Litecraft BeamX.7 User manual

Bedienungsanleitung
User Manual

Vielen Dank für den Kauf dieses LITECRAFT Produktes. Zu Ihrer eigenen Sicherheit lesen Sie
bitte vor der ersten Inbetriebnahme diese Bedienungsanleitung sorgfältig.
INHALTSVERZEICHNIS
SICHERHEITSHINWEISE 3
BESTIMMUNGSGEMÄßE VERWENDUNG 4
MONTAGE 5
ELEKTRISCHER ANSCHLUSS 6
REINIGUNG UND WARTUNG 6
BEDIENUNG 7
WIRELESS DMX-BETRIEB 9
DISPLAY-MODUS 10
DMX-MODUS 12
PHOTOMETRISCHE DATEN 14
TECHNISCHE SPEZIFIKATIONEN 14
Thank you for purchasing this LITECRAFT product. For your own safety, please read the instruction manual carefully
before turn on the product for the first time.
CONTENT
SAFETY NOTES 15
DESIGNATED USE 16
INSTALLATION 17
ELECTRICAL CONNECTION 18
CLEANING AND MAINTENANCE 18
OPERATION 19
WIRELESS DMX-MODE 21
DISPLAY-MODE 22
DMX-MODE 24
BEAM SPECS 26
TECHNICAL SPECIFICATION 26

SAFETY NOTES
•Each person which is responsible for the installation, the use or service of this unit must be:
•qualified
•hastofollowtheinstructionsinthismanual.
WARNING!
Be careful when using the device. You risk an electrical shock from high voltage, if you touch the wires!
•Thedevicehasleftourcompanyinmanufacturerproofed state. To maintain this status and to ensure a
permanent safe operation, it is absolutely necessary to follow the safety instructions and warnings in this
manual.
IMPORTANT!
Errors, caused by not following these instructions are not covered by the warranty. The manufacturer will not accept
liability for any resulting defects or problems.
•Keep the unit away from radiators or other heat sources!
•Iftheunithasbeenexposedtotremendoustemperature changes (e.g. after transportation), do not turn it on
immediately. The resulting condensation could damage the unit. Don`t switch unit on until the device reaches
room temperature.
•ThisdevicebelongstoprotectionclassI.Therefore, it is imperative that the green/yellow wire is connected to
the earth contact of the plug. The electrical connection must be made by a qualified person.
•Makesurethatthecablehasneverbeensqueezedor damaged by sharp objects. Check the device and the
cables regularly.
•Ifthecableisdamaged,itmustbereplacedimmediately by the manufacturer, its service agent or a qualified
person in order to avoid danger.
•Lenses, glasses or UV filters must be replaced if they are visually damaged, or their effectiveness is impaired,
e.g. by broken glass or by deep scratches.
•Ensure that wires never come in contact with other wires! Handle the power cord and all connections with
caution!
•Makesurethatthelinevoltageisnothigherthanthe voltage specified in this manual.
•DisconnecttheunitfromtheACmainswhenitisnot in use or when cleaning it. Disconnect the connection
only by pulling the cable plug.
•Usingthefixtureforthefirsttime,canresultin light smoke and odors. This is a normal process and does not
constitute a defect.
RISK OF BURNS!
Do not touch the unit during operation! The housing may reach high temperatures.
RISK TO HEALTH!
Never look directly into the light source. Especially epileptics risk an epileptic shock! Disconnect the unit from the AC
mains when not in use or when cleaning it.
•Defectscausedbymodificationsofthedevicebyunqualified handling or an unqualified person are not
covered by the warranty.
•Keep the product away from children and unskilled people.
•Therearenowearpartsinthedevice.Maintenanceand service must be performed only by an authorized
service partner.
WARNING! Please make sure to read safety instructions for handling of integrated battery in chapter SAFETY
INSTRUCTIONS BATTERY!

DESIGNATED USE
This product is a spotlight, which is designed only for professional use on stages, discotheques, theatres, etc. This
product is approved for mains connection up to 230 VAC and designed for indoor use.
•Please avoid any kind of shocks and outer actions during its installation or transportation.
•Takecareoftoohighambienttemperature,humidity and dust when choosing the installation location. Assure
that all cables are fixed. Incorrect operation may lead to danger.
•Image shows the minimum distance to illuminated objects. Minimum distance between fixture and
illuminated surface is 0,1 meters
•Assure that the area below the mounting position of the fixture is roped in while mounting, dismantling and
service.
•Thespotlightitselfanditsaccessorieslikecolor frame and barndoors have to be safed with a suitable safety
chain.
•Assure that the maximum ambient temperature is never exceeded.
•Donotputthefixtureinoperationbeforeyouarefamiliar with its functions. Keep the product away from children
and unskilled people.

INSTALLATION
•There are specific regulations like DGUV V17/18 (old BGV C1) or country related regulations which need to
attend during the installation. The installation has to be handled by skilled persons only!
•Suspension device hast to be built and calculated in order to handle up to 10 times its specific load limit over
a time of one hour without permanent or harmful deformation.
•Installationhastobedonewithaseparate,independent suspension device like a safety chain. A second
suspension device has to be built in order to assure that in case of error no part of an installation can fall off.
•Trepassingthedangerzonebelowtheinstallationduring the assembling is prohibited.
•Installerhastotakecareofallsafetyandmachinery installations are approved by authorized persons before
first operation or after changes before restarting.
•Installerhastotakecareofallsafetyandmachinery installations are approved by skilled persons at least
once a year.
•Installerhastotakecareofallsafetyandmachinery installations are approved by authorized persons at least
every four years during the acceptance inspection.
•Spotlightshouldideallyinstalledoutsidepeopleslounge area.
ATTENTION!
Installation overhead needs a high level of experience. This includes (but is not just limited to) calculation and
definition of load capacity, used installation material and regular safety inspections of used material and the fixture
itself. Never try to do the installation by yourself if you are not qualified, instead you have to instruct a skilled installer.
Inappropriate installations can cause injuries and/or damage of property.
•Spotlighthastobeinstalledoutsideareaswherepeople can touch it.
•Professional truss system or similar licensed suspension systems have to be used if the spotlight is used in
suspension from ceiling or other constructions. Spotlights can never be installed freely suspended!
ATTENTION!
Spotlights can cause injuries when fall off. If you are not trained in questions of safety for the different kinds of
installation do NOT install the spotlight!
•Assure that the mounting surface can hold at least ten times the point load of the spotlight before installing the
fixture.
ATTENTION!
Assure the specified safety distances to flammable material.
•Attach the spotlight with its yoke and the use of a suitable hook/clamp to your truss system. According to your
installation also similar but approved suspension devices are possible. The therefor used opening has a
diameter of about 10 mm.
•Wheninstallingthespotlightoverheadmakesureto safe the fixture by a safety chain which is specified at least
with a load limit of 12 times of the spotlights weight. Only safety chain with approved connective can be used.
Attach the safety chain to its designated opening and attach it to the truss system or a similar and safe
attachment point. Assure to close the fasteners as specified.
•Toadjusttheangleofthefixtureopenthelocking screw, set the fixure in its position and close it by hand.

ELECTRICAL CONNECTION
•Connectiontothemainsisonlyallowedbyskilledpersons.
•Before connecting the fixture to the mains, assure that the specifications are corresponding.
•Electrical grounding has to be used in the whole installation!
ATTENTION!
Installationhastobeapprovedbyanauthorizedperson before first operation!
CLEANING AND MAINTENANCE
•Installerhastotakecareofallsafetyandmachinery installations are approved by skilled persons at least once
a year.
•Installerhastotakecareofallsafetyandmachinery installations are approved by authorized persons at least
every four years during the acceptance inspection. Following points need to receive special attention:
•All screws used for mounting the fixture or parts of it need to be proof and must not show
corrosion.
•Housing, Suspension device and installation site (ceiling, suspension, truss) must not show
deformation.
•All power cords must not show any damage, aging (for example porous wires) or sediments.
Other, to the location related and usage aligned regulations will be observed by the skilled person
and safety defects will be fixed.
ATTENTION!
Make sure that the fixture is disconnected from mains during all maintenance! Is it important to unplug mains
connector!
•Thefixturemustberegularlycleanedfromdirtand dust. Only use a wetted, lint-free cloth for cleaning the
fixture. Never use alcohol or any kind of solvent for cleaning.
•Insidethefixturetherearenopartswhichneedmaintenance. Maintenance & service must be done by
authorized dealers only. Only use original spare parts!
Advice!
If you have further questions, your local dealer will be happy to help you.

OPERATION
•This device has several DMX- and Stand-Alone-Modes. In DMX-mode, multiple devices can be connected and
controlled by a controller. The device accepts the settings of the DMX-controller, as soon as the corresponding
start address is set.
•Slave mode:
Connect the DMX-output of the master device (XLR female) to the DMX-input of the slave device (XLR male).
Set the slave device to mode Slave (display shows: <SLAVE>). The slave device accepts all settings of the
master device (such as programm, programm speed, color).
•Displaydescription:
The display shows the different DMX-modes & the DMX-start address or programm, programm speed, etc.; the
first line shows the mode, the second line the corresponding value.
•Button description:
Press the MENU button to get access to the menu. Press the UP/DOWN button to select the relevant topic.
Press ENTER button to change the relevant topic; change the relevant topic by pressing UP/DOWN button to
set the DMX-start address or any of the pre-programmed modes or the speed values. Use the UP button to
increase the value. Use the DOWN button to decrease it. Press ENTER button again to save your settings and
get access to next menu.
NOTE!
If you hold the UP or DOWN button for longer, the value changes faster. The device has an automatic storage for all
settings. When you turn the device off and on again, it works with the previously set values. If the unit is not operated or
about 30 seconds, the buttons are locked. Unlock these by pushing one of the backside buttons for about three seconds.
•Theunitisadditionallyequippedwithaninfraredremote control. The use of this infrared remote control is
possible in every mode. Point the infrared remote control in direction of the infrared receiver on top of the
fixture. Choose a color or a program by use of the infrared remote control. To leave infrared-mode press the
button “OFF” on the remote control, press one of the backside buttons on the fixture or switch off the unit and on
again by removing the mains plug from the mains.

A. B. C. D. E. F. G.
H. I. J. K. L. M. N.
A. Yoke
B. IR-Sensor
C. Locking Screw
D. CRMX-Input
E. DMX-Input 5 pin
F. DMX-Output 5 pin
G. Safety Attachment Point
H. Menu-Button
I. Up-Button
J. Mains-Input
K. Down-Button
L. Mains-Output
M. Enter-Button
N. LC-Display

WIRELESS DMX-MODE
The unit is equipped with a connector for an optional LumenRadio CRMX Wireless DMX-module. The module is
compatible to CRMX transmitter units from LumenRadio and Wireless Solutions transmitter units version G3 and
G4.
For the use with CRMX the LumenRadio CRMX Wireless DMX-module needs to be plugged to the backside USB-
connector and the unit must be set to one of the five DMX-modes. Press MODE button and use UP/DOWN buttons
until display shows „DMX Chan“. Press ENTER and choose the right mode by use of UP/DOWN buttons.
Furthermore you need to choose the corresponding DMX-start adress. Which mode is the right one for you is up to
the range of functions you would like to use, the library and the channels of the used DMX-controller. Please read
chapter DMX-Mode of this manual to get an idea of which channels can be controlled in which DMX-mode.
Up next there is a need for logical connection (pairing) of the unit with external DMX-transmitter. Press CONNECT
button on DMX-transmitter shortly. The transmitter searches for all available units and connects to them. The logical
connection (pairing) is done and safed until it is released manually.
NOTE!
If a unit is not connecting to an external DMX-transmitter it is already connected logical to another transmitter. In this
case the connection needs to be released manually. Press and hold CONNECT button on the LumenRadio CRMX
Wireless DMX-Module for at least 3 seconds. After this please repeat the procedure for logical connection (pairing)
whilst pressing CONNECT button on DMX-transmitter shortly again.

DISPLAY-MODE
display function
DEF. SET DEF. SET
<***>
*** =
<NO>
<YES>
reset all parameter to factory defaults
DMX Addr DMX Addr
<***>
*** = DMX-adress
display the DMX-adress
(2 Ch = <001-511>)
(3 Ch = <001-510>)
(4 Ch = <001-509>)
(5 Ch = <001-508>)
(10 Ch = <001-503>)
(default setting = 1)
DMX Chan DMXChan
**** =
**** =
< 2Ch>
< 3Ch>
< 4Ch>
< 5Ch>
<10Ch>
setting DMX-channel mode
(description of modes in next chart)
(default setting = 4 Ch)
Dimmer Dimmer
<***>
*** =
<OFF>
<1>
<2>
<3>
<4>
setting dimmer curve
OFF = dimmer linear
1 = dimmer delayed 1
2 = dimmer delayed 2
3 = dimmer delayed 3
4 = dimmer delayed 4
Master/Slave Master/Slave
<******>
****** = Master
****** = Slave
setting working mode
(Master = control without external
controller)
(Slave = control with external controller)
(default setting = Slave)
ColSet ColSet
<Red>
<***>
*** = <0-255>
<Green>
<***>
*** = <0-255>
<Blue>
<***>
*** = <0-255>
<White>
<***>
*** = <0-255>
setting brightness for each color in
steps of 256

ColProgr ColProgr
<**>
** =
<00-31>
31 pre-programmed chasers available
(deactivation of all pre-programmed
chasers by menu Master/Slave!)
Speed
<**>
** =
<00-30>
setting speed in 30 steps for the pre-
programmed chaser available
WhiteBal WhiteBal
<Red>
<***>
*** = 125-255
<Green>
<***>
*** = 125-255
<Blue>
<***>
*** = 125-255
setting white balance
(default setting =
R = 255, G = 255, B = 255)
Temp. Temp
<***C>
<***C = Betriebstemperatur
Display the current temperature inside
the fixture
DispPerm <DispPerm ***>
*** = ON
*** = OFF
setting automatic switch off for lcd
backlite
(default setting = On)

DMX-MODE
mode display function
2 channel
mode
< 2 Ch> ch1 = color macro
000-255 stepless rgb color mix
ch2 = master dimmer
000-255 stepless brightness
3 channel
mode
< 3 Ch> ch1 = dimmer red
000-255 stepless brightness red
ch2 = dimmer green
000-255 stepless brightness green
ch3 = dimmer blue
000-255 stepless brightness blue
4 channel
mode
<4 Ch> ch1 = dimmer red
000-255 stepless brightness red
ch2 = dimmer green
000-255 stepless brightness green
ch3 = dimmer blue
000-255 stepless brightness blue
ch4 = dimmer white
000-255 stepless brightness white
5 channel
mode
<5 Ch> ch1 = dimmer red
000-255 stepless brightness red
ch2 = dimmer green
000-255 stepless brightness green
ch3 = dimmer blue
000-255 stepless brightness blue
ch4 = dimmer white
000-255 stepless brightness white
ch5 = master dimmer
000-255 stepless brightness
10 channel
mode
<10 Ch> ch1 = dimmer red
000-255 stepless brightness red
ch2 = dimmer green
000-255 stepless brightness green
ch3 = dimmer blue
000-255 stepless brightness blue
ch4 = dimmer white
000-255 stepless brightness white
ch5 = color macro
000-255 stepless rgb color mix
ch6 = flash rate
000-020 no function
021-255 flash rate from s -> f
ch7 = programms
000-020 no function
021-099 color jumps
100-149 color fades
150-255 no function
ch8 = speed
000-255 stepless speed
ch9 = dimmer mode

000-020 mode set on display
021-049 off = dimmer linear
050-099 1 = dimmer delayed 1
100-149 2 = dimmer delayed 2
150-199 3 = dimmer delayed 3
200-255 4 = dimmer delayed 4
ch10= master dimmer
000-255 stepless brightness

BEAM SPECS
1 m
3 m
5 m
red
4.690 lx 670 lx 230 lx
green
11.050 lx 1.860 lx 273 lx
b
l
ue
450 lx 70 lx 22 lx
white
10.190 lx 1.450 lx 518 lx
rgbw
24.580 lx 3.710 lx 1.374 lx
TECHNICAL SPECIFICATION
•voltage: 100-260 V 50-60 Hz
•power consumption: 0,2 A @ 230 V
•measurements: 21,6 x 15 x 23,1 cm
•weight: 2,3 kg
•DMX-channels: 2 / 3 / 4 / 5 / 10
•ip rating: IP 20
