LINK-MI LM-HT201DKM User manual

DVI KVM HDBaseT Extender
USER MANUAL
LM-HT201DKM
1. Description
The DVI KVM extender provides extension of DVI signals long distances over a
single CAT6 cable, it supports high resolution up to 4K*2K, RS232 and KVM signal
transmission function. The extender can use for a wide range of applications requiring
long distance transmission of high resolution with high quality by its good stability
and powerful security.
2. Features
1. Transmits DVI video signals up to 100m over a single CAT6 cable
2. Support video resolution up to 1920*1080P@60Hz and 4K*2K
3. Support HDBaseT technology
4. Support KVM, keyboard and mouse signal transmission
5. Support RS232 signal bi-directional transmission, baud rate self-adaptive
6. Compliance with DVI 1.0 and HDCP 1.2 standard
7. High compatibility, can auto-match source and display device
8. Built-in automatic adjustment system, make the image smooth, clear and stable
9. Built-in ESD protection system
10. Simple to install, plug and play

3. Specifications
Parameter
Description
Video
Standards
DVI 1.0; HDCP 1.2
Maximum pixel clock
165MHz
Maximum data rate
10.2Gbps
Resolution
1920X1080P@60Hz, 4K*2K
Connector
DVI-D
Impedance
100Ω
RS232
Interface
Industrial terminal
Signal direction
Bi-directional
Baud rate
Self-adaptive, Max: 115200bps
Data bits
8
KVM
Interface
PC: MINI-USB
Keyboard and mouse: USB-A
Ethernet
Interface
RJ45
Transmission
distance
1080P: CAT6---100m
4K*2K: CAT6---70m
Other
Power supply
The power adapter: DC 5V/2A
Power dissipation
MAX 6W
Temperature
Operating: -5℃~ +70℃
Humidity
Operating: 5% ~ 90%
Dimension
105*76*27mm
The warranty
1 year free warranty

4. Panel
Transmitter:
Receiver:
Port name
Description
DVI IN/OUT
DVI signal input/output
RJ45
Ethernet interface
RS232
Serial port( G: Ground, T: transmit, R: receive )
K/M TO PC
Connect to PC
K/M
Connect to keyboard and mouse
LED indicator
Description
LINK
Video signal connection indicator
POWER
System power indicator
5. Package list
1. 1pcs DVI transmitter
2. 1pcs DVI receiver
3. 2pcs Power adapter
4. 1pcs User manual
5. 1pcs MINI USB cable
6. Installation

1. Connect the provided DC/5V power supplies to the power socket of the transmitter
and the receiver,
2. Connect an DVI cable between the DVI input port of transmitter and the DVI
output port of the video source,
3. Connect the DVI output port of receiver to the display device with DVI cable,
4. Connect the transmitter RJ45 port to the receiver RJ45 port using a single CAT6
cable.
7. Diagram
