Introduction
The Variable Height Table Pedestal (Fig. 1) has two telescoping cylinders, powered by gas struts, that allow
the pedestal height to be adjusted from 13" to 28". The top cylinder extends a maximum of 8 ½" and the
bottom cylinder extends a maximum of 9".
For information on the assembly or individual components of this product, please visit:
https://support.lci1.com/lci-interiors.
Fig. 1
9"
8 ½"
Top Cylinder
Bottom Cylinder
Pedestal Base
Table Top
(OEM Supplied)
FURNITURE
VARIABLE HEIGHT TABLE PEDESTAL

Rev: 11.08.19 Page 5 CCD-0001573-07
Failure to follow instructions provided in this manual may result in death, serious personal injury
and/or severe product and property damage, including voiding of the component warranty.
The "CAUTION" symbol above is a sign that a procedure has a safety risk involved that may cause
personal injury and/or product damage, including voiding of warranty, if not performed safely and
in accordance with the safety procedures stated herein.
Moving parts can pinch, crush or cut. Keep clear and use caution.
The "WARNING" symbol above is a sign that a procedure has a safety risk involved and may cause death
or serious personal injury if not performed safely and within the parameters set forth in this manual.
Safety
Read and fully understand all instructions before installing and operating this product. Adhere to all safety labels.
This manual provides general instructions. Many variables can change the circumstances of the instructions,
i.e., the degree of difficulty, operation and ability of the individual performing the instructions. This
manual cannot begin to plot out instructions for every possibility, but provides the general instructions,
as necessary, for effectively interfacing with the device, product or system. Failure to correctly follow the
provided instructions may result in death, serious personal injury, severe product and/or property damage,
including voiding of the LCI limited warranty.
Minimum Pedestal Heights
• Both cylinders compressed (Fig. 2).
• Bottom cylinder extended, and the upper cylinder compressed (Fig. 3).
• Top cylinder extended, lower cylinder compressed (Fig. 4).
13"
19 ¾"22 ¼"
Fig. 2 Fig. 3 Fig. 4

Rev: 11.08.19 Page 6 CCD-0001573-07
Keep people and pets clear of the table top when raising the Variable Height Table Pedestal.
The cylinder extends quickly when the locking collar handle is released.
Operation
Extending
A
A
Handle in
closed position
Handle in
open position
B
B
1. Pull the handle (Fig. 5A) on one of the locking collars away from the table pedestal. This will disengage
the clamp that holds the cylinder in place (Fig. 5B). The strut will then extend the cylinder to its full
height or, if less than the full cylinder height is needed, have a second person push down on the center
of the table until the cylinder is at the desired height.
2. Push the handle back towards the cylinder to lock the cylinder into the desired height.
3. Repeat steps 1 and 2 for the other cylinder, if necessary.
Retracting
NOTE: The assistance of a second person is recommended for retracting.
1. Pull the handle (Fig. 5A) on the cylinder that is being retracted.
Make sure to push down on the CENTER of the table top. Pushing down on the edge could pull the
table top away from the pedestal or crack the table top.
2. Have the second person push down on the center of the table until the cylinder is retracted at the
desired height.
3. Push the handle back towards the cylinder to lock the cylinder into the desired height.
4. Repeat steps 1 through 3 for the other cylinder, if necessary.
Make sure to push down on the CENTER of the table top. Pushing down on the edge could pull the
table top away from the pedestal or crack the table top.
Fig. 5

Rev: 11.08.19 Page 7 CCD-0001573-07
Maintenance
The Variable Height Table Pedestal requires very little maintenance. The gas struts are sealed in the
cylinders. The only required maintenance involves keeping the columns clean and free of debris.
Adjustment
If a cylinder creeps up after it has been retracted and locked, the collar can be tightened by hand-turning
the thumbscrew (Fig. 6A) on the locking collar (Fig. 6B).
1. Pull the handle (Fig. 6C) on the locking collar open.
2. Hand-tighten the thumbscrew to pull the edges (Fig. 6D) of the collar closer together, making sure to
leave some gap between the edges.
3. After tightening, make sure that the handle closes correctly. If it is difficult to close the handle, unscrew
the thumbnail slightly then try closing the handle again.
Troubleshooting
A
B
C
D
What Is Happening? Why? What Should Be Done?
Table will not raise.
Too much weight on the table. Reduce weight or manually assist the table in raising.
Levers are not released. Check to make sure level is fully released.
Object obstruction. Make sure there is nothing preventing the table from
raising fully.
Table will not lower.
Locking collar too tight. Check to make sure thumb screw is not too tight.
Levers are not released. Check to make sure lever is fully released.
Object obstruction. Make sure there is nothing preventing the table from
lowering fully.
Table is creeping
upwards.
Lever is not closed. Make sure lever is fully closed.
Locking collar is too loose. Adjust thumb screw.
Table is creeping
downwards.
Lever is not closed. Make sure lever is fully closed.
Locking collar is too loose. Adjust thumb screw.
Too much weight on the table. Reduce weight on the table.
Fig. 6

Rev: 11.08.19 Page 8 CCD-0001573-07
Introduction
Our one-piece, steel frame Tri-Fold Sofa requires no spare mattress to store. In just four simple steps, it
transforms into a comfortable bed. Traditional hide-a-beds have uncomfortable mattresses with support
bars that can make sleeping uncomfortable. Air mattress hide-a-beds eliminate the support bar issue, but
can be damaged more easily and become unusable. The Tri-Fold Sofa coverts from sofa to a very supportive,
high-density foam sleep surface in four simple steps. Now campers can actually look forward to sleeping on
the couch!
Additional information about this product can be obtained from www.lci1.com/support or by downloading
the free myLCI app. The app is available on iTunes® for iPhone® and iPad® and also on Google Play™ for
Android™ users.
iTunes®, iPhone®, and iPad® are registered trademarks of Apple Inc. Google Play™ and Android™ are
trademarks of Google Inc.
FURNITURE
TRI-FOLD SOFA

Rev: 11.08.19 Page 9 CCD-0001573-07
Safety Information
Fig. 1
Moving parts can pinch, crush or cut. Keep clear and use caution.
Failure to follow the instructions provided in this manual may result in death, serious injury, unit
damage, or voiding of the component warranty.
Operation Instructions
NOTE: Refer to Fig. 1 for steps 1-5.
1. Remove back cushions from the hook and loop fabric strips and set aside.
2. Fold out the couch seat to expose the middle seat.
3. Fold out the couch seat legs and set upright.
4. Fold down the stationary back.
5. Use back cushions as headrest or pillows.
Back
Cushion
Couch
Seat
Couch
Seat
Front
Kick
Rail Foot
Arm
Insert
Arm
Assembly
Stationary
Back
Middle
Seat
V2
Frame
Middle
Seat
Stationary
Back
Couch Seat Legs

Rev: 11.08.19 Page 10 CCD-0001573-07
Introduction
The modular dinette seatback provides for seating at the dinette or the lounge. The backrest brackets
installed on the dinette/lounge cushions provide for placement in two positions, either installed as a dinette
backrest or repositioned for use as a lounge backrest. Brackets to hold the backrest are installed on both
sides of the seat.
Safety
Read and understand all instructions before installing this product. Adhere to all safety labels.
This manual provides general instructions. Many variables can change the circumstances of the instructions,
i.e., the degree of difficulty, operation and ability of the individual performing the instructions. This
manual cannot begin to plot out instructions for every possibility, but provides the general instructions,
as necessary, for effectively interfacing with the device, product or system. Failure to correctly follow the
provided instructions may result in death, serious personal injury, severe product and/or property damage.
The "WARNING" symbol above is a sign that a procedure has a safety risk involved and may cause
death or serious personal injury if not performed safely and within the parameters set forth in
thismanual.
The "CAUTION" symbol above is a sign that a procedure has a safety risk involved and may cause
serious personal injury and/or severe product or property damage if not performed safely and
within the parameters set forth in this manual.
Moving parts can pinch, crush or cut. Keep clear and use caution.
FURNITURE
FOREST RIVER DINETTE SEATBACK

Rev: 11.08.19 Page 11 CCD-0001573-07
Operation
Fig. 1
Lounge
Position
Dinette
Seating
1. Install the seatback in the brackets behind the lounge seat for the lounge position (Fig. 2).
2. Move the dinette seatback and install in the other set of seat brackets to create dinette seating (Fig. 3).
Make sure the backrest posts are completely seated in the brackets (Fig. 1). Improper placement
could cause the backrest to tip over and cause injury.
Fig. 2
Fig. 3
