Lippert Components Thomas Payne Jackknife User manual

THOMASPAYNEFURNITURE.COM
Tilt front of sofa up to
access the front frame bar
onto which the kick panel
will be positioned (fig.E).
E
Hook kick panel over the front frame bar
and center (fig. F). Drop the front of the
sofa back down and position your new sofa.
F
Assembly
instructions for:
Jackknife Sofas
Your Thomas Payne
Jackknife sofa ships
partially assembled.

A
B
Start assembly by turning the sofa
over with the bottom and back lying
flat facing up (fig. A).
Take the two leg brackets which can
be rotated or used on either side of the
sofa and align with the corresponding
holes in the frame (fig. B).
Turn sofa upright to attach the front
kick panel (fig. D).
C
D
Insert the 3/4'' length bolt through the
bottom of the frame and attach the
washer and nylock nut from the top.
Using either a 1/2'' socket, open-end,
box or adjustable wrench from both
above and below, tighten snuggly using
caution not to overtighten (fig. C).
Each kit includes the following hardware:
(4) 5/16''-18 x 3/4'' Bolt
(3/4'' long, 5/16'' diameter, 18 threads per inch)
(4) 5/16'' flat washer
(4) 5/16''-18 nylock nut
For assembly, you will need any two of the following:
•ratchet with a 1/2'' socket
•1/2'' open-end or box wrench
•adjustable wrench
