Linsar LS50UHDSM20 User manual

50"
ULTRA HD
SMART TV
User Manual
MODEL: LS50UHDSM20

2
Welcome
Welcome to Linsar!
This user manual tells you all you need to know about setting up your newTV.
Please take special note of any important safety and usage information presented with the symbol.
All products brought to you by Linsar are manufactured to the highest standards of performance and safety
and, as part of our philosophy of customer service and satisfaction, are backed by a comprehensive
1Year Warranty.

3
Networking 17
Connecting to a Wireless Network 17
Connecting to a Wired Network 18
TV Setting Menus 19
Picture 21
Audio 23
Channel 24
General 26
PVR Option 28
Time 30
Lock 31
Network 32
App Settings 33
High Dynamic Range (HDR) 34
Smart TV 35
Smart TV Applications 35
App Portals 36
Contents
Welcome 2
Unpack and Prepare 4
What's in the box 4
Important Tips 5
Attaching the stand 6
Wall-mounting the TV 7
Connect to power 8
Connect your antenna 8
Controls and Connections 9
Get to know your TV 9
Buttons on the TV 9
Ports on the TV 10
Remote Control 12
Setup 12
Using the Remote Control 13
Buttons & Functions 14
On-Screen Set Up 16
TV Guide 37
Recording 38
Recording Live TV 39
Scheduled Recording 39
Playback 39
Pause Live TV (Time-shift) 40
USB Mode 41
Set up 41
Troubleshooting 44
Specications 47
Compliance and
Responsible Disposal 48

4 | UNPACK AND PREPARE
Unpack and Prepare
What's in the box
In the box you will find:
A. 50" Ultra HD SmartTV
B. Remote Control
C. AAA Batteries
D. AV Cable
E. TV Stands
F. Screws forTV Stands
G. Warning Sheet
H. TVToppling Safety Message
I. Quick Start Guide
J. Warranty Certificate
K. General Safety Warnings
L. User Manual
You will need:
• Phillips-head screwdriver (for stand installation)
• Someone to help you lift and install yourTV
• Antenna cable (to watch liveTV)
• Broadband internet connection (to use smart apps)
See the flap of the box
for how to handle theTV
without damaging it!
G
HIJKL
E
F
Before installing your newTV, check you have everything needed.

UNPACK AND PREPARE | 5
Important Tips
• Place theTV on a level surface.
• Place theTV away from any source that may generate heat or vibrations.
• Make sure there is enough space around vents for airflow.
• The remote control works up to 5 metres away from theTV.
• Unplug theTV before cleaning it.
• Clean using a dry cloth only - do not use water or chemicals.
• Use only the power supply provided.
• It is highly recommended to use safety straps for securing theTV in place.
• Keep liquid, children and pets away from theTV at all times.

6 | UNPACK AND PREPARE
1
2
3
Unless you are wall-mounting theTV, you will need to
attach its stand/legs.
1. Lay theTV face-down on a soft, flat surface (like
the sofa, or a towel on a table) larger than theTV
itself.
2. Match stands to the installation points on the
underside of theTV.
3. Attach the stands to the TV at the installation
points using the screws provided. (Grab a
screwdriver for this bit). Make sure the legs
are facing away from each other (not leaning
inwards).
Attaching the stand
• ThisTV is heavy! We recommend asking
someone to help you lift it.
• Unplug theTV from the power outlet before
installing or removing the stand.
• Only touch the frame, not the screen.
• It is highly recommended to use safety straps
for securing theTV.
CAUTION!
Do not apply
excessive force as
you might damage
the screw holes.
33

UNPACK AND PREPARE | 7
200mm
Back of theTV
200mm
Wall-mounting the TV
TheTV comes with holes on the back panel for use
with wall-mounting brackets (bracket not included).
Use four standard M6*12mm screws (or longer,
depending on the mounting bracket) to wall-mount
thisTV (screws are not included).
• Unplug theTV from the power outlet
before wall-mounting.
• Contact a professional for assistance with
wall-mounting theTV.
Required
• VESA Mounting
Bracket
• 4 x M6*12mm
screws (or longer
as required)
The screws in the package are for securing the TV
stand only. If you are wall-mounting theTV, consult a
qualified installer for advice on bracket support and
wall support.

8 | UNPACK AND PREPARE
Free-to-airTVinHD(HighDenition)
High Definition (HD) channels provide
the best viewing quality and are
available with a digital antenna
connection.
TV channels in Ultra HD resolution are
not currently available in Australia.
Therefore when you watch HD
broadcast signals on an Ultra HDTV,
the picture can appear 'soft' and lacks
the detail you see when watching the
same content on a HDTV.
Connect to power
Make sure theTV is switched off at the power outlet
until you have finished connecting your cables.
Connect your antenna
Antenna cable not included.
ABC HD
SBS ONE HD
7HD
9HD
10 HD
PRIME7 HD
WIN HD
Example
HD Channels
Don't forget to plug in theTV to
the power outlet. Leave the power
switched off until installation is
finished.

CONTROLS AND CONNECTIONS | 9
MEDIA
SOURCE MENU
VOL + VOL -
CH + CH -
See next page for more info on the connections.
Controls and Connections
Buttons on the TV
Get to know your TV
Back of theTV
1. : Switch theTV on or to standby.
2. VOL + / VOL - : Increase/decrease the volume level.
3. CH + / CH - : Select the next/previous channel.
4. SOURCE : Change the input source.
5. MENU : Enter the settings menu.
1
2
3
4
6
5
On/Standby light and
Remote sensor

10 | CONTROLS AND CONNECTIONS
Ports on the TV
2 3 4 5
1
1
Headphone
Jack
SOUND
Connect to your headphones, amplifier or audio device, using
an AUX cable (not included).
2AV IN
CVBS/Y
You can use this to connect your DVD player. Supports Standard
Definition (SD) resolution. Requires an AV cable (included).
3
COMPONENT
IN
You can use this to connect your DVD player. Supports Full High
Definition (FHD) resolution.This also requires a component
cable (not included).
4AUDIO IN
SOUND
You can use this to connect audio to yourTV for AV or
component video inputs. Requires an RCA stereo audio cable
(not included). However you can also use the supplied AV cable.
5USB
STORAGE
• PVR record and pause liveTV
• Play your stored media files (supported file codecs and
extensions may vary)
• Software updates
AUDIO INAV/COMPONENT IN (5V 500mA)

CONTROLS AND CONNECTIONS | 11
86 7 9
6LAN
INTERNET
Connect to your broadband modem using a network cable
(not included) for the best streaming experience. However, the
TV also has built-in Wi-Fi.
7
DIGITAL
AUDIO OUT
(OPTICAL)
SOUND
Connect an external digital audio device. Use an Optical cable
(not included) to connect the unit with an amplifier, soundbar or
other audio decoding device for digital audio signal output.
8
HDMI IN
Use a high-speed
HDMI cable for
best picture and
sound quality.
SOUND SOUND
COMPUTER
All-digital connection between theTV and any HDMI device.
Supports Ultra HD resolution. Requires a high-speed HDMI
cable (not included).
9 ANTENNA IN
FREE-TO-AIR
TV
Connect your antenna cable for liveTV. (Antenna cable not
included.)
DIGITAL
AUDIO OUT
(OPTICAL)
ANTENNA
IN
HDMI IN 2 HDMI IN
(ARC)

12 | REMOTE CONTROL
Setup
Insert two AAA size batteries according to the polarity
markings (+/-) inside the compartment. Make sure the
batteries are correctly aligned and properly pushed
into place.
Precautions When Using Batteries
• Do not use old and new batteries together.
• Do not use different types of batteries (e.g.
Manganese and Alkaline batteries) together.
• Remove the batteries from the remote if you do
not intend to use it for a long time.
• When discarding used batteries, follow any
guidelines for recycling and disposal of batteries
that apply in your local area.
• Keep batteries away from children and pets.
• Never throw batteries into a fire or expose them
to extreme heat.
Remote Control
1
2
3

REMOTE CONTROL | 13
Using the Remote Control
To use the remote, point it towards the remote sensor
at the front of theTV.The remote will not operate if its
path is blocked.
The remote has a range of up to about 5 metres from
theTV at an angle of up to 30 degrees to either side of
the sensor, as illustrated below.
Image is an
example only.
Remote sensor
location onTV
may vary.
5m
Remote Hints and Tips
• Do not drop, step on or otherwise
impact the remote control.This
may damage the parts or lead to
malfunction.
• Do not place objects between the
remote control and the remote
sensor.
• Do not use this remote control
while simultaneously operating a
remote control for other devices.

14 | REMOTE CONTROL
Buttons & Functions
(ON): Switch theTV to On or
Standby
NUMBER BUTTONS: Key in aTV
channel number
CH.LIST: Display or exit the channel
list
MENU: Access streaming apps,TV
settings
/ / / : Press the UP/DOWN/
LEFT/RIGHT buttons to navigate
RETURN: Return to the previous
screen/menu
(MUTE): Mute or restore
sound
: Return to the previous
viewing channel
APPS: Direct access toYouTube,
Toon Goggles, Foxxum and
Netflix app
SOURCE: Switch the input source
OK: Confirm your selection
EXIT: Exit/Quit the current screen

REMOTE CONTROL | 15
INFO: Display program information
VOL :Turn the volume up or down
GUIDE: Launch theTV Guide (DTV)
: Skip backwards
/ TIMESHIFT: Play/Pause liveTV and
video playback
: Rewind
/ / / RED/GREEN/
YELLOW/BLUE: Functions are according
to the on-screen display
/RECORD: Record aTV program
INDEX: Display the list of recorded
programs
P.MODE: Cycle through the different
preset picture modes
CH : Go to the next or
previous channel
: Skip forwards
: Fast forward
/ FAV: Stop/Display your favourite
channel list
PIC SIZE: Press to select desired
screen size
S.MODE: Cycle through the
different preset sound modes
SUBTITLE: Enable/disable subtitles

16 | ON-SCREEN SET UP
On-Screen Set Up
Make sure equipment is properly connected (as shown on
pages 10-11) before connecting theTV to power.
On/Standby light is
RED in standby mode.
First Time Setup menu
When you turn theTV on for the first time, the First
Time Setup menu will appear.
Follow the prompts using the / / / / OK
buttons to select your preferences.You will be guided
through:
2. Country 3. Environment
4. Data Collection And Firmware Update Notice
5. Connect To The Internet
6. Set Up Netflix
7. Select Input Source
8. Tune TV Channels
Note: If you choose to setup Netflix or select an input source other than
DTV, the set up wizard will exit and will not let you tuneTV channels.
To tune channels, go to Menu >TV Settings > Channel > Auto Scan.
If you make an error, you can update your
preferences in the settings menu later.
If you are using a wired network, connect an ethernet cable to
theTV and select 'wired'.TheTV will automatically connect to
the Internet.
If you are using a wireless connection, select 'Wireless'.TheTV
will scan for nearby wireless networks. Make sure that theTV is
within the range of your wireless modem/router, and you have
your Wi-Fi password handy.
Or, you can connect to the internet later by going to the User
Menu settings.
5. Connect To The Internet
Make sure theTV is plugged
in at the power socket and
switched on. Press the (ON)
button to turn on theTV.
On/Standby light is
OFF when theTV is on.

NETWORKING | 17
Networking
You can set up yourTV so that it can access the Internet
through your home network using a wired or wireless
connection.
Connecting to a Wireless Network
• Press the MENU button on the remote to selectTV
Settings > Network.
• Change network type to 'Wireless' and press OK.
TheTV will automatically search nearby Wi-Fi access
points. When done, it will display a list of available
networks.
• In the list of networks, press the / button to select
your home network, then press the OK button.
• When the Wi-Fi password entry screen appears, use
the on-screen keyboard. Use the / / / buttons
on the remote control to select a character and press
OK to enter it.
• Input the correct password, select ‘Connect’ and press
the OK button to connect to the network. If connection
is successful, a tick will appear next to your Wi-Fi
networks's name.
If theTV isn't connecting
to the internet check the
troubleshooting section for
more info!

18 | NETWORKING
Connecting to a Wired Network
• Connect an ethernet cable to the LAN port on the
back of theTV.
• Press the MENU button on your remote to select
TV Settings > Network.
• Change the NetworkType setting to 'Wired'.The
TV will automatically pick up the network setting
from the modem and connect to the network. If
connection is successful, you will see 'Connected'
on-screen.
• Press the EXIT button to close the menu.
Make sure you have an ethernet
cable on hand if you want to
connect to a wired network

TV SETTING MENUS | 19
Menus Index
Picture 21
• Picture Mode
• User Mode Settings:
• Contrast, Brightness,
Colour, Sharpness, Tint
• ColourTemp
• Advanced Options:
• Backlight, Noise Reduction
• Open HDR
Audio 23
• Sound Mode
• Bass/Treble
• Balance
• Auto Volume
• Digital Audio Output
• Surround Sound
• AD Switch
TV Setting Menus
Menu Navigation Buttons
Press the MENU button and selectTV Settings. See
the guide below for all the other buttons you'll need
to use to adjust and change your settings.
Function Remote Button
Display the main menu
Enter a sub menu
Select an option /
Adjust a value /
Return to the previous menu
MENU
OR
RETURN
Exit a menu
EXIT
MENU
MENU
Once you have
programmed any settings,
the unit will retain them
in its memory until you
change them, even after
turning theTV off.

20 | TV SETTING MENUS
Channel 24
• Auto Scan
• DTV ManualTuning
• Program Edit
• Channel List
• Favourite List
• Signal Information
• OAD
General 26
• OSD Language
• Subtitle Language
• Audio Language
• Hearing Impaired
• Transparency
• Zoom Mode
• VGA Settings
• Other Settings:
• HDMI EDID, INLINK, DLC
• PVR Option
• Restore Default
• Software Update (USB)
• View End User License
Agreement
• HbbTV
• Software Update (Network)
• Software Information
PVR Option 28
• Recorded List
• Record
• Remind
• Schedule List
• PVR File System
Time 30
• SleepTimer
• Auto Standby
• OSD ActiveTime
• Time Zone
• DST (Daylight SavingTime)
Lock 31
• Change Password
• System Lock
• Channel Lock
• Parental Guidance
• Clear Lock
Network 32
• NetworkType:
• Wired: (Auto Connect,
Manual Connect, Disable
Connect)
• Wireless: (Connect,
Manual Setup)
• My Network
• IP Address
App Settings 33
• Deactivate Netflix
• Terminate Netflix
• Netflix Version
!
