Link HDMI-SWISS User manual

User Manual
Version: V1.0.1
LINK HDMI-SWISS
HDMI In-line Controller

1. Do not expose this apparatus to
rain, moisture, dripping or
splashing and that no objects filled
with liquids, such as vases, shall be
placed on the apparatus.
6. Clean this apparatus
only with dry cloth.
2. Do not install or place this unit in
a bookcase, built-in cabinet or in
another confined space. Ensure the
unit is well ventilated.
3. To prevent risk of electric
shock or fire hazard due to
overheating, do not obstruct the
unit’s ventilation openings with
newspapers, tablecloths,
curtains, and similar items.
4. Do not install near any heat
sources such as radiators, heat
registers, stoves, or other apparatus
(including amplifiers) that produce
heat.
5. Do not place sources of naked
flames, such as lighted candles, on
the unit.
7. Unplug this apparatus
during lightning storms or
when unused for long
periods of time.
8. Protect the power cord
from being walked on or
pinched particularly at
plugs.
9. Only use attachments /
accessories specified by
the manufacturer.
10. Refer all servicing to
qualified service
personnel.
Important Safety Instructions

This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Warnings of FCC

1
Table of Contents
Introduction .................................................................................................... 2
Features ................................................................................................... 2
Package Contents .................................................................................... 3
Specifications............................................................................................ 3
Panel Description ..................................................................................... 4
Application Diagram....................................................................................... 6
EDID Presets ................................................................................................. 7
RS232 Control ............................................................................................... 8
Troubleshooting ........................................................................................... 10
Warranty Terms and Conditions ................................................................... 11

2
Introduction
Thank you for purchasing this product. For proper installation and optimum
performance, please read the instructions in this manual carefully.
LINK HDMI-SWISS is an HDMI In-line Controller, with resolutions up to
4K@60Hz (chroma sub-sampling 4:4:4 8-bit only) and HDCP 2.2. It features
de-embedded audio distribution system. And its rotary EDID switch has 15
EDID presets and can help negotiate the HDMI handshake in certain situations.
It also could automatically trigger CEC command to turn on or off TV with CEC
support, pre-loaded RS232 commands to power on or standby projector, and
relay control to turn on or off projection screen.
Features
•Support video source up to 4K@60Hz 4:4:4 8-bit and HDCP 2.2
•HDMI audio de-embedded out with Digital Coaxial and Analog Stereo
•Rotary switch for EDID Management with 15 EDID presets
•Built in CEC controller from HDMI out
•Built in RS232 controller, to pre-load and store RS232 command of sink
device
•Built in RELAY control to automatically turn Projector Screen ON/OFF, by
detecting input signal status

3
Package Contents
•1 x HDMI-SWISS
•1 x Power Adapter (DC 12V 1A)
•3 x 3.5mm 3-Pin Phoenix Connector
•2 x Mounting Brackets (with Screws)
•1 x User Manual
Specifications
Technical
Input/Output Signal Type HDMI with 4K@60Hz 4:4:4, HDCP 2.2
Input/Output Resolution
Supported
Up to 4096x2160@60Hz, including
4K@60Hz/4K@30Hz/1080P/1080i/720P
Deep color 4K: 8/10/12 bit
1080P: up to 16 bit
Maximum Data Rate 18 Gbps
Maximum Pixel Clock 600MHz
Audio Format Supported
HDMI: Supports audio formats in HDMI 2.0
specification, including PCM,
Dolby True HD, DTS HD Master Audio, Dolby
Atmos and DTS:X
S/PDIF: PCM 2.0/5.1, up to Dolby Digital and
DTS 5.1
AUDIO OUT (Analog): PCM 2.0
General
Operating Temperature 0°C to 45°C (32°F to 113°F)
Storage Temperature -20°C to 70°C (-4°F to 158°F)

4
General
Humidity 10% to 90%, non-condensing
ESD Protection
Human-body Model:
±8kV (Air-gap discharge)/
±4kV (Contact discharge)
Power Supply DC 12V 1A
Power Consumption
(Maximum)
≤2 W (Pair, PoC)
Device Dimension
(W x H x D)
120mm x 20mm x 80mm /
4.72’’ x 0.79’’ x 3.15’’
Product Weight 0.23kg/0.51lb
Transmission Distance:
Note: T568B straight-through Category cable is recommended.
Cable Type Range Supported Video
HDMI
Input/Output:15m/50ft 1080P@60Hz
Input: 5m/16ft
Output: 10m/33ft 4K@60Hz 4:2:0
Input/Output: 5m/16ft 4K@60Hz 4:4:4
Panel Description
Front Panel
123456

5
No. Name Description
1 DC 12V Connect to the power adapter provided.
2 POWER LED On/Off: The device is powered on/off.
3 HDMI IN Connect to an HDMI source device such as a
Blu-Ray, DVD Player.
4 EDID
Switch for EDID Management with 15 EDID
presets.
5 S/PDIF OUT HDMI audio de-
embedded out with Digital
Coaxial, connect to the amplifier.
6 AUDIO OUT HDMI audio de-
embedded out with Analog
Stereo, connect to the amplifier.
Rear Panel
1234
No. Name Description
1 RELAY1 Turn on the projector screen automatically.
2 RELAY2 Turn off the projector screen automatically.
3 HDMI OUT Connect to an HDMI display such as TV.
4 RS232 Pre-load and store RS232 command of sink
device.

6
Application Diagram
Projec tScreen
Projector
Relay control HDMI
OUTRS232 Control
PC In-ceilingSpeakerAmplifier
HDMI IN AUDIO OUT AUDIO OUT

7
EDID Presets
Switch for EDID Management with 15 presets as follows:
No. Description No. Description
0 Copy EDID FROM HDMI Output A 1400 x 1050@60Hz 2CH
1 3840 x 2160P@60Hz 2CH B 1360 x 768@60Hz 2CH
2 3840 x 2160P@30Hz 2CH C 1280 x 1024@60Hz 2CH
3 1920 x 1080P@60Hz 2CH D 1280 x 960@60Hz 2CH
4 1280 x 720P@60Hz 2CH E 1280 x 768@60Hz 2CH
5 1920 x 1200@60Hz 2CH F 1024 x 768@60Hz 2CH
6 1680 x 1050@60Hz 2CH
7 1600 x 1200@60Hz 2CH
8 1600 x 900@60Hz 2CH
9 1440 x 900@60Hz 2CH
Note: After changing the EDID, please unplug and plug to take effect.

8
RS232 Control
HDMI-SWISS has a built in RS232 controller to pre-load and store
RS232 command for controlling the sink device power on/off the
commands are triggered by detecting input signal status.
To configure the unit’s ability to do this, connect a PC to HDMI-SWISS
via a (RS232 3pins) UART-to-USB cable, check which port on the
computer the RS232 cable is connected to in the device manager. Run
the LINK PORT CONFIGURATION TOOL software and set the
connection parameters correctly before sending any commands to
HDMI-SWISS. Set the baud rate to 57600 and choose the correct port
in the pull-down menu. Then press Connect. Once connected you are
able to set the RS232 output port commands and the relay mode.
LINK PORT CONFIGURATION TOOL menus are described below:
Baud rate: Choose the correct baud rate according to the sink
device, then click “Connect” to connect with the device.
Note: This might be different than the setting of 57600 above and
is determined by the sink device you are connecting to.
Power on: Pre-load and store the command for “power on” to a
sink device, then click “Send” to send and store it on the device.
Power off: Pre-load and store the command for “power off” to a
sink device, then click “Send” to send and store it on the device.
Note: If the sink device requires hex commands, make sure the
Hex box is checked.
Delay: Set delay time (0~30minutes) the sink device will power off
automatically after it cannot detect the input signal, click “set” to
take effect.
Set Terminator: Select the command ending after each RS232

9
command that you are sending from the HDMI-SWISS to the sink
device. Then click “Set” to take effect.
Set Relay Mode: Set relay mode for the sink device.
Latch –relay closes and latches when it is triggered;
Momentary –only closes for a moment and then opens after it is
triggered.
Then click “Set” to take effect.
See below picture:

10
Troubleshooting
1. No Power
•Ensure the power is on.
•Ensure you use the power adapter provided in the package.
2. No Picture or Video Flash
•Ensure all devices are on, and all cables are qualified and
connected properly.
•Ensure all the cables’ length are within the maximum distance (refer
to Specification table).
•Ensure the LED indicator is normal.
•When connecting source to display directly, ensure them can work
properly.
•Ensure the input resolution is supported by the device.
3. No Audio
•Set EDID switch to fix EDID (see “EDID Presets” section), then try.
•For analog audio output, ensure output audio format of source
device is PCM 2.0.
•For digital S/PDIF coaxial audio output，ensure output audio format
of source device is 5.1 channel or below.
4. RE LAY Invalid
Ensure RELAY is set to correct trigger mode, Latch or Momentary.
5. RS232 Output Commands Invalid
•Ensure the commands set via UART port configuration tool are
correct.
•Check the commands case.

11
Warranty Terms and Conditions
For the following cases LINK shall charge for the service(s) claimed for the
products if the product is still remediable and the warranty card becomes
unenforceable or inapplicable.
1. The original serial number (specified by LINK) labeled on the product
has been removed, erased, replaced, defaced or is illegible.
2. The warranty has expired.
3. The defects are caused by the fact that the product is repaired,
dismantled or altered by anyone that is not from a LINK authorized
service partner. The defects are caused by the fact that the product is
used or handled improperly, roughly or not as instructed in the
applicable User Guide.
4. The defects are caused by any force majeure including but not limited to
accidents, fire, earthquake, lightning, tsunami and war.
5. The service, configuration and gifts promised by salesman only but not
covered by normal contract.
6. LINK preserves the right for interpretation of these cases above and to
make changes to them at any time without notice.
