Giant AVAIL ADVANCED 1 User manual

121
road
The all-new frame with aero-sculpted Advanced-grade composite puts speed first and foremost, while
its slightly relaxed geometry provides more comfort for those long weekend rides and that occasional
century. It’s the versatility you need, with speed when it counts!
— 10-speed Shimano Ultegra shifting and compact crankset with Dura-Ace rear derailleur
— FSA Wing Pro women’s handlebar and stem, Fi’zi:k Vitesse HP women’s saddle
— Lightweight Mavic Ksyrium Elite wheelset, Michelin ProRace3 Tires
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
FRAME
SIZES XS,S,M
COLORS Ghost White
FRAME Advanced-Grade Composite
FORK Advanced-Grade Composite,
Alloy OverDrive Steerer
SHOCK N / A
COMPONENTS
HANDLEBAR FSA Wing Pro Women's, 31.8
STEM FSA OS-99
SEATPOST Giant Vector Composite Seatpost
SADDLE Fi'zi:k Vitesse HP w / Ki:um rails
PEDALS Crank Brothers Smarty
DRIVETRAIN
SHIFTERS Shimano R700, short reach
FRONT DERAILLEUR Shimano Ultegra
REAR DERAILLEUR Shimano Dura-Ace
BRAKES Shimano Ultegra
BRAKE LEVERS Shimano Ultegra
CASSETTE Shimano Ultegra 12/27, 10-speed
CHAIN Shimano Ultegra
CRANKSET Shimano Ultegra, 34/50
BOTTOM BRACKET Shimano, External
WHEELS
RIMS Mavic Ksyrium Elite
HUBS Mavic Ksyrium Elite
SPOKES Mavic Ksyrium Elite
TIRES Michelin Pro Race3, 700x25
Folding
EXTRAS
Specifications and availability subject to change without notice.
Key Upgrades (over Avail Advanced 2)
Frame TechnologySpecifications
Actual
Frame Size Part Number Head Angle Seat Angle* Toptub e** Headtube Chainstay Wheelbase Standover Height***
centimeters degrees degrees centimeters centimeters centimeters centimeters inches
XS/43.0 cm 384742 71.0 74.5 51.0 13.0 42.0 98.3 29.0
S/46.5 cm 384743 72.0 74.0 52.5 15.0 42.0 98.5 29.8
M/50.0 cm 384744 72.5 73.5 54.0 17. 5 42.0 99.0 30.7
frame geometry
If you demand a blazingly fast and silky-smooth ride, the all-new, women’s specific Avail
Advanced is your bike. Ride-tuned Advanced Composite Technology and endurance position
geometry will keep you fresh for the final climb or the finish line.
avail advanceD 1 performance
