Linksys Vonage WRTP54G User manual

Model No.
Broadband Router with 2 Phone Ports
Wireless-G
WRTP54G (EU/LA)
Voice
User Guide
GHz
802.11g
4
2,

Wireless-G Broadband Router with 2 Phone Ports
Copyright and Trademarks
Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco Systems,
Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2006 Cisco Systems, Inc. All rights
reserved. Other brands and product names are trademarks or registered trademarks of their respective holders.
How to Use this Guide
Your guide to the Wireless-G Broadband Router with 2 Phone Ports has been designed to make understanding
networking with the Router easier than ever. Look for the following items when reading this guide:
In addition to these symbols, there are definitions for technical terms that are presented like this:
Also, each figure (diagram, screenshot, or other image) is provided with a figure number and description, like
this:
Figure numbers and descriptions can also be found in the “List of Figures” section.
This exclamation point means there is a caution or warning and is
something that could damage your property or the Router.
This question mark provides you with a reminder about something you
might need to do while using the Router.
This checkmark means there is a note of interest and is something you
should pay special attention to while using the Router.
word: definition.
Figure 0-1: Sample Figure Description
WRTP54G-EU-LA-UG-60331NC JL

Wireless-G Broadband Router with 2 Phone Ports

Wireless-G Broadband Router with 2 Phone Ports
Table of Contents
Chapter 1: Introduction 1
Welcome 1
What’s in this Guide? 2
Chapter 2: Planning Your Wireless Network 5
Network Topology 5
Ad-Hoc versus Infrastructure Mode 5
Network Layout 6
Chapter 3: Getting to Know the Router 7
The Back Panel 7
The Front Panel 8
Chapter 4: Connecting the Router 9
Overview 9
Connection Instructions 10
Placement Options 11
Chapter 5: Configuring the Router 13
Overview 13
How to Access the Web-based Utility 16
The Setup Tab - Basic Setup 17
The Setup Tab - DDNS 21
The Setup Tab - MAC Address Clone 23
The Setup Tab - Advanced Routing 24
The Wireless Tab - Basic Wireless Settings 26
The Wireless Tab - Wireless Security 27
The Wireless Tab - Wireless MAC Filter 30
The Wireless Tab - Advanced Wireless Settings 31
The Security Tab - Firewall 33
The Access Restrictions Tab - Filter 34
The Access Restrictions Tab - Device Access Control 36
The Applications & Gaming Tab - Port Range Forwarding 37
The Applications & Gaming Tab - Port Triggering 38
The Applications & Gaming Tab - UPnP Forwarding 39
The Applications & Gaming Tab - DMZ 42
The Applications & Gaming Tab - QoS 43
The Administration Tab - Management 45
The Administration Tab - Log 46
The Administration Tab - Factory Defaults 47
The Administration Tab - Diagnostics 48
The Status Tab - Local Network 49
The Status Tab - Router 50
The Status Tab - Wireless 52
The Voice Tab 53
The Voice Tab - Info 53
The Voice Tab - System 57
The Voice Tab - User 1/2 58
Appendix A: Troubleshooting 63
Common Problems and Solutions 63
Frequently Asked Questions 77

Wireless-G Broadband Router with 2 Phone Ports
Appendix B: Wireless Security 87
Security Precautions 87
Security Threats Facing Wireless Networks88
Appendix C: Finding the MAC Address and IP Address for
Your Ethernet Adapter 91
Windows 98 or Me Instructions 91
Windows 2000 or XP Instructions 92
For the Router’s Web-based Utility 92
Appendix D: Windows Help 93
Appendix E: Glossary 95
Appendix F: Specifications 101
Appendix G: Warranty Information 103
Appendix H: Regulatory Information 105
Appendix I: Contact Information 129

Wireless-G Broadband Router with 2 Phone Ports
List of Figures
Figure 3-1: Back Panel 7
Figure 3-2: Front Panel 8
Figure 4-1: Router Connection Diagram 9
Figure 4-2: Connect the Modem 10
Figure 4-3: Connect a PC 10
Figure 4-4: Connect the Power 10
Figure 4-5: Connect a Telephone 10
Figure 4-6: Measurement between Wall-Mount Slots 11
Figure 5-1: Router’s IP Address 16
Figure 5-2: Router Login 16
Figure 5-3: Setup Tab - Basic Setup (Obtain an
IP automatically) 17
Figure 5-4: Static IP 18
Figure 5-5: PPPoE 19
Figure 5-6: Setup Tab - DDNS (DynDNS.org) 22
Figure 5-7: Setup Tab - DDNS (TZO.com) 22
Figure 5-8: Setup Tab - MAC Address Clone 23
Figure 5-9: Setup Tab - Advanced Routing 24
Figure 5-10: Routing Table Entry List 25
Figure 5-11: Wireless Tab - Basic Wireless Settings 26
Figure 5-12: Wireless Tab - Wireless Security
(WPA-Preshared Key) 27
Figure 5-13: Wireless Tab - Wireless Security (WPA-RADIUS) 28
Figure 5-14: Wireless Tab - Wireless Security (RADIUS) 28
Figure 5-15: Wireless Tab - Wireless Security (WEP) 29
Figure 5-16: Wireless Tab - Wireless MAC Filter 30
Figure 5-17: MAC Address Filter List 30
Figure 5-18: Wireless Client MAC List 30
Figure 5-19: Wireless Tab - Advanced Wireless Settings 31
Figure 5-20: Security Tab - Firewall 33
Figure 5-21: Access Restrictions Tab - Filter 34
Figure 5-22: Filtered MAC Address 34
Figure 5-23: Access Restrictions Tab - Device Access Control 36
Figure 5-24: Applications & Gaming Tab - Port
Range Forwarding 37
Figure 5-25: Applications & Gaming Tab - Port Triggering 38
Figure 5-26: Applications & Gaming Tab - UPnP Forwarding 39
Figure 5-27: Applications & Gaming Tab - DMZ 42
Figure 5-28: Applications & Gaming Tab - QoS 43
Figure 5-29: QoS - Create Rule 44
Figure 5-30: Administration Tab - Management 45
Figure 5-31: Administration Tab - Log 46
Figure 5-32: Administration Tab - Factory Defaults 47
Figure 5-33: Administration Tab -Diagnostics 48
Figure 5-34: Ping Test 48
Figure 5-35: Traceroute Test 48
Figure 5-36: Status Tab - Local Network 49
Figure 5-37: DHCP Active IP Table 49

Wireless-G Broadband Router with 2 Phone Ports
Figure 5-38: Status Tab - Router 50
Figure 5-39: Status Tab - Wireless 52
Figure 5-40: Wireless Client MAC List 52
Figure 5-41: Voice Tab - Info 53
Figure 5-42: Voice Tab - System 57
Figure 5-43: Voice Tab - User 1 58
Figure C-1: IP Configuration Screen 91
Figure C-2: MAC/Adapter Address 91
Figure C-3: MAC/Physical Address 92
Figure C-4: MAC Address Clone 92
Figure C-5: MAC Address Filter 92

Wireless-G Broadband Router with 2 Phone Ports
1
Chapter 1: Introduction
Welcome
Chapter 1: Introduction
Welcome
Thank you for choosing the Linksys Wireless-G Broadband Router with 2 Phone Ports. This Router will allow you
to network wirelessly better than ever, sharing Internet access, files and fun, easily and securely. Plus, after you
have set up your Internet phone service, you can make phone or fax calls using your Internet connection.
How does the Router do all of this? A router is a device that allows access to an Internet connection over a
network. With the Wireless-G Broadband Router with 2 Phone Ports, this access can be shared over the four
switched ports or via the wireless broadcast at either up to 11Mbps for Wireless-B or up to 54Mbps for
Wireless-G. In addition, the WPA standard provides greater security opportunities while the whole network is
protected through NAT technology. All of these security features, as well as full configurability, are accessed
through the easy-to-use browser-based utility.
But what does all of this mean?
Networks are useful tools for sharing Internet access and computer resources. Multiple computers can share
Internet access, so you don’t need more than one high-speed Internet connection. After you have set up your
Internet phone service account, you can also use your Internet access to make Internet phone or fax calls, even
while you’re surfing the Internet. Plus, you can access one printer from different computers and access data
located on another computer’s hard drive. Networks are even used for playing multiplayer video games. All the
while, the Router protects your networks from unauthorized and unwelcome users. So, networks not only are
useful in homes and offices, but also can be fun.
PCs on a wired network create a LAN, or Local Area Network. They are connected with Ethernet cables, which is
why the network is called “wired”.
ethernet: an IEEE standard network
protocol that specifies how data is
placed on and retrieved from a common
transmission medium.
lan (local area network): the computers
and networking products that make up
the network in your home or office.
browser: an application program that
provides a way to look at and interact
with all the information on the World
Wide Web.
mbps: one million bits per second; a unit
of measurement for data transmission.
nat (network address translation): NAT
technology translated IP addresses of a
local area network to a different IP
address for the Internet.
wpa (wi-fi protected access): a wireless
security protocol using TKIP (Temporal
Key Integrity Protocol) encryption, which
can be used in conjunction with a
RADIUS server.

Wireless-G Broadband Router with 2 Phone Ports
2Chapter 1: Introduction
What’s in this Guide?
PCs equipped with wireless cards or adapters can communicate without cumbersome cables. By sharing the
same wireless settings, within their transmission radius, they form a wireless network, which is sometimes
called a Wireless Local Area Network (WLAN). The Router bridges wireless networks of both 802.11b and
802.11g standards and wired networks, allowing them to communicate with each other.
To create your network, install and set up the Router. To guide you through the process, Linksys strongly
recommends that you run the Setup Wizard on the Setup CD-ROM. If you prefer to manually set up the Router,
use the instructions in this Installation and Troubleshooting Guide to help you. These instructions should be all
you need to get the most out of the Wireless-G Broadband Router with 2 Phone Ports.
What’s in this Guide?
This guide covers the basic steps for setting up a network with a router. After going through “Chapter 3: Getting
to Know the Router,” most users will only need to use the following chapters:
• Chapter 4: Connecting the Router
This chapter instructs you on how to connect the Router to your cable or DSL modem, PCs, and telephones
(or fax machines).
• Chapter 5: Configuring the Router
This chapter explains how to configure the Router using your web browser and the Router’s Web-based
Utility. You will configure the Router using the settings provided by your ISP.
When you’re finished with the basic steps, then you are ready to connect to the Internet.

Wireless-G Broadband Router with 2 Phone Ports
3
Chapter 1: Introduction
What’s in this Guide?
You also have other chapters available for reference:
• Chapter 1: Introduction
This chapter describes the Router’s applications and this Installation and Troubleshooting Guide.
• Chapter 2: Planning Your Wireless Network
This chapter describes the basics of wireless networking.
• Appendix A: Troubleshooting
This appendix describes some possible problems and solutions, as well as frequently asked questions,
regarding installation and use of the Router.
• Appendix B: Wireless Security
This appendix explains the risks of wireless networking and some solutions to reduce the risks.
• Appendix C: Finding the MAC Address and IP Address for Your Ethernet Adapter
This appendix instructs you on how to find the MAC address or Ethernet address of your PC’s Ethernet
network adapter.
• Appendix D: Windows Help
This appendix describes how you can use Windows Help for instructions about networking, such as
installing the TCP/IP protocol.
• Appendix E: Glossary
This appendix gives a brief glossary of terms frequently used in networking.
• Appendix F: Specifications
This appendix provides the technical specifications for the Router.
• Appendix G: Warranty Information
This appendix supplies the warranty information for the Router.

Wireless-G Broadband Router with 2 Phone Ports
4Chapter 1: Introduction
What’s in this Guide?
• Appendix H: Regulatory Information
This appendix supplies the regulatory information regarding the Router.
• Appendix I: Contact Information
This appendix provides contact information for a variety of Linksys resources, including Technical Support.

Wireless-G Broadband Router with 2 Phone Ports
5
Chapter 2: Planning Your Wireless Network
Network Topology
Chapter 2: Planning Your Wireless Network
Network Topology
A wireless local area network (WLAN) is exactly like a regular local area network (LAN), except that each
computer in the WLAN uses a wireless device to connect to the network. Computers in a WLAN share the same
frequency channel and SSID, which is an identification name shared by the wireless devices belonging to the
same wireless network.
Ad-Hoc versus Infrastructure Mode
Unlike wired networks, wireless networks have two different modes in which they may be set up: infrastructure
and ad-hoc. An infrastructure configuration is a WLAN and wired LAN communicating to each other through an
access point. An ad-hoc configuration is wireless-equipped computers communicating directly with each other.
Choosing between these two modes depends on whether or not the wireless network needs to share data or
peripherals with a wired network or not.
If the computers on the wireless network need to be accessible by a wired network or need to share a
peripheral, such as a printer, with the wired network computers, the wireless network should be set up in
Infrastructure mode. The basis of Infrastructure mode centers around an access point or wireless router, such as
the Wireless-G Broadband Router with 2 Phone Ports, which serves as the main point of communications in a
wireless network. The Router transmits data to PCs equipped with wireless network adapters, which can roam
within a certain radial range of the Router. You can arrange the Router and multiple access points to work in
succession to extend the roaming range, and you can set up your wireless network to communicate with your
Ethernet hardware as well.
infrastructure: a wireless network
that is bridged to a wired network via
an access point.
ssid: your wireless network’s name.
ad-hoc: a group of wireless devices
communicating directly to each other
(peer-to-peer) without the use of an
access point.
network: a series of computers or
devices connected for the purpose of
data sharing, storage, and/or
transmission between users.
ethernet: IEEE standard network
protocol that specifies how data is
placed on and retrieved from a common
transmission medium.

Wireless-G Broadband Router with 2 Phone Ports
6Chapter 2: Planning Your Wireless Network
Network Layout
If the wireless network is relatively small and needs to share resources only with the other computers on the
wireless network, then the Ad-Hoc mode can be used. Ad-Hoc mode allows computers equipped with wireless
transmitters and receivers to communicate directly with each other, eliminating the need for a wireless router or
access point. The drawback of this mode is that in Ad-Hoc mode, wireless-equipped computers are not able to
communicate with computers on a wired network. And, of course, communication between the wireless-
equipped computers is limited by the distance and interference directly between them.
Network Layout
The Wireless-G Broadband Router with 2 Phone Ports has been specifically designed for use with both your
802.11b and 802.11g products. It is compatible with all 802.11b and 802.11g adapters, such as the Notebook
Adapters for your laptop computers, PCI Adapters for your desktop PCs, and USB Adapters when you want to
enjoy USB connectivity. The Broadband Router will also communicate with the Wireless PrintServer and Wireless
Ethernet Bridges.
When you wish to connect your wireless network with your wired network, you can use the Broadband Router’s
four Ethernet network ports. To add more ports, any of the Broadband Router's Ethernet network ports can be
connected to any of Linksys's switches.
With these, and many other, Linksys products, your networking options are limitless. Go to the Linksys website at
www.linksys.com/international for more information about products that work with the Wireless-G Broadband
Router with 2 Phone Ports.
access point: a device that allows
wireless-equipped computers and other
devices to communicate with a wired
network. Also used to expand the range
of a wireless network.

Wireless-G Broadband Router with 2 Phone Ports
7
Chapter 3: Getting to Know the Router
The Back Panel
Chapter 3: Getting to Know the Router
The Back Panel
The Router’s ports and the Reset button are located on the back panel of the Router.
Internet This Internet port connects to your cable or DSL modem.
Phone1 For your primary Internet phone line, the Phone1 port allows you to connect the Router to
your phone (or fax machine) using an RJ-11 phone cable (not included).
Phone2 If you have a second Internet phone line, the Phone2 port allows you to connect the
Router to your second phone (or fax machine) using an RJ-11 phone cable (not included).
Ethernet 1-4 These four Ethernet ports connect to network devices, such as PCs or more switches.
Reset Button There are two ways to reset the Router to its router factory defaults. Either press the Reset
Button for five seconds, or restore the defaults from the Router's Web-based Utility.
Power The Power port is where you will connect the power adapter.
Figure 3-1: Back Panel
NOTE: If you want to reset
the Router to its voice factory
default settings, then you will
need to use the Router’s Web-
based Utility and obtain a user
name and password available
only from your Internet phone
service provider. Contact your
provider for more information.
NOTE: The Internet port
only accepts a straight-
through cable. Do NOT
connect a crossover cable to
the Internet port.

Wireless-G Broadband Router with 2 Phone Ports
8Chapter 3: Getting to Know the Router
The Front Panel
The Front Panel
The Router’s LEDs, which inform you about network activities, are located on the front panel.
POWER Blue/Red. The POWER LED lights up blue when the Router is powered on. If the blue LED is
flashing, the Router is booting up or upgrading its firmware. If the LED lights up red, then
disconnect the power, and wait five seconds. Then reconnect the power.
ETHERNET 1-4 Blue. The ETHERNET LED lights up when there is an active connection through the
corresponding port. If the LED is flashing, then there is traffic moving through that port.
WIRELESS Blue. The WIRELESS LED lights up when there is an active wireless connection. If the LED is
flashing, the Router is sending or receiving data over the wireless network.
PHONE 1-2 Blue. The PHONE LED is solidly lit when a telephone or fax machine has an active or
registered connection to your Internet phone service provider through the corresponding
port (PHONE 1 or 2). It flashes when the phone is being used or is off the hook.
INTERNET Blue. The INTERNET LED lights up when the Router is connected to your cable or DSL
modem. If the LED is flashing, the Router is sending or receiving data over the Internet port.
Proceed to “Chapter 4: Connecting the Router.”
Figure 3-2: Front Panel

Wireless-G Broadband Router with 2 Phone Ports
9
Chapter 4: Connecting the Router
Overview
Chapter 4: Connecting the Router
Overview
To begin installation of the Router, you will connect the Router to your PCs, telephone(s) or fax machine(s), and
cable or DSL modem. The following connection diagram illustrates a basic network setup with wired
connections to one desktop PC and telephone and a wireless connection to one notebook PC.
Figure 4-1: Router Connection Diagram
Telephone
Router
Cable/DSL
Modem
Internet
Desktop PC
Notebook PC
NOTE: If you already have a
router in your network, then
replace your existing router with
the Wireless-G Broadband Router
with 2 Phone Ports.

Wireless-G Broadband Router with 2 Phone Ports
10 Chapter 4: Connecting the Router
Connection Instructions
Connection Instructions
1. Make sure that all of your hardware is powered off, including the Router, PCs, and broadband modem.
2. Attach the antenna to the Router’s antenna port.
3. Connect your broadband modem’s Ethernet cable to the Router’s Internet port.
4. Connect one end of an Ethernet network cable to one of the numbered ports on the back of the Router.
Connect the other end to an Ethernet port on a network device, e.g., a PC, print server, or switch.
Repeat this step to connect more PCs or other network devices to the Router.
5. Power on the broadband modem.
6. Connect the included power adapter to the Router’s Power port, and then plug the power adapter into an
electrical outlet. The Power LED on the front panel will light up when the adapter is connected properly.
7. Power on your PC(s).
8. Plug a standard telephone into the Router’s Phone1 port.
9. If you have a second Internet phone or fax line, repeat step 8 to connect a telephone or fax machine to the
Router’s Phone2 port.
Proceed to the following section, “Placement Options.”
Figure 4-3: Connect a PC
Figure 4-4: Connect the Power
Figure 4-2: Connect the Modem
Figure 4-5: Connect a Telephone
IMPORTANT: Do not connect the Phone port to a telephone wall jack. Make sure you only connect
a telephone or fax machine to the Phone port. Otherwise, the Router or the telephone wiring in your
home or office may be damaged.
NOTE: Make sure your
telephone is set to its tone
setting (not pulse).

Wireless-G Broadband Router with 2 Phone Ports
11
Chapter 4: Connecting the Router
Placement Options
Placement Options
There are two ways to place the Router. The first way is to place it horizontally on a surface, so it sits on its four
rubber feet. The second way is to mount it on a wall. This option uses the Router’s four wall-mount slots on its
bottom panel. The distance between two adjacent slots is 62 mm (2.44 inches).
To use the wall-mount option, follow these instructions:
1. Make sure you have four screws that are size #4—this indicates a diameter measurement of 2.845 mm
(0.112 inches).
2. Determine where you want to mount the Router.
3. Drill four holes into the wall. Make sure adjacent holes are 62 mm (2.44 inches) apart.
4. Insert a screw into each hole, and leave 5 mm (0.2 inches) of its head exposed.
5. Maneuver the Router so the wall-mount slots line up with the four screws.
6. Place the wall-mount slots over the screws and slide the Router down until the screws fit snugly into the
wall-mount slots.
Proceed to “Chapter 5: Configuring the Router.”
62 mm
(2.44 inches)
Figure 4-6: Measurement between
Wall-Mount Slots

Wireless-G Broadband Router with 2 Phone Ports
12 Chapter 4: Connecting the Router
Placement Options
