Performance PL 156GG-A1 User manual

Please follow these instructions for easy assembly.
Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from
Remove all wrapping materials, including staples & packing straps before you start to assemble.
Do not tighten any screws or bolts until the unit is completely assembled.
Thank you for purchasing the Performance 5 Adjustable Shelf Bookcase.
KLIX CAM INSTRUCTIONS
being scratched.
Keep all hardware parts out of reach of children.
Check that you have all parts and hardware.
IMPORTANT !!
Left Gable
Klix Cam
14 Pcs
Back Panel
Cam Lock
14 Pcs
Right Gable Kick Plate
A B C
Housing
Cap
14 Pcs
D
Adjustable
Glide
4 Pcs
1 2 3 4
Fixed Shelf
Top Panel
Bottom Panel Adj. Shelf x 4
6 Hole
L-Bracket
1 Pc
Shelf Support
Pin
16 Pcs
E F
Center Shelf
Pin
4 Sets
GH
5 SHELF BOOKCASE
5 6 7
8
PL 156GG-A1
M4 x 65
Allen-Key
1 Pc
9
Screw
#6 x 58"
6 Pcs
Insert the cam with the arrow
pointing towards the hole in
the edge.
Line up Cam Lock,
turn clockwise.
1 2
Insert the Cam Lock into
Klix Cam. Turn Klix Cam to
lock.
3
Page 1 of 2

87
B
Screw Adjustable Glide(4)
into bottom of Left Gable(B)
and Right Gable(C).
6
4
Attach Right Gable(C) to
Back Panel(A), Top Panel(E),
Bottom Panel(F) and Kick
Plate(D).
D
F
Insert Shelf Support Pins(6)
into the pre drilled holes and
place Adjustable Shelves(H)
at convenient distances.
Attach Housing Cap(3) to all
Klix Cams(2) by pushing neck
thought center of cam.
78
H
6
3
Lie Bookcase on its Back.
Attach L-Bracket(7) to
Bottom Panel(F) and Kick
Plate(D) as shown. Tighten
Screws(8) securely.
Place Fixed Shelf(G) in
center of bookcase. Fastens
with Center Shelf Locking
Pins (5).
D
F
Attach Back Panel(A) to Left
Gable(B).
4
AC
E
B
A
1
E
Attach Top Panel(E) to Left
Gable(B) and Back Panel(A).
Attach Kick Plate(D) and
Bottom Panel(F) to Left
Gable(B).
F
5
G
A
B
D
F
B
A
5 SHELF BOOKCASE
2 3 E
PL 156GG-A1
Page 2 of 2
