Linksys EtherFast EG0801W User manual

EtherFast® 10/100/1000 8+1
Workgroup GigaSwitch
igrate your network to Fast Ethernet’s Gigabit
speed with the EtherFast®10/100/1000 8+1
Workgroup GigaSwitch.This new compact 10/100
Switch from Linksys provides blazing transfer speeds for
your network applications with integrated Gigabit connec-
tivity.
Apply this switching power to your current Ethernet net-
work, and your data traffic efficiency will improve several
times over. Connect your workstations to the Switch's
10/100 ports,and speed up access time for all your users in
just one move. Connect to your server through the single
Gigabit port for full-duplex, dedicated bandwidth of up to
2000Mbps—the speed is yours!
With the EtherFast®10/100/1000 8+1 Workgroup
GigaSwitch, you can connect your existing 10/100 Ethernet
network to your Gigabit server backbone without purchas-
ing costly Gigabit adapters for each workstation. In addi-
tion, the Gigaswitch has easy, hassle-free setup with no
configuration required.
Savemoney andtime with thisall-in-one solutionfor Gigabit
connectivity over your 10/100 Ethernet network.
• 1 Gbps Full Duplex Switch Port and 8 10/100Mbps
Auto-Detect Half/Full Duplex Switch Ports
• Internal Built-In 256KB SRAM for Buffer Memory
• Up to 4096 MAC Addresses Table/Hashing Algorithm
on Address Learning
• Support Store and Forward Architecture and Performs
Forwarding and Filtering at Non-blocking Full Wire
Speed
• Supports Aging Function and 802.3x Flow for Full
Duplex and Back-Pressure Function for Half-Duplex
Operation
• Supports Congestion Flow Control
• Provides 3 LEDs per Port to Indicate the Packets
Traffic Pattern and Link Status
• Signal Regeneration Ensures Data Transfer Integrity
• Free Technical Support—24 Hours a Day, 7 Days a
Week for NorthAmerica Only
• One-Year Limited Warranty
• Gigabit Speed Now Available Using Standard
Networking Cable - No Fiber Cabling
Necessary
• Each 10/100 Port Automatically Detects and
Negotiates Up to 100Mbps
• Integrates Your Existing 10/100 Network with
a Gigabit Server Backbone Connection
• Channels Full Duplex, Dedicated
Bandwidth to Each Port for Optimal
Performance
• Easy to Use—No Configuration Required
• Free Technical Support—24 Hours a Day,
7 Days a Week for NorthAmerica Only
• One-Year Limited Warranty
EtherFast®10/100/1000 8+1 Workgroup GigaSwitch
(EG0801W)
M
Enjoy Blazing Fast,Easy andAffordable Gigabit
Integration ForYour Network
Features
Features
Benefits
Benefits
MMiiggrraatteettooGGiiggaabbiitt
SSppeeeeddOOvveerrCCooppppeerr
Instant Gigabit Series

EtherFast® 10/100/1000
8+1 Workgroup GigaSwitch
• EtherFast® 10/100/1000 8+1 Workgroup
GigaSwitch
• AC Power Adapter
• User Guide and Registration Card
Linksys
17401 Armstrong Ave.
Irvine, CA 92614 USA
Information [phone]
Technical Support [phone]
[phone]
Fax [phone]
World Wide Web http://www.linksys.com
Email [email protected]
[email protected]
China
Tech Support (10) 6432 1920
Sales (10) 6432 1923
Fax [phone]
Japan
Telephone [phone]
Fax [phone]
Philippines
Telephone [phone]
Fax [phone]
Singapore
Telephone [phone]
Fax [phone]
Thailand
Telephone [phone]
Fax [phone]
United Kingdom
Tech Support 0870 7393939
Sales 01245 352403
Fax [phone]
Package Contents
DS-EW5PCISK-10206NC DG
Specifications
Model Number EG0801W
Standards IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE
802.3x
Protocol CSMA/CD
Ports Eight 10/100 RJ-45 Ports, One Gbps Full-
Duplex Switch Port
Cabling Type UTP Category 3 or better (10BaseT)
UTP Category 5 or better (10/100BaseT)
UTP Category 5e or better (1000BaseTX)
Topology Star
Speed Per Port 10Mbps or 100Mbps (Half Duplex)
20Mbps or 200Mbps (Full Duplex)
1000Mbps or 2000Mbps (Gigabit Port)
LEDs Link/Act, Full/Half Duplex
Environmental
Dimensions 7.31”x 6.06”x 1.88”(186mm x 154mm x 48mm)
Unit Weight 13.6 oz. (.39Kg)
Power 3.3V DC,5A
Certifications FCC Class B,
CE Mark Commercial
Operating Temp. 32ºF to 122ºF (0ºC to 50ºC)
Storage Temp. -4ºF to 158ºF (-20ºC to 70ºC)
Operating Humidity 10% to 85% Non-Condensing
Storage Humidity 5% to 90% Non-Condensing
