Operating Instructions
HDMI to SDI Converter, with 2 SDI outputs
Operating Instructions
Dear Customer
Thank you for purchasing this product. For optimum performance and safety,
please read these instructions carefully before connecting, operating or
adjusting this product. Please keep this manual for future reference.
FEATURES
1) Convert HDMI to SD/HD/3G-SDI.
2) Distributes 1 HDMI source to 2 SD/HD/3G-SDI output simultaneously.
3) Support HDMI input resolutions:
1080p (50/60/59.94/30/29.97/25/24/23.98Hz)
1080i (60/59.94/50Hz), 720p (60/59.94/50Hz), 480i (60/59.94HZ)
4) Work with SDI to HDMI converter to cascade many layers.
5) Support transmission distance up to 100m over RG59 cable.
6) With mounting ears
NOTICE
Our company reserves the right to make changes in the hardware, packaging
and any accompanying documentation without prior written notice.
1
Operating Instructions
TABLE OF CONTENTS
Specifications
Package Contents
Panel Descriptions
Connecting and Operating
Maintenance
Product service
Warranty
SPECIFICATIONS
Operating Temperature Range
-5 to +35℃(+23 to +95℉)
Operating Humidity Range
5 to 90%RH (No Condensation)
Resolutions Support
1080p (50/60/59.94/30/29.97/25/24/23.98Hz)
1080i (60/59.94/50Hz), 720p (60/59.94/50Hz)
480i (60/59.94Hz)
SDI Standard
3G -SDI/HD-SDI/SDI
Input
1x HDMI (Standard Type A connector)
Output
2x SDI(BNC)
Power consumption
2.5watts(Maximum)
Dimension (L×W×H)
95x95x29mm
Net Weight
245g
Note: Specifications are subject to change without notice. Mass and
dimensions are approximate.
PACKING CONTENTS
1) Main Unit. HDMI -SDI converter
2) DC5V 1A Power Supply.
3) Operating Instructions
2
Operating Instructions
PANEL DESCRIPTIONS
Input Panel Output Panel
1) Indicator of SDI Output
2) Indicator of power Input
3) SDI/HD-SDI Output port
4) HDMI input port
5) Power input
Connecting and Operating
1.Ensure the Converter is disconnected from power.
2.Connect source to the HDMI input and sink to SDI output .
3.Connect 5VDC power to the converter.
Attention: Insert/Extract cable gently
Typical Application
3
Operating Instructions
MAINTENANCE
Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner of
benzene to clean this unit.
PRODUCT SERVICE
1) Damage requiring service: The unit should be serviced by qualified
service personnel if:
(a)The DC power supply cord or AC adaptor has been damaged;
(b)Objects or liquids have gotten into the unit;
(c)The unit has been exposed to rain;
(d)The unit does not operate normally or exhibits a marked change in
performance;
(e)The unit has been dropped or the cabinet damaged.
7) Servicing Personnel: Do not attempt to service the unit beyond that
described in these operating instructions. Refer all other servicing to
authorized servicing personnel.
8) Replacement parts: When parts need replacing ensure the servicer uses
parts specified by the manufacturer or parts that have the same characteristics
as the original parts. Unauthorized substitutes may result in fire, electric shock,
or other hazards.
4) Safety check: After repairs or service, ask the servicer to perform safety
checks to confirm that the unit is in proper working condition.
WARRANTY
If your product does not work properly because of a defect in materials or
workmanship, our Company (referred to as "the warrantor" ) will, for the length
of the period indicated as below, (Parts(2)Year, Labor(90) Days) which starts
with the date of original purchase ("Limited Warranty period"), at its option
either(a) repair your product with new or refurbished parts, or (b) replace it with
a new of a refurbished product. The decision to repair or replace will be made
by the warrantor.
During the "Labor" Limited Warranty period there will be no charge for labor.
During the "Parts" warranty period, there will be no charge for parts. You must
mail-in your product during the warranty period. This Limited Warranty is
extended only to the original purchaser and only covers product purchased as
new. A purchase receipt or other proof of original purchase date is required for
Limited Warranty service.
MAIL-IN SERVICE
When shipping the unit carefully pack and send it prepaid, adequately insured
and preferably in the original carton. Include a letter detailing the complaint
and provide a day time phone and/or email address where you can be
reached.
4
