Liqua H-Flex Steam Liner User manual

H-Flex Steam Liner
Rev05 - 190926
1
Instructions Manual

The scope of this operation is to circulate steam through the
Steam Liner and heat the entire cargo for faster melting.
Rev05 - 190926
2
Scope…

Open the H-Flex box and ensure that
the following are in the package:
1. E-Flex Easy Flexitank
2. Steam Liner
3. 23 pieces of Grids
4. Steam Hose
5. Warning Labels
6. Adhesive Tape
Contents of the Box...
The box will be used as door protection board.
DO NOT throw it away!
Rev05 - 190926
3

Sweep the container carefully with a broom.
Ensure that nails, sharp and rough objects that
may damage/puncture the flexitank are
removed.
Cover uneven areas on the walls and on the floor
with duck tape.
Preparation...
Rev05 - 190926
4

Unroll the container liner into the container.
There are 12 straps sewn to the steam liner.
Tie the straps to the closest lashing rings.
Preparation...
Rev05 - 190926
5

Preparation...
Unroll the steam hose and spread through the
container.
The free ends of the steam hose should be located
approximately 50cm away from the mid line
towards the side walls.
50cm 50cm
Mid Line
Rev05 - 190926
6

Rev05 - 190926
7
There is a steam connection on the Steam Liner.
Screw the steam distributor to connector.
Preparation...

50x50cm Grids
Steam
Liner
Rev05 - 190926
8
Couple the grids and position them as below.
50cm
42cm
42cm

Preparation...
Ensure that grids are positioned according to our instructions.
Ensure that the grids are leaning on the container front wall.
Rev05 - 190926
9

Preparation...
Ensure that the hoses are located to the middle row of the grids.
Rev05 - 190926
10

Preparation...
Ensure that the free ends of the steam hoses and
the Steam Distributor are covered with provided PP fabric.
Free end of the
steam hose
Steam Distributor
Rev05 - 190926
11

Preparation...
Ensure E-Flex is leaned on the Steam Liner
front panel.
Unfold the E-Flex on the grids.
Ensure E-Flex is placed at the center of the
container.
Do not to step on the E-flex while unrolling.
Do not to wear shoes during the fitting
operation.
Rev05 - 190926
12

Preparation...
Ensure the last fold at the front/nose side of the E-Flex is taped to the
front wall of the steam liner .
Rev05 - 190926
13

You will find pre-cuts/holes on each side wall for lashing. Pass the
lashing belts through the small cuts which is shown with red circle.
Belt Tying...
Rev05 - 190926
14
Use the big gap shown with blue circle to tie the belt to the lashing lug/ring. The
ring is behind the Steam Liner. Use the gap to pull the belt and then tie to the ring.

Belt Tying...
FASTEN THE
BELTS TO
CONTAINER
LASHING
RINGS HERE
Rev05 - 190926
15
The straps are must
be taut but not
tight.
Tie the lashing strap to
the CENTER lug/lashing
ring in past the joining
knot.

Rev05 - 190926
16
The flexible harness prevents any flexitank movement. However to make sure that
any sharp object/bolts on the door does not damage the flexitank, the carton box
should be collapsed and used for protection.
The box will be used as a door protector. Collapse the box as shown.
Door Protection...

Rev05 - 190926
17
Suspend the boards to the door closing bars.
Door Protection...

Rev05 - 190926
18
Fill in the provided Check List and stick it to the door on the right hand side.
Check List...

IMPROPER FITTING MAY CAUSE CAPACITY PROBLEMS,
INNER LAYERS MAY GET STUCK AND STRETCH. THIS MAY
CAUSE SEVERE LEAKINGS. ONLY TRAINED AND LICENSED
OPERATORS ARE ALLOWED TO FIT OUR FLEXITANKS.
IF FITTING OPERATION HAS BEEN PERFORMED AT ANOTHER
LOCATION, PLEASE ENSURE THAT THE E-FLEX HAS NOT
MOVED DURING LOCAL TRANSPORTATION.
Warning...
Rev05 - 190926
19

Rev05 - 190926
20
Thank you for choosing
H-Flex Steam Liner
