Lippert SKYLINE User manual

1
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.24.23
Skyline eBike
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0005293
Skyline eBike
Installation and
Owner’s Manual
(For Aftermarket Applications)
Part #Part # DescriptionDescription
2021014622 Skyline eBike
Table of Contents
Introduction ............................................ 2
Safety ................................................... 2
Parts List ................................................ 3
Resources Required ................................... 4
Preparation ............................................. 4
Unpack eBike from Box ................................ 4
Charge Battery ........................................ 4
Download eBike Application, “Lippert Ebikes” ......... 6
Assembly ............................................... 7
Install Handlebars ...................................... 7
Install Seat ............................................. 7
Install Mudguard ....................................... 7
Install Front Wheel ..................................... 8
Install Pedals. .......................................... 8
Install Front Brake. ..................................... 8
Place Phone Holder on Handlebars. ................... 9
Post Assembly Verication ............................ 9
Getting to Know the Electronics Package .......... 10
LED Display Touch Pad .............................. 11
Understanding Pedal Assistance .................... 12
The eBike system can only be activated when the
following requirements are met: ..................... 12
Battery Pack ........................................ 13
Battery Charger ...................................... 15
Understanding Battery Discharge Issues ............ 15
Additional Battery Safety ............................ 15
Operation ............................................. 16
First Use of Bike ..................................... 16
Best Safety Practices ................................ 17
Using the eBike Application ......................... 18
Using the Touchpad OR the eBike Application ...... 18
Download eBike Application, “Lippert Ebikes” ....... 18
User App Access .................................... 19
Maintenance .......................................... 21
General Care ........................................ 21
Setting Up Suspension .............................. 21
Wheel Truing ........................................ 21
Rear Derailleur Set Up ............................... 22
Front Derailleur Set Up .............................. 22
Brakes Adjustment and Replacements .............. 23
Tires, Tubes and Valves ............................. 23
Lubrication ........................................... 23
Rear Hub Motor ...................................... 23
Troubleshooting ...................................... 24
Specications Tables ................................ 25
General Specications of the Skyline eBike ......... 25
DT Motor Controller .................................. 26
Battery Charger ...................................... 26
Battery Pack ......................................... 26
Rear Hub ............................................ 26
Lubrication ........................................... 27
Torque ............................................... 27
Notes .................................................. 27

2
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.24.23
Skyline eBike
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0005293
Introduction
Spend less time charging and more time riding with the
advanced lithium-ion battery of Lippert Li-Series ebikes.
This electric Skyline city bike is perfect for added mobility
and sightseeing, featuring a range of up to 45 miles per
charge and Bluetooth-ready, smartphone compatibility.
Additional information about this product can be obtained
from lci1.com/support or by using the LippertNOW app.
Replacement kits can be ordered from https://store.lci1.
com/ or by using the LippertNOW app.
The LippertNOW app is available for free on Apple App
Store®for iPhone®and iPad®and also on Google Play™for
Android™users.
App Store®and iPad®are registered trademarks of Apple
Inc.
Google Play™and Android™are trademarks of Google Inc.
For information on the assembly or individual components
of this product, please visit:
https://support.lci1.com/convenience-and-leisure/
NOTE: Images used in this document are for reference
only when assembling, installing and/or operating this
product. Actual appearance of provided and/or purchased
parts and assemblies may differ.
Safety
Read and understand all instructions before installing or
operating this product. Adhere to all safety labels.
This manual provides general instructions. Many variables
can change the circumstances of the instructions, i.e., the
degree of difficulty, operation and ability of the individual
performing the instructions. This manual cannot begin to
plot out instructions for every possibility, but provides the
general instructions, as necessary, for effectively interfacing
with the device, product or system. Failure to correctly
follow the provided instructions may result in death, serious
personal injury, severe product and/or property damage,
including voiding of the Lippert limited warranty.
FAILURE TO FOLLOW INSTRUCTIONS PROVIDED
IN THIS MANUAL MAY RESULT IN DEATH, SERIOUS
PERSONAL INJURY AND/OR SEVERE PRODUCT AND
PROPERTY DAMAGE, INCLUDING VOIDING OF THE
COMPONENT WARRANTY.
ALWAYS WEAR EYE PROTECTION WHEN
PERFORMING SERVICE, MAINTENANCE OR
INSTALLATION PROCEDURES. OTHER SAFETY
EQUIPMENT TO CONSIDER WOULD BE HEARING
PROTECTION, GLOVES AND POSSIBLY A FULL FACE
SHIELD, DEPENDING ON THE NATURE OF THE TASK.
THE “WARNING” SYMBOL ABOVE IS A SIGN THAT
A PROCEDURE HAS A SAFETY RISK INVOLVED
AND MAY CAUSE DEATH OR SERIOUS PERSONAL
INJURY IF NOT PERFORMED SAFELY AND WITHIN
THE PARAMETERS SET FORTH IN THIS MANUAL.
THE “CAUTION” SYMBOL ABOVE IS A SIGN THAT
A SAFETY RISK IS INVOLVED AND MAY CAUSE
PERSONAL INJURY AND/OR PRODUCT OR
PROPERTY DAMAGE IF NOT SAFELY ADHERED TO
AND WITHIN THE PARAMETERS SET FORTH
IN THIS MANUAL.

3
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.24.23
Skyline eBike
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0005293
Parts List
NOTE: Part numbers are shown for identification purposes
only. Not all parts are available for individual sale. All parts
with a link to the Lippert Store can be purchased.
Skyline eBike (2021014622)
LetterLetter PNPN DescriptionDescription QtyQty
A
2022075471 Front Brake Assembly 1
2022075472 Rear Brake Assembly 1
B 2022075485 Front Chainwheel 1
C 2022075487 Fork 1
D 2022075489 Front Wheel 1
E 2022075491 Grips 1
F 2022075494 Pedals 1
G 2022076596 Rear Wheel 1
H 2022077483 Saddle 1
I 2022078172 Front Tire 1
J 2022078501 Rear Tire 1
K 2022084003 Battery Charger 1
L
2022085005 Battery Pack 1
2022086007 DT Motor Controller 1
M 2022086987 LED Display Touch Pad 1
N 2022088011 Pedal Assist Sensor 1
NOTE: Consult the Getting to Know the Electronics
Package section for more information about the Battery
Charger (K), Battery and Controller (L), LED Display (M),
and Sensor (N).
B
C
F
D
I
J
G
K
N
A
E
L
M
H

4
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.24.23
Skyline eBike
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0005293
Resources Required
• 1 to 2 people
• Box cutter
• Scissors
• 4mm hex key
• Lubricating bike grease
• 15mm spanner wrench
• Screwdriver
• Smart device
• Mobile Application
• Access to an electrical
outlet
• Bicycle grease
• 15mm box wrench
• Sidecuts
• Ratchet
• Socket Wrench, various
sizes
Unpack eBike from Box
1. Find an open space where the eBike assembly can
safely be completed, such as a personal garage or
workshop area.
2. Carefully unpack eBike from packaging. Lift the bike
upwards out of the box, place it safely on the oor. Take
out the saddle and small parts.
NOTE: eBike may be received with the neck packed
backwards. Double check so the handlebars are not
assembled backwards. If necessary, loosen the neck and
rotate 180 degrees.
Preparation
3. Keys (Fig. 2) are zip-tied to the Crank arm where the
pedals will be installed. Cut the zip ties, put keys in safe
place.
NOTE: Keep battery keys in a safe place. Battery keys do
not start eBike, but lock and unlock battery from eBike so it
can be removed for charging purposes.
Charge Battery
The battery must be charged before riding. The battery
included with the eBike will be in a sleep state when
received; partially charge but not enough to immediately
operate the eBike. the battery should be set aside to
charge while assembling eBike and ideally given 24-48
hours to charge.
1. Find a safe, dry place to charge battery. Only use
the charger in indoor areas and do not leave a charging
battery unattended.
Fig.1
Fig.2

5
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.24.23
Skyline eBike
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0005293
3. Plug charger into wall (Fig. 5).
2. Remove the battery from frame by inserting the key into
the lock on the front left side of battery rack (Fig. 3A). Turn
key and pull the battery to slide it off (Fig. 4) and out of the
back of the rack.
4. Plug battery into charger to start charging (Fig. 6).
Fig.4
Fig.5
Fig.3
A
Fig.6
NOTE: Only charge the battery with the charger provided.
Using the wrong charger risks the life of the battery and
presents a potential fire hazard.
5. When battery is without a charge, the battery will display
a red light. When the battery is charged and ready to use,
the display light will be green.
6. When the battery is fully charged, disconnect the
charger from the battery and wall socket.
NOTE: For more information about the battery and battery
charger, please read “Battery Pack” and “Battery Charger”
sub-sections of Electronics Package section.

6
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.24.23
Skyline eBike
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0005293
Download eBike Application, “Lippert Ebikes”
It is highly recommended to download the eBike app during
the preparation and assembly of the eBike. Downloading
the app and pairing the eBike with the app ensures the
latest updates are applied for maximum eBike use.
Regardless of using the app or not when operating, it is
essential from time-to-time to check for firmware updates
to make sure eBike assembly and equipment are current
and operating to manufacturer standards.
1. Make sure the smart device being pairing to the eBike is
connected to the Internet and Bluetooth settings are turned
on.
2. Download the eBike app from the appropriate app store.
3. Using the smart devices’ camera app or QR code
reader, scan the QR Code underneath the frame of the
eBike (Fig. 7A).
4. Walk through the app/pairing setup process as prompted
by the Lippert Ebikes app.
For more information about using the app, see the Using
the eBike Application section of this manual.
NOTE: Lippert Ebikes application can only be used for
the eBikes: Lippert Gladiator and Skyline City with ACTIA
products. The application connects the ACTIA controller
of the eBike via Bluetooth to a smart device; this allows
access to diagnostic and infotainment functions.
NOTE: Lippert Ebikes application can be installed on
smartphone with Android Version greater than Android 8.0
or IOS 12.1.
NOTE: To install, search for "Lippert Ebikes" in the App
Store for iPhone (or other Apple smart devices) or the
Google Play Market for Android smart devices. The QR
Code can also be scanned to access the download link of
the application.
A
Fig.7

7
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.24.23
Skyline eBike
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0005293
Assembly
A
Install Handlebars
1. Insert handlebar neck into front stem (Fig. 8).
2. Adjust to desired height and center (Fig. 8A) with front
fork.
NOTE: Do not raise above max height marking on neck.
3. Tighten with 6mm hex (Fig. 9).
Tighten
4. Loosen handlebars and pivot (rotate up) to desired riding
position. Tighten with 6mm hex.
Install Seat
1. Flip quick lock open (Fig. 10A) to allow the seat post to be
inserted into the frame.
A
2. Insert seat into the seat post (Fig. 11A) and ip quick lock
to secure seat.
A
NOTE: As seat is positioned, do not adjust outside of the
range of the alignment marks.
NOTE: For the next steps, it will be necessary to carefully
maneuver eBike so the handlebars and seat are on the
ground supporting the bike.
Install Mudguard
NOTE: Nuts and bolts are installed in the frame for the
mudguard.
1. Use two (2) 10mm wrenches (Fig. 12A) to loosen nut from
bolt. Remove nut, leaving the bolt and front reector in
place.
Fig.8
Fig.9
Fig.10
Fig.11
Fig.12
A
A

8
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.24.23
Skyline eBike
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0005293
2. Place top tab of the mudguard (Fig 13A) onto the bolt and
reinstall the nut removed in Step A. Tighten using two (2)
10mm wrenches.
3. One at a time, remove the screws in the front fork
(Fig. 14A) and place through the mudguard support arm
(Fig. 14B).
B
A
4. Secure into fork using 4mm hex key.
Install Front Wheel
1. Place front wheel into fork, paying close attention to
the position of the security washers into the designated
retaining holes (Fig. 15).
2. Verify front wheel security washers are in proper
position (Fig. 15A).
A
B
A
NOTE: Figure 16A shows the front wheel security washer
out of place for reference.
3. Tighten nuts using 15mm wrench (Fig. 15B).
Install pedals.
1. Insert pedals into crank arm (Fig. 17).
2. Left (L) pedal is REVERSE THREADED.
3. Pedals are labeled right and left and must be put on the
appropriate side (Fig. 18).
Fig.13
Fig.14
Fig.15
Fig.16
Fig.17
A
Fig.20
Install front brake.
1. Squeeze the right and left brake arms together (Fig. 19).
Brake pads should be contacting the rim.
2. Insert the brake cable into quick-release lever (Fig. 20A).
3. Test brake function.
A
Fig.18
Fig.19

9
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.24.23
Skyline eBike
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0005293
Place Phone Holder on Handlebars.
1. Find phone holder and unpack.
NOTE: Do not immediately discard plastic tube filling in
Phone Holder clamp. This may be necessary to ensure
Phone Holder can tightly grip the handlebars.
2. Eyeball where it will be easy to look down at phone and
still be as safe as possible while riding/looking at the road.
3. Loosen handlebar clamp and clasp to the handlebar.
4. Re-tighten to secure in place.
5. On the back of the Phone Holder, loosen knob on the
back to release the frame.
6. Pull open the frame to smart device’s size, and then
snuggly cradle the smart device within the Phone Holder’s
frame.
7. Re-tighten knob on back, to secure smart device in
place.
Post Assembly Verification
After eBike has been successfully assembled (and before
every ride), check the eBike for the following:
• Tires are aired up and not flat.
• Wheels spin freely of guards.
• Axles are tight and secure so wheel will not fall out.
• There is no play in the wheel bearings
• The spokes are correctly tensioned
• The chain is lubricated
• The pedals are tight.
• Check all key bolts are tight: stem bolts, seat clamp bolts
etc. Vibrations occur when riding eBike that can lead to
bolts loosening (Even bolts with thread-lock on)
• Make sure the saddle is at the correct riding height and
position. Check it is not beyond the minimum insertion
mark.
• Check brake functionality; pull the levers and ensure the
pads engage with the rim or disc and spring back so they
are not touching when the bike is moving.
• Check for signs of material fatigue. Deformations,
fractures, cracks, signs of impact, etc.
NOTE: DO NOT ride eBike even if just one of the
defects is present and consult preferred bicycle service
technician.

10
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.24.23
Skyline eBike
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0005293
It is also advisable to become familiar with the Electronics
Package of the Skyline eBike to ensure safe riding and to
get the most out of the eBike ride.
LetterLetter PNPN DescriptionDescription QtyQty
A 2022086987 LED Display Touch Pad 1
B 2022085005 Battery Pack 1
C 2022086007 DT Motor Controller 1
D 2022088011 Pedal Assist Sensor 1
E 2022084003 Battery Charger 1
NOTE: Part numbers are shown for identification purposes
only. Not all parts are available for individual sale. All parts
with a link to the Lippert Store can be purchased.
A
B
C
D
E
Getting to Know the Electronics Package

11
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.24.23
Skyline eBike
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0005293
LED Display Touch Pad
The LED Display Touch Pad (Fig. 21) provides riders with
the following information:
• Smart battery indicator
• Assistance-level indicator
• The walk-assistance function
• Error indication
Switching the eBike System On/Off
• To switch ON the eBike system, hold the MODE button
for 2 seconds.
• In the same way, hold the MODE button for 2 seconds
again and the eBike system will be switched off.
NOTE: When parking the eBike for more than 10 minutes,
the eBike system will switches off automatically
Switching walk-assistance mode On/Off
To access the walk-assistance mode, press and hold the
DOWN button.
NOTE: eBike will move at a uniform speed of 3.7 mph (6
kph). The walk-assistance function switches off as soon as
the DOWN button is released.
NOTE: Do not block the eBike after activation of the
walking assistant. The motor can get damaged that way.
15 mph (25 kph)
13 mph (22 kph)
11 mph (19 kph)
10 mph (16 kph)
8 mph (13 kph)
Fig.21

12
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.24.23
Skyline eBike
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0005293
The range is influenced by many factors:
• Battery capacity
• Weight of the rider
• Weight of the luggage
• Selection of path
Assistance level selection
Assistance level indicates the output power of the motor.
The default value is level “1”.
Press the UP/DOWN button to select assistant level from
level “0” (no light) to level “5”.
Error Indication
If there is something wrong with the electronic control
system, the lights will toggle.
Fig.22
Understanding Pedal Assistance
The eBike system can only be activated when the following
requirements are met:
A. A sufficiently charged battery pack is inserted.
B. The display module is properly inserted in the holder.
C. The speed sensor is connected properly.
The assistance is activated when start pedaling. The
assistance is disabled when:
• The rider stops pedaling
• The configured speed limit is exceeded
NOTE: Walk-assistance does not need pedaling.
The eBike can also be ridden without assistance by
switching off the eBike system, or by setting the assistance
level to “0”.
When the battery pack is empty the assistance can be
limited when the battery in low state-of-change as follows:
• If state-of-change is less than 30% the allowed max
assistance level is 4.
• If state-of-change is less than 25% the allowed max
assistance level is 3.
• If state-of-change is less than 20% the allowed max
assistance level is 2.
• If state-of-change is less than 15% the allowed max
assistance level is 1.
• Experience and concentration of the rider
• State of maintenance of the eBike
• Type, condition, and air pressure in the tires
• Nature of the route
• Speed, average speed, and changes in speed
• Traffic flow, for example, stop and go
• Wind direction and wind speed

13
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.24.23
Skyline eBike
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0005293
Battery Pack
Switching the battery pack ON/OFF
• To switch on the battery pack, toggle ON/OFF Button
(Fig. 23A) to I position.
• In the same way toggle ON/OFF Button to O, the eBike
system will be switched off.
Light Flashing Function
To activate this function, click on the state-of-change
indicator button (Fig. 23B) then two clicks on the flashing
button.
Battery Indicator
• To activate this function, click on the state-of-change
indicator button.
• The three lights (Fig. 23C) are lighting when the battery is
in high voltage. When the battery is in low voltage, the
under lights will light to notice that the battery needs to be
recharged immediately.
NOTE: Every three months, allow the battery to completely
lose it’s charge and then recharge.
NOTE: Figure 23D is where the charger plugs into the
battery.
Fig.23 A
C
D
B
For safety, the Battery Pack ensure continuous monitoring
of current, voltage and temperature. If one of these
parameters gets out of functional range, the Battery Pack
will shut down.
If the battery shuts down, it can be reset by:
• Switch On/Off
• Plug the charger. (Must be used also if no activity of the
Battery for a period of 4 days / Ship Mode)
If the eBike is not in use, remove the battery and store it at
a temperature between 32°F (0°C) and 104°F (40°C) in a
dry environment.

14
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.24.23
Skyline eBike
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0005293
Battery Storage
For storage, the battery should have a capacity of at least
40%. It is recommended to always discharge the battery
completely and then fully charge. It is highly recommended
to Switch OFF the Battery after using the eBike.
Fig.24
Fig.25
Inserting the battery (Fig. 24)
• Connect the battery by sliding it across the mount plate.
• When the battery is mounted. Turn the key to the right to
lock the battery in.
NOTE: The key can now be removed.

15
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.24.23
Skyline eBike
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0005293
Battery Charger
Use only batteries and chargers supplied by the
manufacturer. Use of other battery packs can cause injury
and increase the risk of fire. The charger is designed for
indoor use only. Do not expose to rain or snow. Do not
incinerate, disassemble, or short circuit batteries. If the
performance of the batteries decreases substantially, it is
time to replace the batteries. Store the charger in a cool
and dry place when not in use. Disconnect the supply
before making or breaking the connections to the battery.
During charging, the battery must be placed in a well-
ventilated area.
Charging Instructions
1. Connect the charger three pin circular jack into the
recharge battery pack charging connector (Fig. 26A).
Fig.26
Fig.27
2. Plug the charger (Fig. 27A) into the socket (Fig. 27B).
A
A
B
Understanding Battery Discharge Issues
The eBike battery, when received, has a charge but not
enough to have a successful first ride. As mentioned, the
battery should be set aside to charge while assembling
eBike and ideally given 24-48 hours to charge.
As with all electronics dependent on a battery for power,
the battery will discharge as used making it vital to charge
the battery from use to use.
However, if the eBike is not used and the battery is
not connected to the charger, the battery will gradually
discharge and become less powerful. If aware that the
eBike will not be used for an extended period of time,
take battery off of the eBike and attach to the charger to
maintain the battery’s health.
Additional Battery Safety
The following tips will help keep the eBike’s battery safe
and full functional, as well as protect users and property
from harm and injury.
• Do not throw the battery pack into a fire.
• Do not use the battery for any other purpose.

16
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.24.23
Skyline eBike
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0005293
• Avoid contact with metal objects (paper clips, coins,
keys, nails, screws, or other small metal objects, as this
may cause a short circuit. Shorts caused in this way will
invalidate any warranty claims.
• Do not open the battery pack. This could cause a short
circuit. Opening of the battery package will invalidate any
warranty claims.
• Ensure that the power plug is fully inserted into the wall
outlet.
• Pull on the plug instead of the cable to unplug the power
cord from a wall outlet.
• Always keep the battery charging set away from
flammable gases when charging.
• The charger can be hot. Do not wrap the charger.
• The charger can be hot. Do not place the charger on floor
coverings such as carpets, rugs, etc.
• The charger can be hot. Avoid long skin contact with the
charger.
• Do not immerse the battery or the charger. Do not use in
rain.
• Do not charge the battery for more than 24 hours
continuously.
• The charger can be used with an input voltage in the
range of 90V to 264VAC ⁄Hz.
• Avoid leaving the battery exposed to direct sunlight for a
long time.
Operation
First Use of Bike
1. Make sure battery is fully charged
2. Insert the battery then turn the key to lock (Fig. 28).
3. Push ON/OFF switch to I position (Fig. 29A).
Fig.28
Fig.29
4. Turn ON the TouchPad (Fig. 30A).
5. Select assistance level (Fig. 30B).
6. Pedal and ride.
Fig.30
A
A B

17
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.24.23
Skyline eBike
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0005293
Best Safety Practices
NOTE: Riding an eBike is more different than a regular
pedal bicycle than most riders think. Read this section and
the rest of the manual thoroughly to ensure a safe and
enjoyable ride.
How Safe Riding is Ensured
• Start on the lowest assist setting and learn the feeling of
pedal assistance.
• eBikes are heavier than normal bikes, and move faster;
more power, more speed, and more weight. Start slowing
down sooner on eBike than on a normal bike. Start
braking with a lighter hand and a gradual pull of the brake
levers.
NOTE: Never just grab the front brake lever — brake with
both front and rear evenly.
• eBikes can withstand light rain and small splashes, but
is not designed to be subjected to inclement weather,
extremely heavy showers, or submersion in water.
• Always wear a helmet when riding. Ensure that the
helmet fits head and is securely tightened down. Before
riding, read local laws and comply with all rules relating to
cycling and eBiking in local area.
• While riding, do not focus too much attention on the
screen, as this can lead to accidents.
• Ensure that the wheels are securely attached to the bike
before riding. If the wheels are not securely attached, the
bike may fall over, causing severe damage.
• Remove the battery pack from the eBike before working
on it (e.g., assembly work, maintenance, etc.), before
transporting it by car or plane, or before storing it. There
is a risk of injury in case of accidental activation of the
eBike system.
• After having carefully read the user manual, store it in a
safe place for later reference.
• Use only batteries and chargers from Lippert the eBike.
Use of other battery packs can cause injury and involve
a risk of fire. Lippert will assume no liability or warranties
for damage or injuries when using other battery packs.
• Examine the battery charger regularly for damage,
especially the cable, plug and housing. If the battery
charger is damaged, it must only be used after it has
been repaired.
• This product must not be used by persons (including
children) with reduced physical, sensory, or mental
capabilities, or who lack experience and knowledge,
unless they are supervised by a person responsible for
their safety or instructed in the use of the product.
• Do not let children play near the product.

18
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.24.23
Skyline eBike
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0005293
Using the eBike Application
Using the Touchpad OR the eBike Application
The Skyline eBike can be controlled by the Touchpad OR
the application, but not both.
If the desired riding experience is to just ride, use the
Touchpad and refer to the Touchpad sub-section.
if the desired riding experience is to also collect data on
the ride and utilize GPS, then installing the application
and pairing the eBike and smart device via bluetooth is
advisable.
While riding, if the eBike application is open, the
application will override other functions of the phone, such
as calls and text messages. In case of emergency, the
rider should familiarize themselves with how to override
applications using smart device.
Download eBike Application, “Lippert Ebikes”
Lippert Ebikes by ACTIA application allows an
interconnected and interactive experience with the Skyline
eBike.
1. Make sure the smart device being paired to the eBike is
connected to the Internet and Bluetooth settings are turned
on.
2. Download the eBike app from the appropriate app store.
NOTE: To install, search for "Lippert Ebikes" in the App
Store for iPhone (or other Apple smart devices) or the
Google Play Market for Android smart devices. The QR
Code can also be scanned to access the download link of
the application.
NOTE: Lippert Ebikes application can be installed on
smartphone with Android Version greater than Android 8.0
or IOS 12.1.
3. Using the smart devices’ camera app or QR code
reader, scan the QR Code underneath the frame of the
eBike (Fig. 31A).
4. Walk through the app/pairing setup process as prompted
by the Lippert Ebikes app.
NOTE: Lippert Ebikes application can only be used for
the eBikes: Lippert Gladiator and Skyline City with ACTIA
products. The application connects the ACTIA controller
of the eBike via Bluetooth to a smart device; this allows
access to diagnostic and infotainment functions.
Fig.31
A

19
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.24.23
Skyline eBike
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0005293
User App Access
Launch Lippert eBike App
1. Start the app to land on the login screen (Fig. 32).
2. Create an account if a new Lippert eBike user (Fig. 32A).
If the rider previously registered as a Lippert eBike user,
login to user account (Fig. 32B).
Register as a new Lippert eBike user
1. Press Create Account (Fig. 32A)
2. Fill in the required information (Fig. 33)
3. Press Sign Up (Fig. 33A)
4. The Lippert Server will send an email with a link. Click
on the link to activate account.
5. The Lippert Server will conrm that the registration
process has been completed.
6. From now on, this will be the USERNAME and
PASSWORD to login into the app.
NOTE: If an email notification is not received, make sure
to check Spam and/or Junk folders as the email may
have been routed there. Also, double check that the email
entered is correct.
NOTE: Screens may vary slightly from smart device
interface to another.
A
A
B
Fig.32
Fig.33

20
lippert.com 432-LIPPERT (432-547-7378) Rev: 03.24.23
Skyline eBike
Installation and Owner’s Manual
(For Aftermarket Applications)
CCD-0005293
eBike Pairing and Connection (Fig. 40)
1. Press Add Bike (Fig. 34A).
2. Remove battery and scan QR code on the eBike frame
as referenced earlier (Fig. 31A) (as referenced earlier).
3. Reconnect the battery
4. Turn ON the bike
5. Press nish
6. Enter PIN code
A. To get started, the PIN code will default to: 000000
B. The user/rider will be asked to setup a unique 6 digit
PIN code.
C. This 6 digit PIN code will be necessary to keep the
eBike and App and Controller connected.
7. Press OK
User App Agreements
User will be prompted for the app to access things such as:
making phone calls, camera usage, location, etc. These all
MUST be agreed to for the user to utilize the app.
Riding the eBike (Fig. 35)
1. For the eBike statistic menu, click the orange paperclip
(Fig. 35A)
2. Press Go Ride (Fig. 35B).
A
B
CDE F G
H
A
Callout Description
APaperclip
CHome
DCheck diagnostic information
EEdit settings
F Check statistics
G To see ride history
H To connect to bike
Fig.34
Fig.35
