LINK-MI LM-H60S User manual

MINI MHL/HDMI TO SCART Converter
User manual
Thank you for purchasing this product. For optimum performance and safety, please read these
instructions carefully before connecting, operating or adjusting this product. Please keep this
manual for future reference.
Introduction
The MINI MHL/HDMI to SCART converter which will convert digital MHL/HDMI video and audio
signal to composite video signal and the FL / FR stereo audio signal, while support DVI system
sideline signals. Help users convert the high quality of the HDMI signal and smart Phone MHL
signal to normal CVBS signal (standard-definition 480i, 576i,).So that can play on CRT TV, VHS
VCR, DVD recorders, etc. The MHL/HDMI to SCART converter support NTSC and PAL TV
formats output.
Features
1. No need to install drivers, portable, flexible, plug and play
2. High quality scaling technology for input resolutions .
3. Support NTSC and PAL two standard TV formats output
4. Compatible with HDMI1.3
5. Share your smart phone photos, music and movies on the TV

1
Specifications
Input ports
1×HDMI
Output ports
1×SCART
Dimensions(L×W×H)
88×58×26mm
Weight
45g
Input Resolution
640 ×480@60Hz,800 ×600@60Hz,1024 ×768@60Hz,1280
×720@60Hz,1280×1024@60Hz,1360×768@60Hz,1600×
1200@60Hz,1920 ×1080@60Hz,480i/60Hz,480p/60Hz,
76i/60Hz,576p/60Hz,720p50/60Hz,1080i50/60Hz,1080p23.9
7/24/25/50/59.94/60Hz
CVBS output
PAL,NTSC
Operating Temperature
0°C ~ 40°C / 32°F ~ 104°F
Storage Temperature
20°C ~ 60°C / -4°F ~ 140°F
relative Humidity
20 ~ 90% RH (non-condensing)
Power Consumption (MAX)
3W

2
Operation controls and Functions
Front Panel Rear Panel
1) PAL/NTSC Switch: Switch the CVBS output format.
2) HDMI Input: Connect the HDMI to your source equipment such like DVD/Game console.
3) LED indicator: When the DC5V power on, the indicator will be light.
4) Power: Plug the 5VDC power supply into the unit and connect the adapter to AC wall outlet.
5) SCART output: Connect the SCART output to your display equipment(like TV SET).

3
Package
1. Mini MHL/HDMI to SCART Converter
2. 5V1A DC Power Supply Adapter
3. MHL to HDMI Cable
4. Operation Manual
Application Example

4
Support MHL smart Phone series
Samsung
I9100,i9108,i9188,I997,Samsung Galaxy Note(i900)
HTC
HTC sensation(HTC G14/G18/G19),HTC Flyer, HTC EVO 3D
Z710,Z710e,Z710T
LG
LU6200, LG P940
SONY
LT26i
NOKIA
N10
Because of the different connecter, The Samsung smart phone Galaxy S3,S4 series
( I9300,I9308, I939 ,Note2 N7100 ,I9500) need add a micro USB 5pin to 11pin connector.
