LINK-MI LM-DA01-Audio User manual

1
USER MANUAL
Digital to Analog Audio Converter
LM-DA01-Audio
Table of Contents
1.0 introduction ……………………….…….……...1
2.0 Specifications………………..……..…..….…….2
3.0 Package Contents…………………….…………2
4.0 Panel Descriptions………………………………3
5.0 Connection and Operation……...………………4
Dear Customer
Thank you for purchasing this Audio Converter.
For optimum performance and safety, please read these instructions carefully before
connecting, operating or adjusting this product. Please keep this manual for future
reference
1.0 Introduction
This Digital to Analog Audio Converter is designed for either home or professional audio
switching. It converts Coaxial or Toslink digital audio signals to analog L/R audio and
available for connection to an external device such as an amplifier via standard
RCA-style jacks. This Converter is small in size and quite easy to install.
1.1Features
This Converter has many features that enable it to perform in a superior manner. Among
those features you will find:
1. Converts Coaxial or Toslink digital audio signals to analog L/R audio
2. Supports sampling rate at 32, 44.1, 48 and 96 KHz.

2
3. 24-bit SPDIF incoming bit stream on left and right channels
4. Provides electromagnetic-noise-free transmission.
5. Easy to install and simple to operate.
2.0 SPECIFICATIONS
Signal Inputs/Output
Input Audio
Coaxial or Toslink digital audio
Output Audio
L/R audio and 3.5mm
Connector
Input audio connector
Toslink、1XRCA(Coaxial)
Output audio connector
2XRCA（R/L）+ Headphone
Sampling rate
32, 44.1, 48 and 96 KHz
Size(L-W-H)
72(D)x55(W)x20(H)>
Weight (Net)
<78g>
Power Requirement
External Power Supply
5V DC@<1A>
Power Consumption
0.5 watts (max)
3.0 PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make sure the
following items are contained in the shipping carton:
1).Main unit (Digital to Analog Audio Converter).
2). DC 5V Power Supply
3) User’s Manual.
4.0 PANEL DESCRIPTIONS
Please study the panel drawings below and become familiar with the signal
input(s);output(s) and power requirements.

3
5.0 CONNECTION AND OPERATION
Before installation, please make sure all devices you wish to connect have been turned
off.
1) Connect the audio source device to the Converter using appropriate Toslink or Coaxial
cables.
2) Connect the A/V Receivers or Amplifiers to the Converter using appropriate L/R cable.
3) Insert the DC side of 5v power supply into the converter and then connect the AC side
of the power supply into the wall outlet.
Note: When connected to the Toslink and Coaxial cables at the same, the product will
give priority to Toslink input.
Typical application .
