BUSINESS SERIES
PRODUCT DATA
Model: WVC2300
Wireless-G Business
Internet Video Camera
with Audio
High quality wireless video surveillance
platform provides flexible installation
Linksys Business Series Surveillance products provide customizable ways for small business
owners to monitor and protect their companies. These high-quality solutions can be optimized
for many different applications and sites. Each camera can be quickly mounted utilizing the
bracket included in the package. Its compact form factor also enables the camera to be put
inside a protective enclosure for interior or exterior installations. The camera uses removable
CS-mount lenses and can be customized with optional zoom, wide-angle, vari-focal, auto-iris, or
other type lenses as required for a specific application or setting.
The WVC2300 Camera can be mounted on any Pan-Tilt (PT) base that supports the Pelco_D
protocol and can be remotely rotated and controlled through an RS-485 interface. The WVC2300
also has two input and two output ports which can be used for connecting the camera to an alarm
panel, siren, Passive InfraRed (PIR) sensors, smoke detectors, lighting switch (on/off), door sensors,
etc.
The WVC2300 uses a high-quality progressive scan CCD Sensor delivering good quality video.
The CCD sensor also has low-light sensitivity so video can be captured even in very low light
environments or during“near dark” times of day. Additionally, the camera incorporates an IR Cut Filter
which, when used with a separate IR lamp, allows for video capture in total darkness.
The WVC2300 Camera supports dual codecs (MPEG-4 and MJPEG). Both codecs can be used
simultaneously. MPEG-4 gives efficient bandwidth consumption with good quality compression and
is optimal for real-time viewing of video. MJPEG gives optimal video quality with lossy compression
making it ideal for large volume storage to a NAS device.
The WVC2300’s audio capabilities include 2-way audio, embedded microphone, external speaker and
microphone ports, and voice compression. With extensive feature support like IP Multicast, RTSP, RTP, and
3GPP, video can be viewed from multiple endpoints and client applications like 3G phones, and Quicktime
clients on PCs or WiFi phones. The Wireless capabilities of the WVC2300 includes support for 1x2 MIMO,
providing better range than traditional 802.11g, and strong wireless security utilizing WPA. Support for
multiple network protocols like 802.1p priority, 802.1q VLANs, and Dynamic DNS, make the solution ideal
for multiple IP surveillance applications. The 2300-series cameras can also be managed securely using
HTTPS.
Linksys Business Series Surveillance Cameras are also Linksys One Ready. That means they include the
necessary firmware to be integrated into a Linksys One data or data/voice network.
Wireless Box camera with
interchangeable lenses,
and I/O ports allow for
flexible installation for
multiple applications
High quality CCD sensor
with low light sensitivity
and an IR Filter switcher
provides optimal video
image under multiple
conditions
Simultaneous dual
CODEC provides optimal
combination of viewing
and storage of video
Two-way audio, IP
multicast, 3GPP, and lots of
other advanced features
make this solution ideal for
surveillance deployments
WVC2300

PRODUCT DATA
BUSINESS SERIES
Features
Standard box-type
camera allows for flexible
installation
Mounts in a standard
outdoor or indoor enclosure
Provides controls for
mounting on a Pelco pan/tilt
base and control movement
remotely
Removable CS-mount lens
- camera can be customized
for multiple applications
- zoom lens, wide-angled,
vari-focal, auto-iris lenses, etc
1/4’’ Progressive Scan CCD
sensor delivers good quality
video
Low light sensitivity with
high-quality lens, sensor, and
a programmable IR-cut filter
functionality
Audio input/output for
external microphone and/or
speaker
IO ports facilitates alarm
triggers, turn on/off of lights,
etc
IEEE 802.11b/g wireless
support with 1x2 MIMO for
better wireless range and
coverage
Dual CODEC (MPEG-4
and MJPEG) supported
simultaneously
IP Multicast support
RTSP video/audio streaming
to unicast and multicast
clients
4x Digital zoom – can also
use optical zoom with
appropriate interchangeable
lens
•
•
•
•
•
•
•
•
•
•
•
•
•
Wireless-G Business Internet Video Camera
with Audio
Specifications
Model WVC2300
Standards IEEE802.11g, IEEE802.11b, IEEE802.3, IEEE802.3u,
IEEE802.1p (QoS Priority), IEEE802.1q (VLAN), 802.11e (Wireless QoS)
Protocols Supported TCP/IP, HTTP, DHCP, SMTP, FTP, NTP, DNS, UPnP, RTP, RTSP and DDNS
Ports Ethernet, Microphone IN, Speaker OUT, Power (12V, 1A), GPIO,
4-Pin IRIS Port
Buttons Reset
Cabling Type UTP CAT 5
LEDs Power, Network
Camera Type Box
IO ports RS-485 x 1 (2 Pins) - Supports Pelco “D” Protocol Commands
Input Control x 2 (2 Pins)
Output Control x 2 (2 Pins)
Lens
Sensor 1/4” Progressive CCD Sensor
Illumination [email protected]
Lens Type CS-Mount lens, Fixed Focus; Adapter also Included for Lenses that Require
More Distance Between Sensor and Lens
Focal Length 500mm~Infinity (for Included Lens)
Field of View 60º (for Included Lens)
Video Resolution 640x480 (VGA), 320x240 (QVGA), 160x120 (QQVGA)
Frame Rate 1 to 30 fps (Selectable)
Iris Provides Iris Control for CS-Mount Auto-Iris Lens When Attached
Setup/Config
Web UI Built-in Web UI for Easy Browser-Based Configuration (HTTP)
Management
Web Browser Internet Explorer 5.x or Above
Limited support for Netscape and Firefox. Browser controls for PTZ,
Audio, and Motion Detection are limited or not supported with Netscape
and Firefox. Please consult support.linksys.com for browser compatibility.
Event Logging Event Logging (SYSLOG)
Web F/W Upgrade Firmware Upgradable Through Web-Browser
Video Compression
Dual Codec MPEG-4 Simple Profile
MJPEG
Simultaneous Dual-Stream
Snapshot JPEG
Modulation NTSC and PAL
Image Settings Brightness and Contrast
Zoom 4x Digital Zoom
Night Vision IR Cut Filter for Low Light
Video Controls Auto-White-Balance(AWB), Auto-Exposure(AES)
Image Control Select Video by Quality, Bandwidth, and Frame Rate
Format 3GPP for Use with 3G Phones
Alerts
Motion Detection 4 Detection Areas with Individual Sensitivity
E-mail Alert 3 E-Mail Addresses
FTP Uploading FTP Server Address and Login Settings
Instant Messaging Jabber Client Support
Scheduled Schedule by Day or Time
Triggers Inputs 1, Input 2, Motion Detection
Actions Outputs 1, Output 2, Messaging, E-mail, FTP
Audio
Summary 2-Way Audio
Built-In Microphone - 6mm, -40db + 3db
Microphone Input - 3.5 mm Phone Jack

PRODUCT DATA
BUSINESS SERIES
Linksys
A Division of Cisco Systems, Inc.
121 Theory
Irvine, CA 92617 USA
E-mail: [email protected]
[email protected]
Web: www.linksys.com
Linksys products are available in more
than 50 countries, supported by
12 Linksys Regional Offices throughout
the world. For a complete list of local
Linksys Sales and Technical Support
contacts, visit our worldwide website
at www.linksys.com
Check the product package and contents for specific features supported. Specifications are subject to change without notice. Linksys is a registered trademark or
trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2007 Cisco Systems, Inc. All rights reserved. Other brands
and product names are trademarks or registered trademarks of their respective holders.
7082910NC-RR Model: WVC2300
3GPP allows viewing of
video on a mobile device
Motion detection with event
notifications to an e-mail
account or alarm log in the
monitoring software
JPEG snapshots at multiple
resolutions that can be sent
to an FTP server
Overlay watermarks/
graphics and text
Up to 10 unicast users and
unlimited multicast users
Built-in web server for
remote access over IP
Secure control over HTTPS
Included software for
monitoring and recording
up to 16 cameras
simultaneously
•
•
•
•
•
•
•
•
Speaker Output - 3.5 mm Phone Jack
Compression G.726 - 16K, G.711 A-law and µ-law
Sampling Rate 8 KHz
Default Bit Rate 16Kbps
Management Utility
Monitoring/Recording Software Monitoring and Recording for up to 16 Cameras
Advanced Search Histogram or by Time and Date
Recording Set Up to Record by Motion Trigger, Manual or Schedule
Recording and Playback
Security
WEP/WPA WEP 64bit/128bit, WPA-TKIP, WPA-PSK
User List User Rights List to View Video and/or to Camera Control Functions
Username/Password Logon Authentication 20 Character Username and 8 Character Password
Kensington Lock Physical Security Option
Network
RTP/RTSP Real-Time Protocol, Real-Time Streaming Protocol Allows for Viewing from
any Client Supporting These Protocols, like 3G Phones or Quicktime Client
NTP Network Time Protocol Keeps Time of Camera in Sync with your Network
SMTP Simple Mail Transfer Protocol Client allows video clips to be E-Mailed
FTP Client FTP Client Facilitates Scheduling Transfer of Images to an FTP Server
DDNS Dynamic DNS Facilitates Reaching the Camera by a Name Irrespective of
Camera’s IP Address. Supports DynDNS, TZO, and 3322 Dynamic
DNS Services
UPnP Allows Autodiscovery of the Camera by Other UPnP Devices
IP Filtering Allow or Disallow Access by IP Address
Power
Power Options External Power Adapter: 12V/1A, 110~120V AC/60Hz, Switching
Power Consumption 10W
Environmental
Dimensions 4.72" x 2.99" x 1.81" (120 x 76 x 46 mm)
Unit Weight 1.15 lb (0.52 kg)
Power External Power Adapter 12 VDC 1A 110~120VAC/60Hz Switching
Certification FCC Part 15C Class B, CE, UL, EMC/EMI Part 15B Class B for US
Operating Temp. 32 to 122ºF (0 to 50ºC)
Storage Temp. -4 to 158ºF (-20 to 70ºC)
Operating Humidity 10% - 80%
Storage Humidity 0% - 19%
Package Contents
WVC2300 Wireless Business Internet Video Camera with Audio
Stand Kit
Antennas (x2)
Power Supply (12V 1A)
6’ Ethernet Cable
CS-Mount Lens Adapter Ring for Wider Focal Length Lens
Allen Wrench
Quick Installation Guide
Setup CD
Minimum Requirements
Wired Ethernet or Wireless 802.11b/802.11g Network
Network Adapter With Ethernet Network Cable and TCP/IP Protocol Installed Per PC
Switch/Router To Support Multiple Connection Points
Internet Explorer 5.x or above with ActiveX Support for Viewing
Microsoft Windows Vista, XP, 2000, ME or 98SE
2 GHz Pentium 4, or AMD Athlon Class CPU with 512 MB RAM
128 MB AGP Video Adapter
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
