Lippert Components TI-325 User manual

Rev: 06.28.19 Page 1 CCD-0002702
JACKKNIFE SOFA SUPPORT LEG INSTALLATION GUIDE
TI-325
FURNITURE
Purpose
This document describes the procedure for attaching legs to the jackknife sofa. The aftermarket leg kit is PN
364582 and contains two 11 ½" x 2" legs, four ⁄" - 18 x ¾" bolts and four nylon locknuts.
Resources Required
• Socket wrench
• ½" socket
• ½" open-end wrench
Installation
1. Stand sofa on its side to provide access to one leg bracket.
2. Install bolts facing outward in the holes on the end of each side of the leg bracket (Figs 1 and 2).
3. Insert leg section onto the bolts (Fig. 3).
Fig. 1
Hole at End
of Bracket
Hole at End
of Bracket
Fig. 2
Bolt Facing
Outward
Fig. 3

Rev: 06.28.19 Page 2 CCD-0002702
As a supplier of components to the RV industry, safety, education and customer satisfaction are our primary concerns. Should you
have any questions, please do not hesitate to contact us at [phone] or by email at [email protected]. Self-help tips,
technical documents, product videos and a training class schedule are available at lci1.com or by downloading the MyLCI app.
JACKKNIFE SOFA SUPPORT LEG INSTALLATION GUIDE
TI-325
FURNITURE
4. Place nut on end of bolts.
5. Apply open-end wrench to the bolt head to prevent movement while tightening the nut (Fig. 4).
6. Using a ½" socket and socket wrench, firmly tighten the nut (Fig. 5).
7. Repeat procedure to fasten the other bolt.
8. Turn sofa over to provide access to the other leg bracket (Fig. 6).
9. Repeat steps 2 through 7 for the second leg.
10. The legs are now attached to the jackknife sofa (Fig. 7).
Fig. 4 Fig. 5
Fig. 6 Fig. 7
