Linksys SE3005 User manual

Package Content
• SE3005/SE3008 Gigabit Switch - 4 x FootPads
• PowerAdapter SE3005/SE3008 -Wall-MountKits
• Quick InstallationGuide
ProductOverview
SE3005 SE3008
LED defini ti on
System LED (Blue) -TheLED 1s solidwhen the switch is powered on .
LINK/ACT/GB(Green) E LEDslightupgreenwhen a 1Gbpsconnection isdetected.
Theyflashwhenthere is traffic on the corresponding port
LINK/ACT/GB(Orange} mLEDslightuporangewhena 100/10Mbpsconnection is detected
Theyflashwhen there is traffic on the corresponding port .
In stall YourSwitch
1 Power on the switch
If replacing anexistingswitch, disconnect it
Switch ~
2 Usean ethernetcable to connectyourswitch to a router
Router

3 Usean ethernetcable to connecteachadditionaldevice.
Specifications
Item
Model
Standards
Ports
Cabling Type
LEDs
Dimensions
Unit Weight
Power
Certification
OperatingTemperature
StorageTemperature
Operating Humidity
StorageHumidity
Specification
SE3005,SE3008
Additional
Device
IEEE802 .3, 802 . 3u , 802 . 3x , 802.3ab , 802 . 3az
5/8 RJ-4510/100/1000Mbpsports
Cat5 orbetterethernetcable
Bluesystem LED
Green/Orange LINK/ACT/GB LEDs(5/8)
SE3005 ·120mmx 88mm x 26mm
SE3008 .168mmx 90mm x 26mm
SE3005 252g
SE3008 358g
DC 12V/0. 5A
FCC Class B, CEClass B
32°F to104°F(0°C to 50°C)
4°F to 158°F (- 40°C to 70°C)
10TO 90% ,non-condensing
5 to 90% ,non-condensing

TECHNICAL SUPPORT
Information about Linksys Products can be found at https : //www .linksys.com/support
or call 800-326 · 7114 (U .S. & Canada).
Linksys.com
Belkin, LINKSYS and many product names and logos are trademarks of the Belkin group of companies. Third-party
trademarks mentioned are the property of theirrespective owners. The use of the word partnerdoes not imply a
partnership relationship betweenBelkin or any of its affiliatesand any other company.
IQ 2018 Belkin International. Inc. and/or its affiliates. All rights reserved.
8820-02676 Rev. A00

■
. -
LIN<SYS ®
Information
Class B Gigabit
Switch Products
I
■

tatement
DECLARATION OF CONFORMITYWITH FCC RULES FOR ELECTROMAG-
NETIC COMPATIBILITY
We, LINKSYS of 121 Theory, Irvine, CA 92617, declare under our sole responsi-
bility that the Class 8 Gigabit Switch products to which this declaration relates,
comply with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this
device mustaccept any interference received, including interference that may
cause undesired operation.
This producthas been tested and complies with the specifications for a Class
8 digital device, pursuant to Part 15 of the FCC Rules. This equipment gener-
ates, uses, and can radiate radio frequency energy and, if not installed and
used according to the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur
in a particularinstallation. If this equipment does cause harmful interference to
radio or television reception, which is found by turning the equipment off and on,
the user is encouraged to try to correct the interference by one ormore of the
following measures:
• Reorient orrelocate the receiving antenna
• Increase the separation between the equipment or devices
• Connect the equipment to an outletotherthan the receiver's
• Consult a dealer or an experienced radio/TV technician for assistance
FCC Caution: Any changes ormodifications notexpressly approved by the party
responsible for compliance could void the user's authority to
operate this equipment.
Innovation Science and Economic Development Canada Statement
This digital apparatus complies with CAN ICES-3(8).
Operation is subject to the following two conditions:
1. This device may not cause interference and
2. This device mustaccept any interference, including interference that may
cause undesired operation of the device.
Avis d'Avis d'lnnovation, Sciences et Developpement economique Canada
Cetappareil numerique est conforme aux normes NMB-3(8) du Canada.
Le fonctionnement est soumis aux conditions suivantes :
1.Ceperipherique ne doit pas causerd'interferences;
2.Ce peripherique doit accepter toutes les interferences rec;ues, y compris
celles qui risquent d'entra,ner un fonctionnement indesirable.
■

WARNING: Do not use this productnearwater, for example, in a wet
basement ornear a swimming pool.
WARNING: Avoid using thisproduct during an electrical storm.
There may be a remote risk of electric shock from
lightning.
WARNING: The power adaptor is the equipment's disconnection
device. The power outlet must be located nearby the
equipment and its access must be easy.
AVERTISSEMENT: N'utilisez pas ce produitaproximite d'une
source d'eau, sur un sol humide ou pres d'une
piscine, par exemple.
AVERTISSEMENT: Evitez d'utiliser ce produitpendant un orage. La
foudre pourraitprovoquer un choc electrique.
AVERTISSEMENT: L'adaptateur de courant secteur est le disposi-
tive de sectionnement de l'equipement. La prise
de courant secteur doit etre situee aproximite
de l'equipement et facile d'acces.
UserInformation for ConsumerProducts Covered by EU Directive 2012/19/
ECon Waste Electric and Electronic Equipment(WEEE)
This documentcontains important information for users with regards to the
proper disposal and recycling of Linksys home networking products. Consumers
are required to comply with this notice for all electronic products bearing the
following symbol:

gngnsh- Environmental Information for Customers in the European Union
European Directive 2012/19/EC requires that the equipmentbearing this symbol
)Ef on the productand/or its packaging must not be disposed of with unsorted
municipal waste The symbol indicates that this productshould be disposed of
separately from regular household waste streams. It isyour responsibility to dis-
pose of this and other electric and electronic equipment via designated collection
facilities appointed by the government or local authorities. Correct disposal and
recycling will help prevent potential negative consequences to the environment
and human health. For more detailed information about the disposal of your old
equipment, please contact your local authorities, waste disposal service, or the
shop where you purchased the product.
Frarn;ais (French) -Informations environnementales pour les clients de l'Union
europeenne La directiveeuropeenne 2012/19/EC exige que l'equipement sur
lequel estappose ce symbole%sur le produit et/ou son emballage ne soitpas jete
avec les autres ordures mena~os. Ce symbole indique que le produitdoit etre
elimine dans un circuit distinct de celui pour les dechets des menages. II estde
votre responsabilite de jeter ce materiel ainsi que tout autre materiel electrique ou
electronique par les moyens de collecte indiques par le gouvernement et les pou-
voirs publics des collectivites territoriales. L'elimination et le recyclage en bonne
et due forme ont pour but de luttercentre l'impact nefaste potentiel de ce type de
produits surl'environnement et la sante publique. Pour plus d'informations sur le
mode d'elimination de votre ancien equipement, veuillez prendre contact avec les
pouvoirs publics locaux, le service de traitement desdechets, ou l'endroit ou vous
avez achete le produit.
Visit linksys. com/ support for award-winning
24/7 technic al support
© 20 17 Belkin International, Inc. and/or itsaffiliates. All rights reserved. BELKI N,
LI NKSYS and many productnames and logos are tradem ar ks of the Belkin group
of companies. Third-party trademarks mentioned are the prope rt y of their
respective owners.
8820-02657 Rev. A00

LIN<SVS ®
.
.
Warranty and Support Information

WARRANTY AND SUPPORT INFORMATION
IMPORTANT!
PLEASE RETAIN PROOF OFPURCHASE AND PRODUCT WARRANTY INFORMATION
LIMITED WARRANTY
(UNITED STATES AND CANADA)
This warranty is provided to you by Belkin International, Inc, or one of its subsidiaries or affiliates ("Belki n")
IMPORTANT NOTICE REGARDING YOUR CONSUMER RIGHTS
The benefits we give in this manufacturer'swarrantyare additional toanyrightsandremedies that youmay
have under local consumer protection laws. Nothing in this warranty limits or affects your legal rights.
This manufacturer's warranty is governed by the laws of the country in which you purchased your Belkin, Linksys
or Wemo product. In many countries, consumers have rights under local consumer laws. Those consumer rights
may differ between countries, states and provinces, and often cannot be excluded . Your local consumer rights
organization can advise you on your legal rights.
This manufacturer's warranty is not intended to:
• change or exclude any ri ghts under consumer law that cannot be lawfully changed or excluded; or
• limit or exclude any right you have against the person who sold the Belkin, Linksys or Wemo product to you if
that person has breached their sales contract wi th you.
-------~---------------~
WHAT DOESTHIS WARRANTY COVER?
Belkin warrants that the producthardware and any software media (i.e., media on which the product software is
provided) will be free from defects 1n materials and workmanship under normal use during theWarranty Period
described below. This means that theproductwon't be defective, and that it will look and work as advertised during
therelevant period
This warranty does not apply to productspurchased from a source otherthan Belkin or a BelkinAuthorized Reseller.
How long is the product warranted?
Belkin warrants that the hardwarein this Belkin, Linksys or Wemo product, and any associated software media,
will be free from defects in materials and workmanship undernormal use during the Warranty Period. The Warranty
Period begins on the datethe product was purchased by the original end-userpurchaserand lasts for the period set
out in the table below:
Product Type Warranty Peri od
Newproducts 12 months
Refurbished products
90 days
Repaired or replacementproducts The longer
of the original WarrantyPeriod or 30 days
Softwaremedia(ifprovided with the product)
90 days
A claim under this warranty is onlyeligible if it is madewithin the Warranty Period.
What isn 't covered?
Belkin does not give any warranty:

• in relation to software or services, provided by Belkin or any third party, included in or with the product;
• that the product, software or services will alwaysoperate uninterrupted or errorfree;
• that the product, software or services, or anyequipment, system or networkon which the product, software or
servicesare used are 100% secure and cannot be hacked; or
• that a third party service the product needswill always be available.
Note: Although Be lkin doe snotm ake the se prom i ses in this warranty , you may have additional rights under
consumer laws .
Will thi s war r ant y always appl y?
This warranty does not apply if:
• the product has beentampered with or the assembly seal hasbeen removed or damaged;
• the product hasbeen altered or modified by someone other than Belkin;
• the warranty claim was made fraudulently or by misrepresentation;
• the product was not installed, operated, repaired, or maintained in accordance with Belkin's instructions;
• the product has been subjected to abnormal physical or electrical stress, misuse, negligence, or accident;
• damage to the product iscosmetic, including scratches and dents, or defectscaused by normal wear and tear or
normal aging of the product;
• the serial numberon the product has been altered, defaced, or removed; or
• the product was supplied or licensed for beta, evaluation, testing or demonstration purposes, and you didn't buy or
license the product.
Note: Although this warr a nty doesn 't apply in these situations,youmay have additional rights underconsumerlaws.
How will Belkin make thing s ri ght?
If you make an eligible claim underthiswarranty, Belkin will, at its election:
• repair the product with new or refurbished parts, or pay the reasonable costs of repairing the product;
• replace the product with a reasonably available equivalent new or refurbished Belkin, Linksys or Wemo product; or
• refund you the purchase price of the product, minus any rebates and discounts.
Any repaired or replacement productsare warranted for the remainder of the originalWarranty Period or 30 days,
whichever is longer. All productsand parts that are replaced become the property of Belkin.
Note: The rights and remedies outlinedabove are the only rights and remediesavailable under this warranty .
How ever, you mayhave addit ional rights underconsumerlaws.
GENERAL EXCLUSIONS AND LIMIT A TIONS OF LIABILITY
IN THOSEJURISDICTIONS WHERE ITCAN LAWFULLY DO SO, AND TO THE MAXIMUM EXTENT PERMITTED
BYAPPLICABLE LAW, BELKIN, ITS RESELLERS AND ITS SUPPLIERS HEREBY DISCLAIM A ND EXCLUDE
ALL OTHER WARRANTIES, EXPRESS, STATUTORY OR IMPLIED, INCLUDING BUTNOTLIMI TED TO IMPLIED
WARRANTIES OF MERCHANTABILITY, ACCEPTABILITY, SATISFACTORY QUALITY, NON-INFRINGEMENT, TITLE,
FITNESS FOR A PARTICULAR PURPOSE, LOSS OF OR DAMAGE TO DATA, LACK OFVIRUSES OR FR EE FROM
VIRUS OR MALWAREATTACK, SECURITY, PERFORMANCE, LACK OF NEGLIGENCE, WORKMANLIKE EFFORT,
QUIETENJOYMENT, THATTHE FUNCTIONS CONTAINED IN THE PRODUCT WI LLMEETYOUR REQUIREMENTS,

OR THAT DEFECTS IN THE PRODUCT WILL BE CORRECTED, OR THAT YOUR USE OF THE PRODUCT WILL
GENERATE ACCURATE, RELIABLE, TIMELY RESULTS, INFORMATION, MATER IAL OR DATA. NO ORAL OR
WRITTEN INFORMATION OR ADVICE GIVEN BY BELKIN, A DEALER, AGENT OR AFFILIATE SHALL CREATE A
WARRANTY. TO THE EXTENT WARRANTIES CANNOT BE DISCLAIMED OR EXCLUDED, THEY ARE LIMITED TO
THE DURATION OF THE RELEVANT EXPRESS WARRANTY PERIOD.
EXCEPT AS PROVIDED IN THIS WARRANTY AND TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW,
INNO EVENT SHALL BELKIN, ITS AFFILIATES, ASSOCIATES, DEALERS, AGENTS OR SUPPLIERS OR THEIR
RESPECT I VE OFFICERS, DIRECTORS, EMPLOYEES, LICENSOR$ AND ASSIGNS BE LIABLE FOR ANY DI RECT,
INDIREC T, EXEMPLARY, PUNITIVE, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES WHATSOEVER
(INC L UD I NG BUT NOT LIMITED TO DAMAGES FOR LOSS OF PROFITS OR REVENUE, FOR BUSINESS
INTERRUPTION, FOR PERSONAL INJURY, FOR LOSS OF PRIVACY, FOR LOSS OF ABILITY TO USE ANY THIRD
PARTY PRODUCTS OR SERVICES, FOR FAILURE TO MEET ANY DUTY INCLUDING OF GOOD FAITH OR OF
REASONABLE CARE, FOR NEGLIGENCE, AND FOR ANY OTHER PECUNIARY OR OTHER LOSS WHATSOEVER),
REGARDLESS OF THE THEORY OF LIABLITY (CONTRACT, TORT OR OTHERWISE) ARISING OUT OF OR IN
ANY WAY RELATED TO THE USE OF OR INABILITY TO USE THE PRODUCT, EVEN IF BELKIN OR SUCH OTHER
EN TITIES HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN NO EVENT SHALL THE TOTAL
AGGREGATE LIABILITY OF BELKIN, ITS AFFILIATES, ASSOCIATES, DEALERS, AGENTS OR SUPPLIERS TO YOU
FOR ALL DAMAGES EXCEED THE PRICE YOU PAID FOR THE PRODUCT. THIS LIMITATION IS CUMULATIVE AND
WILL NOT BE IN CREASED BY THE EXISTENCE OF MORE THAN ONE INCIDENT OR CLAIM. THE FOREGOING
LIM I TATIONS WIL L APPLY EVEN IF ANY WARRANTY OR REMEDY PROVIDED FAILS OF I TS ESSENTIAL
PURPOSE. NOTH I NG IN THIS SECTION SHALL LIMIT THE LIABILITY OF BELKIN IN RELATION TO DEATH OR
BODILY INJURIES.
THE WARRANTIES AND REMEDIES SET OUT IN THIS AGREEMENT ARE EXCLUSIVE, AND, TO THE
EX T ENT PERMITTED BY LAW, IN LIEU OF ALL OTHERS ORAL OR WRITTEN, EXPRESS OR IMPLIED. SOME
JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF IMPLIED WARRANTIES OR OF LIABILITY
FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE FOREGOING LIMITATIONS MAY NOT APPLY TO YOU.
If any term is held to be illegal or unenforceable, the legality or enforceability of the remaining terms shall not be
affected or impaired.
BELKIN TECHNICAL AND WA RR A NT Y SUPPORT INFORM A TI ON
HOW DO I GET HELP?
If you have a question aboutyourproduct or experience aproblem with it, please go to http://www.belkin.com/support
or http://support.linksys.com. You will find lots of online supporttools and information to helpyou with yourproduct.
What s hould I do if my p ro du ct is defe c ti ve?
You always have the option to return the product to the original seller if you have a problem You can make a claim
based on this warranty or any consumer laws that apply to you
You canalso make aclaim under this warranty or local consumer laws by contacting Linksys or BelkinTechnical
Support. To find out how to contact us, click the "Contact Us" linkon the home page of http://Linksys.com or
http://www.belkin.com. If you are located outside the United States, you will need to choose yourregion/location first:
F or Linksys.com:
ht tp://www.linksys.com/us/change-region/
ForBelkin.com:
http://www.belkin.com/us/-Click the "Change Region" link at the bottom of the website and selectyour location
If I be li eve my product is def ec tive and cov ered by this warranty, what do I nee d to do?
You will need to contact Technical Support for your region at the links above So that we can helpyou, you will need

to give us some information when you contact us:
• your product model, hardware revision and serial number;
• the name of your InternetService Provider (ISP); and
• proof that you purchased the product, with the date of the purchase shownand place where it was purchased
WE WI LL ALWAYS NEEDA DATED PROOF OF OR IGINAL PURCHASE TO PROCESS WARRANTY CLAIMS.
Sometimeswe will need you to send the productback to us so that we can fix or replace it. If we askyou to return
your product to us by post, you will be given a Return MaterialsAuthorization (RMA) numberand we'll tell you where
to send the product. You will need to make sure the product isproperly packaged andshipped, andyou will be
responsible for the costs of returning your product to us. We need to identifyyour productwhen it reaches us, so
you'll need to include the RMA numberAND a copy of yourdated proof of original purchase (please keep the original)
with the returned product. We also recommend that you send the package by registered and insured mail or by
overnightcourier to protect the packagewhile it is in transit.
What happens when I return my produ ct?
Defectiveproductscovered by this warrantywill be replaced without charge with the same product or an equivalent
product of equal or greatervalue, or Belkin will provideyou with a refund of the purchase price of the product, minus
any rebates and discounts. The remedy offered will bedetermined by Belkin in its sole discretion.
We can onlyshipreplacement or repaired products to locations in the countrywhere the original productwas purchased.
Belkin mayneed to delete all or part of yourdata to repair or replace your product. Belkin mayalso install software
updates as part of warranty service. PLEASE MAKE SURE THATYOU BACK UP ALL OF YOUR DATA ON THE
PRODUCT BEFORE SENDING IT IN FOR REPAIR OR REPLACEMENT BELKIN IS NOTRESPONSIBLE FOR ANY
LOSS OFDATA OR SOFTWARE DURI NG WARRANTY SERVICE.
Replacements not covered underwarranty or yourrights underconsumer lawmayberefused by place of purchase, or
may be subject to charge.
T ec hni cals upport
This warranty is not a service or support contract Details on our technical supportofferings and policies (including
any applicable fees) can be found at http://www.belkin.com/support or http://support.linksys.com.
Belkin provides many differentoptions to supportyou. Please clickon or go to the appropriate website below for
more details. Please make sure to change to your local country if necessary.
• Belkin and Wemo Products: http://www.belkin.com/support
• Linksys Products: http://support.linksys.com
Along with the Limited Warranty, Belkin provides ComplimentaryAssistedTechnical Support for the Warranty Period
to get your hardware up and running. ComplimentaryAssistedTechnical Support includestechnical support(by
phone) and live chat (through your computer). At this time, live chat isonly available in certain countries. Please visit
our websites(indicated above) in your local area for details.
Foradditional support beyond the Complimentary AssistedTechnical Support period or for assistance on advanced
features beyond basic support, please contact our Technical Support team to learn more about how we can helpyou
get the most out of your product. Please note that you may be assessed a fee to speak with our technician if you
contact us outside the ComplimentaryAssisted Technical Support period.
Additional information on some of our Premium Support Offeringscan be found at:
Linksys Networking Products -http://www.linksys.com/us/premium-support/
Belkin and Wemo Networking Products-http://www.belkin.com/us/belkin-premium-support/
Please Note: Some of these offeringsmay not be offered inyourcountry
Telephone supportmay not be available where you live and may be subject to charge.
