steam generator. After switching on, the "Work" lamp lights up and the
temperature display shows the temperature. Pressing it again switches the steam generator off again.
LIGHT:
Turns the lights on or off in the steam room. When the lights are on, the LIGHT indicator lamp will be
lit.
TEMP:
Opens the temperature setting. The temperature can be set between 35°C and 55°C by pressing the
arrow keys.
TIME
TEMP
ON/
OFF
LIGHT
1700
mm
Power
Control
Sensor
Work
indicator
up and down key
Lighting
indicator
Temperature
display
TIME
TEMP
ON/
OFF
LIGHT

TIME:
Opens the duration setting. The duration can be set between 1 and 60 minutes using the arrow keys.
If the temperature in the cabin is higher than the set temperature, steam production is stopped.
If the temperature falls below 2°C less than the set temperature, the steam generator is switched on
again.
Sauna 3-18KW 400V 3 ~
Relay box Control Sensor
TAB
KW
4.5
6
Amp mm AWG
2
400V 3~
6.8 412
9412
Sauna
heaters
5XTAB *
Sauna heaters
34.5 2.5 13
862086234.5
Sauna heaters
L3L2
L1NN
1NW
VUN
*
3XTAB
Sauna
heaters
6164061645
8102681030
230-240V ~200-208V ~
AWGmm
22
AmpAWGmmAmp
9
6
KW
TAB
Sensor
Control
Relay box
Sauna 4.5-9KW 200-240V ~
200-240V ~
L3
Sensor
654321 7 8
1 2 3 4 5 6
L1 L2
N
*Use 90 C copper wire
*
3XTAB
Relay box Relay box
Circuit board Control
6X0.2mm2
NL2
L1 L3
380V 3~
N U V W N 1 N N L1 L2 L3
654321 871 2 3 4 5 6
Sensor
400V 3~
KW
Amp
2
AWGmm
1241610.5
106
23
116
15
12
18 27 6 9
18
12
6
13.6
9
2
6X0.2mm
Control
Relay box
Circuit board
Relay box
5XTAB *
Use 90 C copper wire
*

Connecting the cables tot he control box
After setting up your sauna cabin, the cables from the control display, temperature sensor and sauna
heater must be connected to the silver control box on the roof of the sauna.
This should only be carried out by a specialist!
The necessary cables are on the side of the cables where the control box is located, taped to a side
panel.

Connecting the Sauna-Controller / Display
Open the control box on the roof by unscrewing it.
.

Connecting the temperature sensor
Pull the temperature sensor cable through the ventilation opening in the ceiling and attach it to the
ceiling with the bracket.
Connecting the sauna stove
The sauna stove must also be connected to the control box on the roof.
3-core cables are used for 3kw, 4.5kw or 6kw ovens.
Pull the wire through the right hand opening in the control box and connect both the ground and all
wires as shown in the picture:
This is connected as follows:
Yellow to the ground symbol, blue to N, and brown to U. V and W remain blank with 3-wire cables.
