LITELOK FLEXI-O User manual

YOU SHOULD HAVE RECEIVED
• Sold Secure Bicycle Silver and ART2 rated
• Independent insurance rated
• Hardened steel lock casings
• Hard wearing outer sleeve
• Patented in-line lock allows multiple locks to be
joined together for extra length
• Pick resistant disc detainer style lock mechanism
• Patented BOAFLEXICORE® composite strap
employing high tensile steel in a polymer matrix
• Each single Litelok® supplied with 2 keys
& 2 WrapStraps
• Rattle-free design, makes no noise when carried
on the bike
FLEXI-O
1.1kg
2.4lb
70.0cm
27.6in
5cm
1.9in
74.0cm
29.1in
LITELOK®
Weight
Length
Width
Locking
Circumf-
erence
88W
1.31kg
2.8lb
88.5cm
34.8in
5cm
1.9in
92.5cm
36.4in
100W
1.40kg
3.0lb
96.5cm
37.9in
5cm
1.9in
100.0cm
39.4in
108W
1.46kg
3.2lb
103.5cm
40.7in
5cm
1.9in
107.5cm
42.3in
LITELOK® ONE SPECIFICATION
7
3
4
6
5
2
PLEASE DO NOT USE
LITELOK® AS A WEAPON
YOU DO NOT NEED THE KEY TO CLOSE THE LITELOK
HOLD LITELOK FIRMLY & TURN THE TWO ENDS IN
SNAP THE LITELOK SHUT
FULLY INSERT THE KEY (*)
ROTATE THE KEY A HALF TURN (180º) CLOCKWISE
OPEN LITELOK KEEPING THE LOCK PART STRAIGHT
THE LITELOK WILL NATURALLY SPRING OPEN
READY TO USE
There is a slight knack to opening Litelok which,
once you’ve got it, becomes second nature.
We suggest that you practice using Litelok a few times
before taking it out with your bike.
REVERSE THE SEQUENCE TO LOCK
INSTRUCTIONS
2 KEYS 2 WRAPSTRAPS
1 LITELOK® TWIN LITELOK®
You will have two sets if you
have purchased a TWIN LITELOK®
You can use the same key on
both locks and connect them
together in series (as shown) or
in parallel (e.g. front wheel/back
wheel) for extra security.
3
2
!WARNING!
DO NOT LEAVE THE KEY IN THE LOCK.
IF YOU ACCIDENTALLY DROP THE LOCK & IT LANDS ON THE KEY,
IT CAN DAMAGE THE LOCK/KEY
!WARNING!
KEEP HANDS AWAY FROM CLOSE LINE TO AVOID PINCHING
DO NOT LEAVE THE KEY IN THE LOCK.
OPENING YOUR LITELOK® LOCKING YOUR LITELOK®

Zeal Innovation Ltd (Zeal) provides a warranty that LITELOK
(the product) is free from manufacturing defects in material
and workmanship. This warranty is one year from the date of
purchase unless otherwise stipulated in local law.
The warranty is void if the product is tampered with in any
way. Upon return of the defective product to Zeal or its
authorized distributor for inspection, free and clear of all liens
and encumbrances and accompanied by proof of purchase
and a statement of the defect/s, Zeal will replace the product.
This limited warranty may not be assigned or otherwise
transferred in any way and may not be extended, altered or
varied. To the fullest extent allowable by the laws applying
All Patents, Trademarks & Copyright are property of Zeal Innovation Ltd
t/a Litelok, Unit 10, Technium 1, Swansea Waterfront, Swansea SA1 8PH, UK
CARRYING YOUR LITELOK® ONECINCHING YOUR LITELOK® ONE
WEARING YOUR LITELOK® ONE (IF WEARABLE VERSION PURCHASED)
WARRANTY INFORMATION
Carry your LITELOK SAFELY.
We recommend either putting it in a bag or attaching it with
BOTH of the two high visibility hook and loop wrapstraps
provided within your bike frame.
Please see www.litelok.com for examples.
This may not work for all frames in which case you need to find
another location which is SAFE and SECURE. Failure to secure
your LITELOK correctly may also result in damage to your bike’s
paintwork. If you are unsure whether your LITELOK is secured
safely DO NOT SET OFF ON YOUR BIKE. Take time to adjust
or find another way to carry your LITELOK.
We recommend you cinch
your LITELOK into a tight
circle, securing together
using both WrapStraps
provided. This will enable
you to fit your LITELOK into
the Frame Mounts with in
the Frame of your bike.
Please see www.litelok.com
for examples.
Wearing it is incredibly simple.
Wrap your LITELOK around your hips and close it using
the integrated Lock Stopper.
The Lock Stopper keeps the LITELOK securely fastened
around your body without locking so you don’t need
a key. It acts as a quick release mechanism to open
and close the LITELOK, letting you easily put it on and off.
When it’s time to secure your bike, simply take the
LITELOK off your hips, remove the Lock Stopper and
then click together to lock your bike as normal. PLACE LOCKSTOPPER
ONTO LOCK CLOSE LOCK ATTACH SAFETY LOOP TO PREVENT ACCIDENTAL OPENING
23
www.litelok.com | [email protected]
LITELOK ONE has been designed to be quick and easy to use.
DO NOT FORCE the key if the lock jams and ALWAYS push the key in
fully before turning 180º clockwise. If you have trouble it might be because
the key was not fully inserted. Wiggle the key gently, side to side and turn
anticlockwise, remove and try again. If any issue persists please contact
the place of purchase.
KEEP ONE AS SPARE and take note of the key code to register your
product on Litelok.com to enable you to order replacements if required
at a later date.
Wipe all surfaces with a soft cloth and a small amount of
soapy water if required. Dry well and avoid introducing water
into the locking mechanism. Lubricate with a small amount
through key hole periodically. LITELOK is supplied with an
aerospace-rated anti-corrosion protection coating and
has been designed to resist dirt and corrosion but we
recommend drying if it gets wet. This coating should last
a year and you can reapply with a proprietary product.
Please contact us for recommendations.
USING YOUR LITELOK® KEYS CARING FOR YOUR LITELOK® ONE
here to, this limited warranty is in lieu of any other warranties,
either express or implied, including but not limited to any
warranties of merchantability or fitness for a particular
purpose, all of which are expressly excluded and disclaimed.
Zeal Innovation Ltd will not be liable for loss of profits, any
special, incidental, or consequential damages, which
purchaser may sustain, any damages for claims by any third
party or punitive damages, even in the event of notice of the
possibility of such damages.
Zeal reserves the right to change the specification and design
details of its products without notice in the pursuit of
excellence.
e&oe
