Amart Furniture CASSIUS 70811 User manual

Imported by Amart Furniture Pty Ltd, Qld, Brisbane Australia.
For any assistance with assembly or for missing parts please phone
Amart Furniture, Customer Service Free call 1800 351 084
ASSEMBLYINSTRUCTION
CASSIUS2SEATER
ITEMCODE70811
ImportedbyAmartFurniturePtyLtd,Qld,BrisbaneAustralia.
Foranyassistancewithassemblyorformissingpartspleasephone
Amart Furniture,CustomerServiceFreecall1800351084
170811
85cm
246cm
Depth:107cm

PRE‐ASSEMBLYPREPARATION
Before you start:
1. Choose a clean, level, spacious assembly area. Avoid hard surfaces that may
damage the product
2. Take care when lifting. Product should be assembled as near as possible to
the point of use
3. Ensure that you have all required contents for complete assembly
4. Always read the assembly instructions carefully before beginning assembly.
5. Keep all hardware parts and packaging out of reach of small children.
6. Do not over tighten the screws and bolts as this may damage the threads
20
270811
2
WARNING
•DoNotallowchildrentoplayonthismechanisedfurnitureor
operatethemechanism.Legrestfoldsdownonclosingsothat
achildcouldpossiblybeinjured.Alwaysleaveinanuprightand
closedposition.Keephandsandfeetclearofmechanism.Only
theoccupantshouldoperateit.

Step1: Locatepackageofreclinerpowercordandarmtablekitwhich
arefixedonthemechanismatthebottomoflefthandfacingrecliner.
Step2: Installthearmtablelidonthetablebracketwithfourboltsby
Allenkey.
370811
BoltM6X16
4pcs
Allen key
1pcs
ArmTableLid ArmTableBracket
1pcs 1pcs
ReclinerPowerCord
1pcs
With2people
carefullyturn
ontobackon
pieceofcardboard
orcarpettoprotect
covering
clockwiseturning
theAllenkeyfor
tightenofthebolts
Armtablekit Reclinerpowercord

Step3: Attachthetablebrackettothebaseinsideleftorrightarm
pocketaccordingtodemand.
Step4: Plugreclinerpowercordintothesocketatthebackpanelofleft
handfacingrecliner.
470811
SAFETYNOTE:
PLEASEENSURETHATALLELECTRICALCORDSANDCABLESARECLEAR
OFTHEFRAMEANDMECHANISM. AFAILURETODOSOMAYSEVER
YOURPOWERCORDRESULTINGINSERIOUSINJURYORDEATH.
Baseinside
armpocket

Step5: Locatepackagesofsoundpowercordandreadinglightthatare
placedintozipperpocketatthebottomconsole.
Step6: Attachthereadinglighttothebaseinsidebackcover,then
connectthecordofreadinglightwithcordinsidebackcover.
570811
With2people
carefullyturn
ontobackon
pieceofcardboard
orcarpettoprotect
covering
SoundPowerCord
1pcs
ReadingLight
1pcs
Readinglight
Baseinside
backcover
Cordofreadinglight
Cordinsidebackcover
ButtonSwitch
atthefrontof
lightbar

Step7:Plugsoundpowercordintothesocketatthebackpanelof
console.
Step8:Locatepackageofreclinerpowercordwhichisfixedonthe
mechanismatthebottomofrighthandfacingrecliner.
670811
SAFETYNOTE:
PLEASEENSURETHATALLELECTRICALCORDSANDCABLESARECLEAR
OFTHEFRAMEANDMECHANISM. AFAILURETODOSOMAYSEVER
YOURPOWERCORDRESULTINGINSERIOUSINJURYORDEATH.
With2people
carefullyturn
ontobackon
pieceofcardboard
orcarpettoprotect
covering
ReclinerPowerCord
1pcs
Reclinerpowercord

Step9:Plugreclinerpowercordintothesocketatthebackpanelof
righthandfacingrecliner.
Step10:Connect3piecesfromrighttoleft.BeginwithRHFelectric
recliner,thenconsoletillfinalitemofLHFelectricrecliner.
770811
SAFETYNOTE:
PLEASEENSURETHATALLELECTRICALCORDSANDCABLESARECLEAR
OFTHEFRAMEANDMECHANISM. AFAILURETODOSOMAYSEVER
YOURPOWERCORDRESULTINGINSERIOUSINJURYORDEATH.
slideclipsatconnectingitemintoclipsat
connecteditem,thentogetherpressfrontand
rearsideofconnectingitemtoensurethe
clipsgointoeachothertothebottom.
Right
1stPCS
Left
3rdPCS

Step11:Connectthecordsoflightstripbetweeneverypiece.
870811
SAFETYNOTE:
PLEASEENSURETHATALLELECTRICALCORDSANDCABLESARECLEAR
OFTHEFRAMEANDMECHANISM. AFAILURETODOSOMAYSEVER
YOURPOWERCORDRESULTINGINSERIOUSINJURYORDEATH.

YES NO
970811
