HumDTTM Series Master Development System
Quick Start Reference
Remove Contents
Remove kit contents including development boards,
antennas, batteries, modules and USB cables.
1Set Up the Programming Docks
With the power off, set up boards by inserting EVMs into
sockets on the Programming Docks and attaching the
antennas.
2
Revised 6/25/14
Install the Windows software from the
CD that is included with the kit. If already
installed, skip this step.
Install the Software
3
Connect the Programming Docks to a
computer with the cables included with
the kit. USB drivers are on the CD so
install them if prompted by the computer.
Connect the Programming Docks
4
Start the software. It automatically
detects conected modules and reads
their configurations.
Start the Software
5

MODE_IND
RESET
CMD_DATA_IN
POWER_DOWN
VCCD
CTS
VCCD
CMD_DATA_OUT
VCC
VCCD
GPIO_7
ACTIVE
LNA_EN
PA_EN
GPIO_0
VCCD
VCCD
GPIO_6
GPIO_5
GPIO_4
GPIO_3
GPIO_2
GPIO_1
Warning: Installing or removing a Carrier Board
while power is applied could cause permanent dam-
age to the module. Either turn off power to the board
or unplug the USB cable before installing or removing a
Carrier Board
!
