Linksys SR2024C Operation manual

Wire-speed switching and Linksys reliability in a 24-port Gigabit
switch
Product Data
Model SR2024C
Wired
24-Port 10/100/1000 Gigabit
Switch
The 24-Port 10/100/1000 Gigabit Switch provides non-blocking, wire
speed switching for your 10, 100, and 1000 megabit network clients.
Drop this switch in place of your current workgroup hub or switch,
and you can upgrade your high-requirement workstations to full
Gigabit speeds as necessary, while continuing to service other clients
at their current speeds. Or build your network from the ground up,
with appropriate link speeds for each user's requirements. Either
way, it's perfect for graphics, multimedia, and other applications that
have to move large files across the network quickly. And when you
need to expand your network even further, the two Mini-GBIC ports
let you add fiber-optic capability easily and cost effectively.
With the 24-Port 10/100/1000 Gigabit Switch, you can connect your
existing 10/100 Ethernet network to a Gigabit server backbone
without any additional equipment. All ports have automatic MDI/
MDI-X crossover detection, so you don't have to worry about the
cable type. Each port independently and automatically negotiates for
best speed and whether to run in half- or full-duplex mode. Address
learning and aging is supported, as well as 802.3x flow control with
head-of-line blocking prevention to keep your high-speed clients
from bogging down in lower-speed traffic. Fast store-and-forward
switching prevents damaged packets from being passed on into the
network.
World famous Linksys reliability and the limited lifetime warranty give
you peace of mind and the rackmount form factor integrates
smoothly into your network infrastructure. Let the Linksys 24-Port
10/100/1000 Gigabit Switch kick your network into high gear.
Twenty-four 10/100/1000Mbps,
half/full duplex, switched ports, and
two Mini-GBIC expansion ports.
Forwards packets at non-blocking,
full wire speed.
All ports have auto speed
negotiation and auto MDI/MDI-X
crossover detection.
Linksys reliability and limited
lifetime warranty.

24-Port 10/100/1000 Gigabit Switch
Wired
Check the product package and contents for specific features supported. Specifications are subject to change without notice. Linksys is a registered trademark or trademark of
Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2006 Cisco Systems, Inc. All rights reserved. Other brands and product names are
trademarks or registered trademarks of their respective holders.
Model SR2024C
SR2024C-DS-60425NC RR
Features
• 24 RJ-45 ports for 10BASE-T/
100BASE-TX/1000BASE-TX connections
• Supports half duplex and full duplex modes
auto-negotiation for all ports.
• Auto MDI/MDI-X support on all ports for
easy cable detection
• Efficient MAC Address learning engine
supports up to 8K MAC Addresses
• Provides store-and-forward forwarding
scheme.
• Standard width and mounting kit (included)
make it easy to be installed into a rack
• Two mini-GBIC ports for easy expansion to
other mini-GBIC equipped switches
• Integrated 256K packet buffer memory
• Supports Jumbo frame of 9K bytes
• Supports IEEE802.3x full duplex operation
• RoHS Compliant
Linksys
A Division of Cisco Systems, Inc.
121 Theory
Irvine, CA 92617 USA
E-mail: [email protected]
[email protected]m
Web: http://www.linksys.com
Linksys products are available in more than
50 countries, supported by 12 Linksys Regional Offices
throughout the world. For a complete list of local
Linksys Sales and Technical Support contacts, visit our
Worldwide Web Site at www.linksys.com.
Minimum Requirements Package Contents
• Cat5 Ethernet Network Cable
• TCI/IP Protocol installed on each computer within the
network
• Network Adapter installed in each computer
• Network Operating System (e.g. Windows®, Linux, MacOS
X)
• 24-Port 10/100/1000 Gigabit Switch
•ACPowerCord
• User Guide with On-line Registration Card
• Set of Rack Mounting brackets
Specifications
Model SR2024C
Standards IEEE 802.3, 802.3u, 802.3x, 802.3ab
Ports 24 RJ-45 10/100/1000 + 2 Mini-GBIC ports
Cabling Type Category 5e or better
LEDs System, 1 through 24
Environmental
Dimensions 10.98" x 1.75" x 9.45"
(W x H x D) (279 mm x 44.45 mm x 240 mm)
Weight 4.78 lbs (2.17 kg.)
Power 110-120VAC, 100W
Certification FCC Class A, CE
Operating Temp. 0ºC to 40ºC (32ºF to 104ºF)
Storage Temp. -40ºC to 70ºC (-40ºF to 158ºF)
Operating Humidity 20% to 95% relative humidity
Storage Humidity 5% to 95% Non-Condensing
