ProConnect®4-Station
CPU Switch
Take control of your PCs with the ProConnect®CPU Switch. Ready to run out of the box,the ProConnect®CPU Switch lets
you connect multiple PCs to a single keyboard, monitor, and
mouse. Switch between PCs with the press of a key,or use the
switch’s cycling feature to rotate between each PC’s progress
automatically at programmed intervals. Got a notebook PC?
Plug it into the CPU Switch and control it from your desktop’s
full-sized keyboard, monitor, and mouse - just like a docking
station!
Builtto last,theProConnect®4-PortCPU Switch virtually elim- inates cable swapping, while you save storage space and
hundreds of dollars in hardware costs. Your connection can be
simple and inexpensive with the Linksys ProConnect®CPU
Switch. It’s the perfect choice for any Server room, Internet
Service Provider,or testing lab where you need to manage mul-
tiple PCs efficiently and easily.
• Supports HotKeys and Pushbutton Switching
• Serves as a Convenient Docking Station for Notebook PCs
• Supports Hot-Swapping of Cables
• Cycling Feature Switches Among PCs Automatically
• Fully Expandable - Cascade CPU Switches Together to
Support up to 64 PCs
• Runs with Virtually All Software and Operating Systems
• Compatible with Virtually All Standard PS/2, AT/Serial, and
Windows Keyboards
• Sturdy Metal Chassis and Quality Connectors
• Free Technical Support-24 Hours a Day, 7 Days a Week for
North America Only
• 1-Year Limited Warranty
• Switch Instantly Among Multiple PCs with the
Touch of a Button
• Benefit from Incredible Savings in Equipment,
Space, and Power Costs
• Conserves Desktop and Storage Space
• Serves as a Convenient Docking Station for
Notebook PCs
• Free Technical Support—24 Hours a Day,
7 Days a Week for North America Only
• 1-Year Limited Warranty
Conserve Desktop Space While Using
Multiple PCs
Features
Features
Benefits
Benefits
CCoonnnneeccttMMuullttiipplleePPCCss
wwiitthhJJuussttOOnneeCCoonnssoollee
ProConnect®4-Station CPU Switch (SVIEW04 ver. 2)
PS/2 CPU Switch Cabling Kit (SVPS06)
ProConnect
®
Series

Package Contents
DS-SVIEW04 v2-10525NC KL
ProConnect®4-Station CPU Switch
• One ProConnect®4-Station CPU Switch
• One AC Power Adapter
• One User Guide and Registration Card
Linksys
17401 Armstrong Ave.
Irvine, CA 92614 USA
Sales Information [phone]
Technical Support [phone]
[phone]
Fax [phone]
World Wide Web* http://www.linksys.com
Email [email protected]
[email protected]
China
Tech Support (10) 6432 1920
Sales (10) 6432 1923
Fax [phone]
Japan
Telephone [phone]
Fax [phone]
Philippines
Telephone [phone]
Fax [phone]
Singapore
Telephone [phone]
Fax [phone]
Thailand
Telephone [phone]
Fax [phone]
United Kingdom
Tech Support 0870 7393939
Sales 01245 352403
Fax [phone]
*Visit our website for the most current contact information
System Requirements
4-Station Console Ports:
• One VGA, SVGA, or Multisync monitor capable of
the highest resolution that you will be using on any
computer installed
• One PS/2 style mouse
• One PS/2 style keyboard
PC’s:
• One VGA, SVGA or Multisync video card
• One 6-pin mini-DIN (PS/2 style) or DB-9 (standard
serial) mouse port
• One 6-pin mini-DIN (PS/2 style) keyboard port with
a +5V DC on pin 4 and Ground on pin 3 or a 5-pin
DIN (AT style) keyboard port with +5V DC on pin 5
and Ground on pin 4.
One Serial to PS2 adapter for computers using Serial
Ports
One AT to PS2 adapter for computers using AT Ports
Please contact Linksys if you have any product questions.
Specifications
Model Numbers: SVIEW04 ver. 2
Cabling Kits*: SVPS06
Scan Intervals: 5, 10, 20, and 40 seconds
Monitors
Supported: VGA, SVGA, and MultiSync with DDC, DDC2, and
DDC2B
Maximum
Resolution: 1920 x 1440 SVGA
Ports: Four CPU ports and three Console ports
Buttons: Four Port Selection buttons and One Auto Scan
Button
LEDs: Online Port, Selected Port
Environmental
Dimensions: 8.8” x 6” x 2” (224mm x 152mm x 52mm)
Unit Weight: 42.3 oz. (1.2 Kg)
Power: 9V DC (1.62w maximum power consumption)
Certifications: FCC Class B, CE Mark Commercial
Operating Temp: 5ºC to 40ºC (41ºF to 104ºF)
Storage Temp: -10ºC to 60ºC (14ºF to 140ºF)
Operating Humidity: 10% to 85%, Non-Condensing
Storage Humidity: 5% to 90%, Non-Condensing
* Cable kits for connecting PCs to the CPU switch are sold by the above
model number, separately. If you have any questions about cabling
kits, please contact Linksys for assistance.
